ST.22 Revision task force report
SCIT/SDWG/8, March 2007
2
Task force achievements

• gtgt Proposal for the ST.22 revised standard ready
• gtgt Answers to questions raised at the last SDWG
  prepared

3
Revision of WIPO Standard ST.22

• Purpose of the Revision
• Facilitate the OCR of patent applications to save
  costs and improve publication and search quality
  for the IP community
• Way to achieve
• Adapt the recommendations to the technical
  progresses made in OCR technology in the last ten
  years
• Adopt the revision of the standard
• Actively promote the standard to applicants
  (publication on web sites, fees adaptations)

4
Revised standard ST.22 what s new?

• The essence of the standard has NOT changed but
• The scope of application of the standard has been
  precised
• The recommendations have been reformulated with a
  modern vocabulary
• Good and bad examples that illustrate the
  recommendations have been added in a new appendix
• The recommended font size is now 14pts
• Embedded drawings shall be well separated from
  the text lines with wide white margins

5
Task force achievements

• gtgt Proposal for the ST.22 Revised standard ready
• gtgt Answers to questions raised at the last SDWG
  prepared

6
Answers to questions raised at the last SDWG
meeting

• Question 1 (Paragraph 36 of SCIT/SDWG/7/9)
• The task force shall examine the use of
  non-Latin based characters, so that the standard
  can cover non-Latin character based languages at
  a later stage.
• Two new recommendations have been added to WIPO
  standard ST.22
• (1) mixing Latin and non-Latin characters in
  text paragraphs is not recommended
• (2) for texts in the Chinese language, the Song
  font is recommended

7
Answers to questions raised at the last SDWG
meeting

• Question 2 (Paragraph 37 of SCIT/SDWG/7/9)
• The SDWG also mandated the Task Force to examine
  the optical character recognition (OCR) accuracy
  rate (currently better than 98.5) to see if a
  higher accuracy rate should be specified.
• Currently, the recommended minimal accuracy rate
  for searching is 98.5. The task force proposes
  to raise the recommended minimal accuracy rate in
  average to 99.5 in order to obtain a better
  quality for the search. (This still represents in
  average 15 errors per page). Search engines
  should also work with similarity in order to
  compensate the OCR errors.

8
Answers to questions raised at the last SDWG
meeting

• Question 3 (Paragraph 38 of SCIT/SDWG/7/9)
• The task force shall take into consideration
  what font styles and font sizes should be
  recommended for optimizing readability, for
  screen presentation and for OCR.
• For OCR, the answer can be found in paragraphs
  number 31 and 33 of the proposed revised Standard
  ST.22.

9
Answers to questions raised at the last SDWG
meeting
Question 3 Extract of revised ST.22 31.The
minimal recommended font size is 12 points, 14
points being preferred. As a general rule, all
characters of a paragraph should have the same
font size. 33.The recommended fonts are the
following in order (a) Monospaced family
OCR-B, Courier New (b) Serif family ITC
Officina Serif, Times New Roman (c) Sans Serif
family Verdana, ITC Officina Sans ,
Arial However, the Arial and Times New Roman
fonts are not recommended for applications
containing chemical and/or mathematical formulae,
as well as acronyms mixing letters and digits.
For Chinese characters, the Song font is
recommended.
10
Answers to questions raised at the last SDWG
meeting

• Question 3
• Concerning screen presentation
• No strong recommendation for a preferred font
  style.
• Larger fonts (like Verdana) may have a small
  subjective advantage over narrow fonts (like
  Times New Roman).
• The recommended font size for screen readability
  depends on the resolution of the screen and on
  the age of the target audience.

11
Answers to questions raised at the last SDWG
meeting

• Question 3
• For more details, please refer to the following
  studies
• http//hid.fidelity.com/q22002/fonts.htm
• http//desktoppub.about.com/library/howto/ht_types
  ize.htm?oncetrue
• Chapter 11 of http//www.usability.gov/guidelines
  /
• http//www.humanfactors.com/downloads/feb99.asp
• http//psychology.wichita.edu/optimalweb/text.htm

12
Conclusion

• The task force proposes the document at
  http//www.wipo.int/meetings/en/details.jsp?meetin
  g_id12446 for promulgation by the SDWG.
• The task force proposes to remain active in order
  to gather in more details recommendations for
  non-latin languages, follow up the application of
  the revised standard and report about it and
  analyse any further proposed changes to the
  standard.

13
Conclusion

• gtgt I would like to thank the members of the task
  force for their active contributions
• Elisabeta Balbaie (Romanian Patent Office)
• Bruce Cox (United Stated Patent and Trademarks
  office)
• Katja Daubert (German Patent and Trade Mark
  Office)
• Ramona Dumitrache (Canadian Intellectual Property
  Office)
• Matthias Guenter (Swiss Federal Institute of
  Intellectual Property)
• Gennady N Egouliev (Federal Institute of
  Industrial Property, Russian Federation)
• Long Ning (Chinese State Intellectual Property
  Office)
• Nygren Patrik (European Patent Office)
• Rob Wills (Intellectual Property Office
  Australia)

14
Conclusion

• gtgt Questions?
