Dressed Human Model Detection

1
Dressed Human Model Detection

• By
• Adam Schwarz
• CAP 5937

2
Overview

• Purpose
• Why we want to
• What challenges we have to overcome
• Means
• Model Classification
• Bayesian Similarity Measure (BSM) and Body Part
  Identification
• Recursive Context Reasoning (RCR)

3
Why Would We Want To?

• Mobile Robot Navigation
• Working safely among humans
• Visual Surveillance
• Human Motion Capture
• Animation, VR, and HCI applications
• Shape-Based Image Retrieval

4
Challenges

• Appearance Variations
• Clothing
• Articulation
• Occlusion
• Other People (crowded areas)
• Objects (Partially visible person)
• Projection Ambiguities
• Projection from 3D model to Image Plane

5
Appearance Variations
Variations due to Clothing
Variations due to Articulation
6
Occlusion
By an Object
By other People
7
Model Classification

• Requirements for good Object Classification
• Independent of Scale, Orientation, and Position
• Handle partial occlusions
• Allow for articulated moving parts
• Handle shape distortions due to noise
• Allow for some shape variations
• Support efficient shape recognition and
  classification

8
Model Classification (cont.)
1st Find Contour Outlines
9
Model Classification (cont.)
2nd Shape Decomposition
Random NCM Natural
NCM - Negative Curvature Minima (small circles)
A good start, but not exactly what we need. So
we introduce another constraint
10
Model Classification (cont.)

• Short-Cut Rule for a valid cut
• Must be a straight line
• Cross an axis of local symmetry
• Join 2 points on the outline (at least 1 NCM)
• Be the shortest cut, if there are several
  possible competing cuts
• Extraneous calculations alternate method next

11
Model Classification (cont.)

• Salience Constraint replaces axis of symmetry
  calculation
• Salience defines how pronounced a part is, or
  part-like it is
• 3 Factors determine Salience
• Size relative to whole object
• Degree to which the part protrudes
• Strength of its boundaries

12
Model Classification (cont.)

• Lets take a look at an example and break down
  the formula

• Cl and Cr have equal arc length based on cut PPM

• Tp represents the threshold determining if a cut
• makes a significant part or not

• P represents a test point for the cuts end

The Smallest Cut
Salience of Part ( Curve / Cut )
13
Model Classification (cont.)

• Final Step Grouping over-segmented parts
• We consider all NCM over a certain magnitude
  threshold to avoid noise
• This may leave extraneous cuts for the same parts
• So we group starting with the largest parts first
  when several possible merges exist
• Continue until no more non-decomposable larger
  parts can be created and all existing large parts
  cant be decomposed into significant parts

14
Model Classification Summary
Find Humans Silhouette-Contour Outline
Smooth Outline and Find all significant NCM over
a magnitude threshold to cut out noise
15
Model Classification Summary
Group All Over-Segmented Parts to get Natural
Shape Decomposition
Use Short-Cut Method and Salience Constraint to
create cuts
16
Human Body Model
Side View
Front View

• We are working with Images, so 2D models are
  preferred
• We also find that these two models are sufficient
• The models also have probability distributions of
  the spatial relationships between the parts and
  the torso

17
Human Body Model (cont.)

• Each body part is modeled by a ribbon

Width (w) the average width along the
ribbon Length (l) the major axis from the ribbon
spine Aspect Ratio (a) w/l, invariant under
similarity transforms, captures the global shape
while ignoring small local shape deformations
18
Human Body Model (cont.)

• Aspect Ratio alone is too ambiguous to
  distinguish different parts (ex. Head and Torso)
• The Origin of each part is located at the joint
  connecting the part to its parent in the connect
  to hierarchy (more on this in a bit)
• Exception to this is the torso, whose center is
  its geometric center

19
Human Body Model (cont.)
General Connect To Hierarchy used as a guide
map todetermining parts relationships to each
other
20
Human Body Model (cont.)

