Chapter 9: Articulations A

1
Chapter 9ArticulationsAP Biology 141
2
Articulations

• Body movement occurs at joints (articulations)
  where 2 bones connect
• Joint Structure
• Determines direction and distance of movement
  (range of motion)
• Joint strength decreases as mobility increases

3
What are the major categories of joints, and the
structure and function of each category?
4
Functional Classification
Table 91
5
Functional Classifications

• Synarthrosis
• no movement
• Amphiarthrosis
• little movement
• Diarthrosis
• more movement

6
Synarthroses

• Also called immovable joints
• Fibrous or cartilaginous connections
• May fuse over time
• Amphiarthroses
• Also called slightly moveable joints
• Fibrous or cartilaginous connections

7
Diarthroses

• Synovial joints
• Also called freely moveable joints
• Subdivided by type of motion

8
Structural Classification
Table 92
9
Structural Classifications

• Bony
• Fibrous
• Cartilaginous
• Synovial

10
Synarthroses (Immovable Joints)

• Are very strong
• Edges of bones may touch or interlock
• 4 Types of Synarthrotic Joints
• Suture
• Gomphosis
• Synchondrosis
• Synostosis

11
Suture

• Bones interlocked
• Are bound by dense fibrous connective tissue
• Are found only in skull
• Gomphosis
• Fibrous connection (periodontal ligament)
• Binds teeth to sockets

12
Synchondrosis

• Is a rigid cartilaginous bridge between 2 bones
• epiphyseal cartilage of long bones
• between vertebrosternal ribs and sternum
• Synostosis
• Fused bones, immovable
• metopic suture of skull
• epiphyseal lines of long bones

13
Amphiarthroses

• More moveable than synarthrosis
• Stronger than freely movable joint
• 2 Types of Amphiarthroses
• Syndesmosis
• bones connected by ligaments
• Symphysis
• bones separated by fibrocartilage

14
What is the basic structure of a synovial joint,
and what are the common accessory structures and
their functions?
15
Synovial Joints (Diarthroses)

• Also called moveable joints
• At ends of long bones
• Within articular capsules
• Lined with synovial membrane

16
Articular Cartilages

• Pad articulating surfaces within articular
  capsules
• prevent bones from touching
• Smooth surfaces lubricated by synovial fluid
• reduce friction

17
Synovial Fluid

• Contains slippery proteoglycans secreted by
  fibroblasts
• Functions of Synovial Fluid
• Lubrication
• Nutrient distribution
• Shock absorption

18
Synovial Joints Accessory Structures

• Cartilages
• Cushion the joint
• fibrocartilage meniscus (articular disc)
• Fat pads
• Cushion the joint
• fibrocartilage meniscus (articular disc)
• Accessory Ligaments
• Support, strengthen joints
• Sprain
• ligaments with torn collagen fibers

19
Synovial Joints Accessory Structures

• Tendons
• Attach to muscles around joint
• Help support joint
• Bursae
• Pockets of synovial fluid
• Cushion areas where tendons or ligaments rub

20
Synovial Joints Stabilizing Factors

• Prevent injury by limiting range of motion
• collagen fibers (joint capsule, ligaments)
• articulating surfaces and menisci
• other bones, muscles, or fat pads
• tendons of articulating bones

21
Injuries

• Dislocation (luxation)
• articulating surfaces forced out of position
• damages articular cartilage, ligaments, joint
  capsule
• Subluxation
• a partial dislocation

22
What are the dynamic movements of the skeleton?

• Types of Dynamic Motion
• Linear motion (gliding)
• Angular motion
• Rotation

23
Linear Motion

• Pencil maintains vertical orientation, but
  changes position

Figure 92a, b
24
Angular Motion

• Pencil maintains position, but changes orientation

Figure 92c
25
Circumduction Rotation

• Pencil maintains position and orientation, but
  spins

• Circular angular motion

Figure 92e
26
Planes (Axes) of Dynamic Motion

• Monaxial (1 axis)
• Biaxial (2 axes)
• Triaxial (3 axes)

27
Types of Movements at Synovial Joints

• Terms describe
• plane or direction of motion
• relationship between structures

28
Linear Motion

• Also called gliding
• 2 surfaces slide past each other
• between carpal or tarsal bones

29
Flexion
Angular motion Anteriorposterior plane Reduces
angle between elements
Figure 93a
30
Extension

• Angular motion
• Anteriorposterior plane
• Increases angle between elements
• Hyperextension
• Angular motion
• Extension past anatomical position

31
Abduction
Figure 93b, c
32
Abduction

• Angular motion
• Frontal plane
• Moves away from longitudinal axis
• Adduction
• Angular motion
• Frontal plane
• Moves toward longitudinal axis

33
Circumduction

• Circular motion without rotation
• Angular motion

Figure 93d
34
Rotation
Figure 94
35
Rotation

• Direction of rotation from anatomical position
• Relative to longitudinal axis of body
• Left or right rotation
• Medial rotation (inward rotation)
• rotates toward axis
• Lateral rotation (outward rotation) rotates away
  from axis

