Cocomo Lecture II EEE493 2000

1
Cocomo - Lecture II EEE493 2000
Royal Military College of Canada Electrical and
Computer Engineering

• Major Greg Phillips
• greg.phillips_at_rmc.ca
• 1-613-541-6000 ext. 6190

Dr. Scott Knight knight-s_at_rmc.ca 1-613-541-6000
ext. 6190
2
Refs

• Pressman, R.S., Software Engineering a
  Practitioners Approach 5th Ed., McGraw-Hill,
  2001, Chapter 4
• Boehm, Barry, Software Engineering Economics,
  Prentice-Hall, 1981

3
Teaching Points

• Modes of development
• Intermediate COCOMO model
• Example

4
Review

• What is the major cost driver in COCOMO?
• What economies of scale does COCOMO seem to
  capture? How do we see this in the model?
• What diseconomies of scale does COCOMO seem to
  capture? How do we see this in the model?
• What are phase distributions used for?

5
Consider

• All software is not developed under the same set
  of circumstances
• What about developing
• new kinds of systems
• in new development environments
• on hardware being developed at the same time
• using new algorithms
• in an embedded environment
• under contract
• Introduce 3 Modes of Development

6
Organic Mode

• As in previous discussions, small-to-medium sized
  product development in a familiar, in-house
  development environment. A generally stable
  development environment, minimal need for
  innovative data processing architectures and
  algorithms. Relaxed schedule constraints.

7
Semidetached Mode

• Team members have an intermediate level of
  experience with related systems. Perhaps a
  mixture of experienced and inexperienced people.
  Parts of the project may require rigorous
  interfaces.

8
Embedded Mode

• Need to operate within tight constraints.
  Product must operate within a strongly coupled
  complex of H/W, S/W, regulations, and operational
  procedures. Cost of changing other parts of the
  complex is high. Tighter requirements and more
  inflexible scheduling.

9
Basic COCOMO Formula
Note what is happening to the scalars and
exponents
10
Example Estimates
Note large changes in effort and
productivity, small changes in schedule
11
Phase Distributions
12
How good is it?

• This is an empirical model so it can only be as
  good as its database
• For the data it was calibrated toBasic COCOMO
  is
• within a factor of 1.3 - 29 of the time
• within a factor of 2 - 60 of the time

13
Basic COCOMO Accuracy
14
Intermediate COCOMO

• Basic COCOMO plus
• the addition of 15 more cost driver attributes
• new set of effort equations
• Accuracy
• within a factor of 20 - 68 of the time

15
Intermediate COCOMO Accuracy
16
Intermediate COCOMO Formula
17
Cost Driver Effort Multipliers
18
Cost Driver Ratings
Note see handout for module complexity ratings
19
A Pricing ExampleMicroprocessor Communications
Software
20
Cost Driver Ratings Microprocessor
Communications Software
21
Project Cost Microprocessor Communications
Software

• PMnom 2.8(10)1.2 44 pm
• PMadj 44 pm ? 1.17 51 pm
• 51 pm ? 6000 /pm 306,000

nominal
adjusted
22
Next ClassCocomo - Lecture III