• Now we can parameterize a body part with the
  following vector
• v (a, l, x, y, ?)
• a - Aspect Ratio, l - length
• x, y - origin located in the parent part
• ? - intersection angle between major axis of this
  part and its parent part

21
Human Body Model (cont.)

• With m parts as defined in the previous slide, we
  can represent a model with four model matrices
• Aspect Ratio Vector A a1, , am
• Length Ratio Matrix S sij i, j 1,,m where
  sij li / lj
• Relative Position Vector X x1, y1,,xm,ym
• Orientation/Posture Vector T ?1, , ?m
• A and S are TRS-Invariant

22
Human Body Model (cont.)

• We only need to know the relative positions of
  the six main parts (head, torso, two arms, and
  two legs)
• So we put the parts into a normalized torso
  coordinate system with the torso length as 1
• We get TRS-invariant relative positions
• U (0,0,u1,v1,,u5,v5)
• Where (ui, vi) ((xi,yi) - (x1,y1)) / l1 and
  (x1,y1) are the coordinates of the torsos center
  with l1 being the torsos length

23
Human Body Model (cont.)

• We now have the human model (H) parameterized
  with three TRS-invariant matrices H A, S, U
• This constrains the aspect ratios, relative
  sizes, and positions of the body parts
• This could be extended by imposing constraints on
  the orientation T to form stronger constraints on
  the appearance of a person, but this is not done
  in this paper

24
Human Body Model (cont.)

• TRS-invariant Probabilistic Model
• Implementing probability distributions to
  accommodate shape variation among people
• For simplicity, we assume Gaussian distributions
  and statistical independence between A, S, U
  matrices
• They can be estimated by

Variance
Distribution Function
Average
25
Human Body Model (cont.)

• Importance of the TRS-invariant Probabilistic
  Model
• These probability distributions provide metrics
  to evaluate the shape, size relationship, and
  configuration similarities between the detected
  contour and the human body model (used later on!)
• The parameters for the averages (means) and
  variances are pre-calculated from observed data
  in the human population and stored in a table for
  reference

26
Human Body Model (cont.)

• Dressed Human Modeling
• What if clothing obscures some of the body parts
  we are looking for?
• The model class should represent the generic
  shapes of its objects and emphasize shape
  differences between classes, while the shape
  variations within the class should not influence
  its description.
• For the Human Model, clothing is often the
  primary cause of these shape variations.

27
Human Body Model (cont.)

• Merged Body Parts are introduced to handle the
  variations caused by clothing and other occluders

Example
Example A lady is wearing a skirt, you will not
see her two legs and may or may not even see her
feet. For this you would represent her legs as
body part lower. This gives us more flexibility
with handling clothing.
28
Human Body Model (cont.)

• Sample models using merged body parts with
  different levels of detail, which become the
  Dressed Human Models

29
Human Body Model (cont.)

• How do merged parts help?
• Like regular body parts, the merged parts are
  also modeled with ribbons and connect with each
  other at joints
• The TRS-Invariant Probabilistic representation is
  used to encode the shapes of the merged parts and
  their relationships with the other parts
• A new relationship is introduced in the form of
  part-of (Using the previous example, the two
  legs are part-of the merged body part lower)
• The location of a part can now be inferred from
  their connected parts or from the merged parts
  covering them

30
Human Body Model (cont.)

• Trunk the special merged body part
• Covers the torso and some other body parts
• Occupies the same position as the torso
• Length and width are adjustable to handle various
  different self occlusions and clothing variations
• Length constraint is therefore the sum of the
  lengths of the trunk and the attached parts

head
Sample Trunk
31
Human Body Model Summary

• TRS-invariant dressed human model
• Independent of size, pose, articulation, and
  clothing
• Part-based representation used to model occluding
  contour
• Merged parts representing multiple body parts
• Parts organized into hierarchy to facilitate
  coarse-to-fine decomposition and classification

32
Similarity Measure

• What makes a good shape similarity measure for
  classifying a highly deformable shape such as a
  person
• Large similarity measurements within the class
• Independent of position, size, and orientation
• Support articulation and partial occlusion
• Handle noise, deformation, and low resolution
  blur
• Needs to be efficient to compute

33
Similarity Measure (cont.)

• How is Similarity Measure used?
• It evaluates the resemblance between a contour
  (test data) and a model (known) based on the best
  match between their body parts
• Each ribbon that is decomposed from the contour
  is compared against our models body parts

