SIFT (Lowe 99)

1
SIFT (Lowe 99)Beyond Bags of Features
Spatial Pyramid Matching for Recognizing Natural
Scene Categories (Lazebnik et al
2006)(various slides stolen from the web)
TexPoint fonts used in EMF. Read the TexPoint
manual before you delete this box. AAA
2
Scale-Invariant Feature Transform

• Generates image features, keypoints
• invariant to image scaling and rotation
• partially invariant to change in illumination and
  3D camera viewpoint
• many can be extracted from typical images
• highly distinctive

3
Algorithm Stages

• Scale-space Extrema Detection
• Uses difference-of-Gaussian function
• Keypoint Localization
• Sub-pixel location and scale fit to a model
• Orientation assignment
• 1 or more for each keypoint
• Keypoint descriptor
• Created from local image gradients

4
Scale Space
5
Difference Of Gaussian Pyramid
Blur Resample
A
B
A
B
6
Difference Of Gaussian Pyramid
A- B
7
Extrema Detection

• Keypoint must be a minima or maxima of its 8
  neighbors at its scale and the 9 neighbors above
  and 9 below.

8
Extrema Detection
9
Keypoint Localization and Refinement

• Refine keypoint/extrema position fitting a 3D
  quadratic model to get subpixel accuracy of x,y
  position and scale.
• Throw out points that have low contrast
• Remove points that are too edgy.

10
Keypoint Localization and Refinement
11
Keypoint Localization and Refinement
12
Orientation Assignment

• Create histogram of local gradient directions
  computed at selected scale
• Assign canonical orientation at peak of smoothed
  histogram
• Each keypoint specifies stable 2D coordinates (x,
  y, scale, orientation)

13
Example from paper
14
SIFT Descriptor

• Try to mimic complex cells in the visual cortex
• Selective to spatial frequency and orientation
  but allows for shifts in position
• Be robust to small affine transformations
• Local affine transformations affect positions
  more than orientation and spatial frequency.

15
SIFT Descriptor

• Thresholded image gradients are sampled over
  16x16 array of locations at keypoint scale
• Create array of orientation histograms rotated
  relative to orientation of keypoint.
• 8 orientations x 4x4 histogram array 128
  dimensions
• Distribute each sample to adjacent bins by
  trilinear interpolation (avoids boundary effects)

16
3D object recognition example from paper
17
SIFT Review

• Generates image features, keypoints
• invariant to image scaling and rotation
• partially invariant to change in illumination and
  3D camera viewpoint
• many can be extracted from typical images
• Each keypoint has an associated descriptor that
  is
• Relative to keypoint orientation and scale
• Is robust to small affine transformations.

18
SIFT Review

• Note
• We can skip the keypoint detection.
• Pick a grid over the image and make descriptor
  for each point.
• Fei Fe and Perona (CVPR 2005) showed this works
  better for scene classification.

19
Beyond Bags of Features Spatial Pyramid Matching
for Recognizing Natural Scene Categories
(Lazebnik et. al 2006)Many slides borrowed
from http//www.ima.umn.edu/2005-2006/W5.22-26.06
/activities/Lazebnik-Svetlana/ima_poster.pdfand
http//people.csail.mit.edu/kgrauman/slides/pyr_m
atch_iccv2005.ppt
20
Overview

• Adds approximate global geometric
  correspondence to bag of features techniques
  for scene recognition
• Spatial pyramid matching partitions the image
  into multiscale subregions and computes feature
  histograms.
• Use weak-features (orientated edges at multiple
  scales) and strong-features (Vocabulary formed
  by gridded SIFT descriptors)

21
Motivation

• A pre-attentive approach Recognize scene as
  whole without examining its constituent objects.

22
Images as collections of features

• Image as unordered set of d-dimensional feature
  vectors
• Varying number of vectors per instance

23
Classifiers (hand wavy)

• Training data multiple images for each class
• Image is represented by unordered set of features
• We need some way to compare feature set X to
  feature set Y.
• Some similarity function K(X,Y).

24
Classifiers (hand wavy)

• Nearest neighbor Input X,
• find Y that maximizes K(X,Y) for all Y in the
  training set.
• Label X with the class label for Y.
• SVM use K(X,Y) as kernel function
• Inner product
• Mercer Kernel

25
Partial matching

• Compare sets by computing a partial matching
  between their features.

26
Computing the partial matching

• Earth Movers Distance
• Rubner, Tomasi, Guibas 1998
• Hungarian method
• Kuhn, 1955
• Greedy matching
• Pyramid match

Grauman and Darrell, ICCV 2005
for sets with features of dimension
27
Pyramid match overview
Pyramid match measures similarity of a partial
matching between two sets

• Place multi-dimensional, multi-resolution grid
  over point sets
• Consider points matched at finest resolution
  where they fall into same grid cell
• Approximate optimal similarity with worst case
  similarity within pyramid cell

No explicit search for matches!
28
Pyramid match overview
29
Pyramid Match

• d dimensional feature vectors
• A sequence of grids at resolutions 0 L
• At level l

d2, L2
30
Pyramid match Kernel

• Matches at level l include matches at level l 1
• New matches at level l (for l0L-1)
• Penalize easy matches at larger scales with
  weight
• Match kernel

31
Vocabulary of M features

• Only features of the same type can be matched.
• Each channel m treated separately

32
Vocabulary of M features
33
Spatial pyramid representation
d2 (x,y)
M classes of features
34
Feature Extraction
35
Experimental Results
36
Scene Category Dataset
37
Scene Category Retrieval
38
Scene Category Confusion
39
Caltech 101
40
Caltech 101 Comparision
41
Caltech 101 Challenges
42
Gratz
