Optimizing Recursive Information Gathering Plans

1
Optimizing Recursive Information Gathering Plans
Eric Lambrecht, Subbarao Kambhampati Senthil
Gnanaprakasam Arizona State University Tempe,
USA rakaposhi.eas.asu.edu/yochan.html
2
Information Gathering
user
Gatherer
wrapper
db
wrapper
lthtmlgt
cgi
3
EMERAC Query Planning System
Build query plan using source inversion
Execution Optimizations Source call ordering
Logical OptimizationsRedundancy removal
Execute query plan
Duschka (with Genesereth Levy) 97
Optimization steps
4
Organization

• Optimization challenges in EMERAC
• Building Source Complete Plans Review
• Logical optimization
• Minimization of recursive IG plans by removing
  redundant source calls
• Execution optimization
• Ordering source calls to minimize both access and
  tuple-transfer costs
• Implementation and Results
• Contributions

5
Modeling Information Gathering

• Information sources
• relational
• answer select queries (possibly a restricted
  set of query patterns)
• autonomous
• World model
• relational
• Query on the world model
• Reformulate the query as calls on information
  sources. Optimize. Execute.

Local as View model
6
Modeling Sources
Sources related to world model by describing them
as views over world model
movie-hut(X, Y) -gt title-time(X, Y),
title-actor(X, Z)
house-of-movies(X, Y) -gt title-time(X, Y),
title-actor(X, Z)
query(X, Y) - title-time(X, Y)
Required binding..
7
Optimization challenges in EMERAC
Traditional
Information Gathering

• Multiple sources export partial and overlapping
  portions of a relation
• Need to minimize plans to remove redundancy
• Sources are rarely fully relational
• Only limited types of queries allowed
• Wrapped web-pages
• Form-interfaced databases
• Certain forms of join computation may be
  precluded
• Need to model query capabilities

• Each relation is exported in to-to by a single
  database
• All sources are assumed to be fully relational

8
Continued
Optimization challenges in EMERAC

• Tuple-transfer costs are assumed to dominate the
  query-execution costs
• Use of Bound-is-easier assumption
• Assume availability of full source-statistics
• Selectivity indices, histograms etc.

• Access cost source latencies tend to equal or
  dominate the transfer cost
• Need to consider number of source calls
• Need for considering bushy joins (instead of just
  left-linear join trees)
• Full statistics are rarely available about
  internet sources
• Sources are decentralized and autonomous
• Difficult to do systematic optimization

9
Source Access Limitations

• Sources can have a variety of access limitations
• Form interfaced databases may require certain
  attributes to be bound
• Whitepages may require the name of the person
• To get the numbers of a set of n people, we will
  have to access the source n times
• and may be unable to handle bindings of other
  attributes
• A Whitepages database may not take the address of
  a person as a bound attribute
• To get the number of John Doe, who lives on Lemon
  St, we will have to get the numbers of all John
  Does, and locally filter the ones not living on
  Lemon Street
• Wrapped web-pages cannot select over any
  attributes

10
Representing Source Access Limitations

• Use annotations on the attributes of the source
  relation
• annotation identifies attributes that must be
  bound
• annotation identifies un-selectable
  attributes
• S(X,Y,Z)
• A form-interfaced web-page that requires bindings
  for X and is able to do selections only on Z.
• and annotations help identify feasible
  binding patterns for sources
• Sb-- are feasible Sf-- are infeasible
• Sbbf must be modeled as Sbff filtered locally
  with binding on Y

11
Properties of optimal information gathering plans

• Source-complete no other plan returns more
  information using the available sources
• Source-minimal a plan for which no information
  source can be removed, yet the plan returns the
  same answer.
• Access-cost minimal a plan which reduces the
  number of separate accesses to individual sources
• Bandwidth-minimal a plan that, when executed,
  transfers the smallest amount of data over the
  network yet is still source complete

12
Ensuring properties of optimal information
gathering plans
Build query plan
Logical Optimizations
Execution Optimizations
Execute query plan
Source completeness
Source-minimality
Access cost and bandwidth minimality
13
Building Source Complete Plans
Duschka, Genesereth 97
query(X, Y) - title-time(X, Y)

• movie-hut(X, Y) -gt title-time(X, Y),
  title-actor(X, Z)

house-of-movies(X, Y) -gt title-time(X, Y),
title-actor(X, Z)
Source Inversion Rules
title-time(X, Y) -
movie-hut(X, Y)
ltX, f1(X, Y)gt
title-actor (X, X, Y) - movie-hut(X,
Y)
dom(X) - movie-hut(X, Y)
dom(Y) - movie-hut(X, Y)
title-time(X, Y) - dom(X),
house-of-movies(X, Y)
ltX, f2(X, Y)gt
title-actor (X, X, Y) - dom(X),
house-of-movies(X, Y)
dom(Y) - dom(X), house-of-movies(X, Y)
query(X, Y) - title-time(X, Y)
Binding restrictions lead to recursion in the plan
14
Problems with Plans derived from source inversion
rules

