Title: Thermodynamics and Energy


1
Thermodynamics and Energy
  • Basic Concepts

2
Thermodynamics
  • Science of Energy
  • What is Energy?
  • Ability to cause change
  • Thermodynamics
  • Greek words therme (heat) and dynamis (power) or
    Turn heat into power
  • Now includes all aspects of energy and energy
    transformations

3
Laws of Energy
  • Conservation of Energy Principle
  • Energy can change from one form to another but
    total amount remains constant
  • First Law of Thermodynamics
  • Can neither create nor destroy energy
  • Second Law of Thermodynamics
  • Energy has quality as well as quantity

4
History
  • Early work in 1850s by
  • William Rankine
  • Rudolph Clausius
  • Lord Kelvin (William Thompson)

5
Thermodynamics
  • Classical thermodynamics
  • Macroscopic view
  • Looks at results of actions at overall level
  • Statistical thermodynamics
  • Microscopic view
  • Looks at actions at individual particle level
  • Most engineering work at macroscopic level.

6
Units
  • Base units
  • Mass, m (or force), length, L, time, t,
    temperature, T
  • Derived units
  • Velocity, V, energy, E, volume, v

7
Units
  • Systems
  • SI, international
  • Mass based
  • Decimal system
  • English (US Customary System, USCS)
  • Force based (gravitational)
  • Unique relationships abound

8
Key Units
9
Key Units
  • Newton (N) force required to accelerate a mass
    of one kg at a rate of one meter/second2
  • Pound-force (lbf) force required to accelerate a
    mass of 32.174 lbm (1 slug) at a rate of one
    foot/second2
  • Weight is a force, mass is not weight

10
Key Units
  • Specific weight ? weight per unit volume or ?
    ?g where ? is density and g is the gravitational
    constant.
  • Work (energy) force times distance, newton-meter
    (Nm) called a joule (J)
  • Energy is English system is BTU energy required
    to raise the temperature of 1 lbm of water at
    68F by 1F.
  • 1BTU 1.0551 kJ

11
Dimensional Homogeneity
12
Systems and Control Volumes
  • System a quantity of matter or a region in space
    chosen for study
  • Surroundings everything outside the system
  • Boundary the surface that separates the system
    and the surroundings

13
Systems and Control Volumes
14
Systems and Control Volumes
  • Closed System (Control Mass) fixed amount of
    mass, no mass can cross boundary, energy can
    cross boundary
  • Special case no energy crosses boundary,
    isolated system

15
Systems and Control Volumes
16
Systems and Control Volumes
  • Open Systems (Control Volumes) selected region
    in space, both mass and energy cross the boundary
    of the system

17
Systems and Control Volumes
18
Systems and Control Volumes
19
Properties of a System
  • Characteristics of a system are called Properties
  • Examples pressure, temperature, mass, volume
  • Intensive Properties independent of mass of
    system
  • Temperature, density, pressure
  • Extensive Properties value depends on size or
    extent of system
  • Total mass, total volume, total momentum

20
Properties
21
Extensive Properties
  • Properties per unit mass are called Specific
    Properties
  • Examples specific volume v V/m
    specific total energy e E/m
  • Convention extensive properties, upper case,
    intensive properties, lower case
  • Exceptions mass, pressure, temperature

22
Continuum
  • An assumption that allows us to work problems
  • Disregards atomic nature of substance
  • Continuum assumption allows
  • Treat properties as point functions
  • Properties vary continually in space

23
Density and Specific Gravity
  • Density mass per unit volume
  • ? m/V (kg/m3)
  • Specific Volume volume per unit mass
  • V V/m 1/? (m3/kg)
  • Specific Gravity ratio of the density of a
    substance to the density of a standard substance
    at a give temperature.
  • SG ?/?water (also called relative density)

24
Density and Specific Gravity
25
Specific Weight
  • The weight of a unit volume of a substance is
    called specific weight
  • ?s ?g (N/m3)

26
State
  • State is when all the properties of a system have
    fixed, unchanging, values
  • A system is said to be at a state when all the
    properties in the system can be measured or
    calculated and the system is not undergoing a
    change.

