Title: PC Hardware Basic Guide


1
PC Hardware Basic Guide
  • Module 4 - Motherboard

2
Module 4 - Motherboard
  • Overview
  • It is a Printed Circuit Board that performs the
    key functions to enable smooth running of the
    computer.
  • Lesson Covered in this Module
  • Motherboards
  • Standard Expansion Buses

3
Lesson 1 - Motherboards
  • Introduction
  • Motherboard is a Printed Circuit Board which
    possesses different components for various
    purposes. It contains
  • CPU
  • BIOS,
  • Memory
  • I/O ports
  • External I/O connectors
  • I/O controllers
  • Expansion slots
  • Chipsets.

4
Module 4 - Motherboard
  • Topics Covered in this Lesson
  • Physical Form Factors
  • Motherboard Components
  • System Chipsets and Controllers
  • CMOS Settings
  • Power On Self Test (POST)
  • System Resources

5
Topic 1 - Physical Form Factors
  • Personal Computer Extended Technology (PC-XT)
  • Introduced by IBM, 8088 microprocessor was used.
  • It has socket for the processor and chips

6
Topic 1 - Physical Form Factors
  • AT and Baby AT
  • To overcome the problem created by AT Form
    factor, the Baby AT form factor was introduced.
  • Baby AT is designed to hold the peripheral
    devices like keyboard, video and mouse.
  • It could not accommodate the combination of
    processor, heat sink and fan. Cooling

7
Topic 1 - Physical Form Factors
  • ATX and Micro ATX form factor
  • Here expansion slots were placed on separate
    riser cards.
  • It provides software controlled shut down and
    power up.
  • Micro ATX form factor
  • More space for I/O connectors was provided at the
    rear end.

8
Topic 1 - Physical Form Factors
  • LPX and Mini-LPX
  • It has sound and video to be integrated on to the
    motherboard.
  • It is not suitable for upgrading and offers poor
    cooling.
  • NLX
  • Small in size
  • Suited for low profile desktop cases

9
Topic 2 - Motherboard Components
  • The major components of the motherboard
  • Processor socket or slot
  • Chipset
  • Super I/O chip
  • BIOS
  • SIMM/DIMM sockets
  • Bus slots

10
Topic 2 - Motherboard Components
  • Chipset and Functions
  • Different chips integrated to a single chip
    called the chipset.
  • North bridge and South bridge was introduced to
    the motherboard with PCI slots.
  • The south bridge controls the slower I/O
    components like the Serial ports, USB ports and
    the IDE.

11
Topic 2 - Motherboard Components
  • The new technology, Intel Hub Architecture (IHA)
    uses two chips called hub controllers.
  • The hub controllers are
  • Graphics and Memory Controller Hub (GMCH)
  • I/O Controller Hub (ICH)
  • The chipset determine
  • The voltage provided to the processor
  • Number of processors that can be supported
  • The speed of the processor
  • The different memory modules that are supported
  • Bus speed
  • The different expansion bus that are supported
  • Power Management

12
Topic 3 - System Chipset and Controllers
  • The system chipset and controllers are the
    intelligence of the motherboard.
  • Chipset has a effect on the quality, feature set
    and speed of the computer.
  • Controllers found on motherboards
  • The system chip
  • The keyboard controller
  • The super I/O chip
  • Additional built-in controllers

13
Topic 3 - System Chipset and Controllers
  • Qualities and Functions of Chipset
  • Chipset Processor Support
  • Support for Processor Class and Optimization -
    Supports one generation of processors
  • Support for Processor Speed - Fast processors
    need chipset control circuitry that has the
    capacity to manage them.
  • Support for Multiple Processor - Chipset support
    the capability for building motherboards with two
    or four processors on them.



14
Topic 3 - System Chipset and Controllers
  • Chipset Cache Support - The cache stores recent
    memory accesses by the processor
  • Size of Secondary Cache - Chipsets support cache
    of 256KB or 512 KB.
  • Type of Secondary Cache - three major kinds of
    cache, Asynchronous, Synchronous burst, Pipeline
    burst.
  • Write Policy of Secondary Cache - A write-through
    cache and a write back cache.
  • Cacheability of System Memory - The amount of
    cacheable memory is dependent on the chipset
    control circuitry and the amount of tag RAM on
    the board.

