1An Introduction to Intrusion Detection/Prevention
, Vulnerability Assessment and related
Technologies
Network Security
2Contents
- Lecture aims and learning outcomes
- Assumptions
- Motivation - Why Intrusion Detection and
Vulnerability Assessment - Attack Development
- Vulnerability Development
- Hacker Strategy
- Detection - Intrusion Detection Systems
- Host based IDS
- Network Based IDS
- Prevention - Vulnerability Assessment
- Software
- Services (Audits)
- Web-Based Services
- Counter attacks
- Honey Pots
- Appliances
- Summary
3Lecture aims and learning outcomes
- The lecture aims are
- To describe the problems related to network based
attacks - To describe how some these problems may be
addressed - At the end of this lecture you will be able to
- Demonstrate an understanding of the main issues
relating to threats in the context of network
attacks - Understand a number of basic design components
for building a network security architecture - Demonstrate an understanding of the importance of
a security policy with reference to the security
of a computer network - Describe the features and security mechanisms
which are generally used to implement security
policies for dealing with the security of a
computer network
4Assumption
- Perimeter security devices (e.g. firewalls) and
computer security mechanisms (e.g. application
and OS security) can only offer best effort at
preventing attacks. - They may fail to do so
- a firewall may be misconfigured,
- a password may be sniffed off the network,
- a new attack type may emerge. (cf. Zero-day
attacks) - They do not detect when an attack is underway or
has taken place. - And they do not react to attacks.
5Traditional Methods
- Example
- Imagine continuous inspection of a Unix system by
hand (similar examples for NT, W2K) - The following simplified checklist is taken from
CERT (http//www.cert.org/tech_tips/intruder_detec
tion_checklist.html) - Examine log files for connections from unusual
locations or other unusual activity. For example,
look at your 'last' log, process accounting, all
logs created by syslog, and other security logs. - Look for setuid and setgid files (especially
setuid root files) everywhere on your system.
Intruders often leave setuid copies of /bin/sh or
/bin/time around to allow them root access at a
later time.
6Ad Hoc Intrusion Detection
- Imagine the complexity and degree of expertise
needed to carry out the tasks in this checklist
for every host and every sensitive network link
on a network every single day. - The ad hoc approach is not recommended!
- Automated systems are needed
- monitor multiple hosts and network links for
suspicious behaviour - report this behaviour, possibly react to it.
- Hence Intrusion Detection Systems (IDS).
7Definitions
- Detection
- Intrusion Detection Systems (IDS)
- Network based
- Host based
- Prevention
- Intrusion Prevention Systems (IPS)
- Vulnerability Assessment (VA)
- Counterattack
- Honeypots/nets
8Motivation
4 Vulnerability Development
700
600
Linux (aggr.)
500
Solaris
Windows
400
Total
300
200
100
0
1999
2000
2001
2002
2003
Source SecurityFocus
9Motivation
Auto Coordinated
Cross site scripting
Attack Sophistication
stealth / advanced scanning techniques
High
Staged
packet spoofing
denial of service
distributed attack tools
sniffers
sweepers
www attacks
automated probes/scans
GUI
back doors
network mgmt. diagnostics
disabling audits
hijacking sessions
burglaries
Attack Sophistication
exploiting known vulnerabilities
password cracking
self-replicating code
Intruder Knowledge
password guessing
Low
2000
1980
1985
1990
1995
Source Carnegie Mellon University
10Motivation
Vulnerability Exploit Lifecycle
Vulnerability Scanners adding detection signature
Widespread Awareness
Selective Awareness
First Discovery
Advisory Release
11Unauthorized Use of Computer Systems within the
Last 12 Months
12Origin of the Attack
13Which Type of Attacks ?
14Dollar Amount of Losses by Type
15Reactions to attacks
16A Typical Hacker Strategy
PING
CORP
Internet
NETWORK
SWEEP
Primary Target Identification - Identify
Hosts ( ) with external visibility
denotes internal hosts with high value data but
no external view
17A Typical Hacker Strategy
PORT
CORP
NETWORK
SWEEP
WEB
Primary Target Analysis - Identify services
running on visible hosts to prioritize further
probing activities
18A Typical Hacker Strategy
Primary Target Selection - Determine
vulnerability state of weakest point and
concentrate further activities against this system
19A Typical Hacker Strategy
Primary Target Exploitation - Gain privileges
control of primary target - attacker now
controls a trusted corporate system !