34
Similarity Measure (cont.)

• Next we set up the problem
• n ribbons are found in contour C
• C c1, c2, , cn
• m body parts found in human model F
• F f1, f2, , fm
• H is the match hypothesis, v is view
• H h1, h2, , hm , v
• Note there is a one-to-one correspondence
  between F and H
• For this paper, v is limited to 2 views
  (front/back and side)

35
Similarity Measure (cont.)

• How do we define a match hypothesis H
• First establish a mapping value for each hx ? H,
  1 ? x ? m
• Consider the corresponding fx from our model body
  parts
• Cycle through all ribbons cy ? C, 1 ? y ? n
• If ribbon cy corresponds to part fx, then hx will
  be set to value yElse if no ribbon corresponds
  to part fx, then hx will be set to zero
• Then choose a view v to be portrayed

36
Similarity Measure (cont.)

• Note that when hx is set to zero, it is allowing
  for some ribbons to not be representing parts due
  to occlusion or not being a body part at all
• Next we want to optimize (maximize) our
  hypothesis match H and find H
• However, before we can do that we need to
  understand Bayes Rule and Maximum A Posteriori
  (MAP) theory

37
Bayes Rule

• Basic Probability
• P(A), P(B) the probability that A, B will occur
  (independent events)
• P(AB) the probability that A will occur given
  that B has been observed
• Conditional Probability
• P(A,B) P(AB)P(B) P(BA)P(A) the
  probability of observing both A and B
  (intersection of Venn diagram)
• Example A is all Red Fish and B is all 6 Fish,
  so P(A,B) would be the probability of observing
  6 Red Fish, which is based on the probability of
  observing Red Fish (A) based on our known
  observation of 6 Fish (B) times the probability
  of observing a 6 Fish (more later)

38
Bayes Rule (cont.)

• Based on the conditional Probability definition,
  we can manipulate the equation to get
• P(A,B) P(AB)P(B) P(BA)P(A)
• P(AB)P(B) P(BA)P(A)
• P(AB)P(B)/P(A) P(BA)P(A)/P(A)
• P(AB)P(B)/P(A) P(BA) (Bayes Rule)

39
Bayes Rule (cont.)
1
3
2

• Importance of P(BA) P(AB)P(B)/P(A)
• Think of A as cause and B as effect, assuming A
  is present, we know the probability of B being
  observed (left side of eq, 1)
• Allows us to use the likelihood of a cause A
  given an observation of B (right side of eq, 2)
• It can also be seen how the probability for A
  changes from prior P(A) before we observe
  anything, to posterior P(AB) once we have
  observed B (right side of eq, 3)
• Now Lets take a look at an example -gt

40
Bayes Rule Example

• Now for another look at the fish example
• Red Fish make up 40 of the fish population
  P(A)
• 60 of the total fish population are 6 or longer
  P(B)
• 15 of the fish are 6 Red Fish P(A,B)
• We want to know the probability of seeing a 6
  Fish based on observing a Red Fish P(BA)
• With this information we want to first find the
  probability of having a Red Fish when a 6 Fish
  is observed P(AB)
• Next, lets look at the equations to see how we
  made this decision -gt

41
Bayes Rule Example (cont)

• We know P(A), P(B), and P(A,B)
• We want P(BA), and we know Bayes Rule says
  P(BA) P(AB) P(B) / P(A)
• So its easy to see that we need to first know
  P(AB) before we can apply Bayes Rule
• So we use our rule for conditional probability we
  saw earlier
• P(A,B) P(AB) P(B)
• If we divide both sides by P(B), we get
• P(AB) P(A,B) / P(B) 0.15/0.6 25

42
Bayes Rule Example (cont)

• Now we can apply Bayes Rule to find P(BA)
• P(BA) P(AB) P(B) / P(A) ?
• P(BA) 0.25 0.6 / 0.4 ?
• P(BA) 37.5
• We could then also apply the alternate form of
  the conditional probability rule as a check
• P(A,B) P(BA) P(A)
• P(A,B) 0.375 0.4 15
• So we see that once observing a Red fish, we have
  a 37.5 chance of observing a 6 fish

43
MAP Maximum A Posteriori

• In essence, MAP is used to select the world
  parameters (or data model) that will maximize the
  probability of the desired result based on the
  observed conditions
• Now back to our human detection problem and
  applying Bayes Rule.

