Testing Plan

1
Testing Plan
2
The Goal of Test Planning

• The IEEE Standard 829-1998
• To prescribe the scope, approach, resources, and
  schedule of the testing activities. To identify
  the item being tested, the features to be tested,
  the testing tasks to be performed, the personnel
  responsible for each task, and the risk
  associated with the plan.

3
The Goal of Test Planning

• To establish the list of tasks which, if
  performed, will identify all of the requirements
  that have not been met in the software. The main
  work product is the test plan.

4
Test Methodology

• Test Plan
• Test Design
• Test Implementation
• Results Analysis and Documentation

5
Test Plan

• The test plan is a by-product of the detailed
  planning process thats undertaken to create it.
  Its the planning process that matters, not the
  resulting document.

6
(..cont) Test Plan

• The test plan documents the overall approach to
  the test. In many ways, the test plan serves as a
  summary of the test activities that will be
  performed.
• It shows how the tests will be organized, and
  outlines all of the tester needs which must be
  met in order to properly carry out the test.
• The test plan should be inspected by members of
  the engineering team and a senior manager.

7
(..cont) Test Plan

• The initial test plan is abstract, and the final
  test plan is concrete (fuzzy to focus).
• The initial test plan contains high level ideas
  about testing the system without getting into the
  details of exact test cases.
• The most important test cases come from the
  requirement of the system.

8
Steps for Test Plan

• Plan the test phase
• Define test strategy
• Planning the resource requirement
• Distribute tester assignment
• Plan test schedule

9
Test Phase

• Based on the proposed development model and
  decide whether unique phases, or stages, of
  testing should be performed over the course of
  the project.
• In code-and-fix model, theres probably only one
  test phase test until someone yells stop.
• In waterfall and spiral model, there can be
  several test phases from examining the product
  spec to acceptance testing.

10
(..cont) Test Phase

• Each phase must have criteria defined for it that
  objectively and absolutely declares if the phase
  is over and the next one has begun.

11
Test Strategy

• Test strategy describes the approach that the
  test team will use to test the software both
  overall and in each phase.
• When you are presented with a product spec
• youll need to decide if it is better to use
  black-box or white-box testing?
• If mix when will you apply each and which part?
• Manually or use tools? If using tools, develop
  the tools or purchase?

12
Resource Requirement

• The process of deciding whats necessary to
  accomplish the testing strategy.
• Everything that could possibly be used for
  testing over the course of the project needs to
  be considered.

13
(..cont) Resource Requirement

• Example
• People How many, what experience, what
  expertise? Should they be full-time, part-time,
  contract or student?
• Equipment Computers, test hardware, printers,
  tools.
• Office and lab space How big? How will they be
  arranged?
• Software Word processors, databases, custom
  tools. What will be purchased? What need to be
  written?
• Outsource companies Will they be used? What
  criteria? Cost?

14
Tester Assignments

• Break out the individual tester assignments.
• The inter-group responsibilities discussed
  earlier dealt with what functional group
  (management, test, programmers, and so on) is
  responsible for what high-level task.
• Identify the testers responsible for each area of
  the software and for each testable feature.

15
Example of Tester Assignments
16
Test Schedule

• The test schedule takes all the information
  presented so far and maps it into the overall
  project schedule.
• Critical stage because a few highly desired
  features that were thought to be easy to design
  and code may turn out to be very time consuming
  to test.
• Gantt Chart (Tools Microsoft Project).

17
(..cont) Test Schedule

• An important consideration with test planning is
  that the amount of test work typically is not
  distributed evenly over the entire product
  development cycle.
• Some testing occurs early in the form of spec and
  code reviews, tool development, etc, but the
  number of testing tasks and the number of people
  and amount of time spent testing often increases
  over the course of the project.

18
Example of Test Schedule

• Testing Task Date
• Test Plan Complete 05/03/2008
• Test Cases Complete 01/06/2008
• Test Pass 1 15/06/2008 01/08/2008
• Test Pass 2 15/08/2008 01/10/2008
• Test Pass 3 15/10/2008 15/11/2008

19
Test Design

• Definition by IEEE 829
• Test design specification refines the test
  approach (defined in the test plan) and
  identifies the features to be covered by the
  design and its associated tests. It is also
  identifies the test cases and test procedures, if
  any, required to accomplish the testing and
  specifies the feature pass/fail criteria.

