Decentralizing Grids

1
Decentralizing Grids

• Jon Weissman
• University of Minnesota
• E-Science Institute
• Nov. 8 2007

2
Roadmap

• Background
• The problem space
• Some early solutions
• Research frontier/opportunities
• Wrapup

3
Background

• Grids are distributed but also centralized
• Condor, Globus, BOINC, Grid Services, VOs
• Why? client-server based
• Centralization pros
• Security, policy, global resource management
• Decentralization pros
• Reliability, dynamic, flexible, scalable
• Fertile CS research frontier

4
Challenges

• May have to live within the Grid ecosystem
• Condor, Globus, Grid services, VOs, etc.
• First principle approaches are risky (Legion)
• 50K foot view
• How to decentralize Grids yet retain their
  existing features?
• High performance, workflows, performance
  prediction, etc.

5
Decentralized Grid platform

• Minimal assumptions about each node
• Nodes have associated assets (A)
• basic CPU, memory, disk, etc.
• complex application services
• exposed interface to assets OS, Condor, BOINC,
  Web service
• Nodes may up or down
• Node trust is not a given (do X, does Y instead)
• Nodes may connect to other nodes or not
• Nodes may be aggregates
• Grid may be large gt 100K nodes, scalability is
  key

6
Grid Overlay
Condor network
Grid service
Raw OS services
BOINC network
7
Grid Overlay - Join
Condor network
Grid service
Raw OS services
BOINC network
8
Grid Overlay - Departure
Condor network
Grid service
Raw OS services
BOINC network
9
Routing Discovery
discover A
Query contains sufficient information to locate a
node RSL, ClassAd, etc Exact match or semantic
match
10
Routing Discovery
bingo!
11
Routing Discovery
Discovered node returns a handle sufficient for
the client to interact with it - perform
service invocation, job/data transmission,
etc
12
Routing Discovery

• Three parties
• initiator of discovery events for A
• client invocation, health of A
• node offering A
• Often initiator and client will be the same
• Other times client will be determined dynamically
• if W is a web service and results are returned to
  a calling client, want to locate CW near W gt
• discover W, then CW !

13
Routing Discovery
X
discover A
14
Routing Discovery
15
Routing Discovery
bingo!
16
Routing Discovery
17
Routing Discovery
outside client
18
Routing Discovery
discover As
19
Routing Discovery
20
Grid Overlay

• This generalizes
• Resource query (query contains job requirements)
• Looks like decentralized matchmaking
• These are the easy cases
• independent simple queries
• find a CPU with characteristics x, y, z
• find 100 CPUs each with x, y, z
• suppose queries are complex or related?
• find N CPUs with aggregate power G Gflops
• locate an asset near a prior discovered asset

21
Grid Scenarios

• Grid applications are more challenging
• Application has a more complex structure
  multi-task, parallel/distributed, control/data
  dependencies
• individual job/task needs a resource near a data
  source
• workflow
• queries are not independent
• Metrics are collective
• not simply raw throughput
• makespan
• response
• QoS

22
Related Work

• Maryland/Purdue
• matchmaking
• Oregon-CCOF
• time-zone

CAN
23
Related Work (contd)

• None of these approaches address the Grid
  scenarios (in a decentralized manner)
• Complex multi-task data/control dependencies
• Collective metrics

24
50K Ft Research Issues

• Overlay Architecture
• structured, unstructured, hybrid
• what is the right architecture?
• Decentralized control/data dependencies
• how to do it?
• Reliability
• how to achieve it?
• Collective metrics
• how to achieve them?

25
Context Application Model
answer
data source
26
Context Application Models
Reliability Collective metrics Data
dependence Control dependence
27
Context Environment

• RIDGE project - ridge.cs.umn.edu
• reliable infrastructure for donation grid envs
• Live deployment on PlanetLab planet-lab.org
• 700 nodes spanning 335 sites and 35 countries
• emulators and simulators
• Applications
• BLAST
• Traffic planning
• Image comparison

28
Application Models
Reliability Collective metrics Data
dependence Control dependence
29
Reliability Example

C
E
D
B
G
30
Reliability Example

C
E
D
B
CG
G
CG responsible for Gs health
31
Reliability Example

C
E
D
B
G, loc(CG )
CG
32
Reliability Example

C
E
D
B
G
CG
could also discover G then CG
33
Reliability Example

C
E
D
X
B
CG
34
Reliability Example

C
E
D
G.
CG
35
Reliability Example

C
E
D
G
CG
36
Client Replication

C
E
D
B
G
37
Client Replication

C
E
D
B
G
CG2
CG1
loc (G), loc (CG1), loc (CG2) propagated
38
Client Replication

C
E
D
B
G
CG2
X
CG1
client hand-off depends on nature of G and
interaction
39
Component Replication