• Every source that is remotely relevant to the
  query is made part of the plan
• Many of these sources may be overlapping

title-time(X, Y) -
movie-hut(X, Y) title-actor (Y, X, Y)
- movie-hut(X, Y)
dom(X) - movie-hut(X, Y)
dom(Y) - movie-hut(X, Y)
ltX, f1(X, Y)gt

• If both movie-hut and house-of-movies have same
  information
• both sources are not necessary
• the recursion is not necessary

title-time(X, Y) - dom(X),
house-of-movies(X, Y) title-actor (Y,
X, Y) - dom(X), house-of-movies(X, Y)
dom(Y) - dom(X),
house-of-movies(X, Y)
query(X,Y) - title-time(X, Y)
ltX, f2(X, Y)gt
15
Minimizing information gathering plans

• Model source overlaps
• Use LCW statements
• Rewrite the source-complete plan
• Greedily remove rules from plan with uniform
  equivalence and LCW statements ( make the plan
  source-minimal)
• Uniform containment checks Sagiv, 88
• Use heuristics to guide removal and pull out
  recursion first

16
LCW Statements
View movie-hut(X, Y) -gt title-time(X, Y),
title-actor(X, Z) LCW movie-hut(X, Y) lt-
title-time(X, Y), title-actor(X, Z) To check if
one rule, r , with information source predicates
contains another rule, r , see if r s s l
contains r s s v
1
2
1
2
Inter-source subsumption relations Mirror
sources can also be handled
Etzioni et al 97, Duschka 97
17
Uniform Equivalence

• Equivalence
• Two datalog programs X and Y are equivalent if,
  for every set of extensional predicates, the two
  programs produce the same output.
• Undecidable
• Uniform Equivalence
• X and Y are equivalent if, for every set of
  extensional and intensional predicates the two
  plans produce the same output
• Decidable
• Implies equivalence

Sagiv 88
18
Testing for Uniform Containment
p(X, Y) - q(X, Y) q(X, Y) - r(X, Y)
uniformly contain
p(W, X) - r(W, X)
?
does
assert r(W, X) and try to derive p(W, X)
19
Greedily Minimizing Information Gathering Plans

• Remove non-recursive IDB predicates
• Sort the rules so those with dom predicates come
  before those without dom predicates
• for each rule r do
• let r be a rule of P that has not yet been
  considered
• let P be the program obtained by deleting rule r
  from P
• if Ps s l uniformly contains rs s
  v then
• replace P with P. Prune unreachable rules.

Source costs can be used



Uniform containment check is exponential in the
worst case
20
Minimization example
title-time(X, Y) -
movie-hut(X, Y)
ltX, f1(X, Y)gt
title-actor (X, X, Y) - movie-hut(X,
Y)
dom(X) - movie-hut(X, Y)
dom(Y) - movie-hut(X, Y)
title-time(X, Y) - dom(X),
house-of-movies(X, Y)
ltX, f2(X, Y)gt
title-actor (X, X, Y) - dom(X),
house-of-movies(X, Y)
dom(Y) - dom(X), house-of-movies(X, Y)
query(X, Y) - title-time(X, Y)
movie-hut(X, Y) lt- title-time(X, Y),
title-actor(X, Z)
21
Relating binding patterns

• Generality of binding patterns
• Sp is more general than Sq if every
  non--annotated attribute that is free in q is
  also free in p (but not vice versa)
• Call to S with binding pattern p will subsume the
  results of call to S with binding pattern q
• For S(X,Y,Z), Sbbf is more general than Sbfb
• Holds only because of annotations
• (B) is the number of bound variables in the
  binding pattern B that are not -annotated
• (.) is used to relate binding patterns of
  different sources (as in bound-is-easier
  assumption)

22
EMERAC
Build query plan
Logical Optimizations
Execution Optimizations
Execute query plan
Source completeness
Source-minimality
Access cost and bandwidth minimality
23
Issues in ordering source calls

• Execution cost is a function of both access cost
  and the tuple-transfer cost (ignoring local
  processing costs)
• Tension between access costs traffic costs
• E.g. Execute S1(W,X) S2(X,Y) where the query
  binds W
• Tuple-transfer cost reduction motivates calling
  sources with the least general binding patterns
  possible
• Bound-is-easier (S1 first, and then feed X
  bindings to S2)
• Access cost reduction motivates calling sources
  with the most general binding patterns possible
• Feeding X bindings for S2 will generate many
  separate accesses, increasing the access cost

