Tuesday Clinical Case conference

1
Tuesday Clinical Case conference
10/2007 Zae Kim, MD
2
(No Transcript)
3
(No Transcript)
4
Acute Interstitial nephritis

• Term first used by Councilman in 1898
• Noted the histopathologic changes in autopsy
  specimens of patients with diptheria and scarlet
  fever
• Immune-mediated cause of acute renal failure
• Characterized by presence of an inflammatory cell
  infiltrate in the renal interstitium and tubules
• there is a paucity of data in the literature
  regarding optimal management of the condition

5
Incidence

• Significant cause of acute renal failure
• series of 109 patients from a large center
• biopsied for unexplained renal impairment with
  normal sized kidneys
• AIN accounted for 29 of 109 (27) cases
• Farrington K, Levison DA, Greenwood RN, Cattell
  WR, Baker LR. Renal biopsy in patients with
  unexplained renal impairment and normal kidney
  size. Q J Med 1989 70 221233

6
Causes
7
The changing profile of acute tubulointerstitial
nephritisBacker RJ Pusey CD, Nephrol Dial
Transplant 2004 Jan19(1)8-11

• A review of three series that totaled 128 pts
• (71) Drugs, with antibiotics responsible for 1/3
• (15) Infection-related
• (8) Idiopathic
• (5) Tubulointerstitial nephritis and uveitis
  (TINU) syndrome
• (1) Sarcoidosis

8
Approximated frequency with which clinical
manifestations occur during
(A) methicillin-induced AIN (B) AIN induced by
drugs other than methicillin (C) AIN induced by
NSAIDs and associated with a nephrotic syndrome
http//www.nature.com/ki/journal/v60/n2/full/44924
87a.htmlfig2
9
Epidemiology

• The overall picture that emerges is of a syndrome
  that is becoming both
• increasingly non-specific in clinical features
• diverse in etiology

10
Noninvasive diagnostic procedureeosinophiluria

• Corwin, HL, Korbet, SM, Schwartz, MM Clinical
  correlates of eosinophiluria. Arch Intern Med
  1985 14510971099
• Nolan, CR, Anger, MS, Kelleher, SP
  Eosinophiluria A new detection and definition of
  the clinical spectrum. N Engl J Med 1986
  31515161519
• Corwin, HL, Bray, RA, Haber, MH The detection
  and interpretation of urinary eosinophils. Arch
  Pathol Lab Med 1989 11312561258
• Ruffing, KA, Hoppes, P, Blend, D, et al
  Eosinophils in urine revisited. Clin Nephrol 1994
  41163166

http//www.nature.com/ki/journal/v60/n2/fig_tab/44
92487t2.htmlfigure-title
11
Noninvasive diagnostic procedure Gallium scan
highly sensitive?

• Gallium67 scintigraphy in the diagnosis of acute
  renal disease. Linton et al, Clin Nephrol. 1985
  Aug24(2)84-7.
• N 44 patients with various biopsy proven renal
  disease
• AIN 11 patients
• Two blinded observers
• Result
• All 11 AIN (100)
• 5/33 (15) of other renal disease had () uptake
• Glomerulonephritis, pyelonephritis

12
Noninvasive diagnostic procedure Gallium scan
not highly sensitive?

• N 16 with AIN
• () gallium scan in 11/16 (68)
• Koselj, M, Kveder, R, Bren, AF, Rott, T Acute
  renal failure in patients with drug-induced acute
  interstitial nephritis. Ren Fail 1993 156972
• N 12 with AIN
• () gallium scan in 7/12 (58)
• Graham, GD, Lundy, MM, Moreno, JJ Failure of
  67gallium scintigraphy to identify reliably
  non-infectious interstitial nephritis. J Nucl Med
  1983 24568570

13
Lab biopsy

• Inflammation of renal interstitium
• Microscopically
• Multifocal cellular infiltration and edema
• Mononulcear cells (lymphocytes and macrophages)
  usually are the predominant types
• Drug reaction
• Mononuclear cells, typically T cells (CD4gtCD8)
• Glomerular and vascular sparing

