Observing the moon

1
Observing the moon
Charlie Elliott Wildlife Center, January 19,
2008 Theo Ramakers
2

• Bad choice for my presentation!
• Needed a lot of research such as
• Moon Observations
• The Moon (Movies and the Web)

3

• Researching the Web brings language issues
• Such as

4

• Researching the Web brings language issues
• Such as
• Is someone who is observing the moon a Lunatic

5

• Researching the Web brings language issues
• Such as
• Is someone who is observing the moon a Lunatic
• While Observing the moon Mooning?

6

A Mooney M20C Airplane
7

Some Lunatic is attempting to set a world record
in Mooning Here in Brussels
8

Annual mooning of the Amtrac train in S.
California
9

Even Santa tried to moon
10

• Concluded that Larry did not want a presentation
  on how to observe those kind of moons
• Went back in time more than a century attempting
  to learn about the basics of the moon

11

• A study of the Sky (1896) Herbert A Howe

12

The same book that mentioned the panic in Atlanta
with Comet 17P/Holmes In 1892
13

• A study of the Sky (1896) Herbert A Howe
• Alexander from Humbolt
• People from Asia Minor say the moon exhibits a
  reflection of earth as if it were a mirror

14

• A study of the Sky (1896) Herbert A Howe
• Alexander from Humbolt
• People from Asia Minor say the moon exhibits a
  reflection of earth as if it were a mirror
• This would be great We could use Google Earth as
  a guide and map to observe the moon

15

• A study of the Sky (1896) Herbert A Howe
• Alexander from Humbolt
• People from Asia Minor say the moon exhibits a
  reflection of earth as if it were a mirror
• In the minds of many, a human figure is outlined
• Judas Iscariot

16


Man in the Moon
17

• A study of the Sky (1896) Herbert A Howe
• Alexander from Humbolt
• People from Asia Minor say the moon exhibits a
  reflection of earth as if it were a mirror
• In the minds of many, a human figure is outlined
• Judas Iscariot
• The casual onlooker perceives a human face with
  eyes, nose and mouth.

18


19


Woman need their place also!!
20


Who said there was no life on the Moon? Rabbits
can jump pretty far!
21


And Frogs can jump far too!!!
22


And Brother Toad is very close.
23


But how Crabs swim to the Moon is a
secret!! Primarily Pacific Region
24

• Most Notable Phases of the moon
• New Moon
• Waxing Cresent
• First Quarter
• Gibbeous Waxing

25

• Most Notable Phases of the moon
• New Moon
• Waxing Cresent
• First Quarter
• Gibbeous Waxing
• Full Moon
• Gibeous Waning
• Last Quarter
• Waning Cresent
• (Complete Phase lunation)

26

The Phases of the Moon in a diagram
27

• Observing the Moon
• Constellations and Stars move across the sky in
  yearly cycles from East to West
• The Moons sidereal orbit takes 27.3 days
• The Moons phase takes 29.5359 days,
• The Moon moves each day approx 12 degrees east
  against the night sky
• Optimal Observation points of interest on the
  the moon change approx. 12 degrees each day.
• Limiting conditions for optimum observation
  during a given month

28

Movement of the Morning Terminator from 1/19/2008
1200 2400 ET
29

• Locations on the moon are identified in
• Selenographic coordinates
• Moon axis runs through the North and South Poles
• Lunar Equator
• Prime meridian runs through apparent center of
  the disk with both longitude and latitude
  libration O
• Coordinates are expressed in North and South
• East and West. (sometimes you might see and -
  signs

30

• Selenographic Coordinates

31

• Selenographic Colongitude
• Points of Sunrise on the Moon
• Location of Morning terminator in degrees west
  from the Prime Meridian
• Sunrise at Prime Meridian concurs with First
  Quarter
• Goes from O-360 degrees

32

• Selenographic Colongitude
• Points of Sunrise on the Moon
• Location of Morning terminator in degrees west
  from the Prime Meridian
• Sunrise at Prime Meridian concurs with First
  Quarter
• Goes from O-360 degrees
• Anything gt90 West or East not visible from
  Earth, with the exception of Libration

33

• Libration
• Orbit of the moon is elliptical
• Rotation is constant
• Speed is sometimes faster, sometimes slower

34

• Libration
• Orbit of the moon is elliptical
• Rotation is constant
• Speed is sometimes faster, sometimes slower
• So the moon is
• Sometimes a little ahead,
• sometimes a little behind