24
Our Approach Assumptions

• Exact optimization is not worth it
• Lack of full source statistics
• NP-hardness of the optimization problem
• Join-ordering, which is a special case, is
  already NP-Complete
• Source access costs dominate tuple-transfer costs
  by default
• Reasonable given the large setup and latency
  costs for internet sources

25
Our Approach Overview

• A greedy approach (along the lines of
  bound-is-easier type procedures)
• By default, attempts to access each source with
  the most general feasible binding pattern
• Reasonable given the assumption that access costs
  dominate transfer costs
• The default is over-ridden if a binding pattern
  is known to produce too much traffic
• Binding patterns producing high traffic are
  stored in a table called HTBP
• Implicitly produces bushy join trees

26
The HTBP Table

• The HTBP table contains, for every source S, the
  least general binding patterns of S which are
  known to produce high traffic
• A call to source S with binding pattern B is
  considered high-traffic producing, if HTBP
  contains SB and B is either equal or more
  general than B
• E.g. Book(Author,Title,ISBN,Subj,Price,Pages)
• HTBP may contain all binding patterns that do not
  bind at least one of the first four attributes
• Bookffffbb listed explicitly in HTBP
• Bookfffffb Bookfffffbf Bookffffff would be
  considered to be implicitly in HTBP
• Advantage HTBP should be easy to specify even if
  full source statistics are not available

27
The Algorithm
For each stage i from 1 to m do For each
unchosen subgoal S pick the most general
feasible BP B of S w.r.t.
V FBP such that B is not in HTBP.
If such a B exists, Push SB
into Ci. Mark S chosen. Add
all variables of S to V If no such B
exists, but there is a feasible binding pattern
for S Pick the BP B with most
bound variables (in terms of (.))
Push SB into Pi If no subgoal has
been chosen at this level (Ci is empty),
and there are some postponed
sources (Pi is non-empty) Choose
SkB in Pi with the maximum (B) value
Push SkB into Ci Add all
variables of Sk to V Return the array C1m

Default case Reduce accesses
HTBP case Reduce transfer costs
28
Example

• Sources DP(AAuthor,TTitle,YYear)
• SM98(TTitle,UURL)
• Query Q(A,T,U,1998)
• Plan Q(A,T,U,1998) - DP(A,T,1998)
  SM98(T,U)

HTBP DPbbb SM98bb Step 1. VY Cand DPfff
DPffb SM98ff XX XX
XX P1 DPffb SM98ff C1
DPffb Step 2. VA,T,Y Cand SM98ff SM98bf
XX XX P2SM98bf
C2SM98bf
HTBP DPffb Step 1. VY Cand DPfff DPffb
SM98ff XX XX C1
SM98ff Step 2. VY, U, T Cand DPfff DPffb
DPfbf DPfbb XX XX
XX C2 DPfbf
HTBP Step 1. VY Cand DPfff DPffb
SM98ff C1 SM98ff
DPfff
Bound-is-easier
29
Implementation
Implemented the technique in the Emerac
Information Gatherer Experimented with
simulated sources derived form DBLP data --
Our approach tended to reduce the total cost over
bound-is-easier approach whenever there were
significant number of binding patterns that are
not subsumed by HBTP
A prototype Information Gatherer written in
JAVA --Incorporates recursive plan
minimization execution ordering --Threading
execution Partial results returned asynchronously
30
Implementation

• The Emerac Information Gatherer
• written in Java
• incorporates rewriting and execution ordering
  techniques
• executes plans in parallel
• returns partial results during plan execution
• object oriented design makes it easy to modify

31
Experiments

• Experimented with simulated sources derived form
  DBLP data
• Our minimization approach reduces access costs by
  removing redundant recursive sources
• Minimization cost offset by the improvements in
  execution time
• Our source ordering approach tended to reduce the
  total cost over bound-is-easier approach whenever
  there were significant number of binding patterns
  that are not subsumed by HBTP

32
LCW vs. Naïve Artificial Sources
33
LCW vs. Naïve DBLP Sources
34
Graceful degradation
35
Contributions

• An approach for minimizing recursive information
  gathering plans
• An approach for ordering source calls in
  information gathering plans
• Attempts at minimizing both access cost and
  tuple-transfer cost
• Implementation Evaluation in EMERAC

36
Current directions

• Integrate minimization source-call ordering
  phases
• Model cost-quality tradeoffs
• Handling run-time exceptions
• unavailability of sources etc.
• Tracking time and solution quality statistics
• Improve the granularity of the HTBP table