14
Course

• Based on the course of methicillin-induced AIN
• drug-induced AIN has long been considered a
  relatively benign nephropathy
• complete recovery of renal function was supposed
  to be the rule if the inciting agent was removed

15
Analysis of published cases of AIN by drugs other
than methicillin course of renal function
recovery

• At the end of follow up
• Only 68 had sCr lt1.7
• Only 40 had sCr lt1.2

68 w crt lt 1.7
49 w crt lt 1.2
Rossert, KI, 2001
16
Prognostic factor?

• could we identify patients with drug-induced AIN
  who are at high risk of incomplete recovery?
• Severity of renal failure?
• Histology
• Diffuse vs patchy infiltrate
• Degree of fibrosis
• Duration of renal failure

17
Severity of renal function as prognostic marker?

• Patients were arbitrarily divided into three
  groups depending on serum creatinine levels at
  the end of follow-up
• Maximum serum creatinine levels did not differ
  among these three groups

Crt lt1.2
Crt gt 2.2
Crt 1.2 2.2
Rossert, KI, 2001
18
Prognostic factor histology?

• Diffuse vs patch interstitial infiltrates
• n 30, less favorable renal prognosis with
  diffuse vs patch
• sCr 2 in 10/18 with diffuse (55)
• sCr 1.1 in 9/12 w patch (75)
• Laberke, HG Bohle, A Acute interstitial
  nephritis Correlation between clinical and
  morphological findings. Clin Nephrol 1980
  14263273
• Two other studies (n 27 and 14) no correlation
• Kida, H, Abe, T, Tomosugi, N, et al Prediction
  of the long-term outcome in acute interstitial
  nephritis. Clin Nephrol 1984 225560
• Buysen, JGM, Houtlhoff, HJ, Krediet, RT, Arisz,
  L Acute interstitial nephritis A clinical and
  morphological study in 27 patients. Nephrol Dial
  Transplant 1990 59499
• Conflicting result

19
Prognostic factor

• Duration of acute renal failure
• N 30
• Mean sCr 1.4 with ARF lt 2 wks
• Mean sCr 3.4 with ARF gt 3 wks
• Laberke, Acute interstitial nephritis, Clin
  Nephrol 14263, 1980

20
Pathophysiology
21
Pathophysiology drug induced AIN

• Drug-induced AIN is secondary to immune reaction
• AIN occurs only in a small percentage of
  individuals taking the drug
• AIN is not dose-dependent
• Association with extrarenal manifestations of
  hypersensitivity
• Recurrencence after re-exposure to the drug
• Experimental models
• Suggest that drugs responsible for AIN induce an
  immune reaction directed against endogenous renal
  antigens

22
Based on Experimental AIN
http//www.nature.com/ki/journal/v60/n2/fig_tab/44
92487f1.htmlfigure-title
23
Involvement of Drug-Specific T cells in Acute
Drug-Induced Interstitial NephritisSpanou et al,
JASN, 17 2919, 2006

• Role of drug-specific responses in patients with
  a histologic diagnosis of DIN (Drug-Induced
  Nephritis)
• Identified drug-specific T cells
• Characterized them phenotypically in vitro

24
Pt 1. Txd w abx for endocarditis, developed ARF
3 weeks after starting abx
Pt 2 Tx for endocarditis, arf after 8 days
Pt 3 ARF after 3 weeks
Involvement of Drug-Specific T cells in Acute
Drug-Induced Interstitial Nephritis Spanou et al,
JASN, 17 2919, 2006
25

• Lymphocyte Transformation Test (LTT) used to
  analyze drug-specific proliferation of patients
  PBMC
• Relies on observation that T cells divide and
  expand after encountering the antigen
• Measures H-thymidine uptake of dividing cells