44
Similarity Measure (cont.)

• We are looking for our optimized hypothesis H,
  which is the MAP hypothesis
• H arg maxH P(H, C person)
• In plain English given that a person is present
  in the image, what is the probability that the
  hypothesis set from contour C is a person

45
Similarity Measure (cont.)

• H arg maxH P(H, C person) ?
• First Application of Bayes Rule to get this
• P(H,C person) P(C H, person) P(H person)
• Ignore the person for now to see this
• P(H,C person) P(C H, person) P(H person)
• We can see
• P(A,B) P(B A) P(A)
• Now make the substitution and this gives us
• H arg maxH P(C H, person) P(H person)

46
Similarity Measure (cont.)

• H arg maxH P(C H, person) P(H person)
• ? P(C H, person) P(person H) P(H) /
  P(person)
• represents the second application of
  Bayes Rule
• Assume all hypotheses have the same prior, then
  P(H) / P(person) is a constant and can be
  dropped
• H arg maxH P(C H, person) P(person H)
• Accordingly the goodness function that rates the
  hypothesis is defined as
• G(H) P(C H, person) P(person H)

47
The Goodness Function

• G(H) P(C H, person) P(person H)
• P(C H, person) this evaluates the degree of
  resemblance between the matched pairs (the
  likelihood )
• P(person H) is proportional to the number of
  identified body parts, the more parts identified,
  the more likely the extracted contour is a person
  (the posterior)
• Thus the MAP hypothesis H maximizes the
  resemblance between the matched pairs and the
  number of identified body parts
• Finally this leads us to our Bayesian Similarity
  Measure (BSM) that evaluates the resemblance
  between the contour C and the human model
• BSM(C) G(H)

48
The Goodness Function (cont.)

• To calculate goodness, we need to estimate the
  likelihood P(C H, person) and the posterior
  probability P(person H)
• Â, S, Û are the aspect ratios, relatives
  sizes (with the other identified parts), and
  relative positions (to the torso) of the
  identified body parts
• This information is compared to the reference
  data for the Model Parts corresponding to the
  identified parts
• Ex Take the identified head and compare it to
  the model head information

49
The Goodness Function (cont.)

• Next we define function N to take the best match
  from each set to use for calculating the
  likelihood
• Show N, using A as an example
• N(Â A, SA ) highest probability of match
• where A is the average, and SA is the variance
  of the Model parameters
• Assuming that Â, S, and Û are statistically
  independent, we can estimate the likelihood as
• P(C H,person) N(Â A, SA ) N(Si Si ,
  SSi) N(Û U, SU)
• Thus taking the best a, s, and u from Â, S, Û
  and using their probabilities to determine the
  likelihood of the contour being a person

50
The Goodness Function (cont.)

• Next estimate the posterior P(person H)
• P(person H) Sdiwi
• where di 0 if hi 0, and di 1 if hi ? 0,
  basically if the part was identified, then add
  its weight wi to the estimate
• wi is the contribution to the presence of a
  person from the identification of this part, and
  is defined as ni /n, where n Sni, ?fj that have
  no subparts.
• ni 1 if fi does not have subparts, head and
  torso are exceptions to this as their presence
  greatly indicate a person (wi gt 0.5)

51
The Goodness Function (cont.)

• For body parts that do have subparts, ni is
  defined recursively
• ni ?Snj ,?fj being the subpart of fi
• where ? lt 1 is a degeneration factor used to
  reduce the false alarms caused by the generality
  of the human model

52
The Goodness Function Summary

• This function is designed to evaluate the
  goodness of a hypothesis H
• G(H) N(Â A, SA ) N(Si Si , SSi)
  N(Û U, SU) P(person H)
• It is looking for the best match between the
  extracted ribbons and the human body parts, the
  higher the value, the better the match

53
Dynamic Model Assembling Step 1

• Find the coarse-level decomposition of the
  contour C by grouping the ribbons whose major
  axes share a common endpoint and have similar
  widths

