EEE 498/598 Overview of Electrical Engineering

1
EEE 498/598Overview of Electrical Engineering

• Lecture 11
• Electromagnetic Power Flow Reflection And
  Transmission Of Normally and Obliquely Incident
  Plane Waves Useful Theorems

2
Lecture 11 Objectives

• To study electromagnetic power flow reflection
  and transmission of normally and obliquely
  incident plane waves and some useful theorems.

3
Flow of Electromagnetic Power

• Electromagnetic waves transport throughout space
  the energy and momentum arising from a set of
  charges and currents (the sources).
• If the electromagnetic waves interact with
  another set of charges and currents in a
  receiver, information (energy) can be delivered
  from the sources to another location in space.
• The energy and momentum exchange between waves
  and charges and currents is described by the
  Lorentz force equation.

4
Derivation of Poyntings Theorem

• Poyntings theorem concerns the conservation of
  energy for a given volume in space.
• Poyntings theorem is a consequence of Maxwells
  equations.

5
Derivation of Poyntings Theorem in the Time
Domain (Contd)

• Time-Domain Maxwells curl equations in
  differential form

6
Derivation of Poyntings Theorem in the Time
Domain (Contd)

• Recall a vector identity
• Furthermore,

7
Derivation of Poyntings Theorem in the Time
Domain (Contd)
8
Derivation of Poyntings Theorem in the Time
Domain (Contd)

• Integrating over a volume V bounded by a closed
  surface S, we have

9
Derivation of Poyntings Theorem in the Time
Domain (Contd)

• Using the divergence theorem, we obtain the
  general form of Poyntings theorem

10
Derivation of Poyntings Theorem in the Time
Domain (Contd)

• For simple, lossless media, we have
• Note that

11
Derivation of Poyntings Theorem in the Time
Domain (Contd)

• Hence, we have the form of Poyntings theorem
  valid in simple, lossless media

12
Derivation of Poyntings Theorem in the Frequency
Domain (Contd)

• Time-Harmonic Maxwells curl equations in
  differential form for a simple medium

13
Derivation of Poyntings Theorem in the Frequency
Domain (Contd)

• Poyntings theorem for a simple medium

14
Physical Interpretation of the Terms in
Poyntings Theorem

• The terms
• represent the instantaneous power dissipated in
  the electric and magnetic conductivity losses,
  respectively, in volume V.

15
Physical Interpretation of the Terms in
Poyntings Theorem (Contd)

• The terms
• represent the instantaneous power dissipated in
  the polarization and magnetization losses,
  respectively, in volume V.

16
Physical Interpretation of the Terms in
Poyntings Theorem (Contd)

• Recall that the electric energy density is given
  by
• Recall that the magnetic energy density is given
  by

17
Physical Interpretation of the Terms in
Poyntings Theorem (Contd)

• Hence, the terms
• represent the total electromagnetic energy
  stored in the volume V.

18
Physical Interpretation of the Terms in
Poyntings Theorem (Contd)

• The term
• represents the flow of instantaneous power out
  of the volume V through the surface S.

19
Physical Interpretation of the Terms in
Poyntings Theorem (Contd)

• The term
• represents the total electromagnetic energy
  generated by the sources in the volume V.

20
Physical Interpretation of the Terms in
Poyntings Theorem (Contd)

• In words the Poynting vector can be stated as
  The sum of the power generated by the sources,
  the imaginary power (representing the time-rate
  of increase) of the stored electric and magnetic
  energies, the power leaving, and the power
  dissipated in the enclosed volume is equal to
  zero.

21
Poynting Vector in the Time Domain

• We define a new vector called the (instantaneous)
  Poynting vector as
• The Poynting vector has the same direction as the
  direction of propagation.
• The Poynting vector at a point is equivalent to
  the power density of the wave at that point.

• The Poynting vector has units of W/m2.

