Deriving Classification Rules

1
Deriving Classification Rules
2
The Covering Approach for Deriving Classification
Rules

• The covering algorithm recursively identifies a
  new test to be added to the current rule to
  further improve accuracy.

3
An Example of the Covering Algorithm

• Step 1 If x gt 1.2 then class a.
• Step 2 If x gt 1.2 and ygt2.6 then class a

4
Continue to Derive More Comprehensive Rules

• The rule if xgt1.2 and ygt2.6, then classa
  covers all as but one.
• A new rule if xgt1.4 and ylt2.4, then class A
  may be added to cover all as.

5
The Covering Algorithm

• The covering algorithm operate by adding new
  tests to the rule under construction, always
  striving to create a rule with maximum accuracy.

6
A More Comprehensive Exampleand the Prism
Algorithm

• Assume we want to derive a rule for
  recommendation hard based on the following
  dataset.

7
Insert Table 1.1 on page 4
8
The Candidate Tests and Their Accuracies
ageyoung 2/8
agepre-presbyopic 1/8
agepresbyopic 1/8
spectacle prescriptionmyope 3/12
spectacle prescriptionhypermetrope 1/12
astigmatismno 0/12
astigmatismyes 4/12
tear production ratereduced 0/12
tear production ratenormal 4/12

• Among the 9 candidates, the following two have
  the highest accuracy

9
The First Intermediate Rule

• Assume that we pick astigmatism yes randomly.
  Then, we have the first intermediate rule
• If astigmatism yes,then recommendation hard.
• Now, consider the remaining possible tests in
  order to refine the rule.

10
(No Transcript)
11
Tests to Refine the Intermediate Rule
ageyoung 2/4
agepre-presbyopic 1/4
agepresbyopic 1/4
spectacle prescriptionmyope 3/6
spectacle prescriptionhypermetrope 1/6
tear production ratereduced 0/6
tear production ratenormal 4/6

• The test tear production rate normal is the
  apparent winner.
• Hence, the intermediate rule becomes
• If astigmatism yesand tear production rate
  normal,then recommendation hard.

12
Insert Table 4.9 on page 102
13
More Tests to Get the Perfect Rule
ageyoung 2/4
agepre-presbyopic 1/2
agepresbyopic 1/2
spectacle prescriptionmyope 3/3
spectacle prescriptionhypermetrope 1/3

• We may include test spectacle prescription
  myope to get a perfect rule.
• The rule now is
• If astigmatism yesand tear production rate
  normaland spectacle prescription myope,then
  recommendation hard.

14
Deriving More Rules to Get 100 Coverage

• The rule that we just derived covers 3 out of 4
  instances that have recommendation hard.
• Therefore, we delete these 3 instances and start
  the process over again.

15
The Complete Rules List for Recommendation Hard

• Eventually, we will get the following list of
  rules
• If astigmatism yesand tear production rate
  normaland spectacle prescription myope,then
  recommendation hard.
• If age youngand astigmatism yesand tear
  production rate normal,then recommendation
  hard.

16
An Example of Overfitting

• Assume that we have derived the following rule.
• If A B C, then Ans yes.
• Further assume that
• 20 training sample pass condition A B and 17 of
  them give yes answer.
• 10 training sample pass condition A B C and 9
  of them give yes answer.

17

• The pessimistic error rates of (1) and (2) under
  the 95 confidence level are
• There fore, we may remove condition C from the
  rule.

18

• Similarly, we can apply the chi-square test. The
  corresponding contingency table is as follows.
• Therefore, condition C should be deleted from the
  rule.

19
Final Remarks on Decision Trees and Decision Rules

• Given a decision tree, we can derive a set of
  decision rules based on the decision tree.
  However, sometimes, it is impossible to do the
  reverse derivation.
• The derivation of a single decision rule focuses
  more on precision rather than the recall rate.

20

• We have used 3 different measures in evaluating
  the effectiveness of a decision among many more
  that have been proposed in literatures.
• Information gain
• Chi-square statistic
• Accuracy.
• How these measures compare is subject to the
  characteristics of the data set and the goal of
  the application.