27
State
28
Equilibrium
  • Equilibrium implies a state of balance, no
    unbalanced driving forces in the system
  • Equilibrium types
  • Thermal system at same temperature
  • Mechanical consistent pressure
  • Phase at equilibrium level
  • Chemical no chemical reactions occur

29
State Postulate
  • State postulate the state of a simple
    compressible system is completely specified by
    two independent, intensive properties
  • Simple compressible system if no electrical,
    magnetic, gravitational, motion, surface tension
    effects
  • Independent if one can be varied while the other
    is held constant

30
State
31
Processes and Cycles
  • Any change that a system undergoes from one
    equilibrium state to another is called a process
  • The series of states through which a system
    passes during a process is called a path of the
    process

32
Processes
  • To describe a process completely need
  • Initial and final states
  • Path it follows
  • Interactions with surroundings

33
Quasi- Processes
  • When a process moves so slowly that all parts of
    the system change at the same rate and are in
    equilibrium with all other parts of the system,
    the process is called quasi-static or a
    quasi-equilibrium process
  • A quasi-equilibrium process is an idealized
    process and does not occur in nature.
  • Serve as a standard to be compared to

34
Iso- processes
  • Iso- processes are processes that one property
    remains constant
  • Isothermal temperature
  • Isobaric pressure
  • Isochoric, isometric specific volume

35
Cycle
  • Special process where the process at the final
    state returns to the initial state

36
Steady-Flow Process
  • Steady no change with time
  • Uniform no change with location over a specific
    region
  • Opposite of steady unsteady or transient

37
Steady-Flow Process
  • Steady-flow process is a process during which a
    fluid flows through a control volume steadily

38
Steady-Flow Process
  • Under steady-flow conditions, the mass and energy
    contents of a control volume remain constant

39
Temperature
  • Relative freezing cold, cold, warm, hot, red-hot
  • Reference to know events, solidifying of water,
    vaporizing of water

40
Thermal Equilibrium
  • Thermal equilibrium occurs when no temperature
    gradient exists, both objects are at same
    temperature

41
Zeroth Law
  • If two bodies are in thermal equilibrium with a
    third body, the are in thermal equilibrium with
    each other.
  • Two bodies are in thermal equilibrium if both
    have the same temperature, even is they are not
    in contact.

42
Temperature Scales
  • Relative or Two Point Scales
  • Based on temperature of ice/liquid water and
    liquid water/water vapor mixtures
  • SI system Celsius scale based on 100 units
    between points (C)
  • English system Fahrenheit scale based on 180
    units between points with lower point set at 32
    units (F)

43
Temperature Scales
  • Thermodynamic temperature scales, absolute scales
  • Based on absolute zero temperature
  • SI system Kelvin scale, freezing point of water
    at 273.15 units (K)
  • English system Rankine scale, freezing point of
    water at 459.67 units (R)
  • Ideal-gas temperature scale

44
Temperature Relationships
  • Kelvin to Celsius T(K) T(C) 273.15
  • Rankine to Fahrenheit
    T(R) T(F) 459.67
  • Between the English and SI systems
  • T(R) 1.8T(K)
  • T(F) 1.8T(C) 32

45
Temperature Relationships
  • Note that
  • ?T(K) ?T(C)
  • ?T(R) ?T(F)

46
Pressure
  • Pressure is a normal force exerted by a fluid per
    unit area
  • Units, force/unit area, N/m2, called a pascal
    (Pa)
  • 1 bar 105 Pa 0.1 MPa 100 kPa
  • 1 atm 101.325 kPa 1.01325 bars

47
Pressure
  • Absolute pressure relative to absolute vacuum
    (absolute zero pressure)
  • Gage pressure relative to atmospheric pressure
  • Pgage Pabs - Patm
  • Pvac Patm Pabs

48
Pressure
49
Pressure with Depth
  • ?P P2 P1 ?g?z ?s?z
  • P Patm ?gh or Pgage ?gh

50
Pressure with Depth
51
Pressure
52
Pressure
53
Pressure
54
Problem-Solving Technique
  • Problem statement
  • Schematic
  • Assumptions approximations
  • Physical laws
  • Properties
  • Calculations
  • Reasoning, verification, discussion
