WMO course-Statistics and Climatology -
Lecture III
Dr. Bertrand Timbal Regional
Meteorological Training Centre, Tehran,
Iran December 2003
2
Statistics of the Climate system---
Spatio-temporal linkages within the system
Statistics and Climatology Lecture III

• Overview
• Links within the system the example of ENSO
• Regression and correlation of variables
• Spatial structures reduction of the degree of
  freedom

3
El Niño / La Niña a large scale feature
Schematic of summer La Niña conditions across the
Equatorial Pacific Ocean
4
El Niño / La Niña a large scale feature
Schematic of summer EL Niño conditions across the
Equatorial Pacific Ocean
5
El Niño a large scale feature

• Temperature, along an equatorial
• longitude-depth section
• Anomalies are relevant for interannual
  variability
• Observed with the TAO array of buoys in the
  Tropical Pacific
• Thermocline movements important for seasonal
  forecasting

6
El Niño sub-surface ocean anomalies

• Anomalous warm water accumulated
• at depth in the West Pacific and travel across
  the basin along the thermocline
• The predictability comes from the slow moving
  ocean anomalies

97-98 El Niño formation
7
Transition to the 98-99 La Niña
8
El Niño air-sea interactions
9
El Niño air-sea interactions
10
El Niño Global Tele-connections
Courtesy of NOAA
11
La Niña Global Tele-connections
Courtesy of NOAA
12
El Niño impact on Australian rainfall
Stratification of the mean climate based on ENSO
phases
13
La Niña impact on Australian rainfall
Stratification of the mean climate based on ENSO
phases
14
El Niño global impact on rainfall
Probability of exceeding median rainfall for
Cold, Neutral and Warm conditions in the
Equatorial Pacific Ocean (Data for 1900-1997)
Stratification of the mean climate based on ENSO
phases.
15
El Niño impact on Australian Wheat Yields
16

• Links within the climate system exist
• El Niño is a planetary scale phenomenon
• Several variables exhibit coherent variations
  (correlation)
• Distant teleconnections are observed (lag
  correlation)
• Probabilities are shifted by ENSO phases
  (predictable)

17
Statistics of the Climate system---
Spatio-temporal linkages within the system

• Overview
• Links within the system the example of ENSO
• Regression and correlation of variables
• Spatial structures reduction of the degree of
  freedom

18
Simple model Least-Squares Regression
Regression
19
Role of outliers

• Outlier detection method to find observations
  with large influence
• Problem often arises from either erroneous data
  or small sample
• Graphical visualisation is essential

r 0.457 r 0.336
In this example, out of 100 points, only one
data is different !
Courtesy of J. Stockburger
20
Graphical visualisation of correlation
The relationship is not linear.
In all cases, the correlation is r0.816 but
Correlation is not robust and resistant
. Instead we can use the rank correlation
correlation based on ranked data
21
An example of a non linear relation
22
Correlation is not causation!
Is ENSO forced by Australian rainfall?
or Are Australian rainfall affected by ENSO?
Correlations between seasonal rain and SOI

• Correlation does not imply causation
• Simultaneous evolution
• Others techniques are needed
• Path analysis (Blalock, 1971)
• Temporal precedence

Courtesy of W. Drosdowsky
23
Lag Correlation and auto-correlation
Lagged correlation between the SOI and cyclone
formation

• (Prior) Lag correlations exhibit the dependence
  between variables
• Predictability arises from lag correlation

24

• Correlation in the climate system
• Correlation coefficientes express the part of
  the variation of two variables which are linked
  (no causality)
• Correlation assumes normality (!) and linear
  relation (!)
• A more robust coefficient is the rank
  correlation
• Lag correlation is useful for causality and
  predictability
• Auto-correlation of meteorological data has
  serious consequences for the use of statistics in
  climate

25
Statistics of the Climate system---
Spatio-temporal linkages within the system

• Overview
• Links within the system the example of ENSO
• Regression and correlation of variables
• Spatial structures reduction of the degree of
  freedom

26
Spatial structure in climate data

• Several motivations to identify large scale
  spatial features
• Data are not spatially independent spatial
  correlation
• Large scale structures are more coherent and
  predictable
• Extract the large scale climate signal
• Reduce the weather noise associated with small
  scales
• Smaller degree of freedom and reduced data set
• Identify useful relationships to exploit for
  climate forecasting

27
Principal-Component (EOF) Analysis

• Objective
• To reduce the original data set to a new data
  set of (much) fewer variables
• To condense a large fraction of the variance of
  the original dataset
• To explore large multivariate data sets (spatial
  and temporal variation)

• Calculation
• PCA are done on anomalies
• Based on the covariance S or the
• correlation R matrix of a vector X XTX
• The principal components are the
• projection of X on the eigenvectors of S ei
• orthogonal one to an other new coordinate
  system
• maximise the variance measured by the
  eigenvalues (?i)

28
Principal-Component (EOF) Analysis

• Eigenvectors (PCA) are orthogonal
• Strong constraint for small domain (Jolliffe,
  1989)
• Typically the 2nd PC is a dipole (not
  necessarily meaningful)
• The number of PCs to be consider is based on the
  eigenvalues

29
EOFs of combined fields
Courtesy of M. Wheeler
200 hPa
850 hPa
30
The phase-space representation of the MJO
M(t) RMM1(t),RMM2(t) Vector M traces -
large anti-clockwise circles about the origin
when the MJO is strong. - random jiggles around
the origin when the MJO is weak. For
compositing, we define the 8 equal-angle phases
as labeled, and described by the angle F
tan-1RMM2(t)/RMM1(t)
Courtesy of M. Wheeler
Southern Summer DJFMA
31
MJO propagation based on vector M in the two
dimensional phase space OLR contour interval 4
Wm-2 blue negative 850 hPa wind Max vector
4.5 ms-1
Courtesy of M. Wheeler
32
Rotated PCs

• Facilitate physical interpretation
• Review by Richman (1986) and by Jolliffe (1989,
  2002)
• New set of variable RPCs
• Varimax is a very classic rotation technique
  (many others)

First two rotated PCAs of Indian/Pacific SSTAs
using data from Jan 1949 to Dec 1991.
Courtesy of W. Drosdowsky
33
Other multivariate analyses

• Extended EOFs and Complex (Hilbert) EOFs are two
  classical extensions of PCs
• Canonical Correlation Analysis extension of PCA
  to two multivariate data sets forecasting one
  variable with the other (book by Wilks, 1995).
• Principal Orthogonal Pattern (POP) and (PIP),
  SVD are other techniques used (book by von Storch
  and Navarra, 1995 and von Storch and Zwiers,
  1999)
• Discriminant analysis (e.g. the operational
  seasonal forecast of the BoM) the conditioning
  is on the predictand and in a sense the reverse
  conditional probabilities are estimated from the
  data, and Bayes theorem is used to invert these
  (article by Drosdowsky and Chambers, 2001)
• Analogue (lecture 7), clustering (book by Wilks,
  1995) and NHMM (next slide) are other techniques
  dealing with classification.
• All techniques can be use for forecasting and
  downscaling

34
An other downscaling approach
Non-homogeneous Hidden Markov Model makes use of
non observed hidden weather states which are
related to observed rainfall structures
Courtesy of S. Charles
35
Summary

• Many interactions in the system ? correlation
• Many issues with correlation robustness,
  causality
• Large scale structure exist ? multivariate
  analyses
• Useful for filtering, organizing and reducing
  the noise in data
• Forecasting uses many of these statistical tools
