Title: Part 1 Basic concepts for data communication


1
Part 1 Basic concepts for data communication
  • Networking fundamentals

2
The five core areas of TNO
TNO Quality of Life
TNO Defence, Security and Safety
TNO Science and Industry
TNO Built Environment and Geosciences
TNO Informa-tion and Communication Technology
  • Facts Figures
  • Established by law in 1932
  • to support companies and governments with
    innovative, practicable knowledge
  • As a statutory organization TNO has an
    independent position
  • Annual turnover 562 Mio euro
  • Employees 4.700

3
Paul Brandt, TNO-ICT
  • If you have any questions or suggestions, do not
    hesitate to get in contact
  • e paul.brandt_at_tno.nl
  • t 015-2857056
  • whttp//www.linkedin.com/in/paulbrandt

Questions cant be stupid. Only answers can.
4
Objective
  • Technical foundation to
  • sift the wheat from the chaff
  • know about possibilities and impossibilities
  • familiarise with the buzz words
  • Get a perspective on the blur of data
    communications

it's not the definitions that decide what
technology to use, but rather the technology that
indicates what kind of network you have!
5
Take home
  • What is it and what is it used for
  • connection-oriented vs. connectionless
    communications
  • circuit-switched vs. packet-switched networks
  • network equipment (gateways, routers, switches,
    )
  • protocols
  • topologies
  • standards
  • proprietary, de-facto, dejure openness
  • actuals related to domotics
  • telecommunication, its particulars
  • Home networking technologies overview
    analysis, TU/e TNO, December 2003
  • it's not the definitions that decide what
    technology to use, but rather the technology that
    indicates what kind of network you have!

6
1. Network layers
To understand any complex system is to break it
down into modular components and then analyze
what they do and how they interact
Networks are most often compartmentalized by
dividing their functions into layers
7
Network layers what are they
  • Each layer is responsible for performing a
    particular type of tasks
  • Tasks can create very elementary functionality
    (buffering bits), very abstract functionality
    (stream video data) and everything in between
  • Coherent, related tasks are grouped into a single
    layer
  • Layers are conceptually arranged into a vertical
    stack
  • Each layer only interacts with the layers above
    it and below it
  • Each layer provides services to the higher
    layers
  • Lower layers are charged with more elementary
    tasks such as hardware signalling, converting
    from bits to electrical signal and vice versa
  • The middle layers in turn use these services to
    implement more abstract functions such as
    transporting data
  • The highest layer uses these abstract services to
    implement user applications (email, web browsing)
  • Layers use protocols to implement the actual
    communication

service functionality
8
Network protocols what are they (1/2)
  • A protocol often refers to a code of conduct, or
    a form of etiquette as observed by, for instance,
    diplomats.
  • Diplomats must follow certain rules of ceremony
    and form
  • to ensure that they communicate effectively
  • to ensure that they communicate without coming
    into conflict
  • to understand what is expected of them when they
    interact, which can be different for different
    conversation partners

9
Network protocols what are they (2/2)
  • Networking protocols define
  • a language ( a logical 1 is represented with
    5 VDC, HTML )
  • and a set of rules ( I will only read messages
    addressed to me )
  • and procedures ( every receipt of a message will
    be acknowledged, except the ACK-msg itself )
  • that enable devices / systems / applications to
    communicate
  • In the context of the OSI Reference Model, a
    protocol is formally defined as a set of rules
    governing communication between entities at the
    same layer
  • In the context of the TCP/IP model, a protocol is
    loosely defined as being similar to a
    communication service

10
Network layers the OSI approach (1/2)
  • Principle of abstraction
  • Define services on a functional level, not how it
    is implemented
  • Protocols are therefore transparent to higher
    layers
  • OSI's major contribution to networking theory is
    in its distinct separation between three
    fundamental concepts
  • Services A service defines what a layer does,
    but abstracts the details of implementation from
    higher levels in the protocol stack.
  • Interfaces The interface makes the layer
    available to higher layers. It defines the
    conventions of communication - what to send and
    what to expect, but also does not deal with
    implementation details.
  • Protocols These are private methods of
    implementation which the higher layers have no
    access to or knowledge of. Thus, they can be
    changed (i.e. to allow adding support for new or
    improved technology) without compromising
    integrity (i.e. altering the basic functioning of
    higher layers).
  • ex. a postoffice
  • Do you know how your letter is routed, by what
    vehicles and at what time, from the mailbox to
    grandmothers home?
  • Do you need to know?
  • Do you want to know?