15
Topic 3 - System Chipset and Controllers
  • Chipset Memory Support - The chipset determines
    several permissible features of the memory
  • Support for Maximum Memory-Determines the maximum
    quantity of RAM a system can have on the
    motherboard
  • DRAM Technology - Regulates whether motherboard
    can make use of FPM, EDO, BEDO, or SDRAM memory.
  • Support for DRAM Packaging and Size - Two main
    types of memory packages are, single in-line
    memory module (SIMM) and dual in-line memory
    module (DIMM).
  • Support for Parity and Error Correction - Error
    correction logic is offered as part of the memory
    control circuits of the chipset.

16
Topic 3 - System Chipset and Controllers
  • Chipset Peripheral and I/O Bus Control - Most
    recent computers use two buses, (ISA) bus and l
    component (PCI) bus.
  • Bus Types - The chipset determines what type of
    buses the system can support.
  • Bus Bridges Bridge is used for connecting
    together devices on two different buses.
  • IDE/ATA Hard Disk Controller - All motherboards
    have integrated into them support for four IDE
    hard disks
  • DMA Controller and DMA Mode Support Process of
    transferring information directly to and from
    memory with no interference of the processor.

17
Topic 3 - System Chipset and Controllers
  • Interrupt Controller
  • USB Support
  • AGP Support
  • Plug and Play

18
Topic 3 - System Chipset and Controllers
  • Chipset Power Management Support Works through
    a number of BIOS settings that determine when to
    shut down different parts of the computer
  • Energy Star
  • Advanced Power Management
  • Display Power
  • Management Signalling
  • System Management Mode
  • Hard Disk Spindown

19
Topic 3 - System Chipset and Controllers
  • Super I/O Controller Chip super I/O controller
    handles three ports
  • Serial Port Control controls the serial ports,
    UART
  • Parallel Port Control manages and controls the
    parallel port
  • Floppy Disk Drive Control supports the Floppy
    Disk Drive and floppy based tape drives

20
Topic 3 - System Chipset and Controllers
  • Processor
  • Two major components
  • Arithmetic and Logic Unit (ALU) performs
    Arithmetic and Logic Operations
  • Control Unit (CU) provides the control signals
    for performing different operations.
  • Cache Memory
  • It is high speed storage memory made of Static
    RAM (SRAM).
  • Two types of cache memory are L1 or the internal
    cache and L2 cache or the external cache.

21
Topic 3 - System Chipset and Controllers
  • I/O Ports
  • Each device connected to a computer uses I/O port
    address.
  • Functions of I/O address
  • Sending commands to the peripheral device
  • Receiving the status of the device whether it is
    idle or busy
  • Send and receive data
  • Configure the device for interrupts
  • Bus Speed
  • The speed of the bus refers to the amount of the
    data that can be transferred across the bus.

22
Topic 3 - System Chipset and Controllers
  • Some of the bus types are,
  • Front side Bus - The bus speed in general refers
    to the speed of the Front Side Bus (FSB).
  • AGP Bus It connects the video card to the
    memory and the CPU.
  • Back side Bus It connects the processor to the
    L2 Cache

23
Topic 3 - System Chipset and Controllers
  • Memory bus It connects the north bridge to the
    memory.
  • IDE or ATA bus It connects the south bridge to
    the disk drives.
  • PCI Bus It connects the PCI slots to the south
    bridge.

24
Topic 3 - System Chipset and Controllers
  • Jumpers
  • It is a small connector which can be placed
    between two pins to make electrical connections.
  • DIP switch
  • The dual inline package switch is a small block
    provided with a lever.

25
Topic 4 - CMOS Settings
  • CMOS BIOS ROM
  • Stores the basic system configuration. The four
    major components of BIOS are
  • POST
  • Bootstrap Loader
  • CMOS Setup
  • BIOS ROM

26
Topic 4 - CMOS Settings
  • CMOS Battery
  • Battery is used to power up the Real time Clock
    Chip.
  • This chip maintains the system date and time.
  • System Configuration
  • The BIOS should find an operating system on a
    hard disk or floppy disk drive to start the
    computer.
  • Starting the Setup Program
  • The settings made in the BIOS setup program are
    stored in the nonvolatile RAM of the CMOS chip.

27
Topic 4 - CMOS Settings
  • Step-by-Step CMOS/BIOS Configuration
  • From the CMOS setup menu, select the menu point
    to examine or change setting and choose Standard
    CMOS setup to begin.

28
Topic 4 - CMOS Settings
  • From the standard CMOS configuration screen you
    can set Date, Time, Hard drives connected to the
    IDE interface, Floppy disk drive types for drives

29
Topic 4 - CMOS Settings
  • Advanced CMOS Configuration
  • Here, you can perform the Number Lock setting,
    keyboard repeats speed, type of video, settings
    for cache memory, and other special features.

