Image Encryption

1
Image Encryption

• Kane Iverson
• John Vreugdenhil SD0807

Advisors Rajesh Kavaserri Rajendra Katti
2
Introduction

• Encryption - The process of transforming
  information (plaintext) using an
  algorithm (called a cipher) to make it unreadable
  to anyone except those possessing
  special knowledge, usually referred to as a key.
• Why do we need Image Encryption?
• To safely and securely transfer images for the
  following uses
• 1.) Military
• 2.) Health Care
• 3.) Mapping and Positioning
• 4.) Picture messaging on Cell Phones
• 5.) Privacy
• 6.) Government Documents

3
Requirements

• Project Requirements
• 1.) Project must be capable to encrypt/decrypt
  images
• 2.) Project must incorporate pseudo random
  number generation into cipher
• 3.) Each pixel in the original image must have
  its value changed
• 4.) Each pixel in the original image must have
  its position changed
• 5.) Project must be capable to work on
  grayscale
• 6.) Have good background on existing image
  encryption systems
• 7.) Project should be resistant to
  chosen-plaintext attacks
• 8.) Project should be implemented using a
  programmable language
• 9.) Minimize non-uniformity in the cipher
  images
• 10.) Minimize pixel correlation within the
  plain image

4
ENCRYPTION (General)
5
Hacking The Cipher

• Mask Method
• The Mask Method takes advantage of the fact that
  most ciphers use the Boolean operation of XORING
  to break the cipher.
• Process
• 1.) You need to create a mask. To do this, you
  need to XOR an encrypted image with a
• plain-text image.
• 2.) You then need to XOR the mask with another
  encrypted image and you should be able to
  recover the original image.
• Creating the Mask

XOR

Encrypted
Mask
Plain
6
Importing Image Into MATLAB

• In order to import images in to MATLAB we used
  the following function
• Image imread()
• This function reads in the desired image as a
  Xdist by Ydist by 3 matrix with the elements
  being integers represented by 8-bit binary
  numbers.
• The read in image was a color image. To convert
  the image to a Xdist by Ydist by 1matrix
  (grayscale) we needed to combine the 3 primary
  colors with each one weighted differently.
• Grayscale(y,x) .2989F(y,x,1)
  .5870F(y,x,2) .1140F(y,x,3)
• This function had to be looped to convert each
  pixel from
• color to grayscale.

7
Pseudorandom Number Generator

• Eventually we will be supplied with a
  replacement from our advisors, but for our
  research and data collected thus far, we have
  used the following
• We used the following function to create a
  sequence of random numbers
• x(n1) u x(n)(1-x(n))
• Note We needed to pick two initial
  conditions for this function
• 1.) x(1) Value between 0 and 1
• 2.) u Value between 3.57 and 4
• Once we had the sequence of random numbers, we
  used an algorithm to take the 24-bit
  representation of the sequence resulting in a
  pseudorandom number sequence composed of 1s and
  0s.
• This binary random number sequence is compiled
  of 12XdistYdist/2 elements.
• Note We reference this sequence as the
  function b.

8
Seeds (8-bit)

• We used our b function to create two Seeds.
• To accomplish this, we sectioned off our b
  function into 8-bit chunks in two different
  ways
• 1.) Seed1(bit(x)) b(24(k-1) x)
• 2.) Seed2(bit(x)) b(24(k-1) 8 x)
• Once we had 8 binary numbers drawn from the b
  function, we multiplied them by the
• corresponding values associated
  with the binary number system and we were left
• with a Seed.
• Ex. Seed1 1128 064 132 116 18
  04 02 11 185
• Using this method, we created XdistYdist/4
  elements for Seed1 and Seed2
• The Seeds then are used as Keys each Seed
  gives you two Keys.

9
D Function

• In order to have a selective process that is
  dependent only on the random number generator, we

• created the D function.
• To do this, we apply weights to two values of
  our b function as following
• D 2b(24(k - 1) j ) b(24(k-1) j 1)
• Thus D can have the following values 0, 1, 2,
  or 3.
• Note The variables j and k are incorporated
  in the for loops containing the
• D function.
• Using the D function, we can now have our
  Cipher more dependent on the random number
  generator.