11
Network layers the OSI approach (2/2)
  • Principle of abstraction was a good idea, and
    still is!
  • Unfortunately
  • the designers of the OSI model built the
    reference model before the protocols existed
  • and did not understand from an engineering
    perspective where various pieces would optimally
    fit
  • and had to deal with politics (IBMs SNA model)
  • Hence the OSI Reference Model should be
    considered as
  • an excellent educational tool, which terminology
    is widely-used to describe behavior and design of
    networks
  • a crappy communication stack that you don't,
    really don't, want to implement as such!

!! Never, ever try to completely fit actual
protocols to the OSI layers !! ? use OSI as a
model, not as a factual reality
12
Network layers the TCP/IP approach (1/2)
It does what it needs to do interconnect, and
thats all there is to it. It provides barebone
functionality as required by that moment and
there are no provisions for future use. And
thats already complex enough!
  • TCP/IP represents the factual reality
  • with the objective to provide internetworking
  • i.e. glueing inherently incompatible networks
    together
  • TCP/IP major contribution was that it was
    engineered, meaning
  • it simply described the existing situation from
    an engineer's perspective and gave little thought
    to ensuring the model made sense
  • it is pragmatic relatively simple
  • it was required to be open
  • it was for free and since it worked it became
    succesful

13
Network layers the TCP/IP approach (2/2)
ex. mailbox Mailbox has got 2 entrances, one for
local mail and one for non-local mail. You
need to know the scope of local
  • t was nice TCP/IP actually worked, and still
    does!
  • Unfortunately, it only speaks its own language,
    i.e.
  • common problems are not solved by a generic
    foundation
  • protocols are not really transparent
  • can't be used to intelligently describe another
    type of protocol stack
  • Hence the TCP/IP reference model should be
    considered as
  • an incomplete, best-effort to provide an
    (inter)networking solution that, without any
    guarantees, actually works out quite nicely most
    of the times
  • really very difficult to explain how it's working
    in the first place

ex. experts disagree on whether TCP/IP should be
modelled with 2, 4 or 5 layers. ex. internet is
TCP/IP need I say more?
14
Network layers the OSI stack (1/2)
application
email
Service interfaces
15
Network layers the OSI stack (2/2)
  • Each layer prepends protocol-specificcontrol
    information to the data
  • The combined data control informationis
    considered the next layers data
  • That data is offered to the service interface
  • Data transfer is therefore vertical
  • Protocols communicate horizontal(through
    protocol-specific control information)

16
Network layers the TCP/IP stack (1/2)
  • Similar services exist at different layers, ex.
    Address translation by DNS ARP
  • Interconnection of multiple networks
  • No formal or informal agreement about mapping of
    OSI TCP/IP stacks can be found in literature
  • TCP connection-oriented
  • UDP connection-less

17
Network layers the TCP/IP stack (2/2)
18
Network layers connected hosts
medium
medium
medium
19
2. Network buzz words
  • Connectionless connection-oriented
  • Circuit-switched packet-switched
  • Unicast / broadcast / multicast / anycast /
    point-2-point
  • Network segmentation

20
Connectionless connection-oriented
21
Packet-switched circuit-switched (1/2)
22
Packet-switched circuit-switched (2/2)
23
Connections versus circuits
  • A Connection is a logical thing whilst a circuit
    is a physical thing
  • A connection implies peers are conscious of
    having established a communication, a circuit
    implies a physical route on layer 2
  • ex. BBC radio broadcast connectionless over
    circuit
  • A circuit is not a prerequisite for a connection
  • Connection-oriented protocols will be used over
    packet-switched networks when applications
    require a connection.