20A Typical Hacker Strategy
Secondary Target Identification - Probing for
high value information or systems which are
then compromised and data stolen or trojan horses
planted, etc.
21Animated Demo
22Detection
23Intrusion Detection Systems
- Popular second layer of network security
enforcement - Passive supervision of exiting network, analogues
to intruder alarms - Creates more work for personal
- There exist 2 different approaches to the
implementation of Intrusion Detection Systems
(IDS) - Knowledge-based IDS
- Network based
- Host based
- Behaviour-based IDS
- Statistical anomaly detection
24Intrusion Detection Systems
- An Intrusion Detection System (IDS) is a network
security system designed to identify intrusive or
malicious behaviour via monitoring of network
activity. The IDS identifies suspicious patterns
that may indicate an attempt to attack, break in
to, or otherwise compromise a system. An IDS can
be network-based or host-based, passive or
reactive, and can rely on either misuse detection
or anomaly detection. IDS vs Firewalls.
Firewalls specify policies about what traffic may
or may not enter a particular computer network.
An IDS monitors patterns of traffic and signals
an alert once it deems that an attack has taken
place.
25Knowledge-based IDS
- ALL commercial IDS look for attack signatures
- specific patterns of network traffic or activity
in log files that indicate suspicious behaviour. - Called a knowledge-based or misuse detection IDS
- Example signatures might include
- a number of recent failed login attempts on a
sensitive host - a certain pattern of bits in an IP packet,
indicating a buffer overflow attack - certain types of TCP SYN packets, indicating a
SYN flood DoS attack.
26Knowledge-based IDS
- Knowledge-based IDS uses information such as
- Security policy
- Known vulnerabilities of particular OS and
applications - Known attacks on systems.
- They are only as good as the information in the
database of attack signatures - new vulnerabilities not in the database are
constantly being discovered and exploited - vendors need to keep up to date with latest
attacks and issue database updates customers
need to install these - large number of vulnerabilities and different
exploitation methods, so effective database
difficult to build - large database makes IDS slow to use.
27Behaviour-based IDS
- Statistical Anomaly Detection (or behaviour-based
detection) is a methodology where statistical
techniques are used to detect penetrations and
attacks. - Begin by establishing base-line statistical
behaviour what is normal for this system? - Then gather new statistical data and measure the
deviation from the base-line. - If a threshold is exceeded, issue an alarm.
28Behaviour-based IDS
- Example monitor the number of failed login
attempts at a sensitive host over a period - if a burst of failures occurs, an attack may be
under way - or maybe the admin just forgot his password?
- This raises the issue of false positives (an
attack is flagged when one was not taking place
a false alarm) and false negatives (an attack was
missed because it fell within the bounds of
normal behaviour). - This issue does also apply to knowledge-based
systems.
29Behaviour-based IDS
- IDS does not need to know about security
vulnerabilities in a particular system - the base-line defines normality
- dont need to know the details of the
construction of a buffer overflow packet. - Normal behaviour may overlap with forbidden
behaviour. - Legitimate users may deviate from the baseline,
causing false positives (e.g. user goes on
holiday, or works late in the office, or forgets
password, or starts to use new application). - If the base-line is adjusted dynamically and
automatically, a patient attacker may be able to
gradually shift the base-line over time so that
his attack does not generate an alarm.
30Host-based and Network-based IDS
- When an IDS looks for attack signatures in
network traffic, it is called a network-based IDS
(NIDS). - When an IDS looks for attack signatures in log
files of hosts, it is called a host-based IDS
(HIDS). - Naturally, the most effective Intrusion Detection
System will make use of both kinds of
information.
31IDS Architecture
- Distributed set of sensors either located on
hosts or on network to gather data. - Centralised console to manage sensor network,
analyze data, report and react. - Ideally
- Protected communications between sensors and
console - Protected storage for signature database/logs
- Secure console configuration
- Secured signature updates from vendor
- Otherwise, the IDS itself can be attacked and
manipulated.
32Network-based IDS
- Uses network packets as the data source.
