Biology 1110 Lab

1
Biology - 1110 Lab
2

• Your Instructor Colleen Roden
• A few things about me
• Undergraduate work done at TTU
• Working on M.S. in Microbiology
• Working towards Ph.D. in Immunology, emphasizing
  in research
• Previously taught overseas.

3
The 1110 Lab

• Designed for Science Majors!!
• The lab counts as 1/4 the course grade
• Lab syllabus guidelines to the lab each week

4

• Safety First!!
• Do not eat, drink, smoke, or apply cosmetics
  when in the lab.
• Use the equipment properly. If you have any
  questions or problems, contact your instructor.
• Clean up spills immediately.
• Report all injuries--no matter how
  minor--immediately to your instructor.
• If you have long hair, tie it back. If you use
  open flames, roll up loose or long sleeves.

5

• Lab Safety continued
• Never taste any substance or solution. Do not put
  anything in the lab into your mouth.
• Treat all live animals gently and with respect.
• At the end of the lab, wash your hands thoroughly
  and return all equipment and supplies to their
  original locations.
• Lab safety is on W-2 in your lab manual.

6
Advice for a SUCCESSFUL Lab

• Read each lab BEFORE coming to class !
• Get to the lab ON TIME! ( I will not wait for
  you!)
• Take notes during lab (both lecture and
  application).
• Pay attention! (Its your grade on the line.)
• Ask questions! (Im not a mind reader.)
• Take your time. (This isnt a race and you will
  be tested on most material covered.)

7
Missing a Lab

• Automatically fails younot really.
• If you have to miss a lab due to sickness, death
  in the family, etc. please let me know as soon as
  possible.
• It will be your responsibility to get notes from
  another student or copies of handouts that were
  given during the missed lab.
• More than two absences will be noted with your
  lecture instructor.

8
Todays Lab

• Turn to Exercise 1 on 1-1 Measurements
• Turn to Understanding the Nature of Science
  (right after W-2).
• You may take notes if you wish because you will
  see this material again either on quizzes or your
  first lab exam or BOTH!

9
Scientific MethodSteps

• Ask a question.
• Formulate a hypothesis (educated guess).
• Two types of hypotheses
• Null (Ho) the tested hypothesis no
  change
• Alternative (Ha) tentatively accepted
  if there is a change

10
The Scientific Method continued

• Formulate testable predictions How can we test
  our hypothesis?
• Conduct tests of our predictions may include
  observations/experiments.
• Analyze the results Do they defend your null
  hypothesis? Do you need to do another test?

11
Todays Application

• Question
• What is the ratio of male to female births in
  human populations?
• Null (Ho)
• Human populations exhibit a 11 sex ratio at
  birth. (The probability of being born male is
  equal to the probability of being born female.)
• Pm Pf 0.5 or 50 chance of either (X, Y
  chromosomes)
• Alternative (Ha)
• Human populations do not exhibit a 11 sex ratio
  at birth.

12
Testable Predictions

• What would be a testable prediction from our Null
  hypothesis?
• A random sample at birth from a human population
  should exhibit a 11 sex ratio.

13
Testing Our Predictions

• How could we come up with a ratio without leaving
  the lab to count human populations?
• Count the males and females in our lab!
• Is this a good test? Why or why not?
• This is not good because it is NOT random!
• What would be a better test?
• Count the males and females (living and dead) of
  your generation in your immediate family
  (brothers and sisters) and total those numbers
  for your lab bench. Then calculate the ratio.

14
Testing continued

• Is this a better test? Why or why not?
• It is better because it is more random.
• What would be the best test for our situation?
• Collect all the data from each lab bench for the
  entire lab and calculate the ratio.
• Why is this an even better test than before?
• It is better because it is more random and gives
  us more numbers to work with.

15
Analyzing Our Results

• What is our ratio?
• _____ males _____ females
• Is it exactly 11?
• Probably not. This does not mean that our null
  hypothesis is false. We must consider sampling
  error.
• Sampling error the difference between our
  sample sex ratio and the entire populations sex
  ratio. Is our difference too much?

16
Calculating Sampling Error and Statistics

• Statistics used to determine if differences
  between the actual results and those predicted
  from the Null Hypothesis are due to sampling
  error or due to a false Null Hypothesis.
• Example The Quarter Flip (page 4 in
  Understanding the Nature of Science)
• Chi-Square Goodness of Fit Test used for
  probabilities of specific outcomes and
  categorical data (heads/tails, male/female)

17
Chi Square Equation
18
Chi-Square Goodness of Fit Test

• Page 6 in Understanding the Nature of Science for
  format of Chi-Square.
• Use Chi-Square table for for critical values.
  (degrees of freedom categories 1)
• Using the Chi-Square format, analyze your results
  from the human sex ratio.
• If your Chi-Square results are less than the
  critical value from the table, you will accept
  your Null hypothesis.
• If your Chi-Square results are more than the
  critical value from the table, you will reject
  your Null hypothesis.

19
Publishing Your Results

• Before the answer to the question can be accepted
  as scientific it must be published in Primary
  Literature.
• Primary literature original articles describing
  research projects written by the researchers and
  published in peer-reviewed journals.
• These articles follow the format Abstract,
  Introduction, Methods, Results, Discussion,
  Literature Cited

20
Primary Literature

• Look at Appendix II-1 (after p. 546) for a
  detailed description of format.
• Books and review articles (summaries of many
  articles on a topic) are NOT considered primary
  literature. Neither are articles in Time,
  National Geographic, Discover, Seventeen, etc.
• Review the rules of how an article is published
  on page 7 in Understanding the Nature of Science.

21
Searching the Primary Literature

• Use the MTSU library.
• Use the MTSU library website.
• Connecting to the library website
• 1. Go to www.mtsu.edu/
• 2. Click on the LIBRARIES link on the left.
• 3. Click on the James E. Walker Library link.
• 4. Click on RESEARCH GATEWAY.
• 5. Click on InfoTrac OneFile.
• 6. Click on Expanded Academic ASAP.

22

• If you are on-campus, the computer will
  automatically take you to the search page.
• If you are off-campus, you will be required to
  enter your MTSU e-mail username and password.
• Once on the Expanded Academic index search page,
  you can enter your search terms and criteria.
• Click on Search and see what you get!

23
Your Lab Assignment

• You are to find 10 primary literature articles on
  one of those topics (or one of your own that your
  instructor has approved).
• Bring a photocopy of the first page of each
  article with you.
• You may print abstracts off the internet for no
  more than 5 of your articles.