10
Chaotic Key-Based Algorithm (CKBA)

• Cipher
• Pros
• Very fast to encrypt/decrypt
• Easy to implement
• Cons
• Very easy to break the encryption
• Only uses 4 keys
• Does not reassign pixels to different positions
• Encrypted image is semi-distinguishable

Use the D (b) function to assign each individual
pixel a D value of 0, 1, 2, or 3
The corresponding value of D will determine which
of the four keys the pixel will be XORED with
The entire image will be ran though this process
until the end result is found an encrypted image
11
Chaotic Key-Based Algorithm (CKBA)

• Results
• 1.) The original image read into MATLAB
• 2.) The Encrypted image
• 3.) Recovered image using the Mask Method

3
2
1
12
Random Control Encryption System (RCES)

• Cipher

Runs through the image and swaps adjacent pixels
according to the b function
Generates a separate set of Seeds for each block
of 16 pixels
Breaks the image vector into 16-pixel blocks
Turns the image into a vector
Uses the D function to determine which of the
four Keys for that Seed to be XORED with
Takes the determined Key and XORS it with the
entire 16 pixel block
Generates a separate set of Seeds for each block
of 16 pixels
13
Random Control Encryption Subsystem (RCES)

• Cipher
• Pros
• More complex than the CKBA encryption method
• Encrypted image is non-distinguishable
• Cipher is more dependent on the random number
  generator
• Implements a method to change the position of
  the individual pixels
• Fast encryption/decryption
• Dramatically increases the number of keys used
  from four to XdistYdist/16
• Cons
• Most of the image can be recovered from the Mask
  Method
• When a pixel is moved, it is only moved one spot
  to the right or left
• If you acquired the ciphers code, you could
  create a fixed mask
• Not secure enough due to the lack change in the
  position of a majority of the pixels

14
Random Control Encryption Subsystem (RCES)

• Results
• 1.) Original Plain-text image
• 2.) Encrypted image
• 3.) Second Plain-text image
• (unknown to attacker)
• 4.) Second encrypted image
• 5.) Hacked second image using
• Mask Method
• 6.) Unrecovered pixels by the
• Mask Method
• (8.65)

1
2
3
4
4
5
6
15
Our Proposed Cipher (In Detail)

• Cipher (Step 1)
• Selective Toggling and Shifting of Original
• 1.) First, we created a Look-Up table by
  using Seed1 and Seed2 to create
• a XdistYdist size vector referred
  to as VLT.
• 2.) We then reshaped our Original Image into
  a vector VGF.
• 3.) Next, using for loops, we compared each
  bit of each element of VGF and VLT.
• 4.) Whenever a bit of VLT was a 1, we would
  toggle the corresponding bit
• of VGF and increment a variable
  Shift by one.
• 5.) Once 8-bits were compared, we then
  shifted that 8-bit number Shift times to the
  right.

16
Our Proposed Cipher (Graphical)

• Cipher (Step 1)
• Selective Toggling and Shifting of Original

10001111
"VLT"
Shift 5
11101001
"VGF"
________
01100110
00110011
After Toggle
17
Our Proposed Cipher (In Detail)

• Cipher (Step 2)
• Vector Look-up Table and Temp Pixel XORING
• 1.) First, we create a vector Look-Up VLT2
  (only 255 elements) table using the look-up
  table from the Selective Toggling and Shifting of
  Original Image step and Seed2.
• 2.) Next, we create a Seed-generated Key
  Vector the same size as our Original Image
  Vector IV.
• 3.) We then XOR each element in the VLT2
  and the IV to leave us
• with our Temp Pixel Vector TPV.
• 4.) Now we take 8-bit integer value of each
  element of TPV and XOR it with the
  corresponding element of the VLT2(TPV).

18
Our Proposed Cipher (Graphical)

• Cipher (Step 2)
• Vector Look-up Table and Temp Pixel XORING

10110011
01001110
11111101
Å

Key
Image Pixel
Temp Pixel
253
11111101
11011001
00100100
Å

Element Number
____ ____
255
1
X
......
Vector Look-Up Table
19
Our Proposed Cipher (In Detail)

• Cipher (Step 3)
• Seed1 Shuffle/ Seed2 Shuffle
• 1.) First we reshaped Seed1 and our image
  into vectors.
• 2.) We then rip apart our Image vector into
  two separate vectors, the bit values of the
  Seed1 vector determine how the 8-bit elements of
  our image vector are separated into the two
  sub-vectors.
• 3.) Once we have successfully spilt the image
  vector into two vectors, we then tie them back
  together.
• 4.) Next, we repeat the process once more,
  but this time the Seed2 vector will determine
  how the image vector is split up.

