Interface Design Compute Memory Timing

1
Interface DesignComputeMemory Timing

• Omid Fatemi
• (omid_at_fatemi.net)

2
Outline

• Connecting to micro-processor
• Timing of microprocessor
• Timing of memory
• Interfacing memory

3
Typical Interface Design
Connect
Sense Reality Touch Reality Connect Transform
Embedded Systems Micros Assembler,
C Real-Time Memory Peripherals Timers DMA
Busses Protocols Standards PCI IEEE488 SCSI USB
FireWire CAN
PC interfaces HCI
4
Processor Timing Diagramfor any memory read
machine cycle
5
Processor Timing Diagramfor any memory write
machine cycle
6
When interfacing memory chips to a
microprocessor, consider the following

• TAVDV address access time
• TRLDV read access time
• TDVWH memory setup time
• TWHDX data hold time
• TWLWH write pulse width
• Refer to 8088 data manual

7
Address Access Time (TAVDV)
8
Timing Requirements during Memory Read

• TAVDV
• 3TCLCL TCLAV TDVCL
• Address Access Time
• from Address is Valid to Data is Valid

9
Read Access Time (TRLDV)
10
Timing Requirements during Memory Read

• TRLDV
• 2TCLCL TCLRL TDVCL
• Read Access Time
• from Read Signal is Low to Data is Valid

11
Memory Setup Time (TDVWH)
12
Timing Requirements during Memory Write

• TDVWH
• 2TCLCL TCLDV TCVCTX
• Memory Setup Time
• from Data is Valid to Write Signal is High

13
Data Hold Time (TWHDX)
14
Timing Requirements during Memory Write

• TWHDX
• TCLCH X
• Data Hold Time (after WR)
• from Write Signal is High to Data is Invalid
  (Inactive)

15
Write Pulse Width / Write-Time (TWLWH)
16
Timing Requirements during Memory Write

• TWLWH
• 2TCLCL Y
• Write Pulse Width / Write-Time
• from Write Signal is Low to Write Signal is High

17
8088 MINIMUM COMPLEXITY SYSTEM TIMING
REQUIREMENTS
18
Computation of Timing Requirements for 8088 using
a 4Mhz Clock

• TAVDV
• 3TCLCL TCLAVmax TDVCLmin
• 3(250 ns) 110 ns 30 ns
• 610 ns
• TRLDV
• 2TCLCL TCLRLmax TDVCLmin
• 3(250 ns) 165 ns 30 ns
• 555 ns

19
8088 MINIMUM COMPLEXITY SYSTEM TIMING
REQUIREMENTS
20
Computation of Timing Requirements for 8088 using
a 4Mhz Clock

• TDVWH
• 2TCLCL TCLDVmax TCVCTXmin
• 2(250 ns) 110 ns 10 ns
• 400 ns
• TWHDX
• TCLCH X
• 118 ns 30 ns
• 88 ns
• TWLWH
• 2TCLCL Y
• 2(250 ns) 60 ns
• 440 ns

21
Timing Requirements for 8088 using a 4Mhz Clock

• TAVDV 610 ns
• TRLDV 555 ns
• TDVWH 400 ns
• TWHDX 88 ns
• TWLWH 440 ns

22
Can we interface a 6264 to the 8088 chip which
uses a 4MHz clock?
23
Timing Requirements for 6264 SRAM

• TAVDV ?
• TRLDV ?
• TDVWH ?
• TWHDX ?
• TWLWH ?

24
HM6264B Series Read TIMING REQUIREMENTS
Chip deselection in to output in
0

30

0

35

ns

HZ2

high
-
Z (CS2)

t
Output disable to output in high
-
Z

0

30

0

35

ns

OHZ

t
Output hold from address change

10


10


ns

OH


25
HM6264B Series Write TIMING REQUIREMENTS
26
HM6264B Series Read Timing Diagram
27
HM6264B Series Write Timing Diagram
28
Timing Requirements for 6264 SRAM

• TAVDV tAA
• TRLDV tOE
• TDVWH tDW
• TWHDX tDH
• TWLWH tWP

29
Timing Requirements for HM6264B-8L

• TAVDV tAA ?
• TRLDV tOE ?
• TDVWH tDW ?
• TWHDX tDH ?
• TWLWH tWP ?

30
HM6264B Series Read TIMING REQUIREMENTS
31
HM6264B Series Write TIMING REQUIREMENTS
32
Timing Requirements for HM6264B-8L

• TAVDV tAA 85 ns
• TRLDV tOE 45 ns
• TDVWH tDW 40 ns
• TWHDX tDH 0 ns
• TWLWH tWP 55 ns

33
Comparing Timing Requirements of 8088 (using 4
Mhz clock) and HM6264B-8L
34
Can we interface a 2764 to the 8088 chip which
uses a 4MHz clock?
35
Timing Requirements for 2764 EPROM

• TAVDV ?
• TRLDV ?
• TDVWH ?
• TWHDX ?
• TWLWH ?

36
M2764A Read Mode AC Characteristics
37
M2764A Read Mode Timing Diagram
38
Timing Requirements for 2764 EPROM

• TAVDV tAVQV
• TRLDV tGLQV
• TDVWH N/A
• TWHDX N/A
• TWLWH N/A

39
Timing Requirements for 2764 EPROM

• TAVDV tAVQV ?
• TRLDV tGLQV ?
• TDVWH N/A
• TWHDX N/A
• TWLWH N/A

40
M2764A Read Mode AC Characteristics
41
Timing Requirements for M2764A-3

• TAVDV tAVQV 180 ns
• TRLDV tGLQV 65 ns
• TDVWH N/A
• TWHDX N/A
• TWLWH N/A

42
Comparing Timing Requirements of 8088 (using 4
Mhz clock) and M2764A-3
43
What if we need to interface a slow memory to
the 8088?
44
Comparing Timing Requirements of 8088 (using 4
Mhz clock) and a certain slow memory chip
45
(No Transcript)
46
RecallWrite Pulse Width / Write-Time (TWLWH)
47
Write Pulse Width / Write-Time (TWLWH) w/ 1 wait
state
48
Comparing Timing Requirements of 8088 (using 4
Mhz clock) and a certain memory chip
caused by 1 wait state during a memory write on
the slow memory chip
49
How do we produce a wait state?

• By turning the READY input of the 8088
  microprocessor to LOW

50
(No Transcript)
51
Requirements for the READY input of the 8088
52
Requirements for the RDY of the 8284
53
(No Transcript)
54
(No Transcript)