20
(..cont) Test Design

• Based on IEEE 829 standard, test design should
  include
• Identifiers
• Features to be tested
• Approach
• Test case identification
• Pass/fail criteria

21
Identifiers

• A unique identifier that can be used to reference
  and locate the test design spec.
• The spec should also reference the overall test
  plan and contain pointers to any other plans or
  specs that it references.

22
Features to be tested

• A description of the software feature covered by
  the test design spec.
• Example the addition function of calculator,
  font size selection and display in WordPad, and
  video card configuration testing of QuickTime.

23
Approach

• A description of the general approach that will
  be used to test the features.
• It should expand on the approach, if any, listed
  in the test plan, describe the technique to be
  used, and explain how the results will be
  verified.
• Example A testing tool will be developed to
  sequentially load and save pre-built data files
  of various sizes. The number of data files,
  sizes, and the data they contain will be
  determined through black-box technique and
  supplemented with white-box examples from the
  programmer. A pass or fail will be determined by
  comparing the saved file bit-for-bit against the
  original using a file compare tool.

24
Test case identification

• A high-level description and references to the
  specific test cases that will be used to check
  the feature.
• It should list the selected equivalence
  partitions and provide references to the test
  cases and test procedures used to run them.

25
(..cont) Test case identification

• Example
• Check the highest possible value Test case ID
  15326
• Check the lowest possible value Test case ID
  15327

26
(..cont) Test case identification

• Its important that the actual test case values
  arent defined in this section.
• For someone reviewing the test design spec for
  proper test coverage, a description of the
  equivalence partitions is much more useful than
  the specific values themselves.

27
Pass/Fail Criteria

• Describe exactly what constitutes a pass and a
  fail of the tested feature.
• What is acceptable and what is not?
• Simple a pass is when all the test cases run
  without finding a bug.
• Fuzzy a failure is when 10 or more of the test
  cases fail.

28
Test Case Planning why?

• Organization
• Even a small software may have thousands of test
  cases.
• The test cases have been created by several
  testers over the course of several months or
  years.
• Proper planning will organize them so that all
  the testers and other project team members can
  review and use them effectively.

29
(..cont) Test Case Planning why?

• Repeatability
• The same test cases can be used several times to
  look for new bug, and makes sure old one get
  fixed.
• Without test case planning, it would be
  impossible to know what test cases were last run
  and exactly how they were run so that we can
  repeat the exact tests.

30
(..cont) Test Case Planning why?

• Tracking
• How many test cases did you plan to run?
• How many did you run on the last software
  release?
• How many passed and how many failed?

31
(..cont) Test Case Planning why?

• Proof of testing (or not testing)
• In high-risk industries, the software test team
  must prove that it did run the tests that it
  planned to run.
• It could actually be illegal, and dangerous, to
  release software in which few test caes were
  skipped.
• Proper test case planning and tracking provides a
  means for proving what was tested.

32
Test Case - Definition

• IEEE 839
• Test case specification documents the actual
  values used for input along with the anticipated
  outputs. A test case also identifies any
  constraints on the test procedures resulting from
  use of that specific test case.

33
Test Case Specs

• IEEE 829 standard lists some important
  information that should be included in the test
  case specs
• Identifiers
• Test item
• Input specification
• Output specification
• Environmental needs
• Special procedural requirements
• Intercase dependencies

34
(..cont) Test Case Specs

• Identifiers
• A unique identifier is referenced by the test
  design specs and the test procedure specs.
• Test item
• Describes detailed feature, code module, etc
  thats being tested.
• Provide references to product specs or other
  design docs from which the test case was based.

35
(..cont) Test Case Specs

• Input specification
• List of all the inputs or conditions given to the
  software to execute the test case.
• If you are testing a file-based product, it would
  be the name of the file and a description of its
  contents.
• Output specification
• Results you expect from executing the test case.
• Did all the contents of the file load as expected?