54
Dynamic Model Assembling Step 2

• Identify the coarse-level body parts and
  evaluate them based on the goodness function

55
Dynamic Model Assembling Steps 34

• If parts at the coarse-level can be further
  decomposed into subparts, consider the fine-level
  information, label parts, and calculate locations
  of the subparts that were missed at the
  coarse-level
• This will be looked at in more depth a little
  later on

56
Body Part Identification

• So why work at the coarse-level instead of just
  using the fine-level data?
• There are fewer body parts, and thus a much
  smaller hypothesis space
• A coarse-level hypothesis will result in a lower
  posterior P(personH), because of the
  degeneration factor (?)
• By combining the constraints on the aspect
  ratios, relative sizes and positions, and the
  posterior P(personH), the goodness function
  selects the human model and model parts at the
  right resolution to label the decomposed contour
  correctly (see the next slide for examples)

57
Body Part Identification (cont.)

• Examples of the coarse-to-fine hypothesis
  selection and dynamic model assembling
• H2 results in the highest goodness value and
  also the most accurate body parts identification

58
Multiple Person Example

• What if the contour represents two people as in
  the example below

In this case, the system will need to pick
multiple hypotheses.
59
Multiple Person Example (cont.)

• Then select the best hypothesis to identify a
  person contained in the contour and remove those
  parts from the contour

Decompose the entire contour into parts
Now go back to the hypothesis selection step and
repeat the selection and body part identification
until all significant parts have been taken care
of.
60
Applying BSM to Human Detection

• For Human Detection a contour is provided and
  the BSM needs to determine whether this contour
  represents the silhouette of a person or not
• BSM(C) gt threshold
• C is a persons silhouette when the above
  expression evaluates to true

61
Human Detection (cont.)

• How to handle ambiguous contours?
• When rotated slightly, contour may no longer look
  like a person
• To avoid false alarms, the threshold is replaced
  by an upper and lower bounds meaning that the
  similarity measurement must be sufficiently high
  or sufficiently low, otherwise it cannot make a
  decision

62
Human Detection (cont.)

• If no decision can be made on the contour
  because it falls in the uncertainty region
  between ?1 and ?2, then a more distinguished
  contour will need to be found, and for this we
  use a Recursive Context Reasoning (RCR) algorithm
  (more on this in a bit, but first some results
  from the human detection method just discussed)

63
Human Detection Results
Correctly identified as humans when compared
against the human model and the goodness values
are listed with the contours
64
Human Detection Results (cont.)
Correctly identified as NOT humans when compared
against the human model and the goodness values
are listed with the contours
65
RCR Algorithm

• The purpose of the Recursive Context Reasoning
  (RCR) Algorithm is to provide a contour updating
  procedure to help re-evaluate the BSM and produce
  a refined (more detailed) contour to determine if
  the original detected contour is a person or not.

66
RCR Algorithm (cont.)

• The basic algorithm
• Step1 Original Contour extraction
• For each contour run Steps 2-7
• Step2 Contour decomposition into natural parts
  (model classification)
• Step3 Body Part Identification (finding best H
  using goodness function)
• Step4 Human Detection (BSM)
• If BSM is in ambiguous region continue, else
  done
• Step5 Update the locations and labels of the
  body parts
• Step6 Align the predicted outlines of the
  missed body parts to the edge features in the
• Step7 Recalculate the similarity measure and
  determine if a person is present or not

new
67
RCR Algorithm (cont.)

• Step5 Update Shapes and Locations of the body
  parts
• Remember a body part is parameterized with a
  vector (a,l,x,y,?)
• Using a weighted Least Squares Method (LSM) we
  can integrate the parameters estimated from the
  labeled contour with the corresponding model body
  parts
• Example on the next slide ?

68
RCR Algorithm (cont.)

• Example find the connection joint for the left
  arm with the torso
• Finding estimate P4, using LSM with estimates P1,
  P2, and P3
• P1 the initial estimate based on body part
  identification
• P2 estimate based on the locations of the torso
  and head
• P3 estimate based on the major axis of the arm

P2
P4
P3
P1
69
RCR Algorithm (cont.)

