Measures of Association and Regression Introduction

1
Measures of Association and Regression
Introduction
2
Measures of Association

• Ask the question, How strong is the
  relationship? or How well can we predict y
  using x
• What is the difference between MoA and...
• Chi-Square or other hypothesis test results
• Recall difference between regression and
  correlation

3
How Strong is the Relationship?
4
How Strong is the Relationship?

• Without an independent variable, our best
  prediction is a measure of central tendency
  (mode)
• With an independent variable, we might be able to
  improve our ability to predict the dependent
  variable.
• How much better can we predict the dependent
  variable with another variable than when we only
  had the mode?

5
Gender and Guns

• ModeFavor Gun Ban
• If all we knew was this, our best prediction
  would be that everyone favors the gun ban.
• We would be right 807 times and we would be in
  error 707 times

6
Gender and Guns

• When we add gender to the mix we would predict
  that all females favor (449 right, 226 wrong) and
  all males oppose (481 right, 358 wrong)
• That gives us a total of 930 right predictions
  and 584 errors

7
How much better do we do?

• Without knowing gender, we made 707 errors
• Knowing gender, we reduced that to 584 errors
• We made 123 fewer errors by knowing gender.
• We can show as a proportion, how big the
  reduction in error is

We make about 18 fewer errors than we did
knowing the mode alone.
8
Proportional Reduction of Error

• This framework is called PRE
• This measure, lambda (?), is appropriate for
  crosstabs that involve a nominal variable
• Similar logic can be applied to analyses of two
  ordinal variables

9
Ordinal PRE Measures

• Basic Logic
• Look at each case
• Did the measure of central tendency alone get it
  right?
• Did adding the ind. Variable get it right?
• Compare to see which is better
• Criterion for good choices?
• Fits your research needs
• Conservative estimate

10
Choices

• Gamma
• Drops cases that are ties
• Overestimates strength
• Kendalls tau-b
• Allows for ties, best for square tables
• Kendalls tau-c
• Allows for ties, best for non-square tables
• Somers d
• Variant of tau statistics, not quite as common

11
Nominal Measures

• If one or both variables are nominal, you should
  use lambda (?).
• Sometimes lambda doesnt work well

• Because we predict that all women approve and
  that all men approve, we get the same prediction!
  We need something else

12
Cramers V (aka phi / f)

• We know that the ?2 statistic said there is a
  real relationship, so we know that its strength
  is greater than 0.
• Cramers V is a mathematical manipulation of the
  ?2 statistic that turns it into a measure of
  association.
• where m is the less of
  (r-1) and (c-1)
• This is not a PRE measure of association, though,
  so its interpretation is a little different.

13
Interpreting PRE MoAs

• All lie on the interval -1,1
• SPSS will calculate them all for you.
• General Guidelines

14
Interpreting PRE MoAs

• SPSS may or may not get the direction of the
  association right (positive or negative). It
  depends on how the variables are coded.
• You should place the appropriate sign by your
  measure of association (but not by Cramers V,
  its always positive)
• Tells you the proportion of errors made by the
  measure of central tendency alone that are no
  longer errors when we add the independent variable

15
Interpreting Cramers V

• For our purposes, you may use the same table as
  for PRE results (weak, moderate)
• You cannot interpret it in terms of reduction of
  error.

16
Directionality

• Some tests are directional while others are
  symmetric
• In directional tests, you get different answers
  depending on which variable is the D.V. and which
  is the I.V.
• In symmetric tests, the answer is the same
• Given the option, choose the directional test and
  specify the right D.V.

17
Finally,

• We only observe a sample, and Cramers V or any
  of the PRE MoAs could be 0 in the population, and
  we observe one higher than 0 by sampling error
  only!
• We can do tests of significance on many of these
• SPSS will do this for you, I wont make you do it
  by hand.

18
Regression
19
Multiple Variables

• So far, we have learned
• How to analyze one variable at a time (CI)
• How to compare two means or proportions (a
  relationship between one variable measured at any
  level and a nominal or ordinal variable with two
  categories)
• How to compare relationships between two nominal
  or ordinal level variables with any number of
  categories (using simple crosstabs)
• Today, we learn about relationships between two
  interval-level variables.