C
E
D
B
G
40
Component Replication

C
E
D
G2
G1
CG
41
Replication Research

• Nodes are unreliable crash, hacked, churn,
  malicious, slow, etc.
• How many replicas?
• too many waste of resources
• too few application suffers

42
System Model

• Reputation rating ri degree of node reliability
• Dynamically size the redundancy based on ri
• Nodes are not connected and check-in to a central
  server
• Note variable sized groups

0.9
0.8
0.8
0.7
0.7
0.4
0.3
0.4
0.8
0.8
43
Reputation-based Scheduling

• Reputation rating
• Techniques for estimating reliability based on
  past interactions
• Reputation-based scheduling algorithms
• Using reliabilities for allocating work
• Relies on a success threshold parameter

44
Algorithm Space

• How many replicas?
• first-, best-fit, random, fixed,
• algorithms compute how many replicas to meet a
  success threshold
• How to reach consensus?
• M-first (better for timeliness)
• Majority (better for byzantine threats)

45
Experimental Results correctness
This was a simulation based on byzantine behavior
majority voting
46
Experimental Results timeliness
M-first (M1), best BOINC (BOINC), conservative
(BOINC-) vs. RIDGE
47
Next steps

• Nodes are decentralized, but not trust
  management!
• Need a peer-based trust exchange framework
• Stanford Eigentrust project local exchange
  until network converges to a global state

48
Application Models
Reliability Collective metrics Data
dependence Control dependence
49
Collective Metrics

• Throughput not always the best metric
• Response, completion time, application-centric
• makespan - response

50
Communication Makespan

• Nodes download data from replicated data nodes
• Nodes choose data servers independently
  (decentralized)
• Minimize the maximum download time for all worker
  nodes (communication makespan)

data download dominates
51
Data node selection

• Several possible factors
• Proximity (RTT)
• Network bandwidth
• Server capacity

Download Time vs. RTT - linear
Download Time vs. Bandwidth - exp
52
Heuristic Ranking Function

• Query to get candidates, RTT/bw probes
• Node i, data server node j
• Cost function rtti,j exp(kj /bwi,j), kj
  load/capacity
• Least cost data node selected independently
• Three server selection heuristics that use kj
• BW-ONLY kj 1
• BW-LOAD kj n-minute average load (past)
• BW-CAND kj of candidate responses in last m
  seconds ( future load)

53
Performance Comparison
54
Computational Makespan
55
Computational Makespan

variable-sized
equal-sized
56
Next Steps

• Other makespan scenarios
• Eliminate probes for bw and RTT -gt estimation
• Richer collective metrics
• deadlines user-in-the-loop

57
Application Models
Reliability Collective metrics Data
dependence Control dependence
58
Application Models
Reliability Collective metrics Data
dependence Control dependence
59
Data Dependence

• Data-dependent component needs access to one or
  more data sources data may be large

discover A
60
Data Dependence (contd)
discover A
Where to run it?
61
The Problem

• Where to run a data-dependent component?
• determine candidate set
• select a candidate
• Unlikely a candidate knows downstream bw from
  particular data nodes
• Idea infer bw from neighbor observations w/r to
  data nodes!

62
Estimation Technique

• C1 may have had little past interaction with
• but its neighbors may have
• For each neighbor generate a download estimate
• DT prior download time to from
  neighbor
• RTT from candidate and neighbor to
  respectively
• DP average weighted measure of prior download
  times for any node to any data source

63
Estimation Technique (contd)

• Download Power (DP) characterizes download
  capability of a node
• DP average (DT RTT)
• DT not enough (far-away vs. nearby data source)
• Estimation associated with each neighbor ni
• ElapsedEst ni a ß DT
• a my_RTT/neighbor_RTT (to )
• ß neighbor_DP /my_DP
• no active probes historical data, RTT inference
• Combining neighbor estimates
• mean, median, min, .
• median worked the best
• Take a min over all candidate estimates

64
Comparison of Candidate Selection Heuristics
SELF uses direct observations
65
Take Away

• Next steps
• routing to the best candidates
• Locality between a data source and component
• scalable, no probing needed
• many uses

66
Application Models
Reliability Collective metrics Data
dependence Control dependence
67
The Problem

• How to enable decentralized control?
• propagate downstream graph stages
• perform distributed synchronization
• Idea
• distributed dataflow token matching
• graph forwarding, futures (Mentat project)

68
Control Example

C
E
D
B
control node token matching
69
Simple Example

B
C
G
E
D
70
Control Example
E, BCD
B
C
E, BCD
C, G
G
E
D, G
D
E, BCD
71
Control Example

C
E
D
B
E, BCD
C
D
E, BCD
E, BCD
72
Control Example

C
E
D
B
E, BCD, loc(SB)
C
D
E, BCD, loc(SC)
E, BCD, loc(SD)
output stored at loc() where component is run,
or client, or a storage node
73
Control Example