Involvement of Drug-Specific T cells in Acute
Drug-Induced Interstitial Nephritis Spanou et al,
JASN, 17 2919, 2006
26
Lymphocyte Transformation Test Drug-specific
proliferation of patients PBMC
Pt 1. Positive proliferative response of PBMC to
flucloxacillin
Pt 2 PBMC proliferative response to penicillin G
Pt 3 PBMC proliferative response to disulfiram
Even though there were multi drug exposure, each
patient elicited proliferative response to only
one drug
Involvement of Drug-Specific T cells in Acute
Drug-Induced Interstitial Nephritis Spanou et al,
JASN, 17 2919, 2006
27
T cell receptor Vb expression in a drug-specific
T cell line by flow cytometry

• PBMC of pt 1 was incubated with flucloxacillin
  and IL-2
• CD3 T cells bearing Vb9 and Vb21.3 were enriched
• Suggesting an oligoclonal T cell expansion

28
TCR-Vb staining in kidney biopsy specimens- to
determine whether the drug-specific T cells from
PBMC might be present in the kidney

• Total CD4 317/mmsq
• TCR-Vb 27 mm/sw

• Total CD4 272/mmsq
• TCR-Vb 120/mmsq

• Both show extensive T cell infiltrate
• Both stained for TCR-Vb specific to
  flucloxacillin (normally found on 4-7 of
  circulating T cell only)

29
Involvement of Drug-Specific T cells in Acute
Drug-Induced Interstitial NephritisSpanou et al,
JASN, 17 2919, 2006

• Implications
• In vitro proliferation assays might be helpful to
  identify the drug that is responsible for the
  hypersensitivity reaction
• Particularly in patients with more than one
  medication exposure
• Its likley that the T cell infiltration into the
  kidney is due to drug-specific T cells, which
  then might coordinate the local inflammatory
  reaction

30
Treatment

• Therapy aimed at modulating the immune response
  has been the main treatment for AIN
• Several small retrospective studies have
  suggested that corticosteroid therapy improves
  clinical outcome however, no prospective studies
  exist
• Pusey CD, Saltissi D, Bloodworth L, Rainford DJ,
  Christie JL. Drug associated acute interstitial
  nephritis clinical and pathological features and
  the response to high dose steroid therapy. Q J
  Med 1983 52 194211
• Buysen JG, Houthoff HJ, Krediet RT, Arisz L.
  Acute interstitial nephritis a clinical and
  morphological study in 27 patients. Nephrol Dial
  Transplant 1990 5 9499
• Enriquez R, Gonzalez C, Cabezuelo JB et al.
  Relapsing steroid-responsive idiopathic acute
  interstitial nephritis. Nephron 1993 63 462465

31
Retrospective study
Drug associated acute interstitial nephritis
clinical and pathological features and the
response to high dose steroid therapy.Pusey et
al, Q J Med 1983
32
Acute interstitial nephritis a clinical and
morphological study in 27 patientsBuysen et al,
Nephrol Dial Transplant. 19905(2)94-9

• N 27 biopsy-proven AIN
• 17 patients
• renal function improved after withdrawal of the
  drug
• 10 patients
• Further decline in renal function in the two
  weeks following admission
• prednisone therapy was instituted
• All with improvement of renal function
• with six returning to normal

33
Acute interstitial nephritis clinical features
and response to corticosteroid therapyClarkson
et al, Nephrology Dialysis Transplantation 2004
19(11)2778-2783

• a retrospective study of all cases (n60) of AIN
  found by reviewing 2598 native renal biopsies
  over a 12 year period
• Of those patients in whom complete follow-up data
  were available (n 42)
• 60 received corticosteroid therapy while the
  remainder received supportive care only

34
Effect of corticosteroid therapy in AIN compared
with conservative management.
Values for serum creatinine (µmol/l) are given as
medianinterquartile range.
35
Why no benefit?

• Patients treated with steroids had more severe
  disease
• Significant proportion of the patients had
  NSAID-associated AIN, which is less likely to
  respond to steroid tx

36
The end
