l2tpd - L2TP for Unix

1
l2tpd - L2TP for Unix

• Land of confusion

2
Overview of L2TP protocol
3
Layer 2 Tunnelling Protocol

• Product of the PPP Extensions working group of
  the IETF
• Largely builds on the work done with L2F at Cisco
• Backwards compatible with L2F

4
L2TP features

• Encapsulates PPP
• Utilizes UDP
• Reliable Signalling channel ("Control
  Connection")
• Unreliable Data Channel
• Data Channel sequencing
• Tunnel level authentication

5
Applications for L2TP

• Half of a secure VPN implementation
• Overlay network
• Avoid University firewalls
• Remote static IP address
• Global addressing behind NAT

6
L2TP Header Format
1 1 1 1 1 1 0 1 2 3 4 5 6 7
8 9 0 1 2 3 4 5 ----------------
TLxxSxOPxxxxVersion --------
-------- Length (opt.)
----------------
Tunnel ID --------------
-- Session ID
----------------
Sequence Number (Ns) -----------
----- Expected Sequence Number (Nr)
---------------- Offset
Size (opt.) ---------------
- Offset Pad (opt.)
----------------
TType bit Set for control packets LLength
bit Set if Length field is present SSequence
bit Set if sequence numbers are present,
always set for Control messages OOffset bit
Set if offset field is present Rarely
used PPriority bit Set if this packet should
be given preferential treatment I've
never seen this used Version Set to 2
currently, 1 indicates L2F as it used
substantially the same header format
7
L2TP Header Format
1 1 1 1 1 1 0 1 2 3 4 5 6 7
8 9 0 1 2 3 4 5 ----------------
TLxxSxOPxxxxVersion --------
-------- Length (opt.)
----------------
Tunnel ID --------------
-- Session ID
----------------
Sequence Number (Ns) -----------
----- Expected Sequence Number (Nr)
---------------- Offset
Size (opt.) ---------------
- Offset Pad (opt.)
----------------
Length Total length of L2TP packet Tunnel ID
Identifies Tunnel that this packet is
associated with Session ID Identifies Session
within the tunnel that this packet is
associated with Sequence Number (Ns) Start
with 0, increment for each packet in
tunnel Expected Sequence Number (Nr) Sequence
number expected in next packet from
peer Offset Size Size, in octets of Offset
Pad field Offset Pad Undefined filler
8
L2TP AVP Format
1 1 1 1 1 1 0 1 2 3 4 5 6 7
8 9 0 1 2 3 4 5 ----------------
MH rsvd Length
----------------
Vendor ID -------------
--- Attribute Type
----------------
Attribute Value ------------
---- ...until length is reached...
----------------
MMandatory bit If you don't understand this
AVP, shut down the tunnel or
session HHidden bit This attribute is
"hidden" Length Overall length of the AVP,
including these headers (minimum value of
6) Vendor ID 0 for IETF defined
AVP's Attribute Type What attribute is
this? Attribute Value Actual attribute data
(if Length field is 6, this field is
absent)
9
L2TP Message Types

• 1 - SCCRQ - Start Control Connection ReQuest
• 2 - SCCRP - Start Control Connection RePly
• 3 - SCCCN - Start Connection Control CoNnected
• 4 - StopCCN - Stop Control Connection
  Notification
• 6 - HELLO - HELLO
• 7 - OCRQ - Outgoing Call ReQuest
• 8 - OCRP - Outgoing Call RePly
• 9 - OCCN - Outgoing Call CoNnected
• 10 - ICRQ - Incoming Call ReQuest
• 11 - ICRP - Incoming Call RePly
• 12 - ICCN - Incoming Call CoNnected
• 14 - CDN - Call Disconnect Notification
• 15 - WEN - Wan Error Notify
• 16 - SLI - Set Link Info

10
The Future of L2TP - L2TPv3

• New data channel header format
• Clarify ambiguities in current standard
• Encapsulates other types of frames than PPP (work
  with PWE3 - Pseudo Wire Emulation Edge to Edge)
• Ethernet
• Frame relay
• Circuit emulation

11
Overview of l2tpd software package
12
History of l2tpd

• Originally written by Mark Spencer
  http//marko.net last version 0.60
• Forked in 2000 by Scott Balmos and David Stipp,
  hosted on Sourceforge http//sf.net/projects/l2tpd

• Turned over control in Jan. 2002 to me
• Obtained support of Mark Spencer for further
  development as well
• Further detail at http//www.l2tpd.org/history.htm
  l

13
l2tpd features

• Tunnel level authentication (currently broken)
• Works as both LNS and LAC (only with PPP on same
  system)
• "Autodial"
• pre-configured peers
• "interactive" control (named pipe)

14
Known bugs

• Challenge Response authentication on tunnels
  broken
• Data channel sequencing support doesn't exist
• pty handling is horrible, though works after a
  fashion
• Session and tunnel shutdown works, barely

15
l2tpd - current work directions

• Bugfixing, bugfixing, bugfixing
• Easily integrated new features (data sequencing)
• Knobs for interoperability
• Did I mention bugfixing?
• No significant new feature work

16
l2tpd-devel

• What I'm calling the "next-generation" l2tpd
• No working code available yet
• kernel-module
• pppd plugin
• l2tpd daemon

17
"Interactive" use of l2tpd
echo "t 204.255.233.225" gt /var/run/l2tp-control
Standard output of l2tpd gives you a tunnel
ID control_finish Connection established to
204.255.233.225, 1701. Local 17767, Remote
86. echo "c 17767" gt /var/run/l2tp-control
18
/etc/l2tp/l2tpd.conf
global port 1701 lns default ip range
192.168.0.1-192.168.0.2 lac 10.0.0.0 -
10.255.255.255 hidden bit no refuse chap
yes require authentication yes ppp debug
yes lac cindsl01 lns 204.255.233.225 autodial
yes lac iostest lns 199.170.85.70
19
l2tpd compared to other tunnelling technologies
20
Why L2TP vs. IPSec Tunnel Mode
L2TP
IPSec Tunnel

• Multi-Protocol
• Authentication flexibility
• Works via NAT
• Multi-Link PPP avoids MTU issues

• Encryption
• Encryption
• Encryption
• Protocol overhead

21
Why L2TP vs. PPTP
L2TP
PPTP

• Open standard
• Not Microsoft - 'nuff said

• Weak encryption
• Microsoft
• Non-standard

22
Why L2TP vs. GRE or IPIP
L2TP
GRE/IPIP

• Scaleability
• Control protocol mechanism
• Authentication
• Multi-protocol

• Low protocol overhead
• Simple configuration
• No dependancy on PPP

23
Why L2TP vs. VTun
L2TP
VTun

• Interoperability
• Open standard

• Can carry varied types of traffic
• Open
• Encryption
• Traffic Shaping