- Typically utilizes a network adapter running in
promiscuous mode to monitor and analyze all
traffic in real-time as it travels across the
network. - The attack recognition module uses three common
techniques to recognize attack signatures - Pattern, expression or bytecode matching
- Frequency or threshold crossing (eg detect
portscanning activity) - Correlation of lesser events (in reality, not
much of this in commercial systems).
33Network-based IDS
Response Capability
UserConfigurable Policy
Attack Recognition
Filter Engine
Packet Grabber
Network Sensor
Adapter
34Placement of Network-based IDS
- Deployment options
- Outside fire wall
- Just inside fire wall
- Combination of both will detect attacks getting
through firewall and may help to refine firewall
ruleset. - Behind remote access server
- Between Business Units
- Between Corporate Network and Partner Networks
35Placement of Network-based IDS
Sensor
Mail server
Firewall
Perimeter Network
Sensor
Web server
Sensor
Console
Protected Network
36Animated Demo
37Host-based IDS
- Typically monitors system, event, and security
logs on Windows and syslog in Unix environments. - Checks key system files and executables via
checksums at regular intervals for unexpected
changes. - Some products can use regular-expressions to
refine attack signatures (e.g. passwd program
executed AND .rhosts file changed). - Some products listen to port activity and alert
when specific ports are accessed limited NIDS
capability.
38Host-based IDS
Response Capability
UserConfigurable Policy
Attack Recognition
Filter Engine
Log files and file checksums
Host Sensor
39Placement of Host-based IDS
- Deployment options
- Key servers that contain mission-critical and
sensitive information - Web servers
- FTP and DNS servers
- E-commerce database servers, etc.
40Placement of Host-based IDS
Internet
Sensor
Mail server
Firewall
Perimeter Network
Web server
Sensor
Human Resources Network
Console
Sensor
41IDS as a Response Tool
- Given the (near) real-time nature of IDS alerts,
an IDS can be used as a response tool as well as
for detection. - NIDS and HIDS have different response
capabilities because they detect different
attacks, or the same attacks but in different
ways.
42HIDS and NIDS
- There are attack types that a HIDS can detect but
a NIDS cannot - SYN flood, Land, Smurf and Teardrop attacks,
BackOrifice, - And vice-versa
- Trojan login script, walk up to unattended
keyboard attack, encrypted traffic, - For more reliable detection, combine both types
of IDS.
43IDS Response Options
44IDS Response Options
- Dangers of automated response
- Attacker tricks IDS to respond, but response
aimed at innocent target (say, by spoofing source
IP address) - Users locked out of their accounts because of
false positives - Repeated e-mail notification becomes a denial of
service attack on sysadmins e-mail account - Repeated restoration of index.html from CD
reduces website availability.
45What is Snort?
- Snort is a fast, flexible, small-footprint,
open-source NIDS developed by the security
community and a benevolent dictator - Lead coder Marty Roesch, now founder of
Sourcefire (http//www.sourcefire.com) - Initially developed in late 1998 as a sniffer
with consistent output, unlike protocol-dependent
output of TCPDump - Licensed under GPL, but version 2.0 may change to
a different license
46Snort Rules
- Snort rules are extremely flexible and are easy
to modify, unlike many commercial NIDS - Sample rule to detect SubSeven trojan
- alert tcp EXTERNAL_NET 27374 -gt HOME_NET any
(msg"BACKDOOR subseven 22" flags A content
"0d0a5b52504c5d3030320d0a" referencearachnids,
485 referenceurl,www.hackfix.org/subseven/
sid103 classtypemisc-activity rev4) - Elements before parentheses comprise rule
header - Elements in parentheses are rule options
47Third-Party Enhancements
- Analysis Console for Intrusion Databases (ACID)
- http//acidlab.sourceforge.net/
- PHP-based analysis engine to search and process a
database of security events generated by various
IDSes, firewalls, and network monitoring tools - Query-builder and search interface, packet viewer
(decoder), alert management, chart and statistics
generation - Description and screenshots taken from ACID web
48(No Transcript)
49(No Transcript)
50Third-Party Enhancements
- Demarc
- www.demarc.com
- NIDS management console, integrating Snort with
the convenience and power of a centralized
interface for all network sensors - Monitor all servers / hosts to make sure network
services such as a mail or web servers remain
accessible at all times - Monitor system logs for anomalous log entries
that may indicate intruders or system
malfunctions - Description and screenshots taken from demarc web
51(No Transcript)
52(No Transcript)
53IDS The Future
- Integrated approach to IDS
- Network and host-based in one system (some
products already do this in a limited way) - The strengths of both NIDS and HIDS (but maybe
all of the weaknesses!) - Better visualisation, management and reporting
tools - Event correlation
- Correlate a number of sub-events which
individually do not indicate an attack but which
when viewed in combination do - Requires much more sophisticated software and
data processing. - Potentially much better attack detection.