24
Transmission methods (1/3)
  • Unicast 1-to-1
  • Multicast 1-to-many
  • Broadcast 1 to all

25
Transmission methods (2/3)
  • Unicast
  • Messages that are sent from one device to another
    device they are not intended for others
  • Eavesdropping! Unicast doesn't guarantee that
    others won't also read it, just that they
    normally will not do so
  • This is the most common type of messaging, so
    this addressing capability is present in almost
    all protocols
  • Broadcast
  • These messages are sent to every device on a
    network
  • Used for a variety of purposes, including finding
    the locations of particular stations or the
    devices that manage different services
  • Broadcasts are normally implemented via a special
    address that is reserved for that function

26
Transmission methods (3/3)
  • Multicast
  • Messages are sent to a group of stations that
    meet a particular set of criteria
  • The most complex type of message because they
    require a means of identifying a set of specific
    devices to receive a message
  • Anycast
  • A message that should be sent to the closest
    member of a group of devices
  • IPv6 only
  • Point to point
  • Only two devices are connected together
    everything sent by one device is implicitly
    intended for the other, and vice-versa
  • Thus, no addressing of messages on a
    point-to-point link is strictly necessary
  • ex. RS-232 protocol

27
Network segmentation (1/2)
  • subnetwork (subnet)
  • A subnetwork is a portion of a network or a
    network that is part of a larger internetwork
  • The abbreviated term subnet also has a specific
    meaning in the context of TCP/IP addressing
  • Segment (Network Segment)
  • A segment is a small section of a network
  • In some contexts, a segment is the same as a
    subnetwork
  • More often it implies something smaller than a
    subnetwork
  • Earlier ethernet
  • the coax cable itself was called a segment
  • segment was shared by all devices connected to
    it, it became the collision domain for the
    network
  • Totally unrelated TCP meaning Segment is the
    name of the messages sent in TCP

28
Network segmentation (2/2)
  • Internetwork (or Internet)
  • refers to a larger networking structure that is
    formed by connecting together smaller ones
  • In others, a network is differentiated from an
    internetwork based on how the devices are
    connected together
  • where a network usually refers to a collection of
    machines that are linked at layer two of the OSI
    Reference Model
  • using technologies like Ethernet or Token Ring
  • and interconnection devices such as hubs and
    switches
  • An internetwork is formed when these networks are
    linked together at layer three using routers that
    pass Internet Protocol datagrams between networks
  • intranet vs. extranet
  • intranet internal network that uses TCP/IP
    technologies
  • extranet is an intranet that is extended to
    individuals or organizations outside the company
    boundaries

29
3. Network topology
  • Line daisy chain
  • Ring is Line with identical start end point
  • Mesh no particular structure, either partial or
    Fully Connected
  • Bus implies single shared medium (ex. ether)
  • Tree Extended Star
  • Hybrids

30
Network topologies types (1/3)
  • LineAlso known as Daisy Chain, data hops from
    one node to another
  • Increases latency
  • Easiest way to add nodes
  • Node or line failure results in network failure
  • Limited data collision (only with single line
    half-duplex mode, only between adjacent nodes)
  • Needs double line for full-duplex
  • RingEach of the nodes is connected to two other
    nodes, similar to Line topology, however
  • with the first and last nodes being connected to
    each other, forming a ring
  • data generally flows in a single direction only
    (dual-ring in two directions)
  • Dual rings are less susceptible to node or line
    failures

31
Network topologies types (2/3)
  • StarConnects all cables to a central point of
    concentration, usually a hub or switch. Nodes
    communicate across the network by passing data
    through the hub.
  • Less susceptible for network failure
  • Central node is SPOF
  • Extended star or tree connect central nodes of
    more stars together
  • Many nodes can be connected using few hops and
    thus low latency
  • BusAll nodes are connected to a common
    transmission medium which has exactly two
    endpoints.
  • data is received by all nodes in the network
    virtually simultaneously
  • very susceptible for data collisions
  • Bus endpoints need proper termination (echo
    induced collisions)

32
Network topologies types (3/3)
  • MeshAt least two nodes with two or more paths
    between them to provide redundant paths
  • Decentralised as opposed to stars
  • Implicit redundancy provides higher network
    reliability
  • Fewer hops between nodes (and hence lower
    latency) implies complexer connections, up to
    full mesh (i.e. (n-1)! connections)
  • Multiple paths also implies path ambiguity

