Nephrology Rounds

1
Nephrology Rounds

• Riki Buchwald, ID fellow
• December 17th 2008

2
Case

• 46 y old AA man with h/o GSW to right trochanter
  in 8/07, s/p ORIF at OSH
• Admitted to Bellevue 9/07 found to have wound
  infection/OM with polyresistant Pseudomonas
• Extensive debridement performed but hardware left
  in place
• Underwent long-term treatment with polymyxin from
  10/07 on. Course complicated by renal failure in
  11/07 that resolved with polymyxin dose
  adjustment.

3
Case

• Hardware removed on 3/12/08
• Wound cx with MRSA
• Received 4 week course of vancomycin and 6 week
  course of polymyxin after hardware removal
  course completed at the end of April

4
Case

• Readmitted in 6/08 with increasing hip pain and
  persistent drainage
• Imaging c/w erosion of the right femoral head
  with joint space loss, septic arthritis and
  chronic osteomyelitis with sinus tract to the
  skin surface
• Debridement and washout performed on 6/18/08 OR
  cx grew MRSA
• Treated with vancomycin
• Developed worsening non oliguric renal failure
  with creatinine increase from 1.1 on admission to
  6.8 mg/dl over 4 weeks

5
Clinical History

• PMH
• - Diabetes, A1c 7.9 in 10/2007
• - HTN
• - Anemia
• - Remote h/o syphilis, treated
• SH no tobacco or drug abuse
• Meds insulin, lisinopril, iron, MVI, folic acid,
  omeprazole, escitalopram,
  cyclobenzaprine, SQ heparin
• ROS several weeks of darkened urine, leg
  swelling
• denied dysuria, macro-hematuria, SOB,
  fevers, joint pain, skin rash

6
Physical Exam

• BP 150/89 HR 93 T 97.2 97 RA
• Middle aged pt, appearing depressed, NAD
• Sitting in wheelchair
• Neck supple
• Lungs CTA
• Heart reg, nl S1 S2
• Abdomen soft, nontender
• Right thigh with surgical scar, sutures in place,
  mild swelling and chronic skin changes, no frank
  drainage
• Ext b/l 3 LE edema

7
Laboratory Data

• Wbc 11.4, 73 PMN,18 Lymph, Eos WNL
• Hgb 7.8
• Plt 332
• Hepatic 42/64/201/0.2/8.2/3.4
• Protein electrophoresis
• TP 7.7, albumin 2.4
• Globulins
• alpha 1, alpha2, beta WNL,
• gamma 2.6 (0.5-1.3) diffuse bands

8
Laboratory Data

• 7/30 K 5.2, Ca 8.8, Phos 6.0 Mg 2.4
• 6/24 UA protein gt300 mg/dl, WBC 2-5,RBC packed,
  fine granular casts, RBC casts
• 7/02 Urine protein 2g/day

9
Laboratory Data

• HIV negative
• Hep B SAb positive, SAg negative
• Hep C negative
• Syphilis IgG/TPPA positive, RPR negative

10
Any ideas?
11

• A Diagnostic Test was Performed

12
Normal glomerulus
13
Nodular mesangial sclerosis
14
Crescentic necrotizing GN
15
RBC casts
16
IgA C3
17
(No Transcript)
18
Diagnosis

• Crescentic necrotizing glomerulonephritis with
  focal mesangial and subepithelial deposits (IgA
  and C3)
• Differential diagnosis
• - IgA Nephropathy
• - post infectious GN
• - pauci-immune ANCA-associated GN
• - Methicillin-resistant Staphyloccocus post
  infectious GN

19
IgA nephropathy
Postinfectious GN
20
Laboratory Data

• C3 172( 75-140) C4 28.5 (10-34)
• ASLO 57
• ANA, ds DNA, ANCA negative
• Anti-GBM negative
• Urine immunofixation negative

21
Final Diagnosis

• MRSA- post infectious GN

22
Objectives

• Postinfectious Glomerulonephritis (PIGN)
• Current trends in PIGN in adults
• Staphylococcus and IgA dominant PIGN

23
Postinfectious Glomerulonephritis

• Acute postinfectious GN (APIGN) disease of
  childhood
• Commonly following a streptococcal infection (
  APSGN)
• Clinical presentation
• 3 phase sequence infection - interval -
  nephritic syndrome
• Course of disease
• 1 week onset of diuresis
• 4 weeks normalization of creatinine
• 3-6 months resolution of hematuria resolution
  of mesangial hypercellularity
• Years resolution of proteinuria