22
Time-Average Poynting Vector

• The time-average Poynting vector can be computed
  from the instantaneous Poynting vector as

period of the wave
23
Time-Average Poynting Vector (Contd)

• The time-average Poynting vector can also be
  computed as

phasors
24
Time-Average Poynting Vector for a Uniform Plane
Wave

• Consider a uniform plane wave traveling in the
  z-direction in a lossy medium

25
Time-Average Poynting Vector for a Uniform Plane
Wave (Contd)

• The time-average Poynting vector is

26
Time-Average Poynting Vector for a Uniform Plane
Wave (Contd)

• For a lossless medium, we have

27
Reflection and Transmission of Waves at Planar
Interfaces
28
Normal Incidence on a Lossless Dielectric

• Consider both medium 1 and medium 2 to be
  lossless dielectrics.
• Let us place the boundary between the two media
  in the z 0 plane, and consider an incident
  plane wave which is traveling in the
  z-direction.
• No loss of generality is suffered if we assume
  that the electric field of the incident wave is
  in the x-direction.

29
Normal Incidence on a Lossless Dielectric (Contd)
x
medium 2
medium 1
z
z 0
30
Normal Incidence on a Lossless Dielectric (Contd)

• Incident wave

known
31
Normal Incidence on a Lossless Dielectric (Contd)

• Reflected wave

unknown
32
Normal Incidence on a Lossless Dielectric (Contd)

• Transmitted wave

unknown
33
Normal Incidence on a Lossless Dielectric (Contd)

• The total electric and magnetic fields in medium
  1 are

34
Normal Incidence on a Lossless Dielectric (Contd)

• The total electric and magnetic fields in medium
  2 are

35
Normal Incidence on a Lossless Dielectric (Contd)

• To determine the unknowns Er0 and Et0, we must
  enforce the BCs at z 0

36
Normal Incidence on a Lossless Dielectric (Contd)

• From the BCs we have

or
37
Reflection and Transmission Coefficients

• Define the reflection coefficient as
• Define the transmission coefficient as

38
Reflection and Transmission Coefficients (Contd)

• Note also that
• The definitions of the reflection and
  transmission coefficients do generalize to the
  case of lossy media.
• For lossless media, G and t are real.
• For lossy media, G and t are complex.

39
Traveling Waves and Standing Waves

• The total field in medium 1 is partially a
  traveling wave and partially a standing wave.
• The total field in medium 2 is a pure traveling
  wave.

40
Traveling Waves and Standing Waves (Contd)

• The total electric field in medium 1 is given by

standing wave
traveling wave
41
Traveling Waves and Standing Waves Example
x
medium 2
medium 1
z
z 0
42
Traveling Waves and Standing Waves Example
(Contd)
43
Standing Wave Ratio

• The standing wave ratio is defined as
• In this example, we have

44
Time-Average Poynting Vectors
45
Time-Average Poynting Vectors (Contd)
We note that
46
Time-Average Poynting Vectors (Contd)

• Hence,

Power is conserved at the interface.
47
Oblique Incidence at a Dielectric Interface
48
Oblique Incidence at a Dielectric Interface
Parallel Polarization (TM to z)
49
Oblique Incidence at a Dielectric Interface
Parallel Polarization (TM to z)
50
Oblique Incidence at a Dielectric Interface
Perpendicular Polarization (TE to z)
51
Oblique Incidence at a Dielectric Interface
Perpenidcular Polarization (TM to z)
52
Brewster Angle

• The Brewster angle is a special angle of
  incidence for which G0.
• For dielectric media, a Brewster angle can occur
  only for parallel polarization.

53
Critical Angle

• The critical angle is the largest angle of
  incidence for which k2 is real (i.e., a
  propagating wave exists in the second medium).
• For dielectric media, a critical angle can exist
  only if e1gte2.

54
Some Useful Theorems

• The reciprocity theorem
• Image theory
• The uniqueness theorem

55
Image Theory for Current Elements above a
Infinite, Flat, Perfect Electric Conductor
electric
magnetic
actual sources
images
56
Image Theory for Current Elements above a
Infinite, Flat, Perfect Magnetic Conductor
electric
magnetic
actual sources
h
h
images
