Gene Expression new frontiers

1
(No Transcript)
2
Gene Expressionnew frontiers

• the processes by which information contained in
  genes and genomes is decoded by cells, in order
  to produce molecules that determine the
  phenotypes observed in organisms,
• transcription is controlled so that the correct
  DNA sequences are expressed as mRNA in the right
  cells, at the right time, and in the right amount.

- and, now we are learning -
- processing and translation of mRNA is further
controlled (through RNA/Protein complexes), via
ancient, conserved processes.
3
Central Dogma addendum
DNA
RNA
Transcription Factors
Protein
4
Transcriptional Network(cell cycle)
(example)
5
Central Dogma addenda
DNA
TGS Transcriptional Gene Silencing
RNA
Transcription Factors
Protein
PTGS Post Transcriptional Gene
Silencing
6
tiny RNAs (20-to-25 nt RNAs)

• in eukaryotic cells, tiny RNAs function as
  transcriptional regulators of gene expression in
  (at least) three distinct pathways,
• small interfering RNAs (siRNAs) direct RNA
  destruction via the RNA interference (RNAi)
  pathway,
• and transcriptional regulation via epigenetic
  processes,
• micro (miRNAs) regulate RNA translation.

7
Ancient History (1)
Cell 75, 843 (1993)
Some development timing genes code for short
anti-sense molecules, appeared to be unique to
C. elegans.
8
miRNAmicro-RNA
How would a cell express this?

• Post-transcriptional regulatory genes,
• contain 22 nucleotides (processed),
• are cleaved from somewhat larger double stranded
  RNA (dsRNA) precursors - by a protein called
  Dicer
• are expressed in certain cell types and at
  certain times during differentiation (also
  called short temporal (stRNA).

9
Anti-Sense Blocking of Translation
miRNA
Why use RNA to block mRNA function?
10
miRNAs

• Conserved amongst eukaryotic cells,
• Often associated with hetrochronic genes,
• difficult to identify in genomic sequences
  because they dont have long ORFs,

How might you locate them?
11
Over Expression Studies

• Make a gene construct with,
• Structural Gene,
• Active promoter (often from a virus promoter),
• Marker gene to be able to determine
  transformation.

• Expect,
• Higher levels of protein,
• Gene-dosage phenotypes,
• Glorious publication.

Frequent Results no protein produced, scorn from
senior scientists.
12
Anti-Sense Studies

• Another good idea use a transgene with the
  coding sequence reversed...

13
Expected Results

• Low, to no detectable single stranded transcript,
• Low, to no protein products,
• Glorious publication detailing gene function.

• Actual Results (Wacky)
• Phenotypes ranged from death to
  over-expression,
• Transcript levels were also extremely variable,
• Scorn from senior scientists.

14
Ancient History (II)(co-suppression)

• Transgene expression often decreases as the copy
  number of transgenes increased.

15
Co-suppression Modes

• ...Transcriptional Gene Silencing (TGS),
• RNA functions in the methylation of promoters and
  structural elements of genes,
• ...Post-Transcritional Gene Silencing (PTGS),
• involves the specific degradation of mRNA via a
  double-stranded RNA intermediate, dsRNA.

16
RNAiRNA interference

• ...while attempting to do anti-sense KO of gene
  expression in C. elegans, Guo and Kemphues, Cell
  81, 611 (1995) observed that sense and anti-sense
  strands worked equally,
• in an anti-sense experiment, a gene is
  constructed so that it produces a complementary
  strand to an expressed transcript,
• the goal is to complement, thus inactivate the
  mRNA.
• ...following up, other researchers found that
  dsRNA worked at least an order of magnitude
  better that either sense or anti-sense strands.

17
RNAi

• ...siRNA control of gene expression by RNA
  processing is now considered a common element in
  eukaryotic cells,
• defense against viruses,
• control of transposable elements,
• regulate gene expression?

• useful for doing Reverse Genetic studies,
• dsRNA triggers sequence specific degradation of
  complementary mRNAs.

18
(No Transcript)
19
Today
Nature 408 331 - 336
20
Ce III 2315 Genes
http//www.wormbase.org
21
Functional GenomicsThe Question(s)

• Can we establish a high throughput system to
  assign cellular function to genes identified in
  metazoans?
• - using cell division and associated processes
  as the scorable phenotype,

• In the process, can we learn about
• cell division genes,
• embryology,
• general development,
• anything else?

22
Differential Interference Contrast
Microscopy Nomarski Optics
23
DIC Microscopy Nomarski Optics
24
Reverse GeneticsKnockomics, Knockology...

• Sequence to Phenotype to Function

25
Forward vs. Reverse Genetics

• Treat thousands of organisms with a mutagen,
• random mutagenesis,
• Identify an individual with a phenotype of
  interest,
• Identify the gene.

• Treat thousands of organisms with a mutagen
  (usually),
• random mutagenesis, or other gene expression
  block,
• Identify individual(s) with a genotype of
  interest,
• Identify the phenotype.

26
Reverse GeneticsFunctional Genomics
Function
Gene DNA Sequence
Phenotype Analysis
Gene Disruption
Development Physiology Cell Biology
27
New Data, New Technologynew paradigms

• The C. elegans genome is sequenced, and we can
  identify 2315 candidate sequences on Chromosome
  III.
• We can see cell division through a microscope,
  and further, we are able to identify many
  abnormalities.
• We have RNAi technology at hand to selectively
  knock down any gene we are interested in.

Further, RNAi can be added to cells prior to
fertilization, mitosis commences after
fertilization.
28
Reverse GeneticsDiscovery Research (High
Throughput)

• Few, if any, hypothesis going in,
• High throughput, (2232 genes),
• Lots of negative results, (87.1 of the genes
  tested),
• Value is in (12.9)
• the analysis of the data in concert with
  annotations in the data sets and references in
  the literature,
• the generation of materials for further
  hypothesis - or - discovery driven research.