• Step6 Predict the parameters of the missed parts
• Goal is to estimate the missing body parts
  parameter vector (aj, lj, xj, yj)
• Assume aspect ratios of the different body parts
  are independent of each other, and the MAP
  estimation of aj is simply its mean (average)
  value and its variance
• aj aj and Saj Saj
• again these mean values and variances are
  pre-computed and stored in a reference table

70
RCR Algorithm (cont.)

• The length of the body part can be estimated
  from any of the identified body parts (note lj
  lj)

where
Basically comparing what we know about the
average length ratios between these two parts and
the length of the model body part to calculate
the missing parts length
71
RCR Algorithm (cont.)

• If more than one part have been identified, then
  the MAP estimate of lj is the weighted summation

I is the set of identified parts
72
RCR Algorithm (cont.)

• Next we need to calculate the position of our
  missing part, which is done using Transform
  matrix T to change the model coordinates to the
  image coordinate system
• XI TUI
• T XIUTI(UIUTI)-1
• where X is the set of coordinates for the
  identified parts in the image coordinate system
  and U is the set of coordinates for the
  identified parts in the model coordinate system
• Estimate the position of the unidentified body
  part as
• (xj, yj, 1)T T(uj, vj, 1) T

73
RCR Algorithm (cont.)

• Now take the translation, rotation angle, and
  scaling involved in transformation T and get
  vector t (tx, ty, ?, s)
• Assume that the predicted location Xj can be
  approximated by a first-order Taylor Series
  Expansion about the mean of t, then the
  uncertainty with Xj is approximated as
• SXj ? JtStJtT TUjTT
• where Jt is the Jacobian and Uj is the position
  in model space
• A Jacobian Matrix in simple terms is the first
  order derivative of each of the given elements in
  the original matrix

74
RCR Algorithm (cont.)

• If the part being predicted is a subpart, then
  the position in the image frame (xj, yj) can be
  inferred from the part fi directly connected to
  it
• (xj, yj) (xi, yi) li(cos?i, sin?i)
• Or from the extended body part fk that is
  covering it
• (xj, yj) Rl(uj, vj) - (uk, vk) (xk, yk)
• where R ( ) and l lk/lk

cos?k sin?k
-sin?k cos?k
75
RCR Algorithm (cont.)

• Examples
• predicting the subparts from the identified parts

Later on, more examples will be shown were the
locations of some of the primary body parts will
be predicted
76
RCR Algorithm (cont.)

• Contour Alignment
• Step1 Render the outline of a body part, if
  unidentified then set orientation to the
  orientation of the torso
• Step2 Align the rendered outline with the edge
  features such that
• ?i arg max? N(B? ? E)
• where B? is the rendered boundary of fi at
  orientation ?, E is set of edge pixels, and N(s)
  is the number of points in the point set s
• Step3 If N(B?i ? E) gt threshold, then body part
  fi is detected and the points in B?i ? E are
  removed from the edge image E, otherwise fi is
  not detected

77
RCR Algorithm (cont.)

• Contour Alignment
• Examples
• 1 the right arm and both legs start at default
  orientation (un-identified) and then aligns them
  to contour
• 2 similarly corrects arm positions

Ex 1
Ex 2
78
RCR Algorithm Example

• Putting it all together and running an example

SM0.60
SM0.67
SM0.33
79
RCR Algorithm Example (cont.)

• After the first iteration, we can kick the car
  out, but the peoples similarity values are too
  low to be classified, so we apply the RCR
  re-evaluation steps
• Find the joints, render missing parts, align to
  contour, run similarity measure again, see if we
  detect or not

SM 0.87
SM 0.76
Two iterations are normally sufficient
80
Resources

• Main Paper
• http//www.ri.cmu.edu/pubs/pub_3767.html
• Bayes Rule and MAP
• http//webcourse.cs.technion.ac.il/236607/Winter20
  02-2003/ho/WCFiles/Tutorial2.ppt
• http//www.cs.ust.hk/martin/comp327/t1.pdf
• Jacobian Matrices
• http//mathworld.wolfram.com/Jacobian.html
• Statistical Variance and Deviation
• http//dorakmt.tripod.com/mtd/glosstat.html