C
E
D
B
B
C
D
74
Control Example

C
E
D
B
B
C
D
75
Control Example

C
E
D
B
B
C
D
76
Control Example

C
E
D
B
B
E
C
D
77
Control Example

C
E
D
B
B
E
C
D
78
Control Example

C
E
D
How to color and route tokens so that they arrive
to the same control node?
B
B
E
C
D
79
Open Problems

• Support for Global Operations
• troubleshooting what happened?
• monitoring application progress?
• cleanup application died, cleanup state
• Load balance across different applications
• routing to guarantee dispersion

80
Summary

• Decentralizing Grids is a challenging problem
• Re-think systems, algorithms, protocols, and
  middleware gt fertile research
• Keep our eye on the ball
• reliability, scalability, and maintaining
  performance
• Some preliminary progress on point solutions

81
My visit

• Looking to apply some of these ideas to existing
  UK projects via collaboration
• Current and potential projects
• Decentralized dataflow (Adam Barker)
• Decentralized applications Haplotype analysis
  (Andrea Christoforou, Mike Baker)
• Decentralized control openKnowledge (Dave
  Robertson)
• Goal improve reliability and scalability of
  applications and/or infrastructures

82

• Questions

83
(No Transcript)
84

• EXTRAS

85
Non-stationarity

• Nodes may suddenly shift gears
• deliberately malicious, virus, detach/rejoin
• underlying reliability distribution changes
• Solution
• window-based rating
• adapt/learn ltarget
• Experiment blackout at
• round 300 (30 effected)

86
Adapting
87
Adaptive Algorithm
success rate
throughput
88
success rate
throughput
89
Scheduling Algorithms
90
Estimation Accuracy

• Objects 27 (.5 MB 2MB)
• Nodes 130 on PlanetLab
• Download 15,000 times from a randomly chosen node

• Download Elapsed Time Ratio (x-axis) is a ratio
  of estimation to real measured time
• 1 means perfect estimation
• Accept if the estimation is within a range
  measured (measured error)
• Accept with error0.33 67 of the total are
  accepted
• Accept with error0.50 83 of the total are
  accepted

91
Impact of Churn
Random mean
Global(Prox) mean

• Jinoh mean over what?

92
Estimating RTT

• We use distance v(RTT1)
• Simple RTT inference technique based on triangle
  inequality
• Triangle Inequality Latency(a,c) Latency(a,b)
  Latency(b,c)
• Latency(a,b)-Latency(b,c) Latency(a,c)
  Latency(a,b)Latency(b,c)
• Pick the intersected area as the range, and take
  the mean

Lower bound
Higher bound
Via Neighbor A
Via Neighbor B
Via Neighbor C
Inference
RTT
Final inference
Intersected range
93
RTT Inference Result

• More neighbors, greater accuracy
• With 5 neighbors, 85 of the total lt 16 error

94
Other Constraints
E, BCD
B
C
E, BCD
C, A, dep-CD
A
E
D, A, dep-CD
D
E, BCD
C D interact and they should be co-allocated,
nearby Tokens in bold should route to same
control point so a collective query for C D can
be issued
95
Support for Global Operations

• Troubleshooting what happened?
• Monitoring application progress?
• Cleanup application died, cleanup state
• Solution mechanism propagate control node IPs
  back to origin (gt origin IP piggybacked)
• Control nodes and matcher nodes report progress
  (or lack thereof via timeouts) to origin
• Load balance across different applications

96
Other Constraints
E, BCD
B
C
E, BCD
C, A
A
E
D, A
D
E, BCD
C D interact and they should be co-allocated,
nearby
97
Combining Neighbors Estimation

• MEDIAN shows best results using 3 neighbors
  88 of the time error is within 50 (variation in
  download times is a factor of 10-20)
• 3 neighbors gives greatest bang

98
Effect of Candidate Size
99
Performance Comparison

• Parameters
• Data size 2MB
• Replication 10
• Candidates 5

100
Computation Makespan (contd)

• Now bring in reliability makespan improvement
  scales well

components
101
Token loss

• Between B and matcher matcher and next stage
• matcher must notify CB when token arrives (pass
  loc(CB) with Bs token
• destination (E) must notify CB when token arrives
  (pass loc(CB) with Bs token

102
RTT Inference

• gt 90-95 of Internet paths obey triangle
  inequality
• RTT (a, c) lt RTT (a, b) RTT (b, c)
• RTT (server, c) lt RTT (server, ni) RTT (ni, c)

• upper- bound
• lower-bound RTT (server, ni) - RTT (ni, c)
• iterate over all neighbors to get max L, min U
• return mid-point