20
Our Proposed Cipher (Graphical)

• Cipher (Step 3)
• Seed1 Shuffle/ Seed2 Shuffle

...1101...
...11101001,10001001,10001011,00000110...
Vector 1
Vector 1
Vector 1
Vector 0
____
________
____
Vector 0
Vector 1
Shuffled Vector
21
Our Proposed Cipher (In Detail)

• Cipher (Step 4)
• D Function Block XORING
• 1.) First, we take our image vector and break
  it into blocks of 16 pixels.
• 2.) Then, we assign four different Seed-based
  Keys to each block. Each Key is mapped to a
  value of the D Function.
• 3.) Next, we use the D Function and the
  head pixel of the block to decide which of the
  four Keys should be XORED with the block.
• 4.) We have also designed a small routine
  that is embedded in this section of code that
  sets a flag whenever D is equal to zero it
  remaps how the Keys relate to the D Function.
• 5.) Block by block, the entire image vector
  is XORED with the Seed generated Keys.

22
Our Proposed Cipher (Graphical)

• Cipher (Step 4)
• D Function Block XORING

Key 1
D0
Key 1
D0
Key 2
D1
Key 2
D1
If D0
Key 3
D2
Key 3
D2
Key 4
D3
Key 4
D3
Å
10111010
________________
_
Block
Head Pixel
Key that is Mapped to Head Pixel's D Value
23
Our Proposed Cipher (In Detail)

• Cipher (Step 5)
• D Function Block Swapping Using Head Pixel
• 1.) With our image still in vector form, we
  create eight 16-element
• vectors.
• 2.) We then loop through the vector image
  recording the D values of the blocks of 16
  pixels until it found two of the same value.
• 3.) Once we found two head pixels with the
  same value, we swapped the two blocks positions
  in the image vector and reset that D values
  counter.
• 4.) This process is continued though the
  entire image vector.
• 5.) While the blocks of pixels aren't being
  moved a large distance relative to the size of
  the image vector (usually only 48-96 pixels), it
  makes a big impact considering that we placed it
  at the end of the Cipher, after all of the Seed
  shuffles.

24
Our Proposed Cipher (Graphical)

• Cipher (Step 5)
• D Function Block Swapping Using Head Pixel

D0
Head Pixel
Block
Image Vector
_
_
_
_
_
_
_
_
_
_
1
9
8
7
6
5
4
3
2
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
D3
D1
D2
D3
Left Unchanged Until Another D3 Head Pixel
_
_
_
_
_
_
_
_
_
_
1
9
8
7
6
5
4
3
2
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
_
Swapped Image Vector
25
Our Proposed Cipher
Results 1.) Original Color 2.) Original
Grayscale 3.) Ciphered Image 4.) Original
Grayscale 5.) Ciphered Image 6.) Mask 7.) 2nd
Ciphered Image 8.) Attack Result 9.) 2nd Original
Grayscale
3
2
1
Å

6
5
4
Å

8
7
6
9
26
Our Proposed Cipher (Results)

• Pros
• Increased complexity
• Resistant to basic chosen-plaintext attacks
• Cipher is more dependent on the Random Number
  Generator
• Dramatically increased how a pixels position is
  changed
• Encrypted image is non-distinguishable
• Attack via Mask Method is non-distinguishable
• Easy to switch out Seeds if needed (New u and
  x(1) values)

• Cons
• Cipher currently takes too long to encrypt
• Vector Look-up Table and Temp Pixel XORING needs
  more work
• Cipher is composed of a lot of steps (Adding to
  time issue)
• Cipher currently only works in grayscale

27
Budget
28
Next Semester

• Things to Do
• Work on Time Issues in code
• Work on Symmetry of Look-Up Table
• Use Cryptanalysis to determine Cipher Security
• Tweak Cipher to Handle Color Images
• Test Each Individual Step of Cipher
• Take Out Non-Efficient Steps of Cipher
• Enable Cipher to Encrypt Images of Varying Sizes
• Make Cipher into Executable File

29
Revised Time Line

• Week1 - Week4 ? Use Cryptanalysis to Determine
  Cipher Security
• Week5 ? Work on Symmetry of Look-Up Table
• Week6 ? Work on Time Issues in Code
• Week7 Week8? Test Each Individual Step of
  Cipher
• Week9 ? Take Out Non-Efficient Steps of Cipher
• Week10 Week12 ? Tweak Cipher to Handle Color
  Images
• Week13 ? Make Cipher into Executable File
• Week14? Clean Up Code and Make Sure Everything is
  Running Smoothly
• Week15 ? Present Project

30
Summary

• Recap CKBA
• Recap RCES
• Recap Our Proposed Cipher
• Whats Left to Do

31
Questions?
????????
