The Basic Technology Research Programme

1
The Basic Technology Research Programme

• Proof of Concept Studies Consortia Building
  Networks

2
Background

• Cross research council endeavour
• administered by EPSRC
• Funding for research to create a new technology
• Change the way we do science
• Underpin the future industrial base

3
Background

• 15 research projects funded up to April 2003
• Total funding for this period - 41M
• To support large, long term, high risk, high
  impact research consortia
• Encourage investigation of speculative ideas

4
Background

• Two levels of funding
• One year start up
• Full grant up to five years
• Two types of start up funding
• Proof of concept
• Consortia building networking

5
Proof of Concept Studies

• One year funding up to 100K
• Research to investigate feasibility of developing
  the new technology
• Output a business case for the next step of
  investigation to be submitted in May 2004
• Basic Technology Programme
• Existing Research Council initiatives
• DTI programmes

6
Consortia Building Networks

• Involvement of the users of the new technology at
  a very early stage
• Funding to form networks hold workshops

7
ParaSurf in silico Screening Technology

• Basic Technology Funding for October 2003 to
  September 2004
• Proof of concept
• Consortia building networking
• Academic partners
• University of Portsmouth
• University of Erlangen
• University of Southampton
• University of Oxford
• University of Aberdeen

8
ParaSurf Proof of Concept Research Programme

• Development of techniques to describe irregular
  solids surfaces
• Development of projection pattern recognition
  techniques for non-planar colour-coded surfaces
• spherical harmonics, molecular topology
• Conformational analysis
• Rigid body dynamics incorporating surface
  features
• rigid parts of molecule treated as anisotropic
  solids linked by rotatable bonds
• Investigate how best to generate prediction
  models using surface properties that define a low
  dimensional chemical space
• QSAR, pattern recognition, artificial
  intelligence, analysis of surfaces
• Bench marking using Grid computing

9
ParaSurf Proof of Concept Research Programme
10
Potential applications of the in silico screening
technology

• High throughput virtual docking
• Physical property mapping
• ADMET prediction
• Long time-period simulation techniques
• Crystallisation and solubility
• Prediction of tautomers
• Chemical reactivity and metabolism

11
(No Transcript)
12
ParaSurf Progress Report

• Letchworth, 16th March 2004

13
Main Areas

• Molecular Surfaces and Property Calculation
• RGB Encoding Pattern Recognition
• Conformational Analysis
• Rigid Body Molecular Dynamics
• Analysis of Variables QSAR models
• Grid Computing
• Consortium Building

14
Datasets

• Small
• Consensus Set of 74 Drug Molecules (diverse)
• QSAR set (31 CoMFA steroids)
• Medium
• WDI subset (2,400 comps)
• Harvard Chembank dataset (2,000 comps)
• Large
• WDI (50,000)
• Maybridge (50,000)

15
Example Molecule
Allopurinol
16
Surface Definition Local Property Calculation
17
Calculations

• 3D co-ordinates from CORINA
• QM calculations with VAMP
• Local Properties and surfaces from ParaSurf

18
ParaSurf v1.0

• Surfaces
• Isodensity Surfaces
• Shrink Wrap
• Marching Cube
• Surfaces fit to Spherical Harmonics
• Properties
• MEP, LIE, LEA and LP
• Encoded at points on the surface
• Encoded as Spherical Harmonic Expansions

19
Small molecule
20
RGB Encoding Pattern Recognition
21
RGB Encoding

• Each Local Property encoded as a colour
• LIE encoded on Red channel
• LEA encoded on Green Channel
• LP encoded on Blue Channel

22
Allopurinol RGB Surface
23
RGB Encoding

• Alternative Encoding
• LIE
• LEA
• Absolute value of MEP

24
Allopurinol RGB Surface
25
Conformational Analysis
26
Conformational Analysis

• Efficient All Atom MD analysis (DASH)
• Treated as time series (not Cluster Analysis)
• Scales linearly with simulation length
• No need for arbitrary choice of number of
  clusters
• Can be analysed using Markov Chain methodology

27
MD studies of Rosiglitazone
28
(No Transcript)
29
Rigid Body Molecular Dynamics
30
Rigid body molecular dynamics

• Well founded methodology e.g. CNS / XPLOR (Axel
  T. Brunger, Stanford University)
• Idea is to use rigid groups to model flexibility
• In the ligand
• and the protein binding site.
• Allows time-steps of 10fs to 20fs.