36
Pronation and Supination

• Pronation
• rotates forearm, radius over ulna
• Supination
• forearm in anatomical position

37
Inversion and Eversion
Inversion twists sole of foot medially Eversion
twists sole of foot laterally
Figure 95a
38
Dorsiflexion and Plantar Flexion

• Dorsiflexion
• flexion at ankle (lifting toes)
• Plantar flexion
• extension at ankle (pointing toes)

Figure 95b
39
Opposition

• Thumb movement toward fingers or palm (grasping)

Figure 95c
40
Protraction and Retraction
Figure 95d
41
Protraction and Retraction

• Protraction
• moves anteriorly
• in the horizontal plane (pushing forward)
• Retraction
• opposite of protraction
• moving anteriorly (pulling back)

42
Elevation and Depression

• Elevation
• moves in superior direction (up)
• Depression
• moves in inferior direction (down)

Figure 95e
43
Lateral Flexion

• Bends vertebral column from side to side

Figure 95f
44
What are the types of synovial joints, and the
relationship of motion to structure?
45
Classification of Synovial Joints by Shape

• Gliding
• Hinge
• Pivot
• Ellipsoidal
• Saddle
• Ball-and-socket

A Functional Classification of Synovial Joints
PLAY
46
Gliding Joints

• Flattened or slightly curved faces
• Limited motion (nonaxial)

Figure 96 (1 of 6)
47
Hinge Joints

• Angular motion in a single plane (monaxial)

Figure 96 (2 of 6)
48
Pivot Joints

• Rotation only (monaxial)

Figure 96 (3 of 6)
49
Ellipsoidal Joints

• Oval articular face within a depression
• Motion in 2 planes (biaxial)

Figure 96 (4 of 6)
50
Saddle Joints

• 2 concave faces, straddled (biaxial)

Figure 96 (5 of 6)
51
Ball-and-Socket Joints

• Round articular face in a depression (triaxial)

Figure 96 (6 of 6)
52
KEY CONCEPT

• A joint cant be both mobile and strong
• The greater the mobility, the weaker the joint
• Mobile joints are supported by muscles and
  ligaments, not bone-to-bone connections

53
How do vertebrae in the vertebral column
articulate? Intervertebral Articulations
Figure 97
54
Intervertebral Articulations

• C2 to L5 spinal vertebrae articulate
• at inferior and superior articular processes
  (gliding joints)
• between adjacent vertebral bodies (symphyseal
  joints)

55
Intervertebral Discs

• Intervertebral discs
• pads of fibrocartilage
• separate vertebral bodies

56
Disc Structure

• Anulus fibrosus
• tough outer layer
• attaches disc to vertebrae
• Nucleus pulposus
• elastic, gelatinous core
• absorbs shocks

57
Vertebral Joints

• Also called symphyseal joints
• As vertebral column moves
• nucleus pulposus shifts
• disc shape conforms to motion

58
Intervertebral Ligaments

• Bind vertebrae together
• Stabilize the vertebral column

59
6 Intervertebral Ligaments

• Anterior longitudinal ligament
• connects anterior bodies
• Posterior longitudinal ligament
• connects posterior bodies
• Ligamentum flavum
• connects laminae

60
6 Intervertebral Ligaments

• Interspinous ligament
• connects spinous processes
• Supraspinous ligament
• connects tips of spinous processes (C7 to sacrum)
• Ligamentum nuchae
• continues supraspinous ligament (C7 to skull)

61
Damage to Intervertebral Discs
Figure 98
62
Damage to Intervertebral Discs

• Slipped disc
• bulge in anulus fibrosus
• invades vertebral canal
• Herniated disc
• nucleus pulposus breaks through anulus fibrosus
• presses on spinal cord or nerves

63
Movements of the Vertebral Column

• Flexion
• bends anteriorly
• Extension
• bends posteriorly
• Lateral flexion
• bends laterally
• Rotation

64
Articulations and Movements of the Axial Skeleton
Table 93 (1 of 2)
65
Articulations and Movements of the Axial Skeleton
Table 93 (2 of 2)
66
What are the structures and functions of the
shoulder, elbow, hip, and knee joints, and what
is the relationship between joint strength and
mobility?
67
The Shoulder Joint
Figure 99a
68
The Shoulder Joint
Figure 99b
69
The Shoulder Joint

• Also called the glenohumeral joint
• allows more motion than any other joint
• is the least stable
• supported by skeletal muscles, tendons, ligaments

70
Structure of the Shoulder Joint

• Ball-and-socket diarthrosis
• Between head of humerus and glenoid cavity of
  scapula

71
Socket of the Shoulder Joint

• Glenoid labrum
• deepens socket of glenoid cavity
• fibrocartilage lining
• extends past the bone

72
Processes of the Shoulder Joint

• Acromion (clavicle) and coracoid process
  (scapula)
• project laterally, superior to the humerus
• help stabilize the joint

73
Shoulder Ligaments

• Glenohumeral
• Coracohumeral
• Coracoacromial
• Coracoclavicular
• Acromioclavicular

