Unicenter NSM Repository Bridge 3.1 -> r11

1
Unicenter NSM Repository Bridge3.1 -gt r11
2
Agenda

• Product Overview / Positioning
• Terminology
• Installation
• Configuration
• Summary

3
Some Background

• Originally Field Developed Code
• First released in 1997 (for TNG 2.1)
• Direct response to Customer requirements
• Already in production at hundreds of sites
• Supported via TNGFDP queue in TCC
• First official GA release in 3.0
• Anything pre-3.0 is still FDP, NOT GA
• Only minor differences between versions
• Update in 3.1 with Linux / Unix support
• Minor changes for R11

4
When is Bridge required

• Federated MDB

5
Unicenter Repository Bridge

• What is it..?!
• World View Application
• NT / W2K and Unix
• Replicates and maintains a policy-defined subset
  of the objects from one Repository to another
• Uses Rules to decide which objects and events
  should be replicated
• Facilitates an n-Tier repository Architecture

A tool for replicating and maintaining a
policy-defined subset of the objects in a Source
Repository to a Destination Repository...
6
What is Bridging..?
Replicate Objects which conform to Bridging
Policy Replicate updates to Properties on Bridged
Objects Delete Objects which no longer conform to
Bridging Policy
Destination MDB
Source MDB
7
Terminology

• Source Repository
• Originating Repository
• Destination Repository
• Target Repository
• Bridge Instance
• Manages the relationship between a Source and
  Destination
• Bridge Configuration
• Source\Destination configuration details
• Determines the data that will be bridged between
  the Source and Destination repository by an
  Instance

8
What does it consist of?

• Bridge Instances
• Implements a Bridge Configuration
• One Instance per Source/Destination pair
• Windows Service / Unix
• Controls Bridge Instance start-up and shutdown
  (during reboot)
• Can control multiple Bridge Instances
• Administrative GUIs
• Configure and control the Bridge Instances

9
Unicenter r11 NSM Install
10
Accessing the Installation
11
Bridge Configuration

• Includes
• Source and Destination repository Details
• Bridging Policy (Rules)
• Logging and Event Configuration
• Start-up and initialisation Options
• Saved as flat ASCII Text File
• Passwords are Encrypted

12
NSM 3.1 CORE Definition
13
NSM 3.1 CORE Definition
14
NSM 3.1 CORE Definition
15
NSM 3.1 CORE Definition
16
Bridge Rule
Bridge 3.1 CORE to r11 Ingres MDB
17
Bridge Rule
Bridge 3.1 Windows 2003 Servers from which are
critical (propagated severity)
18
Displaying 3.1 CORE from r11
This shows 2dmap display NSM 3.1 CORE from r11
setup. Caution This may not be supported
19
R11 MDB display
20
Summary

• TNG Bridge is a powerful tool but is open to
  misuse
• Think carefully about the information required in
  the Destination repository
• Configure instances with efficiency in mind
• Read the documentation but if in doubt, ask.

21
Questions