- Commercial Statistical Anomaly Detection
54Prevention
- Vulnerability Assessment
- Intrusion Prevention Systems
55Vulnerability Assessment
56Vulnerability Assessment
- An examination of the ability of a system or
application, including current security
procedures and controls, to withstand assault. - A vulnerability assessment may be used to
- identify weaknesses that could be exploited
- predict the effectiveness of additional security
measures in protecting information resources from
attack.
57Vulnerability Assessment
- Vulnerability Assessment Methods
- Software solutions (ISS Scanner, Stat, Nessus
etc.) - Audit Services (manual Penetration tests etc)
- Web based commercial (Qualys, Security Point
etc.) - Use a database of vulnerability signatures
- Usually perform a port scan to detect which
services available - Try to identify if service is vulnerable by
- Looking for banner information
- Sending a harmless request and analysing the
response - Actually performing the attack!
- Offer various reporting and management facilities
58Animated Demo
59Lesson learnt from VA
- Keep up-to-date with security (and other) patches
- Form Microsoft OS www.windowsupdate.com
- Enterprise version available Windows Update
Services (WUS) - Microsoft Baseline Security Advisor
- Includes hfnetcheck.exe (from Shavlik)
- Similar for SUN, HP, IBM, CISCO etc. OSs
60Intrusion Prevention Systems
61Intrusion Prevention System - IPS
- Relatively new (marketing) term
- Essentially a combination of access control
(firewall/router) and intrusion detection systems - Often shared technologies between stateful
inspection and signature recognition (looking
deep into the packet) - Inline network IDS allows for instant access
control policy modification - 2004 Gartner study claims by 2005 only integrated
firewalls with IDS (i.e. IPS) will survive - Most success to-date with flood (DoS) attacks
62Definition of an IPS
- Can be defined as an in-line product that focuses
on identifying and blocking malicious network
activity in real time. - Two general categories
- rate-based products
- content-based (also referred to as signature- and
anomaly-based) - Often look like firewalls and often have some
basic firewall functionality. - But firewalls block all traffic except that which
they have a reason to pass - IPSs pass all traffic except that which they have
a reason to block.
63Rate-based IPS
- Block traffic based on load
- too many packets,
- too many connects,
- too many errors.
- In the presence of too much of anything, the
rate-based IPS kicks in and blocks, throttles or
otherwise mediates the traffic. - Most useful rate-based IPS include a combination
of powerful configuration options with range of
response technologies - For example, limit queries to your DNS server to
1,000 per second - Other simple rules covering bandwidth and
connection limiting
64Disadvantages of Rate-based IPS
- Biggest problem with deploying rate-based IPS
products is deciding what constitutes an
overload. - For any rate-based IPS to work properly, need to
know not only what "normal" traffic levels are
(on a host-by-host and port-by-port basis) but
also other network details such as how many
connections your Web servers can handle. - Most products do not provide any help but require
a trained system engineer - Because rate-based IPSs require frequent tuning
and adjustment, they will be most useful in very
high-volume Web, application and mail server
environments.
65Content-based products
- Block traffic based on attack signatures and
protocol anomalies - Worms, e.g. Blaster and MyDoom, that match a
signature can be blocked. - Packets that do not comply to TCP/IP RFCs can be
dropped. - Suspicious behaviour such as port scanning
triggers the IPS to block future traffic from a
single host - The best content-based IPSs offer a range of
techniques for identifying malicious content and
many options for how to handle the attacks, - simply dropping bad packets to
- dropping future packets from the same attacker,
and - reporting and alerting strategies.
- IDS-like technology for identifying threats and
blocking them, content-based IPSs can be used
deep inside the network to complement firewalls
and provide security policy enforcement.