30
Topic 4 - CMOS Settings
  • Recommended Advanced CMOS Settings
  • Depending on the BIOS version, you have to press
    the ESC key, to return to the main menu

31
Topic 4 - CMOS Settings
  • Power Management Configuration
  • After a user defined period of inactivity of
    devices like the monitor, the hard drive, or the
    CPU will go into different low power modes.
  • Standby mode
  • Suspend mode

32
Topic 4 - CMOS Settings
  • Built-In Ports/Peripherals Setup
  • It can enable or disable ports which built in new
    systems.

33
Topic 4 - CMOS Settings
  • Security/Passwords
  • Two types of passwords are
  • One must be entered to allow any use of the
    system
  • Another one must be entered to allow access to
    the BIOS/ CMOS setup
  • Saving and Recording BIOS/CMOS Settings
  • BIOS allows you to save the changes and it will
    reject the changes that happen accidentally.
  • Record the critical BIOS settings

34
Topic 4 - CMOS Settings
  • BIOS Upgrades
  • Change the physical chip or to change its
    contents with software
  • Flash BIOS Upgrade
  • Install the BIOS upgrade loader and BIOS image to
    a floppy disk
  • Incorrect CMOS Configuration
  • Restart by using the BIOS Setup auto-configure
    options, double-check drive configurations, save
    changes, and restart.

35
Topic 4 - CMOS Settings
  • Incorrect Flash BIOS or Failed Update
  • If the update can't be installed, the motherboard
    might have jumpers that write-protects the flash
    BIOS.
  • Clearing the BIOS Password
  • It can be cleared by using a CMOS jumper that is
    present in the motherboard.

36
Topic 5 - Power On Self Test (POST) Error codes
  • Some main functions of BIOS during POST
  • Helps to start the Operating System.
  • Check for the integrity of the BIOS code
  • Some error beeps
  • No beep - Power supply or system board problem
  • 1 long, 1 short beep - System board problem
  • Long beeps - 3270 keyboard card
  • Some error codes
  • 100 to 199 - System board
  • 200 to 299 - Memory
  • 300 to 399 - Keyboard

37
Topic 6 - System Resources
  • System resources are components that are required
    to communicate between the hardware components in
    a PC.
  • Interrupt Request Channels (IRQ)
  • Hardware devices use IRQ signal to the processor
  • There are 16 IRQ channels .

38
Topic 6 - System Resources
  • The snapshot shows the different IRQ channels
    associated with different devices.

39
Topic 6 - System Resources
  • Direct Memory Access (DMA) channels
  • Here the data is transferred between the
    peripheral device and the memory without the
    intervention of the CPU.
  • Devices connected to serial and parallel port do
    not use DMA channels
  • I/O Port Address
  • It is an interface present in a PC to connect
    devices
  • The port address ranges from 0000h to FFFFh

40
Topic 6 - System Resources
  • The snapshot displays the I/O address range used
    by different devices

41
Topic 6 - System Resources
  • Checking for Resource Availability
  • For Windows 3.x or MS-DOS, the resource settings
    can be verified by using the MSD command present
    in the DOS directory.
  • For Windows 2000 or Windows XP, follow the step
    given below to identify the resources used by the
    different devices
  • Click Start ? Programs ?
    Accessories ?System Tools-gt System Information

42
Lesson 2 - Standard Expansion Buses
  • Introduction
  • The expansion slots are used to enhance the
    features of the PC.
  • The expansion slots can hold expansion cards like
    the sound card, VGA card, AGP card, Network card
    etc
  • There are different types of expansion slots.
    Industrial Standard Architecture (ISA) bus
  • Micro Channel Architecture (MCA) Bus
  • Extended ISA (EISA) Bus
  • Video Electronics Standard Association (VESA) Bus
  • Peripheral Component Interconnect (PCI)Bus
  • Peripheral Component Interconnect X
  • Accelerated Graphics Port
  • Audio Modem Raiser and Communication Network
    Raiser

43
Lesson 2 - Standard Expansion Buses
  • Topics Covered in this Lesson
  • PC Bus
  • Industrial Standard Architecture (ISA) Bus
  • Micro Channel Architecture (MCA) Bus
  • Extended ISA (EISA) Bus
  • Video Electronics Standard Association (VESA) Bus
  • Peripheral Component Interconnect (PCI) Bus
  • Accelerated Graphics Port
  • Audio Modem Raiser and Communication Network
    Raiser

44
Topic 1 PC Bus
  • PC bus is an 8 bit expansion slot to connect 8
    bit expansion cards.

45
Topic 2 - Industrial Standard Architecture (ISA)
Bus
  • ISA bus is a 16 bit slot present in 80286, 80386,
    80486 and Pentium systems.
  • The ISA card is configured through jumpers or
    switches

