CS 241 Section Week

1
CS 241 Section Week 12(04/23/09)
2
Outline

• LMP2 Overview
• Brief intro to Networking
• What is a protocol?
• OSI Model
• TCP/IP Model
• UDP and TCP
• Socket Programming Library Functions
• Hypertext Transfer Protocol

3
LMP2 Overview
4
LMP2 Overview

• LMP2 encodes or decodes a number of files
• It has the following parameters
• the filenames
• the number of bytes (rw_units) for each
  read/write from the file
• But, process files in round robin fashion
• encrypt rw_unit of file1
• encrypt rw_unit of file2
• encrypt rw_unit of file3
• encrypt rw_unit of file1

5
LMP2 Overview

• For the output in 2nd part,
• print in get_frame() will suffice
• you may print in my_munmap.
• Most csil machines, use signed char, whose range
  is from -128 to 127. So use unsigned char if you
  compare with 255.

6
LMP2 Overview

• For N files, -The Table of File-Mappings has
  exactly N entries -The Virtual Page Table has
  enough entries to fit each file's length divided
  by 4096B -The Physical Memory Frame Table has 16
  entries
• Example 3 files of length 3072bytes, 2048bytes,
  and 8192bytes -The Table of File-Mappings has 3
  entries-The Virtual Page Table has
• (3072/4096gt1) (2048/4096gt1) (8192/4096gt2)
  4 entries -The Physical Memory Frame Table has
  16 entries and four of them are filled

7
Brief intro to Networking
8
Networking

• Allows computers and other networked devices to
  talk to each other
• How can we tell what the packet we just received
  means?
• Interactions between applications on different
  machines are governed by protocols
• Protocols dictate the format and sequence of the
  information exchange

9
Names and Addresses

• A network address identifies a specific computer
  on the network
• Several kinds of addresses exist MAC address
  (for LANs), IP address (for the Internet), etc.
• Domain or DNS names are used for convenience, so
  we dont have to remember numerical addresses

10
Ports

• Ports are numbers that represent an end-point for
  communication
• Ports are logical, not physical, entities
• All packets arrive to the same physical
  interface, and are then differentiated based on
  the port number (and other contents of the packet
  header)
• Usually, distinct ports are used for
  communication via different protocols
• E.g., port 80 is for HTTP, 22 is for SSH, etc.
• See /etc/services for a list

11
What is a protocol?
12
What is a protocol?

• It is a formal description of message formats and
  the rules that two computers must follow in order
  to exchange messages.
• This set of rules describes how data is
  transmitted over a network.

13
Why are protocols needed?

• Protocols are needed for communication between
  any two devices.
• In what format will the messages be transmitted?
• At what speed should messages be transmitted?
• What to do if errors take place?
• What to do if parts of a message are lost?

14
Network Model

• What is a model? A hypothetical description of
  a complex entity or process.
• Network model - A method of describing and
  analyzing data communications networks by
  breaking the entire set of communications process
  into a number of layers
• Each layer has a specific function

15
Open Systems Interconnect (OSI) Model

• Who made
• International Standards Organization (ISO)
• A Model of How Protocols and Networking
  Components Could be Made
• Open means the concepts are non-proprietary
  can be used by anyone.
• OSI is not a protocol. It is a model for
  understanding and designing a network
  architecture that is flexible and robust.

16
Network Architecture

• A set of layers and protocols is called a network
  architecture
• It refers to the physical and logical design of a
  network

17
7-layer OSI model

• Why so many layers?
• To reduce complexity, networks are organized as a
  stack of layers, one below the other
• Each layer performs a specific task. It provides
  services to an adjacent layer
• This is similar to the concept of a function in
  programming languages function do a specific
  task

18
The Layers of the OSI Model
19
The Layers of the OSI ModelSome Mnemonics
All People Seem To Need Data Processing
Please Do Not Tell Secret Passwords Anytime
20
Physical layer

• Specifications for the physical components of the
  network
• Bit representation encode bits into electrical
  or optical signals
• Transmission rate the number of bits sent each
  second

21
Data Link Layer

• Responsible for delivery of data between two
  systems on the same network. Main functions are
• Framing divides the stream of bits received from
  network layer into manageable data units called
  frames.
• Physical Addressing add a header to the frame to
  define the physical address of the source and the
  destination machines.

22
Network Layer

• Main functions of this layer are
• Responsible for delivery of packets across
  multiple networks.
• Routing Provide mechanisms to transmit data over
  independent networks that are linked together.

23
Transport Layer

• Main functions of this layer are
• Responsible for source-to-destination delivery of
  the entire message.
• Segmentation and reassembly divide message into
  smaller segments, number them and transmit.
  Reassemble these messages at the receiving end.