66Counter attacks
- The Problem of origin
- Honeypots/nets
67Problem of origin
- Denial of Service attacks (DoS)
- In contrast to unauthorised access attacks a DoS
attack does not need to contain method for
communicating back to the attacker - Distributed Denial of Service (DDoS) attacks
- Trin00/Stacheldraht (Feb 2000)
- Attacks on ebay, amazon.com and etrade.com
- MS.Blaster (August 2003)
- Problem of lack of metrics to measure the impact
of Denial of Service attacks more research
required
68What is a DDoS Attack ?
- In a Denial of Service (DoS) attack,
- The attacker overwhelms a targeted system with a
flood of packets to deny availability of services
to legitimate users - In a Distributed Denial of Service (DDoS) attack,
- The attacker uses dozens or even hundreds of
zombie machines to multiply the force of the
attack
69Motives Behind DDoS Attacks
- Until recently attacks appear to be motivated by
- Desire for attention
- Notoriety
- Fun
- Long term, DDoS type attacks could become
motivated by - Economic warfare between competition
- Disgruntled employees/customers
- Monetary gains (i.e. stock market
manipulation/online betting) - Political sabotage and vandalism (party websites
during election campaigns)
70DDoS Components
- All DDoS attacks consist of three parts
- Client Program
- Master Server
- Agent (Zombie) Program
71DDoS Attack Illustrated
72DDoS Attack Illustrated
Zombies
Hacker secretly installs zombie
agent programs, turning unsecured computers into
zombies
2
73DDoS Attack Illustrated
Zombies
Hacker selects a Master Server to
send commands to the zombies
3
74DDoS Attack Illustrated
Zombies
Using Client program, Hacker sends
commands to Master Server to launch zombie attack
against a targeted system
4
75DDoS Attack Illustrated
Zombies
Master Server sends signal to
zombies to launch attack on targeted system
5
76DDoS Attack Illustrated
Zombies
Targeted system is overwhelmed by
bogus requests that shut it down for legitimate
users
6
User
77Minimizing Risk
- Prevent yourself from being victimized
- Ensure your computers are not zombies
- Perform periodic assessments via automated
scanning services - Implement an early warning system
- Automated Intrusion Detection Response tools
- Collect forensic data to prosecute hackers later
78Honeypots
- Technology used to track, learn and gather
evidence of hacker activities - Definition
- a resource whose value is being attacked or
compromised - Laurence Spitzner, The value of honeypots,
SecurityFocus, October 2001 - Strategically placed systems designed to mimic
production systems, but not reveal real data - Modes of operation
- Baiting
- Waiting
- Collating
- Disseminating
79Honeypot types of implementation
- Level of Involvement
- Low Involvement Port Listeners
- Mid Involvement Fake Daemons
- High Involvement Real Services
- Risk increases with level of involvement
80Honeynet
- Network of honeypots
- Supplemented by firewalls and intrusion detection
systems - Honeywall - Advantages
- More realistic environment
- Improved possibilities to collect data
81Honeynet
82Sebek
- Sebek is a data capture tool designed to capture
all of the attackers activities on a honeypot,
without the attacker knowing it. - 2 components.
- Client that runs on the honeypots, its purpose is
to capture all of the attackers activities
(keystrokes, file uploads, passwords) then
covertly send the data to the server. - Server which collects the data from the
honeypots. The server normally runs on the
Honeywall gateway. - Since the Sebek client runs as a kernel module on
the honeypots, it can capture all activity,
including encrypted, such as SSH, IPSec
83Honeynet using a Honeywall
84Summary
- Threats are both internal and external.
- Prevention, detection and reaction are needed in
combination. - Intrusion detection systems are a very useful
second line of defence (in addition to firewalls
and other safeguards). - IDS deployment, customisation and management is
generally not straightforward. - Vulnerability Assessment and Patch Management are
King. - Newer technologies such as IPS and Honeynets can
remove the burden from over worked system and
network administrators.
85IDS Further Reading
- Stallings Chapter 9, pp.292-303 (possibly too
much emphasis on statistical approach
research-focussed rather than commercially
focussed). - An article The future of IDS by Matthew Tanase
at SecurityFocus.com - http//online.securityfocus.com/infocus/1518
- An evaluation of IDS products by Kathleen A.
Jackson - http//www.sekure.net/ids/00416750.pdf
86Questions
- Thank You !
- Merry Christmas
-
- Happy New Year