29
dsRNAs (I)Where do they come from?

• PCR primer pairs were designed for each of the
  genes discovered via bioinformatic analysis of
  the sequenced chromosome,
• and confirmed through EST sequences, or
  experimental expression studies,
• shortest region gt 500 bp, or gt 90 of ORF.

30
dsRNAs (II)PCR Primers

• T3 or T7 promoter sequences were included in the
  PCR primers...

31
T3 and T7 RNA Polymerase

• Bacteriophage T3 and T7 RNA polymerases are
  DNA-dependent RNA polymerases with high sequence
  specificity for T3 or T7 promoters.
• T3 and T7 RNA polymerases synthesize RNA 5' to
  3'.
• These enzymes are isolated from an overproducing
  recombinant E. coli clone, and are available
  commercially.

32
dsRNAs (III)in vitro transcription

• T3 and T7 polymerases were used to make single
  stranded RNA,
• sRNA (sense) and asRNA (antisense)

33
dsRNAs (IV)Where do they come from?

• sRNA and asRNA are then mixed, and form dsRNA,

• Done for 2232 genes, all in 96 well plates...

34
dsRNAs (VI) x 2232

• Quality control
• Each dsRNA reaction product was run out on a gel,
  assayed to see if it migrated as a ssRNA or dsRNA
  based on the estimated size of the product(s)

ssRNA and ds RNA of the same length migrate
differently under electrophoresis.
35
dsRNAs (IV)Where do they come from?

• sRNA and asRNA are then mixed, and form dsRNA,

• Done for 2232 genes, all in 96 well plates...

36
Then What?

• dsRNAs (was) injected ... into the gonads of
  adult wild-type hermaphrodites, which were left
  at 20 C for 24 h,
• Embryos were then removed and analyzed for
  potential defects in cell-division processes,
  capturing 1 image every 5 s using time-lapse
  Nomarski Differential Interference Contrast (DIC)
  microscopy,
• A minimum of three embryos from three different
  worms were filmed from shortly after
  fertilization until the four-cell stage.

320c6
37
And More Progeny Tests

• Three animals were transferred to a fresh plate
  24 h after injection, and left at 20 C.
• Two days later, the plate was inspected with a
  stereomicroscope (2040x magnification) for the
  presence of eggs, F1 larvae and their
  developmental stage (normally L2L4).
• Two days after that, the plate was inspected for
  the presence of F1 adults (normally gt100), their
  overall body morphology and the presence of F2
  progeny.
• Partially penetrant embryonic lethality and
  subtle developmental defects were not scored in
  this analysis.
• Moreover, dsRNAs that gave rise to defects in
  less than 5 of the adult progeny were not
  considered as being associated with a phenotype.

38
But?

• Its supposed to be high throughput, so
  experiments were designed to minimize the time
  required,
• in part to make the acquisition of so much
  meaningless data palatable (89.1),
• in part because it is a whole lot of work no
  matter how you approach it,
• Remember, along with discovery, this experiment
  was designed to establish a workable paradigm for
  future large scale analysis of metazoan (and
  other complex) organisms.

39
So, Firstestablish reliability

• Injected 13 dsRNAs targeted to known components
  of the cell division process,
• all 13 known mutations were observable using DIC
  photography,
• This control tested RNAi efficiency, and the
  efficacy of DIC phenotype scoring...

13 of 13 genes were disrupted, based on clear DIC
image acquisition.
40
High Throughput Protocols 1st establish
acceptable failure rates...

• Tried mixing (multiplexing) dsRNA from 2 or more
  genes...

41
1. Then did it, 2. Then checked the results...

• When a phenotype was observed
• to see which of the two dsRNAs caused the
  phenotype, fresh worms were injected with the
  dsRNA (one at a time),
• genomic sequence was examined to make sure that
  only the dsRNA targeted gene was responsible,
• Gene families,
• Miscalled ORFs.

42
Then checked the results again...
Conclusion As a result, the DIC phenotypes
reported here almost certainly result from
inactivation of the expected genes.
43
(No Transcript)
44
For Example...

• Makes sense.

45
For Example (II)...

• Surprisingso many translation and ribosomal
  proteins involved in meiosis.

46
Forward vs. Reverse Scorecard

• 7 of 7 known chromosome III DIC observable, early
  embryo phenotypes observed,
• 9 of 14 late embryo phenotypes observed,
• 9 of 31 larvae/adult phenotypes observed.

7 of 7 known, plus 126 new genes!
47
Cousins and Orthologs!Everyone and Metazoans
48
Successful?

• High throughput Yes,
• Fidelity Yes, 7/7,
• Discovery Yes, gt 100 new genes involved in early
  embryo development, especially cell division,
• Helpful to Metazoan biologists?

49
Monday
50
(No Transcript)
51
Homologous Recombination Range

• Yes...
• mice, many well characterized mammalian cells,
• bacteria,
• yeast, (remember the bar code deletion project),
• No (maybe)...
• C. elegans (no),
• Arabidopsis (done once, not repeated),
• Drosophila (shown in principle, not repeated),
• the rest?

52
Huh?
53
(No Transcript)
54
Other Remodeling RNAs?

• ESTs (Expressed Sequence Tags) cDNA libraries
  are end sequenced,
• lots of non-protein-coding transcripts are
  found,
• Upwards of 60,000 RNA of these transcripts have
  been identified in the human genome,
• ignored until recently
• one active hypothesis is that they are involved
  in chromosome remodeling.

55
(No Transcript)