36
(..cont) Test Case Specs

• Environmental needs
• Hardware, software, test tools, facilities,
  staff, etc that are necessary to run the test
  case.
• Special procedural requirements
• Describe anything unusual that must be done to
  perform the test.
• Example testing nuclear power plant..?

37
(..cont) Test Case Specs

• Intercase dependencies
• If the test case depends on another test case or
  might be affected by another, that information
  should be included here.

38
(..cont) Test Case Specs

• Example Test case presented in the form of
  matrix or table
• Test Case ID Printer Mfg Model
  Mode Option
• WP0001 Canon BJC-700
  B/W Text
• WP0002 HP LaserJet IV
  Color Auto
• .
• .
• WP00010 HP LaserJet IV
  High Draft

39
Test Procedure / Implementation

• Execute the test cases.
• IEEE 829 defines the test procedure specification
  identifies all the steps required to operate
  the system and exercise the specified test cases
  in order to implement the associated test design.

40
Test Procedures

• How to perform the test cases.
• Information need to be defined
• Identifiers
• Purpose
• Special requirement
• Procedure steps

41
Test Procedure

• Identifiers
• A unique identifier that ties the test procedure
  to the associated test cases and test design.
• Purpose
• The purpose of the procedure and reference to the
  test cases that it will execute.
• Special requirements
• Other procedures, special testing skills, or
  special equipment needed to run the procedure.

42
Test Procedure

• Procedure steps
• Detailed description of how the tests are to be
  run
• Log Tells how and by what method the results
  and observations will be recorded.
• Setup How to prepare for the test.
• Start Steps used to start the test.
• Procedure Steps to run the test.
• Measure How the results are to be determined?

43
(..cont) Procedure Steps

• Shut down Steps for suspending the test for
  unexpected reasons.
• Restart How to pick up the test at certain
  point if theres failure or after shutting down.
• Stop Steps for an orderly halt to the test.
• Wrap up How to restore the environment to its
  pre-test condition.
• Contingencies What to do if things dont go as
  planned.

44
Example of test procedure

• Identifier WinCalcProc98.1872
• Purpose This procedure describe the steps
  necessary to execute the Addition function test
  cases through
• Special Requirements No special requirement
  (Individual test cases).
• Procedure Steps
• Log The tester will use WordPad with the
  Testlog template
• Setup The tester must install a clean copy of
• Start 1) Boot up Windows 98
• 2) Click the Start button
• 3)
• Procedure For each test case identified above,
  enter the test input data using the keyboard
• Measure

45
Result Analysis and Documentation

• Fundamental principles for reporting a bug
• Report bugs as soon as possible
• Effectively describe the bugs
• Minimal, singular, obvious and general etc.
• Be non-judgmental in reporting bugs
• professionally written against the product, not
  the person, state only facts.
• Follow up on your bug reports
• Make sure it reported properly, and given
  attention that it needs to be addressed.
• Get them fixed.

46
Not all bugs are created equally

• A bug that corrupts a users data is more severe
  than one thats a simple misspelling.
• But, what if the data corruption can occur only
  in a very rare instance that no user is ever
  likely to see it and the misspelling caused every
  user to have problems installing the software?
• Which one is more important to fix?

47
How to classify bugs?

• General concept used
• Severity
• Indicates how bad the bug is the likelihood and
  the degree of impact when the user encounters the
  bug.
• Priority
• Indicates how much emphasis should be placed on
  fixing the bug and the urgency of making the fix.

48
Example

• Severity
• System crash, data loss, data corruption,
  security breach.
• Operational error, wrong results, loss of
  functionality.
• Minor problem, misspelling, UI layout, rare
  occurrence.
• Suggestion
• Priority
• Immediate fix, blocks further testing, very
  visible.
• Must fix before the product is released.
• Should fix when time permits.
• Would like to fix but the product can be release
  as it is.
• Data corruption Severity 1, Priority 3.
• Misspelling Severity 3, Priority 2.