20
Two Interests

• Magnitude of relationship between the independent
  variable and the dependent variable (how much
  change in one yields how much change in the
  other).
• Correlation the predictive power of one variable
  on another. This is a Measure of Association
  (but not a PRE Measure of Association)

21
Correlation
22
Types of Correlation

• Positive Correlation An increase in one variable
  results in an increase in the other
• Negative Correlation An increase in one variable
  results in a decrease in the other.

23
Correlation analysis asks

• How good a predictor is the independent
  Variable of the dependent variable?
• How good a predictor of income is education?
• How accurate is our prediction of the effect of
  education on income?
• How close are the Dots to the line
• It is a Measure of Association

24
Computing the Correlation Coefficient, Pearsons r

• Assess how much X and Y move together
  (covariance) out of the amount they move
  individually (variance)

25
Computing r in STATA

• corr var1 var2 var100
• Output looks like this

. corr unemplyd mdnincm flood age65 black
(obs427) unemplyd mdnincm flood
age65 black ------------------------------
--------------------------- unemplyd 1.0000
mdnincm -0.4960 1.0000 flood 0.0827
0.0083 1.0000 age65 0.0319 -0.1634
-0.0272 1.0000 black 0.5037 -0.3065
0.0703 -0.1038 1.0000
26
Interpreting the Correlation Coefficient
27
Note Correlation is Linear
r 0
r .9
r 0
r .8
28
Correlation and Regression

• Regression effects are depicted by the slope of
  the line.
• Correlation can be seen as the spread of points
  around the regression line. The greater the
  amount of spread of points around the regression
  line, the less predictive is X of Y and
  consequently, the weaker the correlation.

29
Correlation 1 Slope 1
30
Correlation 1 Slope -2
31
Imperfect Correlation and Relationships

• We rarely see perfect correlation
• However, even with imperfect correlation, we can
  have some expectation of what will happen on
  average.
• While Correlation is never perfect, we can draw a
  line to summarize the trend in the data points.
  This is the Regression Line

32
Formula for a line

• y mx b (algebraic)
• y a bx (statistical)
• It is the same thing. Well add one more thing
  error
• yi a bx ei is called the sample regression
  function
• Yi a ßx ei is called the population
  regression function

33
Making Predictions
34
Establishing Relationships
35
Establishing Relationships
Now Add 5 years of education
10 Years of Education Means about 12,000 Income
It adds an Additional 4,000 of Income!
36
Where do we Draw the Line?

• Least Squares Principle
• Under the Gauss-Markov assumptions, the Ordinary
  Least Squares estimator is the Best Linear
  Unbiased Estimator
• OLS is BLUE

37
What is the estimator?

• In the bivariate case (1 dependent, 1
  independent), the least squares principle gives
  us these equations for calculating the slope and
  intercept.

38
(No Transcript)
39
Calculating a and b

• b 54.73 / 4.19 13.06
• a 235.7 b (11.2)
• 235.7 13(11.2)
• 235.7 146.27
• 89.43

40
STATA command for Regression

• regress y x
• Output looks like this

. regress turnout diplomau Source
SS df MS Number of obs
426 -------------------------------------------
F( 1, 424) 55.40 Model
1.2806e11 1 1.2806e11 Prob gt F
0.0000 Residual 9.8018e11 424
2.3117e09 R-squared
0.1156 ------------------------------------------
- Adj R-squared 0.1135 Total
1.1082e12 425 2.6076e09 Root MSE
48081 ------------------------------------------
------------------------------- turnout
Coef. Std. Err. t Pgtt 95 Conf.
Interval ---------------------------------------
-------------------------------- diplomau
2164.063 290.7549 7.44 0.000 1592.563
2735.564 _cons 172999.4 6300.284
27.46 0.000 160615.7 185383.1 --------------
--------------------------------------------------
--------
41
How do we interpret it?

• For now, we look at one key thing coefficients
  (slope and intercept)
• 172999.4 2164.073 x
• Every 1 unit increase in the percentage of
  university diploma holders increases voter
  turnout by 2,164 votes, on average.
• If there was a district with no university
  diploma holders, we would expect 172,999 people
  to turnout, on average.