31
QSAR models
32
Distribution of Properties
33
Correlation Matrix
34
Descriptors

• 34 descriptors based on Normal Distribution
• Principal Components
• Spherical Harmonic Co-efficients

35
Descriptors for LIE
36
Other Descriptors

• Moments
• Order 1 Mean
• Order 2 Variance
• Order 3 Skewness
• Order 4 Kurtosis
• Overlapping Gaussians
• Derived from previous work on MD analysis

37
QSAR models

• Models derived from Local Properties
• Surface Integral Model for Solvation Energy
• RMS Error 0.75 Kcal
• Drug Likeness
• SOMs trained on WDI (drugs) Maybridge (general)
• Parameters from PC of Local Property Descriptors
• Medium sized datasets superimposed on SOMs

38
(No Transcript)
39
(No Transcript)
40
GRID Computing
41
GRID Computing

• ParaSurf compiled on
• SGI IRIX
• Windows
• Linux (SUSE)
• IBM AIX
• Future Platforms
• SUN Solaris
• GRID enabling at Portsmouth (Mark Baker),
  Southampton and Oxford.

42
Provisional Timings

• SGI R10k, 256MB
• VAMP 30s/compound
• ParaSurf 10s/compound
• Intel 1.8 Xeon/ AMD Athlon XP-2000
• ParaSurf 2s/compound
• SGI FUEL Workstation R14K
• ParaSurf 2s/compound

43
Conclusions
44
Conclusions

• Properties can be calculated
• Properties can be RGB encoded
• Properties are local
• Properties can be used for QSAR models

45
(No Transcript)
46
Computer vision methods for comparing molecular
surfaces

• Comparing and recognising 3D objects is an active
  research area in robotics and AI.
• Fast methods have been developed for database
  indexing.
• Rotationally invariant descriptors of 3D objects
  are possible.

47
Pattern matching on molecular surfaces

• Can we recognise similar surfaces?
• Can we recognise similar surface fragments?
• Can we identify the most similar surface to our
  target?
• How do we compare field descriptors on the
  molecular surface?

48
Rotationally invariant 3D object descriptors

• Internal coordinates e.g. a distance matrix.
• Energy distributions based on the spherical
  harmonics.
• The spherical harmonic coefficients.
• Radial integration, radial scanning, and
  invariant moments.

49
Surface comparison

• Two different approaches
• Using spherical harmonic molecular surfaces J.
  Comp. Chem. 20(4) 383-395 Ritchie and Kemp 2000
  University of Aberdeen.
• Partial molecular alignment via local structure
  analysis J. Chem. Inf. Comput. Sci. 40(2)
  503-512 Robinson, Lyne and Richards 1999
  University of Oxford.

50
An example grid of surface points
A grid is placed on a ParaSurf surface in order
to reduce the number of surface points from 4038
to 55.
51
Partial molecular alignment

• We do not know which points on the two surfaces
  need to be aligned with each other.
• The essential approach is
• all surface points on one surface are compared
  with all points on the other.
• For two surfaces, with M and N points, MN
  possible alignments are possible
• we want to reduce this large search space!

52
Voting pairs are possible alignments
The voting pairs can have a critical effect on
the quality of the surface alignment.
53
The voting table

• A voting table may list all matching pairs of
  surface points (i.e. all possible alignments).
• A smart editing of votes within the voting table
  can enable speed and accuracy.
• We want to only consider alignments between
  similar local features on the surfaces.
• The more false votes we have in the voting table
  the harder it is to find the optimum alignment.

54
A distance matrix can be used to describe local
surface features
P1
The internal distance matrix can be used to
distinguish between surface points.
P3
By comparing rows and columns from distance
matrices of different surfaces we can detect
similar surface features.
P2
55
Selecting the voting pairs

• Similar local features, or interest points, on
  the molecular surface can be identified using a
  distance matrix.
• For a point on each surface
• Arrays of internal surface point distances are
  calculated for both points i.e. dist1, dist2.
• After a crude alignment, the absolute difference
  of dist1 and dist2 indicates the similarity
  of this pair of points.