35

• Libration
• Orbit of the moon is elliptical
• Rotation is constant
• Speed is sometimes faster, sometimes slower
• So the moon is
• Sometimes a little ahead,
• sometimes a little behind
• Moons orbit is inclined to Earths orbital plane
• Appears to nod up and down
• Net exposure 7 53 East and West 6 51 North and
  South

36

Example of Libration between January 8 and
February 4, 2008
37

• Observing the moon
• Observe details at times when they are most
  distinct (Highest contrast) for the object you
  want to see/capture (Objects near terminator)

38

• Observing the moon
• Observe details at times when they are most
  distinct (Highest contrast) for the object you
  want to see/capture
• Make the moon part of a special configuration
  with other celestial or earth objects

39

• Different ways to observe the moon
• Observe details at times when they are most
  distinct (Highest contrast) for the object you
  want to see/capture
• Make the moon part of a special configuration
  with other celestial or earth objects
• Make many images, increasing the chance of having
  an extraordinary image

40


Day 3
Image Courtesy Jim Honeycut
41

• Day 4

Image Courtesy Jim Honeycut
42

Day 5
Image Courtesy Jim Honeycut
43

Day 10
Image Courtesy Jim Honeycut
44

Full Moon
Image Courtesy Jim Honeycut
45

• To get the best out of your Moon observations
• Use a good Atlas
• Determine when the object is visible
• Use Filters to bring out contrast
• Verify the Phase of the moon (Observation time)
• You can observe some features during daytime
• Plan the observations in advance
• Anticipate what you will see

46

Online Moon Atlas http//www.inconstantmoon.com/a
tlas.htm
The images in the following slides have been
obtained From instantconstantmoon.com See
website for credits.
47


Moon Basins or Mare
48


Bright Spots on the Moon
49


Craters and Other points of interest
50


Use Reverse View Technology to view the Far
Side of the Moon ?
51


Topographic Map of the Near Side of the Moon
meters
52


Topographic Map of the Far-Side of the Moon
meters
53


American Landings
54


Soviet Landings
55


Charles Woods Moon 100 spreadsheets
56


57


58


59


60


61


62


63


http//www.inconstantmoon.com/atlas.htm
64

Jim Honeycutts image of the Hyginus Rilles
Image Courtesy Jim Honeycut
65

Jim Honeycutts image of the Highlands
Image Courtesy Jim Honeycut
66

Whats best visible today January 19, 2008
67


General Area of de Gasparis Rilles
68
Location Map for Rilles de Gasparis
69
Area rich of Rilles
70
Overview of the Gasparis Rilles
71
Rilles de Gasparis Crater
72

• The Moon and other celestial objects
• Eclipses
• Occultations
• Near misses
• Grazing
• Special configurations

73

Moon eclipse of March 3rd 2007 (Angela Poore)
74

The conditions do not have to be perfect as
Angela proves. Moon and Venus
75

Say Hello to the Smiling Cat (Thank you Clevis
for the idea) A special conjunction of the Moon,
Venus, Regulus and Saturn
76

And 1 ½ hours and 105 images later The moon has
sunken quite a lot.
77

And the best image ?
78

Moon and Mars sequence 1 ½ hour on December 23rd
2007
79

The Moon and Mars at Mars apparation
2007 Image Courtesy of Gary Jones (Cleves
brother)
80

Solar Eclipse March 7, 1970. (Larry Owens)
81

• Reference Material
• The next pages show some interesting websites
• Download Charles Woods Moon 100 in Excel
  format for easy
• Sorting, and planning of interesting moon
  features from my
• FILES- section in the CE - Yahoo group
• Virtual Moon Atlas
• On-line Moon Maps and images
• A number of images in this presentation, unless
  mentioned differently, have been taken from some
  of these website

82

Free Downloadable Moon Atlas Virtual
Moon http//www.astrosurf.com/avl/UK_index.html
83
Very nice resource http//www.inconstantmoon.c
om/atlas.htm
84
Very interesting resource links on Selenographia
85

http//www.lpi.usra.edu/resources/cla/
86


Charles Woods Moon website http//the-moon.wikis
paces.com
87


Google for Lunar images http//www.googlelunarxp
rize.org
88


For your observatory Buy an acre of Moon land
for 19.95 https//www.moonlandrush.com/
89

• Thank You
• See you on the moon?
