• 1GS312 CONTAMINATED LAND
• 1GS418 FUNDEMENTALS OF CONTAMINATED LAND

SCHOOL OF EARTH ENVIRONMENTAL
SCIENCES Contaminated Land Remediation
Reclamation Techniques
3
Waste Remediation

• Contaminated Land Remediation Reclamation
  Techniques
• Aims
• Treatments Methods
• Innovative Technologies
• Data information sources

4
Aims

• To return land to beneficial use
• To prevent contaminants on land from causing
  damage
• Principal determinants for choice of reclamation
  method
• Cost
• Regulatory Framework

5
Treatment Of Contaminated Land

• Reduce the amount of toxic materials being dealt
  with by confinement in landfill
• Increase the separation of contaminants from the
  matrix which they are polluting
• Thus
• Reducing volumes of waste generated
• Conserving soil water

6
Reclamation Methods

• Traditional methods
• Isolation
• Covering
• Removal
• Decontamination techniques

7
Isolation Removal

• Isolation
• Capping
• Covering
• Vertical Barriers
• Diversion Trenches
• Break Layers
• Horizontal Barriers
• Removal
• Excavation
• Total Containment

8
Decontamination Techniques

• Separation, Destruction, Stabilisation
• Vapour Extraction
• In-Situ Ex-Situ Bioremediation
• Soil Washing
• Containment
• Stabilisation / Solidification
• Vitrification
• Solvent Extraction
• Pump Treat
• Leaching

9
Capping Covering

• Isolation of contaminants from potential targets
• Prevention of exposure to transport media
• Control of gas, leachate capillary water
• Ground improvement for construction
• Providing a substrate for vegetation
• Conflict between different aims may be difficult
  to overcome
• May lack permanency susceptible to damage
• Requires specialist input in design
  construction to ensure meets performance
  standards
• Ineffective against lateral groundwater movements

10
Cover Systems

• Cover system for contaminated land incorporating
  a clay cap break layer

Geomembrane
Clay Cap
Break Layer
11
Cover Systems

• Cover systems used in metalliferous mine
  reclamation schemes

12
Diversion Trenches

• Cut-off drainage around contaminated areas
• Temporary measure during excavation
• Facilitates the removal of contaminants during
  pump treat operations
• To lower groundwater table to facilitate other
  measures
• Limited applicability to impermeable soils
• Need for specialist input
• Requires long-term monitoring maintenance

13
In-ground Barriers

• Minimise lateral vertical movement of
  contaminants, gases water
• Vertical Barriers
• Displacement Barriers
• Excavated Barriers
• Injection Systems
• Horizontal barriers used where a contaminant
  source is underlain by permeable materials
• Usually installed using injection / grouting
  methods

14
In-ground Barriers

• Specialist input needed
• Difficult to install in heterogeneous ground
  conditions
• Requires long-term maintenance monitoring
• Vertical membrane installation can be difficult
• If not properly installed can lead to costly
  remediation measures
• Sheet piles are costly to install are not
  impermeable

15
Vertical Barrier

• Vertical barrier cut-off drainage in use with
  a simple capping system

16
Excavation

• Used to remove materials from site for final
  disposal or treatment
• Disposal may be on or off - site, with or without
  treatment
• Both contamination poor ground conditions are
  remediated at the same time
• Complete removal of contaminants may not be
  achieved
• Does not destroy contaminants
• Long-term maintenance monitoring of disposal
  areasrequired

17
Decontamination Techniques

• Thermal
• Separation
• Solidification / Stabilisation
• Chemical Methods
• Biological Methods
• In-Situ
• Ex-Situ

18
Thermal Treatment

• Incineration
• Destructive
• Off-Site
• Waste Emissions / Ash
• Thermal Desorption
• Removes Volatiles Semi-Volatiles
• Vitrification
• Intense heat required
• Mixes silica other vitrification materials
• Drives off Volatiles

19
Thermal Treatment

• Incineration Methods
• Rotary Kiln
• Infrared
• Fluidized Bed
• Desorption Methods
• Ex-Situ Thermal Desorption
• In-Situ Stripping

20
Separation Techniques

• Vacuum Extraction
• Soil Washing
• Solvent Extraction
• Electrokinetics
• Leach, Pump Treat

21
Vacuum Extraction

• Schematic vacuum extraction system

22
Groundwater Treatment

• Dual pumping system for groundwater treatment

23
Innovative Treatment Technologies

• Innovative Treatment Technologies
• Soil Vapour Extraction
• Bioremediation, Natural Attenuation
• Soil Washing, In-Situ Soil Flushing
• Chemical Dehalogenation
• Thermal Desorption
• Solvent Extraction
• Air Sparging
• Phytoremediation
• Treatment Walls
• Electrokinetics
• Fracturing

