Title: Daniel Amyot


1
UCM Scenarios andPath Traversal
  • Daniel Amyot
  • damyot_at_site.uottawa.ca
  • SG17, Geneva, March 5th, 2002

2
Objectives
  • Introduce scenario definitions
  • Illustrate one possible path traversal mechanism
  • Illustrate the generation of MSCs from UCMs
  • Present current collection of requirements and
    point out general issues which need to be resolved

3
Scenario Definitions
  • Enhances the behavioral modeling capability of
    UCM paths and path elements
  • Requires a path data model (for conditions at
    various points along the path)
  • Currently, global and modifiable Boolean
    variables
  • Values may be assigned to variables along a path,
    in responsibilities
  • Could be considered
  • Variables may possibly have different types
    (integers)
  • Variables may be scoped to paths or components
  • Scenarios may be structured into sub-scenarios

4
Path Data Model - DTD
  • lt!ELEMENT path-variable-list (boolean-variable)gt
  • lt!ELEMENT boolean-variable EMPTY gt
  • lt!ATTLIST boolean-variable
  • name NMTOKEN REQUIRED
  • boolvar-id ID REQUIRED
  • ref-count NMTOKEN REQUIRED
    gt
  • lt!ELEMENT variable-operation-list
    (variable-operation)gt
  • lt!ELEMENT variable-operation EMPTY gt
  • lt!ATTLIST variable-operation
  • variable-id IDREF REQUIRED
  • value CDATA REQUIRED
    gt

5
Scenario Definitions
  • Requires a more formal definition of some
    notational elements
  • Currently, logical expressions with global
    variables
  • Currently, OR forks, selection policies, start
    points, waiting places, timers covered
  • Scenario definitions consist of
  • Name of scenario (scenarios may be grouped)
  • Set of concurrent start points
  • Set of initial values assigned to global
    variables
  • Postcondition, expressed as a logical expression

6
Scenario Definitions - DTD
  • lt!ELEMENT scenario-list (scenario-group) gt
  • lt!ELEMENT scenario-group (scenario-definition) gt
  • lt!ATTLIST scenario-group
  • name NMTOKEN REQUIRED
  • description CDATA IMPLIED gt
  • lt!ELEMENT scenario-definition ((scenario-start),
  • (variable-init),
    (postcondition)) gt
  • lt!ATTLIST scenario-definition
  • name NMTOKEN REQUIRED
  • description CDATA IMPLIED gt
  • lt!ELEMENT scenario-start EMPTY gt
  • lt!ATTLIST scenario-start
  • map-id IDREF REQUIRED
  • start-id IDREF REQUIRED
    gt
  • lt!ELEMENT variable-init EMPTY gt
  • lt!ATTLIST variable-init
  • variable-id IDREF REQUIRED
  • value (TF) REQUIRED
    gt
  • lt!ELEMENT postcondition EMPTY gt

7
Scenario Highlight (UCMNAV 2)
Example
8
Key Points - Scenario Definitions
  • Path data model is not a problem domain data
    model
  • Improves understanding of scenarios
  • Scenario definitions are the foundation for more
    advanced functionality based on UCM path
    traversal mechanisms

9
UCM Path Traversal
  • Starts at one or more parallel start points as
    defined by user
  • Starts with initial values (true, false, or
    undetermined) for each path data variable as
    defined by the user
  • Moves from path element A to path element B if
    continuation criteria are met for element A
  • Each UCM path element has specific criteria
  • Issues a warning if path traversal is stuck

10
UCM Path Traversal - Example I
?
?
?
?
A
R
A,1
3
2
5
4,?
5,?
,7,R
,6,?
3,?
11
UCM Path Traversal - Example II
?
B
S
3
A
R
5
B
?
A,1
2
7,?
4,?
5,?
3,R
,8,S
B,6,?
12
Example
User
Elevator Control System
down
not requested
up
already on list
down
moving
motor up
select elevator
door close
at floor
on list
OnList
decide on direction
below
motor down
above
else
stationary- memory
requested
in elevator
add to list
motor stop
door open
door closing-delay
remove from list
at requested floor
Arrival Sensor
Service Personnel
switch on
approaching floor
13
Example
User
Elevator Control System
down
not requested
up
already on list
switch on
moving
motor up
select elevator
above
door close
at floor
app. floor
on list
decide on direction
app. floor
below
motor down
above
app. floor
else
switch off
stationary- memory
requested
!OnList
in elevator
add to list
motor stop
Up
!Requested
door open
!Requested
door closing-delay
Requested
remove from list
at requested floor
Arrival Sensor
Service Personnel
switch on
approaching floor
14
Applications of UCM Path Traversal
  • Highlighting
  • Animation
  • Requires sequence numbers
  • MSC generation
  • Requires component information
  • Well-nestedness transformation and warning
    mechanism
  • LQN generation
  • Requires arrival and device characteristics,
    device demands, data access modes, response-time
    requirements
  • Test case generation
  • Requires controllable and observable activities