24
Session Layer

• Main functions of this layer are
• Dialog control allows two systems to enter into
  a dialog, keep a track of whose turn it is to
  transmit.

25
Presentation Layer

• Responsibilities of this layer are
• Translation since different computers use
  different encoding systems (bit order translation

26
Application Layer

• Contains protocols that allow the users to
  access the network (FTP, HTTP, SMTP, etc)
• DOES NOT include application programs such as
  email, browsers, word processing applications,
  etc.

27
Summary of Functions of Layers
28
TCP/IP Model

• Layers in the TCP/IP model
• Physical Layer
• Data Link Layer (MAC)
• Network Layer (IPv4, IPv6)
• Transport Layer (UDP, TCP)
• Application Layer (HTTP, SSH)

29
Networking

• Each layer is (traditionally) self-contained.
• The data-link layer doesnt care if its running
  IPv4 or IPv6, doesnt care it its TCP or UDP.
• When processing the data-link layer, no other
  layer is (traditionally) considered.

30
Networking
31
Networking

• Data Link Layer
• Purpose To transfer packets in a flat addressing
  space.
• Multiple packets go into a hub.
• The hub bundles packets together to send them
  upstream if necessary, based only on the MAC
  address.
• Not significantly covered in this class.

32
Networking

• Network Layer
• Purpose To transfer packets in a hierarchical
  addressing space.
• Streams of packets go into switches.
• Switches determine if the address is within its
  subnet and will route based on subnets
  (IPv4/IPv6).
• Also, not significantly covered in this class.

33
Networking

• Transport Layer
• After the data link and network layer, packets
  have arrived at the destination computer.
• The transport layer
• Provides port multiplexing, allowing for
  multiple programs all communicate without
  receiving every packet.
• Protocol-specific assurances.

34
UDP

• User Datagram Protocol (UDP)
• The simplest commonly used transport protocol.
• Provides
• Port multiplexing
• Error-checking (via simple checksum)

35
UDP

• User Datagram Protocol (UDP)
• Does NOT provide
• Ordering
• Packet A may be sent before Packet B, but Packet
  B may arrive after Packet A
• Reliability
• The sender has no way to know that Destination
  received some packet sent by Sender (assured by
  retransmissions)
• Flow / Congestion Control
• Theres no mechanism to tweak packet size

36
UDP

• User Datagram Protocol (UDP)
• Only a few parameters are needed for UDP
• Source Port
• Destination Port
• From the network layer (IP), you have two more
  parameters
• Source IP
• Destination IP

37
UDP

• UDP Packet

Source Port
Destination Port
Data Length
Checksum
Data
38
TCP

• Transmission Control Protocol
• TCP provides an alternative to UDP to allow for
  more assurances
• Provides
• Port multiplexing
• Ordered data / no duplicates
• Error-free transmission
• Flow control
• Congestion control

39
TCP

• TCP Packet

Source Port
Destination Port
SEQ Number
ACK Number
Offset / Flags
Window Size
Checksum
Urgent Pointer
Optional Fields
Data
40
Socket Programming
41
Socket

• Standard APIs for sending and receiving data
  across computer networks
• Introduced by BSD operating systems in 1983
• POSIX incorporated 4.3BSD sockets and XTI in 2001
• include ltsys/socket.hgt

42
Typical TCP Server-Client
43
Typical UDP Server-Client
44
Programming Sockets

• Lucky for us, the OS does most the work between
  UDP and TCP!
• TCP Socket
• socket(PF_INET, SOCK_STREAM,
  IPPROTO_TCP)
• UDP Socket
• socket(PF_INET, SOCK_DGRAM, 0)

45
Programming Sockets

• To create a socket in C, you need to run two
  commands
• socket()

46
socket

• int socket(int domain, int type, int protocol)
• Creates a communication endpoint
• Parameters
• domain AF_INET (IPv4)
• type SOCK_STREAM (TCP) or SOCK_DGRAM (UDP)
• protocol 0 (socket chooses the correct protocol
  based on type)
• Returns a nonnegative integer corresponding to a
  socket file descriptor if successful, -1 with
  errno set if unsuccessful

47
Programming Sockets

• To create a socket in C, you need to run two
  commands
• socket()
• bind()

48
bind

• int bind(int socket, const struct sockaddr
  address, socklen_t address_len)
• Associates the socket with a port on your local
  machine
• struct sockaddr_in used for struct sockaddr
• sa_family_t sin_family / AF_INET /
• in_port_t sinport / port number /
• struct in_addr sin_addr / IP address /
• Returns 0 if successful, -1 with errno set if
  unsuccessful

49
Programming Sockets

• Since UDP is packet-based and TCP is
  connection-based, you need to establish a
  connection in TCP
• Server listen(), accept()