24
Bioremediation

• Uses naturally occurring micro-organisms
• Breaks down hazardous substances into less toxic
  or non-toxic materials
• Cost-effective, natural process
• Applicable to many common organic wastes
• Techniques can be conducted on-site
• Indigenous or Exogenous Micro-organisms
• Aerobic or Anaerobic conditions
• In-Situ or Ex-Situ

25
In-situ Bioremediation

• Permeable soils
• Bioventing
• Injection of Hydrogen Peroxide
• Groundwater

26
Bioventing
27
In-situ Chemical Oxidation
28
Ex-situ Bioremediation

• Slurry-Phase Bioremediation
• Bioreactor
• Solid-Phase Bioremediation
• Landfarming
• Soil Biopiles
• Composting

29
In-situ Biological Treatment
Idealised recirculating in-situ biological
treatmentprogramme
30
Soil Washing

• Separates silt clay from sand gravel
• Significantly reduces the volume of contaminated
  soil
• Relatively low-cost alternative for separating
  waste minimising volume for subsequent
  treatment
• Transportable technology that can be brought to
  site
• Used to treat a wide range of contaminants
• Provides a closed system, unaffected by external
  conditions
• Allows hazardous wastesto be excavated
  treatedon-site
• Has the potential to remove a wide variety of
  chemical contaminants from the soil is cost
  effective

31
Soil Washing Process
32
In-situ Soil Flushing

• Injects a washing solution into unexcavated soils
• Flushes out the contaminants
• Most effective in soils with low silt or clay
  contents
• Requires the drilling of injection extraction
  wells on-site

33
In-situ Soil Flushing

• Requires greater understanding of the sites
  geology than some other technologies
• Subsurface geological profile critical
• Extensive field investigations may be necessary
  to define the groundwater flow
• Groundwater flow must be understood
• Tailored to treat specific contaminants
• Not highly effective with cocktails

34
In-situ Soil Flushing Process
35
In-situ Soil Flushing
36
Soil Flushing

• In-situ solvent flushing

37
Phytoremediation

• Aesthetically-pleasing, passive, solar energy(!)
  driven clean-up technique
• Most useful at sites with shallow, low levels of
  contamination
• Useful for treating a wide variety of
  environmental contaminants
• Plants break down organic pollutants or
  stabilise metal contaminants
• Act as filters or traps

38
Phytoremediation

• Metals Remediation
• Phytoextraction
• Rhizofiltration
• Treating Organic Contaminants
• Phytodegradation
• Enhanced Rhizosphere Biodegradation
• Phytovolitilization

Photograph of Hybrid Poplar Field
39
Phytoremediation

• Rhizofiltration
• The absorption, concentration, precipitation of
  heavy metals by plant roots
• Phytoextraction
• The extraction accumulation of contaminants in
  harvestable plant tissues including roots
  surfaceshoots
• Phytotransformation
• The degradation of complex organic molecules to
  simple molecules the incorporation of these
  molecules intoplant tissues

40
Phytoremediation

• Phytostimulation or plant-assisted bioremediation
• The stimulation of microbial fungal degradation
  by release of exudates/enzymes into the root zone
  (rhizosphere)
• Phytostabilization
• Involving absorption precipitation of
  contaminants, principally metals, by plants,
  reducing their mobility preventing their
  migration to groundwater (leaching) or air
  (wind transport), or entry into the food chain

41
UPTAKE OF METALS

• Uptake of Nickel by Phytoextraction

42
Destruction of Organics

• Destruction of organic contaminants by
  phytodegradation

43
Chemical Dehalogenation

• Used to treat halogenated aromatic organic
  contaminants
• e.g. PCB's Dioxins
• Chemically converts toxic materials to less toxic
  or non-toxic substances
• Involves heating physically mixing
  contaminated soils with chemical reagents
• Transportable technology
• Glycolate Dehalogenation
• Base-Catalysed Decomposition Process

44
Glycolate Dehalogenation
45
Base-catalysed Decomposition
46
Natural Attenuation

• Uses naturally occurring environmental process to
  clean-up site
• Non-invasive
• Allows site to be put to productive use while
  being cleaned-up
• Requires careful study of site conditions
  monitoring of contaminant levels
• Biodegradation
• Dilution Dispersion
• Adsorption

47
Aerobic Biodegradation
48
Solvent Extraction

• Separates contaminants so that they may be
  treated individually
• Solvent separates or removes hazardous organic
  contaminants
• Does not destroy contaminant but concentrates
  them
• Can then be easily recycled or destroyed by
  another technology
• Transportable technology
• Reduces volumes of contaminated materials
• Process up to 125 tonnes of waste per day
• Designed to operate without air emissions

49
Solvent Extraction Process
50
Soil Vapour Extraction

• Pulls contaminants from soil in vapour form
• Provides an oxygen source which may stimulate
  bioremediation of some contaminants
• Very commonly used technique
• Removes VOC's SVOC's from the unsaturated zone
• SVE with Thermal Enhancement
• Dual Phase Extraction