15
Path Traversal Requirements (1)
  1. Path Traversal shall start at 1 to N parallel
    scenario start points as defined by the user
    (scenario-start).
  2. Path Traversal shall start with initial values
    (true, false, or undetermined) for each path data
    variable as defined by the user (variable-init).
  3. Path Traversal shall move from path element A to
    path element B if a) Path Traversal is
    currently visiting path element A, and b) there
    is a direct connection from A to B
    (hyperedge-connection), and c) the path
    continuation condition of path element A to path
    element B is fulfilled.
  4. The path continuation condition for a start point
    shall be fulfilled if the logical expression for
    its guard evaluates to true (logical-condition of
    start).
  5. The path continuation condition for end points
    not directly connected to waiting places or
    timers shall be always fulfilled.
  6. The path continuation condition for a
    responsibility shall be always fulfilled.
  7. The path continuation condition for an OR-fork
    shall be fulfilled if the path continuation
    condition of exactly one branch of the OR-fork is
    fulfilled.
  8. The path continuation condition for a branch of
    an OR-fork shall be fulfilled if the logical
    expression for the branch evaluates to true
    (branch-condition of path-branching-characteristic
    ).
  9. The path continuation condition for an OR-join
    shall be always fulfilled.
  10. The path continuation condition for each branch
    of an AND-fork shall be always fulfilled.
  11. The path continuation condition for an AND-join
    shall be fulfilled if Path Traversal is currently
    visiting the AND-join for all of its incoming
    paths.

16
Path Traversal Requirements (2)
  1. The path continuation condition for a loop shall
    be fulfilled if the path continuation condition
    of exactly one branch is fulfilled (either the
    loop branch or the exit branch).
  2. The path continuation condition for the loop
    branch shall be fulfilled if the logical
    expression for the loop exit evaluates to false
    (exit-condition of loop).
  3. The path continuation condition for the exit
    branch shall be fulfilled if the logical
    expression for the loop exit evaluates to true
    (exit-condition of loop).
  4. The path continuation condition for a static stub
    shall be always fulfilled.
  5. The path continuation condition for a dynamic
    stub shall be fulfilled if the path continuation
    condition of exactly one plug-in of the dynamic
    stub is fulfilled.
  6. The path continuation condition for a plug-in of
    a dynamic stub shall be fulfilled if the logical
    expression for the selection policy of the
    plug-in evaluates to true (branch-condition of
    plug-in-binding).
  7. The path continuation condition for an end point
    and a waiting place connected directly with each
    other shall be fulfilled if a) Path Traversal is
    currently visiting the end point and the waiting
    place and b) the logical expression for the
    guard of the waiting place evaluates to true
    (logical-condition of waiting-place).
  8. The path continuation condition for a waiting
    place shall be fulfilled if the logical
    expression for its guard evaluates to true
    (logical-condition of waiting-place).

17
Path Traversal Requirements (3)
  1. The path continuation condition for an end point
    and a timer connected directly with each other
    shall be fulfilled if a) Path Traversal is
    currently visiting the end point and the timer
    and b) the path continuation condition for the
    non-timeout path of the timer is
    fulfilled.
  2. The path continuation condition for a timer shall
    be fulfilled if exactly one of the following
    cases occurs a) The path continuation condition
    for the non-timeout path is fulfilled. b) The
    path continuation condition for the timeout path
    is fulfilled.
  3. The path continuation condition for a non-timeout
    path shall be fulfilled if a) the timers
    timeout variable is set to false
    (timeout-variable of
    waiting-place) and b) the timers guard
    evaluates to true (logical-condition of
    waiting-place).
  4. The path continuation condition for a timeout
    path shall be fulfilled if a) the timers
    timeout variable is set to true (timeout-variable
    of waiting-place) and b) a
    timeout path exists for the timer.
  5. The path continuation condition for an empty
    point shall be always fulfilled.