74
Shoulder Separation

• Dislocation of the shoulder joint

75
Shoulder Muscles

• Also called rotator cuff
• supraspinatus
• infraspinatus
• subscapularis
• teres minor

76
Shoulder Bursae

• Subacromial
• Subcoracoid
• Subdeltoid
• Subscapular

77
The Elbow Joint
Figure 910
78
The Elbow Joint

• A stable hinge joint
• With articulations between humerus, radius, and
  ulna

79
Articulations of the Elbow

• Humeroulnar joint
• largest articulation
• trochlea of humerus and trochlear notch of ulna
• limited movement
• Humeroradial joint
• smaller articulation
• capitulum of humerus and head of radius

80
Elbow Muscle

• Biceps brachii muscle
• attached to radial tuberosity
• controls elbow motion
• Elbow Ligaments
• Radial collateral
• Annular
• Ulnar collateral

81
The Hip Joint
Figure 911a
82
The Hip Joint
Figure 911b, c
83
The Hip Joint

• Also called coxal joint
• Strong ball-and-socket diarthrosis
• Wide range of motion

84
Structures of the Hip Joint

• Head of femur fits into it
• Socket of acetabulum
• Which is extended by fibrocartilage acetabular
  labrum

85
Ligaments of the Hip Joint

• Iliofemoral
• Pubofemoral
• Ischiofemoral
• Transverse acetabular
• Ligamentum teres

86
The Knee Joint
Figure 912a, b
87
The Knee Joint

• A complicated hinge joint
• Transfers weight from femur to tibia

Figure 912c, d
88
Articulations of the Knee Joint

• 2 femurtibia articulations
• at medial and lateral condyles
• 1 between patella and patellar surface of femur

89
Menisci of the Knee

• Medial and lateral menisci
• fibrocartilage pads
• at femurtibia articulations
• cushion and stabilize joint
• give lateral support

90
Locking Knees

• Standing with legs straight
• locks knees by jamming lateral meniscus between
  tibia and femur

91
7 Ligaments of the Knee Joint

• Patellar ligament (anterior)
• 2 popliteal ligaments (posterior)
• Anterior and posterior cruciate ligaments (inside
  joint capsule)
• Tibial collateral ligament (medial)
• Fibular collateral ligament (lateral)

92
Articulations of the Appendicular Skeleton
Table 94 (1 of 2)
93
Articulations of the Appendicular Skeleton
Table 94 (2 of 2)
94
What are the effects of aging on articulations,
and the most common clinical problems?
95
Rheumatism

• A pain and stiffness of skeletal and muscular
  systems
• Arthritis
• All forms of rheumatism that damage articular
  cartilages of synovial joints

96
Osteoarthritis

• Caused by wear and tear of joint surfaces, or
  genetic factors affecting collagen formation
• Generally in people over age 60

97
Rheumatoid Arthritis

• An inflammatory condition
• Caused by infection, allergy, or autoimmune
  disease
• Involves the immune system

98
Gouty Arthritis

• Occurs when crystals (uric acid or calcium
  salts)
• form within synovial fluid
• due to metabolic disorders

99
Joint Immobilization

• Reduces flow of synovial fluid
• Can cause arthritis symptoms
• Treated by continuous passive motion (therapy)

100
Bones and Aging

• Bone mass decreases
• Bones weaken
• Increases risk of hip fracture, hip dislocation,
  or pelvic fracture

101
Integration with Other Systems
Figure 913
102
Bone Recycling

• Living bones maintain equilibrium between
• bone building (osteoblasts)
• and break down (osteoclasts)

103
Factors Affecting Bone Strength

• Age
• Physical stress
• Hormone levels
• Calcium and phosphorus uptake and excretion
• Genetic and environmental factors

104
Bones Support Body Systems

• The skeletal system
• supports and protects other systems
• stores fat, calcium, and phosphorus
• manufactures cells for immune system

105
Body Systems Support Bones

• Disorders in other body systems can cause
• bone tumors
• osteoporosis
• arthritis
• rickets (demineralization)

106
SUMMARY (1 of 5)

• Joint classification by motion and structure
• 4 types of synarthroses
• suture, gomphosis, synchondrosis, synostosis
• 2 types of amphiarthroses
• syndesmosis, symphysis

107
SUMMARY (2 of 5)

• Structures of diarthroses
• 3 forms of dynamic motion
• linear or gliding, angular, rotation
• 3 planes of motion
• monaxial, biaxial, triaxial

108
SUMMARY (3 of 5)

• Movements of synovial joints
• gliding, flexion, extension, abduction, rotation,
  pronation, inversion, dorsiflexion, opposition,
  protraction, depression, etc.

109
SUMMARY (4 of 5)

• 6 structural types of synovial joints
• gliding
• hinge
• pivot
• ellipsoidal
• saddle
• ball-and-socket

110
SUMMARY (5 of 5)

• Structures and movements of
• intervertebral articulations
• shoulder joint
• elbow joint
• hip joint
• knee joint
• Effects of aging on joints
• Relationship of the skeleton to other body
  systems