56
Scoring the possible alignments

• The optimum alignment is composed of a rotation R
  and a translation T.
• Apply the current rotation r
• Score the translation vectors t p q of all
  voting pairs (p,q) using a gravitational
  potential
• High potentials identify clusters of similar
  translation vectors.
• The vector with the highest potential is the
  optimum translation T.
• Scoring all r gives R and T.

57
Scoring with a gravitational potential
Translation vectors (x,y coordinates plotted)
Some voting pairs for example rotations
58
Can we use the potential to compare aligned
structures?
59
Can we get better alignments with more voting
pairs?
60
Example alignments
4
3
2
1
61
Example 1 RMSD 0.75
A
B
62
Example 2 RMSD 1.05
A
B
63
Example 3 RMSD 1.20
A
B
64
Example 4 RMSD 1.89
A
B
65
Matching with the surface field descriptors
example 1

• Surfaces are aligned (using a quick search
  method e.g. 45º rotations).
• Best N alignments are selected.
• Each alignment is gently perturbed and optimised
  using the field descriptors.

66
Matching with the surface field descriptors
example 2

• Align using the field descriptors values to
  identify suitable voting pairs
• only match on similar field descriptors.
• Filtering can be achieved by aligning the fields
  separately.
• More accurate alignments can be generated by
  combining field values.

67
Parameterisation

• Voting pairs
• The distance between points in surface grid.
• The number of voting pairs.
• Identifying and selecting local features.
• How to represent the fields at interest points.
• Scoring
• Scoring function to identify the correct rotation
  and translation (e.g. gravitational potential).
• Target function to compare different surface
  alignments (e.g. RMSD).
• Optimising the alignments.

68
(No Transcript)
69
Molecular Surface Property Graphs
Characterize the behaviour of a property f S ?
? on a molecular surface S, in terms of a
directed graph G on S derived from the gradient
vector field x ? grad f(x) Vertices (G)
fixed points of grad f ( critical points of f
). Edges (G) stable and unstable manifolds of
the saddle points.
70
Gradient Flow

• minima
• saddles
• maxima

71
Molecular Surface Property Graph
72
Applications

• Similarity
• Pattern recognition methods
• Maximal common subgraphs
• Complementarity
• Compare ligand graph with graph induced on
  ligand
• by receptor
• QSAR
• Topological indices

73
Example

• S Connolly Surface
• f(x) Electrostatic Potential ? q(i) / d(x,i)
• Method
• Locate critical points of f (Newton-Raphson).
• Linearize at saddles, find eigenvectors of
  Hessian( f ).
• Integrate gradient vector field forward in time
  from 2 points on
• unstable eigenvector, backward in time from 2
  points on stable
• eigenvector (Runge-Kutta).
• Integrate to boundary of Connolly surface patch,
  then continue
• on adjacent patch until reaching another
  critical point.

74
Allopurinol
8 maxima 7 minima 13 saddles
maxima saddles minima ? (S) 2
75
Work in Progress

• Implementation for
• S spherical harmonic surface
• f MEP, LIE, LEA and LP
• Use images of triangulation points as starting
  points for Newton-Raphson search for critical
  points.
• Automatic differentiation.

76
(No Transcript)
77
Summary
Compound screening
Spherical harmonic representation Dave Ritchie
78
Future directions

• High-throughput ligand docking
• Superimposition of ligand and a negative of the
  receptor
• Use of the fields to drive simulation
• Use of the fields to derive intermolecular forces
• Rigid-body motions long time-step MD
• Free energy calculations

79
A hierarchy of methods

• Rapid screening using computationally fast
  approaches
• 3D fields Andy Vinter
• On reduced set
• Semi-empirical property calculations and
  alignments
• On most interesting molecules
• Density-functional or ab-initio calculations and
  alignment
• More accurate molecular representations are used
  as appropriate, as resources allow