24
APIGN Histology
Humps
25
APIGN Outcome

• Long term follow up studies excellent prognosis
  for most children with the epidemic form
• A Japanese study followed 138 children with
  non-epidemic form
• None developed renal insufficiency, all had
  normal serum complement within 12 weeks,
  resolution of proteinuria within 3 yrs and
  hematuria within 4 yrs (Kasahara T et al,
  Pediatr Int 2001 43 364)
• A 12-17 yrs f/u study of 534 children and adults
  in Trinidad showed complete recovery in 96.5
  (Potter EV et al, NEJM 1982 307 725)
• A 2005 study from Brazil studied 56 patients for
  5.4 yrs who had APIGN related to an outbreak of
  Streptococcus zooepidemicus
• 30 with HTN, 49 with reduced GFR, 22 with
  microalbuminuria
• (Sesso R et al, Nephrol Dial Transplant 2005
  201808)
• Literature reports recovery rate in adults
  53-76

26
APIGN What is New in Adults?

• Retrospective studies
• Keller CK et al, Q J Med 1994 87 97
• - Germany 1984-1993 30 patients
• Montseny JJ et al, Medicine 1995 74 63
• - France 1976 - 1993 76 patients
• Moroni G et al, Nephrol Dial Transplant 2002 17
  1204
• - Italy 1979-1999 50 patients
• Nasr SH et al, Medicine 2008 87 21
• - Columbia University 1995-2005 92 patients

27
APIGN in Adults

• of all renal biopsies 0.6 - 4.6
• Median age 49 - 58 yrs
• Underlying disease 40-50
• - Alcoholism /- cirrhosis 2 - 57
• - Diabetes 8 - 29
• - COPD 7 - 33
• - IVDU 3 - 27
• - Malignancy 5 - 10

Moroni G et al 2002
28
APIGN Presentation

• Endocapillary proliferation 70-100
• Crescents (gt 20-30) 14 - 36
• Interstitial infiltration 30 - 80
• ATN 20 - 40
• IF
• C3 deposits 93 - 100
• C1 18 - 35
• IgG deposits 55 - 65
• IgM/IgA 30 - 45
• EM
• Mesangial deposits 33 - 90
• Subendothelial 44 - 75
• Humps 94 - 100

• Nephritic syndrome 60
• Nephrotic Syndrome 30-50
• Mean serum creatinine
• 1.5-6.4 mg/dl
• (?with comorbidities/crescentic GN)
• Mean 24 hr-protein
• 3.6 g (?with comorbidities)

29
Sites of Infection and Microbiology

• Streptococcus 14-47
• Staphylococcus 12-24
• Gram negatives 1-22
• 24-59 w/o microbiologic diagnosis
• Nasr et al
• Mean latent period 3 weeks
• 2 weeks (endocarditis), 3 weeks (SSTI), 4 weeks
  (URI)
• 8 of patients simultaneous diagnosis (20 of pt
  with endocarditis and 27 with PNA)

• URI 24-44
• SSTI 5-25
• Lung 16-18
• Endocarditis 1-13
• Dental 0-13
• UTI 1-12

30
Comorbidities and Histology
With comorbidities
No comorbidities
Moroni G et al, Nephrol Dial Transplant 2002 17
1204
31
Outcome

• CR 28-64 PRD 27-53 ESRD 4-17 Death 4-11
• Correlates of outcome
• - CR younger age, no underlying disease
• h/o URI
• endocapillary disease,
• no crescents or subendothelial deposits

• no interstitial inflammation
• - PRD alcoholism
• nephrotic syndrome
• crescentic GN, interstitial fibrosis
• - ESRD higher baseline creatinine
• underlying diabetic GS

Nasr SH et al, Medicine 2008 87 21
32
PIGN of all biopsies
with atypical infection sites
complete remission
with severe interstitial infiltration
Moroni G et al, Nephrol Dial Transplant 2002 17
1204
33
Do Steroids Matter ?

• Montseny et al
• 17 pt (12 with crescentic GN) treated with
  steroids, 8 additionally with cyclophosphamide
• 2 died, 2 on HD, 3 with progressive CD, 5 with
  stable proteinuria, 5 with CR
• Moroni et al
• CR or partial remission in 54 treated with
  steroids vs 72 of untreated (but pt with
  steroids with higher creatinine and interstitial
  inflammation)
• Nasr et al
• 33 of 52 pt treated with steroids
• Indications renal insufficiency with/without
  crescents
• CR in 12/17 patients with steroid therapy and
  10/23 without (p0.116)

Nasr SH et al, Medicine 2008 87 21 Moroni G et
al, Nephrol Dial Transplant 2002 17 1204
Montseny JJ et al, Medicine 1995 74 63
34
Staph and the Kidney

• 2 staphylococcal associated GN
• - acute proliferative exudative GN associated
  with
• S. aureus endocarditis (resembling
  poststreptococcal GN)
• - membranoproliferative GN associated with
• S. epidermidis and ventricular shunt
  infections (shunt nephritis)

