MesoGreen

1
MesoGreen MG-3500_MESOGUN INTRODUCTION

2
High Performance, Deep Impact with Ergonomic
Design
MesoGreen_MG-3500
New Standard in Digital MesoGun
3
WHAT IS MESOGUN? WHY USE IT?
FREE FROM WEARINESS When you doing several
treatments with conventional syringes, it is
quite a demanding on the hand wrist. MESOGUN
helps hundreds injections with precise
continuous manner. You just pull the trigger.
ENHANCE ACCURACY CONSISTENCY - Once you
set the mesogun, such as dose, rate, frequency
and depth of injection, the mesogun execute
consistently accurately.
4
WHAT IS MESOGUN? WHY USE IT?
MOST IMPORTANTLY PATIENT FEEL COMFORT o
Skin Stability The skin stabilizer
helps to stabilize the skin and eliminate
undesirable movement during injection,
those enhance decreasing the pain
perceived by the patient. o Needle
vibration Few vibration noise makes patient
feel comfortable. o Speed of needle The
faster the needle injects into the skin, the less
pain is perceived. Especially a gun with
pneumatic power(swiss made) helps a dramatic
swift skin puncture. o NO PAIN Can be
injected deeply into the skin without any pain.
5
THE EXCELLENT FEATURES OF MESOGREEN IN A COMPACT
SYSTEM
Versatility The excellent features of
MESOGREEN has achieved it as a reliable,
versatile economical Mesogun designed to meet
every requirements of todays meso-therapy
treatment.
Stability - Automatically detect for
battery residual - Automatically detect for
dose residual - KFDA approval of MesoGreen
- Silent injection makes patient feel
comfortable - Can be injected deeply into
the skin without any pain - Emergency
electrical power supply (100240 VAC) -
Sufficient battery capacity available (long
lasting Max 3 days)
6
EXCELLENT PERFORMANCE WITHOUT COMPROMISE
Convenience - Wireless Product - All
kinds of syringe used from 1cc to 10cc normal
centered cone three pieces standard from any
brands such as Braun, BD Plast, Terumo, Artsana,
Novico - Only one mesogun can use Filler
Syringe. - Lightweight 473g (Gun)
- Easy to load the syringe - Possible to
use both method for Dry and Wet -
One-handed browsing with the jog dial -
Automatically recharge to set on the cradle

7
Economic - High Quality, Reasonable Price
- Possible to regulate a draft of liquid
medicine - No leakage of a draft of liquid
medicine which eliminates waste in
continuous and dosimetric modes
Design - Ergonomic Design - Wearing
high class blue back light (Blue LCD) -
Cybertic jog dial design - Design patent
application (design registration)
8
MesoGreen is configured with
The luxury LCD gives a feeling of high classed
device and the jog dial only the MesoGreen offers
helps user to program and control easily fast
Ergonomic designed grip gives men and women
doctors easy to handle
Cursor The cursor fix the syringe in stable while
using the MesoGreen
Cradle Emergency electrical power supply able to
cope with power variation from 100 volts to 240
volts.
Skin Stabilizer The Stabilizer helps syringe
needle to be injected into the skin eaily
accurately
9
Operating Function Table
Mode Continuous Dose Nappage
Syringe Type 5, 10 ml 1, 3, 5, 10 ml 5, 10 ml
Mode Type C D N
Flow or Dose Injected 3-10ml/min 1-50 µl 1-7 µl
Volume Scale 1ml/min 1 µl 1 µl
Frequency(Speed) 100-250 inj/min
Speed Scal 50 inj/min
Technical Specification
Main Body L322mm H187mm W53mm 473g L322mm H187mm W53mm 473g
Cradle L285mm H60mm W114mm 170g L285mm H60mm W114mm 170g
Battery Li-ion 3.7V / 2,000Ah Li-ion 3.7V / 2,000Ah
Capacity up to 3 days, charging time 3 hours Capacity up to 3 days, charging time 3 hours Capacity up to 3 days, charging time 3 hours
Charger Input 100240V, 60Hz Output 4.2V / 1.5V
Environment Operating Humidity 3075, Temperature 1040 degree Operating Humidity 3075, Temperature 1040 degree Operating Humidity 3075, Temperature 1040 degree
10
Comparison Table
Brand Origin Noise Impact Speed inj/min Needle moving Unit Delicate adjustment (LCD Gun Cradle Wire/wireless
Meso Injector Domestic Middle Middle 300 5 mm Impossible (No No Wire
Meso Master Domestic Middle Middle 300 5 mm Impossible (No No Wire
Dr. injector Domestic Middle Middle 300 5 mm Impossible (No No Wire
DHN4 Foreign Big Big 200 10 mm Impossible (No No Wireless
DEN Hub Foreign Big Middle 200 10 mm Impossible (No No Wireless
Pistol 4 Foreign Big Big 200 10 mm Impossible (No No Wireless
Meso System Domestic Middle Middle 200 10 mm Impossible (No No Wireless
MESO GREEN Domestic Very small Very small 250 10 mm Possible (Yes) Yes Wire/Wireless
MESOMATE Domestic Small Smalll 250 8 mm Possible (Yes) No Wireless
MesoMega Foreign Middle Middle 200 10 mm Possible (Yes) No Wireless
MII Domestic Big Middle 300 5 mm Impossible (No No Wireless
11
Applications

• Acne / Alopecia
• Arthritis Rheumatism
• Arthropathy / Degenerative Arthritis
• Cellulite / Obesity Stretch Lines
• Degenerative Disc Disease
• Fine wrinkles
• Herpes Infection / Hypertrophic Scars
• Lipodystrophy / Ligament Sprain
• Migraine
• Vascular / Pain