18
Path Traversal Requirements (4)
  1. Path Traversal shall execute the value assignment
    statements of a responsibility (variable-operation
    -list) if the path continuation condition for the
    responsibility is fulfilled.
  2. Path Traversal shall execute the value assignment
    statements of a responsibility in the order
    defined by the user.
  3. Path Traversal shall update the values of the
    path data variables immediately after executing
    one value assignment statement.
  4. Path Traversal shall evaluate a logical
    expression to undetermined if any value within
    the logical expression evaluates to undetermined.
  5. Path Traversal shall stop if it cannot move to
    another path element from any of the currently
    visited path elements.
  6. Path Traversal shall regard the values of the
    path variables at the time path traversal stopped
    as postconditions of the traversed scenario.
  7. Path Traversal shall issue a warning if Path
    Traversal has stopped, and a) Path Traversal is
    currently visiting one or more path elements
    other than end points or b) Path
    Traversal is currently visiting one or more end
    points connected directly to
    waiting places or timers or c) the
    postconditions of the traversed scenario do not
    match the postconditions defined
    by the user.

19
UCM Path Traversal Issues
  • Component and plug-in instances
  • Is a component a new instance or does it
    reference an existing component on the same or
    another map?
  • If path traversal visits a plug-in map more than
    once, is it visiting the same plug-in or a new
    instance?
  • If the plug-in is a new instance, the path
    segment on the plug-in map is also a new instance
    but components on the plug-in map may not
    necessarily be new instances
  • Loops
  • Suggested path traversal mechanism may be able to
    deal with loops
  • For which applications do loops have to be
    preserved?
  • Do we need integers?
  • Multiple triggering of the same event (start
    point)
  • Other elements not covered
  • aborts, asynchronous interactions, and dynamic
    responsibilities

20
Key Points - UCM Path Traversal
  • Many correct path traversal mechanisms exist
    because of breadth-first and depth-first
    approaches and various ways of dealing with
    concurrency
  • Path traversal is instrumental for advanced
    functionality such as highlighting, animation, as
    well as the generation of MSC, LQN, and test
    cases
  • The biggest open issues for path traversal
    revolve around component plug-in instances as
    well as loops

21
Generation of MSCs
  • UCMs are good for (Stage 1)
  • Describing multiple scenarios abstractly
  • For analysing architectural alternatives
  • MSC Sequence Diagrams are better for (Stage 2)
  • Developing and presenting the details of
    interactions
  • Describing lengthy sequences of messages in
    scenarios
  • Providing access to well-developed methodologies
    and tools for analysis and synthesis
  • UCM-to-MSC transformation helps to further bridge
    the gap between Stage 1 descriptions
    (require-ments) and Stage 2 descriptions (design).

Stage 1 Requirements and Service Description,
Stage 2 Message Sequence Information
22
Refining UCM with Messages
23
From UCM to MSC
  • UCM component MSC instance
  • UCM path crossing from abstract MSC message
    one component to another (implements
    causal flow)
  • UCM start (or end) point abstract MSC message
  • UCM pre/post-condition MSC condition
  • UCM responsibility MSC action
  • UCM OR-fork or dynamic multiple basic
    MSCsstub with multiple plug-ins
  • UCM AND-fork MSC parallel inline box
  • UCM loop MSC loop box
  • UCM timer MSC timer

24
MSC Generation - Example I
System
A,1
2
4,?
5,?
,6,?
3,?
25
MSC Generation - Example II
System
?

4
8
2
S
5
7
1
A
3
R
6
?
B
26
Why Stop at MSCs?
UCMspec(XML)
RichTrace(XML)
MSC 96
LOTOStest cases
TTCN-3test cases
Performance models
Documentation (ps, pdf, cgm)
27
Key Points - MSC Generation
  • Much value in a tool-supported translation
  • Effortless (push of a button)
  • MSCs in-sync with UCMs, forward traceability
  • Basis for further refinement
  • Synthetic abstract message may be refined into
    more concrete protocol messages
  • Help to bridge the requirements/design gap
  • Requires the path data model, scenario
    specifications, and traversal mechanism
  • Issue (XML) intermediate output, which will be
    post-processed?
Write a Comment
User Comments (0)
About PowerShow.com