Nasr SH et al, Hum Pathol 2003, 34 1235
35
MRSA and PIGN

• In 1980, Spector et al first reported 3 pt with
  S. aureus visceral abscesses who developed acute
  mesangial proliferative GN with mesangial IgA
  deposits
• In 1995, Koyama et al reported 10 pt who
  developed a rapidly progressive GN with nephrotic
  syndrome associated with MRSA infections
  (abdominal 8, PNA 2, arthritis 1, phlegmon 1)
• Renal biopsy in 6 pt showed proliferative GN with
  various degrees of crescent formation and
  glomerular deposition of IgA , IgG and C3
• Elevated serum IgA/IgG and immune complexes
  levels
• High number of T cells with Vb usage in the
  TCR ? Superantigen driven event
• Named MRSA Nephritis or Superantigen- related
  Nephritis

Spector DA et al, Clin Nephrol 1980 14
256 Koyama A et al, Kidney Internat 1995 47 207
36
MRSA and PIGN

• Recent reports similar features after MSSA and
  MRSE infections
• Clinical presentation
• - acute RF with hematuria, severe proteinuria
• - onset 2-16 weeks after infection
• - /- purpura, /- hypocomplementemia
• Mostly mesangial proliferative GN, often with
  crescents and (pre-) dominant mesangial IgA
  deposits
• Several cases do not have subepithelial humps,
  the hallmark of PIGN
• Treatment of infection lead to resolution of GN
  however 40-60 of pt developed ESRD
• Steroid treatment was related to the death in 2
  people but recent report suggest positive outcome
  if used after cure of infection

Nagaba Y et al, Nephron 2002 92 297 Yoh K et
al, Nephrol Dial Transplant 2000 15
1170 Shimizu Y et al, J Nephrol 2005 18
249 Okuyama S, Clin Nephrol 2008 70 344
37
Pathogenesis

• Link between staphylococcal enterotoxins and T
  cell/cytokine activation?
• Superantigen triggered cytokine activation leads
  to class switching to IgA?
• Link to a staphylococcal cell wall antigen that
  co-localizes in glomeruli of patients with MRSA
  nephritis?
• Other IgA dominant immune responses against
  staphylococcal antigens? (eg an envelope antigen
  called probable adhesin that is also found in
  IgA nephropathy)

Nagaba Y et al, Nephron 2002 92 297 Yoh K et
al, Nephrol Dial Transplant 2000 15
1170 Shimizu Y et al, J Nephrol 2005 18 249
38
Diabetes, Staph and the Kidney

• In 2003, Nasr et al in New York reported 5 pt
  with DM who developed an IgA dominant GN after
  staphylococcal infection
• Histology showed diabetic nephropathy with
  superimposed endocapillary proliferation with
  neutrophils and some degree of interstitial
  inflammation
• IgA sole immunoglobulin in 3 cases IF with
  mesangial or mesangial/capillary granular IgA and
  C3 staining
• EM all cases with predominantly mesangial
  deposits and sparse subepithelial deposits
• Findings were similar to IgA nephropathy but all
  pt had low complement, endocapillary
  hypercellularity and humps

Nasr et al, Hum Pathol 2003 34 1235
39
(No Transcript)
40
Endocapillary proliferation
Nodular sclerosis
Subendothelial and subepithelial deposits
Granular IgA
41
IGA-PIGN vs IgA nephropathy
IgA nephropathy ?, IgA1 and J chain
predominance?
Nasr SH et al, Kidney International 2007 71
1317
42
Diabetes and IgA nephropathy

• Increased serum levels of IgA and IgA immune
  complexes
• - secondary to (silent) mucosal infection
• - abnormal IgA clearance (abnormal
  glycosylation or sialylation)
• Thickened BM and mesangial sclerosis hinders
  subepithelial deposit formation gtgt predominantly
  mesangial deposition

Nasr SH et al, Kidney International 2007 71
1317
43
IgA predominant postinfectious GN

• Recently, Haas et al added 13 cases from John
  Hopkins University
• Selection criteria included IgA deposits 3 or
  more subepithelial humps, no clinical history
• Not only associated with staphylococcal infection

Haas M et al, Hum Pathol 2008 39 1309
44
Case follow-up

• 7/11 Proximal femoral osteotomy and acetabular
  excavation performed antibiotic cement beads
  with vancomycin/tobramycin placed
• On 7/17, vancomycin switched to linezolid given
  worsening renal failure
• Creatinine slowly improved
• 7/30 8.9 8/14 5.9 10/08 2.7

45
Summary

• Epidemiology of APIGN is shifting
• Diabetes, alcoholism and age emerge as major risk
  factor prognosis is worse in pt with
  comorbidities and renal inflammation
• Microbiology is changing and staphylococci are
  increasingly important in APIGN
• Histologic pattern are changing, especially in
  immunocompromised persons

46
Summary

• IgA predominant APIGN is recognized as 3rd entity
  of staphylococcal associated GN
• IgA dominant PIGN can be associated with diabetic
  nephropathy
• Exact pathologic diagnosis and pathogenesis is
  still under debate
• This entity has to be differentiated from IgA
  nephropathy (and pauci-immune ANCA related GN)
• Treatment of infection can lead to recovery
  however, pt with underlying diabetic GS have poor
  prognosis

47
Thanks!