51
Air Sparging

• Extends the effectiveness of soil vapour
  extraction to include contaminants that exist in
  groundwater
• Can accelerate clean-up at pump treat sites
• Provides an oxygen source which may stimulate
  bioremediation of some contaminants

52
Air Sparging

• Involves the injection of air or another gas,
  under pressure, into the saturated zone
• Creates subsurface bubbles or air pathways
  horizontally and vertically from the injection
  point
• Causes contacting and mixing between the injected
  gas the subsurface soil and groundwater that
  partitions contaminants into the vapour phase

53
Combined SVE Air Sparging
54
Vacuum Extraction
55
Thermal Desorption

• Heats soil at relatively low temperatures to
  vaporise contaminants remove them
• Most effective at treating VOC's, SVOC's other
  organic contaminants
• Such as PCB's, PAH's pesticides
• Useful for separating organic contaminants from
  refining wastes, coal tar wastes, wood treatment
  wastes paint wastes

56
Thermal Desorption

• Thermal Desorption System
• Pre-treatment Material Handling System
• Desorption Unit (Rotary, Direct-fired,
  Indirect-fired)
• Post Treatment System

57
Thermal Enhancements

• Soil heating effective in expelling organics
• RF heating
• Electrical resistance heating

58
Thermal Desorption Process
59
Treatment Walls

• Passive system that requires no mechanical
  equipment or energy source
• Allows the site to be put to productive use while
  they are being cleaned up
• Can be modified to treat different types of
  contaminants
• Completely breaks down some organic contaminants
• Sorption Barriers
• Precipitation Barriers
• Degradation Barriers

60
Treatment Walls
Ground Surface
Treatment Wall
Contaminated Groundwater
Clean Groundwater
Direction of Groundwater Flow
61
Treatment Walls

• Sorption

Zeolites or Active Carbon
Contaminants are pulled, unchanged, from
groundwater are held by wall surface
Treatment Wall
Clean Groundwater
Direction of Groundwater Flow
62
Treatment Walls

• Precipitation

Limestone
Contaminants are changed into solid forms that
remain in the wall
Treatment Wall
Clean Groundwater
Direction of Groundwater Flow
63
Treatment Walls

• Degradation

Iron Granules or Nutrients / Oxygen for
Biodegradation
Contaminants are broken down into harmless
products that flow through the wall
Treatment Wall
Clean Groundwater
Direction of Groundwater Flow
64
Fracturing

• Pneumatic Fracturing
• Injection of highly pressurized air into
  consolidated sediments
• Extends existing fractures
• Creates a secondary network of fissures
  channels
• Enhances fracture network
• Accelerates removal of contaminants
• Vapour extraction
• Biodegradation
• Thermal treatment

65
Pneumatic Fracturing

• Involves the injection of air or another gas
  under pressure, into unsaturated zone, creating
  micro-fractures for the advective transport of
  contaminants
• Increases the number of subsurface pathways for
  advective flow
• Results in increased contaminant mass removal
  accelerated remediation

66
Fracturing

• Hydrofracturing
• Creates distinct sand filled fractures in low
  permeability over-consolidated clays or
  sediments
• Fractures serve as avenues for bioremediation,
  steam or hot air injection

67
Electrokinetics

• Process that separates extracts heavy metals,
  radionuclides organic contaminants from
  saturated soils, sludges sediments
• Electro-osmosis

68
Geochemical Fixation

• Geochemically fixes inorganic contaminants
  in-place
• Introduces chemical reagents
• Capable of altering pH or redox conditions to
  render the inorganic insoluble
• Geochemically react with metal or metal complex
  with natural soil or sediment material
• Cleaning up, or "fixing," the inorganic
  contaminant in-place

69
Selected References

• Harris J., Birch P. Palmer J. (1996) Land
  Restoration Reclamation - Principles
  Practice, Longman
• Cairney T. (1987) Reclaiming Contaminated Land.
  Blackie.
• Smith M.A. (1985) Contaminated Land Reclamation
  Treatment. Plenum.
• Welsh Development Agency (1993) The WDA Manual on
  the remediation of Contaminated Land. WDA.
• Richards I.G. et al (1993) The Reclamation of
  Former Coal Mines Steelworks. Elsevier.

70
Web Resources

• Hazardous Waste Clean-up Information
• http//www.clu-in.com
• Citizen's Guides to Understanding Innovative
  Treatment Technologies
• http//www.clu-in.com/citguide.htm
• Remediation Technologies Screening Matrix
  Reference Guide
• http//www.clu-in.com/remed1.htm
• Internet On-line Resources
• http//www.clu-in.com/resourc1.htm

71
Web Resources

• US EPA Technology Innovation Office
• http//www.clu-in.org/

72
Web Resources

• Tool Kit of Information Resources for Brownfields
  Investigation and Cleanup
• http//www.clu-in.org/products/toolkit99/start.htm

73
Web Resources

• Terra Vac
• http//www.terravac.com/
• Ground-water Remediation Technologies Analysis
  Centre
• www.gwrtac.org
