Nearest Neighbor

• Paul Hsiung
• March 16, 2004

2
Quick Review of NN

• Set of points P
• Query point q
• Distance metric d
• Find p in P such that d(p,q) lt d(p,q)for all
  p in P

p
q
3
NN Used In

• Image databases Pentland et al
• Color indexing swain et al
• Recognizing 3D objects Murase et al
• Shapes Mori et al
• Drug testing
• DNA sequence matching Buhler

4
Tree-based Approaches

• Quadtrees
• Split middle in all dimensions
• Split until no points or one point left
• Kd-trees
• Split in one dimension
• Pick the middle wisely
• Ball-trees
• Pick two pivots and split
• SR-trees
• We have rectangles and spheres, so why not
  combine them

5
Indyks Gripe

• Beyond 10 or 20 dimensions, tree-based structures
  will look at many points
• No better than brute force linear search
• So he came up with a hash table approach
  Locality Sensitive Hashing (LSH)
• Rest of talk will be on his paper

6
LSH
7
Interlude Near Neighbor

• Set of points P
• Query point q
• Distance metric d
• Find p in P such that d(p,q) lt (1e)d(P,q)where
  d(P,q) is the distance of q to its closest point
  in P

d(P,q)
p
q
(1e)d(P,q)
8
Hash

• Pick a subset I of random coordinates
• Hash function, h(p), will return a bucket ID
• h(p) projection of p on I

9
Intuition

• If two points are close, they hash to same bucket
  with some probability p1
• If they are far, they hash to same bucket with a
  smaller probability p2 lt p1

10
Indyks Hash

• Convert coordinates of p to 0,1d
• Use Hamming distance d(p,q) positions on
  which p and q differ
• Example
• p(0,1,0,1,1,1,0,0,1,0)
• I2,5,7
• Then, h(p)(1,1,0)
• Demo
• http//web.mit.edu/ardonite/6.838/locality-hashing
  .htm

11
Why Locality-sensitive?

• Prh(p)h(q)(1-d(p,q)/D)k
• D is the number of dimensions in the binary
  representation
• k is the size of I
• We can vary the probability by changing k

k1
k2
Pr
Pr
distance
distance
12
Now to Use It (Training)

• Generate l hash functions h1..hl
• Store each point p in the bucket hi(p) of the
  i-th hash array, i1...l

13
Now to Use It (Query)

• Retrieve all the points that belong to the
  buckets h1(q)..hl(q)
• Return the retrieved point that is closest to q
• This solves the Near Neighbor problem

14
Indyks Results

• Compared with another tree-based algorithm
• Color histogram dataset from Corel Draw
• 20,000 images, 64 dimensions
• Used 1k, 2k, 5k, 10k, 19k points for training
• 1k points are used for query
• Computed missed ratio fraction of queries with
  no hits

15
Indyks Results
16
Results II
17
Ugly Side

• Works best with Hamming distance
• Can be extended from L1 and L2 norms
• Requires parameter tweaking (size of I and number
  of hash buckets)
• Does not work well on uniform data

18
Bibliography

• A. Gionis, P. Indyk, R. Motwani. Similarity
  Search in High Dimensions via Hashing. In VLDB
  25th, 1999
• J. Buhler. Efficient Large-Scale Sequence
  Comparison by Locality-Sensitive Hashing. In
  Bioinformatics 17(5) 419-428, 2001
• H. Murase, S. K. Nayar. Visual Learning and
  Recognition of 3D Objects from Appearance. In
  IJCV, Vol. 14, No. 1 5-24, 1995
• A. Pentland, R.W. Picard, S. Scalroff. Photobook
  Tools for Content Based Manipulation of Image
  Databases. In SPIE Vol. 2185 34-47, 1994
• M.J. Swain, D.H. Ballard. Color Indexing. In
  IJCV, Vol. 7, No. 1 11-32, 1991
• G. Mori, S. Belongie, J. Malik. Shape Contexts
  Enable Efficient Retrieval of Similar Shapes.
  CVPR 1 723-730, 2001
• Slides Algorithms for Nearest Neighbor Search
  by Piotr Indyk
• Slides Approximate Nearest Neighbor in High
  Dimensions via Hashing by Aris Gionis, Piotr
  Indyk, and Rajeev Motwani