50
listen

• int listen(int socket, int backlog)
• Puts the socket into the passive state to accept
  incoming requests
• Internally, it causes the network infrastructure
  to allocate queues to hold pending requests
• backlog number of connections allowed on the
  incoming queue
• bind should be called beforehand
• Returns 0 if successful, -1 with errno set if
  unsuccessful

51
accept

• int accept(int socket, struct sockaddr restrict
  address, socklen_t restrict address_len)
• Accepts the pending requests in the incoming
  queue
• address is used to return the information about
  the client making the connection.
• sin_addr.s_addr holds the Internet address
• listen should be called beforehand
• Returns nonnegative file descriptor corresponding
  to the accepted socket if successful, -1 with
  errno set if unsuccessful

52
Programming Sockets

• Since UDP is packet-based and TCP is
  connection-based, you need to establish a
  connection in TCP
• Server listen(), accept()
• Client connect()

53
connect

• int connect(int socket, const struct sockaddr
  address, socklen_t address_len)
• Establishes a link to the well-known port of the
  remote server
• Initiates the TCP 3-way handshake
• Cannot be restarted even if interrupted
• Returns 0 if successful, -1 with errno set if
  unsuccessful

54
Programming Sockets

• In both TCP and UDP, you send and receive by
  using the same calls
• recv() / recvfrom()

55
recv and recvfrom

• int recv(int socket, void buf, int len, int
  flags)
• int recvfrom(int socket, void buf, int len, int
  flags, const struct sockaddr from, socklet_t
  fromlen)
• receives data into the buffer buf
• recvfrom is used for unconnected datagram
  sockets. If used in connection-mode, last two
  parameters are ignored.
• Returns the number of bytes actually read if
  successful, -1 with errno set if unsuccessful

56
Programming Sockets

• In both TCP and UDP, you send and receive by
  using the same calls
• recv() / recvfrom()
• send() / sendto()

57
send and sendto

• int send(int socket, const void msg, int len,
  int flags)
• int sendto(int socket, const void msg, int len,
  int flags, const struct sockaddr to, socklet_t
  tolen)
• sends data pointed by msg
• sendto is used for unconnected datagram sockets.
  If used in connection-mode, last two parameters
  are ignored.
• Returns the number of bytes actually sent out if
  successful, -1 with errno set if unsuccessful

58
close and shutdown

• int close(int socket)
• int shutdown(int socket, int how)
• close
• Prevents any more reads and writes
• same function covered in file systems
• shutdown
• provides a little more control
• how
• 0 Further receives are disallowed
• 1 Further sends are disallowed
• 2 same as close
• Returns 0 if successful, -1 with errno set if
  unsuccessful

59
Using Sockets in C

• include ltsys/socket.hgt
• include ltsys/types.hgt
• include ltnetinet/in.hgt
• include ltunistd.hgt
• On csil-core
• gcc o test test.c
• On some systems, e.g., Solaris
• gcc o test test.c lsocket -lnsl

60
TCP Client/Server Example

• Run the provided test-server and test-client
  executables in two separate windows.
• test-client sends the string Hello World! to IP
  address 127.0.0.1 port 10000
• test-server listens on port 10000 and prints out
  any text received
• Next week, we will reproduce this behavior with
  codes client.c and server.c

61
HyperText Transfer Protocol
62
HTTP

• Hypertext Transfer Protocol
• Delivers virtually all files and resources on the
  World Wide Web
• Uses Client-Server Model
• HTTP transaction
• HTTP client opens a connection and sends a
  request to HTTP server
• HTTP server returns a response message

63
HTTP (continued)

• Request
• GET /path/to/file/index.html HTTP/1.0
• Other methods (POST, HEAD) possible for request
• Response
• HTTP/1.0 200 OK
• Common Status Codes
• 200 OK
• 404 Not Found
• 500 Server Error

64
Sample HTTP exchange

• Scenario
• Client wants to retrieve the file at the
  following URL (http//www.somehost.com/path/file.h
  tml)
• What a client does
• Client opens a socket to the host
  www.somehost.com, port 80
• Client sends the following message through the
  socket
• GET /path/file.html HTTP/1.0
• From someuser_at_uiuc.edu
• User-Agent HTTPTool/1.0
• blank line here

65
Sample HTTP exchange

• What a server does
• Server responds through the same socket
• HTTP/1.0 200 OK
• Date Mon, 17 Apr 2006 235959 GMT
• Content-Type text/html
• Content-Length 1354
• lthtmlgt
• ltbodygt
• (more file contents)
• .
• .
• .
• lt/bodygt
• lt/htmlgt

66
Reference

• Beej's Guide to Network Programming
• http//beej.us/guide/bgnet/

67
Summary

• Protocols
• Socket Programming
• Library Functions
• Hypertext Transfer Protocol
• Request
• Response