33
Network topologies 3 levels of abstraction
  • Physical level topologies
  • Nodes of a network and the physical connections
    between them
  • The layout of wiring, cables,
  • The locations of nodes, and the interconnections
    between the nodes
  • Level 1 abstraction
  • (Signal level topologies)
  • The path that the signals take when propagating
    between the nodes
  • Consider this equal to Logical Level Topologies
  • Logical level topologies
  • Level 2 and up abstraction
  • The path that the data takes between nodes
  • Logical topologies are able to be dynamically
    reconfigured by special types of equipment such
    as routers and switches
  • The logical topologies are generally determined
    by network protocols as opposed to being
    determined by the physical layout

34
4. Network equipment
  • Devices
  • Wired wireless media
  • Power over ethernet
  • Structured cabling

35
Network equipment devices (1/2)
  • Repeater Hub layer 1
  • segment (length) extension by signal
    strengthening Ethernet up to 5 segments
    between 2 hosts
  • signal in signal out
  • identical speed over all segments
  • collision repeater by jamming signal
  • cable breakage less dramatic (results in 2
    operational, distinct networks)
  • Switch layer 2 "switched ethernet"
  • isolate physical layer (packet errors
    collisions to segment only)
  • Learn location of devices (MAC addresses)
  • various speeds, more optimal bandwidth usage

36
Network equipment devices (2/2)
  • Bridge layer 2
  • Provides switch functionality, and
  • Layer 2 protocol translator (ethernet lt-gt
    bluetooth)
  • Creates logical network from individual physical
    segments
  • Router Layer 3
  • Layer 3 protocol implementation translation
  • performs routing based upon protocol
    prescriptions
  • Gateway Layer 4 and above
  • Protocol implementation translation above layer
    3
  • Interconnects end-to-end systems with varying
    protocols

37
Network equipment Media (1/2)
  • Wired media
  • Don't take it for granted
  • impedance signal distortian and length
  • terminators and reflections
  • environmental mutual interference
  • Available wired media
  • Twisted pair
  • Coaxial
  • Fiber
  • Power lines

38
Network equipment Media (2/2)
  • Wireless media
  • Radio frequency (RF)
  • Differ in frequency transmission speed
  • Differ in bandwidth available channels
  • Differ in emmitted power distance
  • Highly regulated
  • Some radiobands are very crowded (WLAN, GSM)
  • Infrared (IR)
  • Requires line of sight
  • Restricted to Point-to-point
  • Hardly used

39
Network equipment Power over ethernet
  • Not to be confused with ethernet over power / PLC
  • Powering network devices through ethernet cables
  • Defined as IEEE standard 802.3af
  • 48 VDC / 400 mA / 15.4 W max
  • powered pairs may also carry data
  • Extension to the standard IEEE 802.3at
  • All pairs may carry power
  • Provide up to 56 watts of power

40
Network equipment Structured cabling (1/2)
  • Defined by Telecommunication Industry Association
    (TIA) as TIA-942
  • Telecommunications Infrastructure Standards for
    Data Centers, april 2005
  • Defines
  • Site space layout requirements to buildings
  • Cabling infrastructure standards for
    terminology physical organisation
  • Tiered Reliability standards for achieving 4
    levels of availability
  • Environmental considerations a.o. power heat
    dissimination

41
Network equipment Structured cabling (2/2)
  • Cabling infrastructure defines
  • Entrance Facilities is where the building
    interfaces with the outside world.
  • Equipment Rooms host equipment which serves the
    users inside the building.
  • Telecommunications Rooms are where various
    telecommunications and data equipment resides,
    connecting the backbone and horizontal cabling
    sub-systems.
  • Backbone Cabling as the name suggests carries the
    signals between the entrance facilities,
    equipment rooms and telecommunications rooms.
  • Horizontal Cabling is the wiring from
    telecommunications rooms to the individual
    outlets on the floor.
  • Work-Area Components connect end-user equipment
    to the outlets of the horizontal cabling system.
Write a Comment
User Comments (0)
About PowerShow.com
