Cache and Caching

1
Cache and Caching

• David Sands
• CS 147 Spring 08
• Dr. Sin-Min Lee

2
The Cache

• Faster memory access times.
• Remembering frequently accessed data.
• Block of memory for temporary storage or indexing.

3
What are Pages?

• Not made of paper
• Just a block of data being accessed.
• Memory from disk -gt RAM or container.
• When we are out of page space, what do we do?

4
Page Replacement Algorithms

• Optimal Page Replacement-- swap page that will
  not be used for a while with a page that is about
  to be used.
• First in, First out (FIFO)-- queue
• Second-Chance-- circular queue. If reference
  bit is set, put at last place. If not set, cache
  it.
• Clock-- just like second-chance, but uses a
  hand iterator instead of putting at back of
  queue.

5
More Algorithms
woot

• Not Recently Used -- favors keeping page in
  cache that are recent (keep track of referenced /
  modified)
• Least Recently Used-- assumes new pages in cache
  will be used again in near future. Hard to
  implement.
• Random-- swaps random pages compare to FIFO
  and LRU - fast
• Not Frequently Used-- counter variable for
  uses of a page. Swaps out the underutilized
  pages.
• Aging-- Favoritism for recently referenced
  pages. Priority. Swaps out old pages first.

6
Primitive Example
-- Fetch D then C then B then A from the tree
memory. -- What we access is chained above the
tree into tree-like cache. -- If we do FIFO
algorithm, we replace D if theres no cache space
left.
7
Cache Types

• Memory Cache-- RAM to CPU
• Disk Cache-- Disk to CPU
• Memory, hardware, software, disk, page, and
  virtual memory caches

8
Disk Cache

• Hard disk Buffer ? cache
• The page cache is controlled by the Kernel

9
Other Cache Examples

• DNS daemon mapping IP addresses.
• Web Browser Recently visited website.
• Search Engines popular sites.
• Databases indexing and data dictionary.

10
L1, L2, L3 Cache

• Provides tiers of cache memory
• As memory size and distance from CPU increases,
  access time becomes longer.
• Cost-benefit problem.
• L3 Cache not required, but has larger storage, so
  we like it.

11
L1, L2, L3 Cache (cont.)
?L1 Inside processor chip(like registers)

• L2 Outside processor(can be on motherboard)

? L3 between L2 and main memory
12
Cache Write Policy

• Datum is written to cache
• How do we update the entry in main memory?
• Write through-- if there is a copy in the cache,
  updates the cache data on the fly.-- overloads
  BUS with multiple requests.
• Write back-- Updates the cache data with final
  data only.-- reduces BUS traffic, hides
  inconsistency.

13
Hit or Miss? - searching
Does the desired Tag in the cache memory match an
index in Main memory? -- If so, use the data
from cache- HIT. -- Else, search the main memory
for the data- MISS.
HIT RATIO Percent of accesses that HIT.
14
Miss Rate vs. Cache Size

• 1.00 - Hit Miss

Method of cache mapping to data elements
15
Time Analysis for One L1 Cache

• L1 CacheAvg. Cost rCh (1-r)Cm
• r hit ratio
• Ch L1 cache access time
• Cm memory access time
• This is a probability distribution function.

16
Multiple Cache Analysis

• Just extend the probability function
• L1 and L2 Cache Setup
• Avg. Cost r1Ch1 r2Ch2 (1-r1-r2)Cm
• 1 L1 cache
• 2 L2 cache
• Probability for memory fetch 1-r1-r2

17

• ?

18