46
Topic 3 - Micro Channel Architecture (MCA) Bus
  • Bus Mastering - The components that can take
    control over the bus are called bus masters.
  • Features of MCA
  • It is a 16 or 32 bit bus created by IBM
  • Supports bus mastering
  • Operates at 10-12 MHZ
  • Can be configured through software
  • Has Lower Noise Level

47
Topic 4 - Enhanced ISA
  • It is a 32 bit bus.
  • Capable of using multiple bus mastering devices.
  • Compatible 8 bit PC bus, 16 bit ISA bus.
  • Software setup capability for boards

48
Topic 5 - Video Electronics Standard Architecture
(VESA) bus
  • It is a 32 bus.
  • It is used to connect video cards, I/O cards and
    multimedia expansion cards
  • Disadvantages of the VESA
  • 80486 dependence
  • Limited number of slots
  • No bus mastering
  • Boards are configured through jumpers

49
Topic 6 - Peripheral Component Interconnect (PCI)
bus
  • PCI
  • Operates at a speed of 33 MHz or 66 MHz
  • It is a 64 bit bus
  • Communicates with processor using a bridge
    circuit.
  • PCI-X
  • Operates at 133 MHz bus speed
  • Offers 64 bit Band width
  • Supports 1 GB/Sec data transfer rate
  • Supports efficient bus operation
  • Provides backward Compatibility

50
Topic 7 - AGP Bus
  • It is designed for connecting video cards.
  • PCI bus with 2.1 version at 66MHZ is the basis
    for AGP slot.
  • It supports a new technique called texture cache.

51
Topic 8 - Audio Modem Raiser and Communication
Network Raiser
  • This specification developed by Intel.
  • The function of the modem and the analog I/O
    audio circuitry are combined together on a small
    circuit board
  • The small circuit board is called raiser card
  • The AMR card enhances the performance by
    providing better quality audio solutions.

52
Topic 8 - Audio Modem Raiser and Communication
Network Raiser
  • Communication Network Raiser Card
  • This is a standard developed by Intel
  • It contains chips for the functioning of modems
    and audio devices.
  • PCMCIA or PC Card
  • It is an expansion board used for laptop and
    notebook computers.
  • It is used for interfacing components like the
    Memory, fax/modems, SCSI adapters

53
Topic 8 - Audio Modem Raiser and Communication
Network Raiser
  • The following figure shows different Bus
    interfaces and the devices that can be connected
    to each of them

54
Lesson 3 - Choosing, Installing and
Troubleshooting a Motherboard
  • Introduction
  • Motherboard is the most important component of
    the computer.
  • This is the central component to which every
    other component is attached,
  • Topics covered in this module
  • Choosing a Motherboard
  • Installing a Motherboard
  • Troubleshooting a Motherboard

55
Topic 1-Choosing a Motherboard
  • Choosing a Motherboard
  • Choosing an appropriate motherboard can be quite
    a challenging task. A lot of factors affect the
    choice of the motherboard.
  • Future upgradeability of the system is the most
    important one
  • It should support a higher hard drive capacity, a
    higher Memory slot on the motherboard, whether it
    has an AGP slot.

56
Topic 1-Choosing a Motherboard
  • IT should support the following
  • Mother form factor
  • CPU compatibility
  • Functionality
  • Connectors

57
Topic 2-Installing a Motherboard
  • Installing a Motherboard
  • Installing a motherboard should be done with a
    lot of care.
  • Connect the motherboard to the mounting holes and
    tighten the screws.
  • Set the jumpers and switches to the appropriate
    positions.
  • Once the motherboard is secure, then start
    connecting the different wires to their
    appropriate sockets.

58
Topic 3 Troubleshooting a Motherboard
  • Troubleshooting a Motherboard
  • Troubleshooting the motherboard is the trickiest
    part for a technician.
  • This requires a lot of time, patience and
    documentation. Since the troubleshooting has to
    be done at the chip-level, troubleshooting a
    motherboard can cost more time and money than
    buying a new one.

59
Conclusion
  • PC bus is an 8 bit expansion slot to connect 8
    bit expansion cards
  • The major components of the motherboard are
  • Processor socket or slot
  • Chipset
  • Super I/O chip
  • BIOS
  • SIMM/DIMM sockets
  • Bus slots
  • ISA bus is a 16 bit slot present in 80286, 80386,
    80486 and Pentium systems
  • Future upgradeability of the system is the most
    important one
Write a Comment
User Comments (0)
About PowerShow.com
