ALIARDS: Adjuvant Therapy

1
ALI/ARDSAdjuvant Therapy

• Thomas Genuit, MD, MBA, FACSDirector of Trauma
  Sinai Hospital BaltimoreAss. Professor
  SurgeryThe Johns Hopkins School of Medicine

2
ARDS Tx. Approaches
Adjuvant Lung Therapy Inhaled NO, Prostacycline
(PGE2) Surfactant Therapy Corticosteroids Anti-inf
lammatory therapy NSAIDS, Vit C,E, PAF
inhibitor, anti-TNF, anti-IL 1, 8, NF-kB
Lisofylline, Pentoxyphylline O2 radical
scavengers, anti-oxidants a-Prot.-C (in
sepsis)C V V H Decrease Alv. EdemaDiuretics
ß2-agentsDopamine Enhanced alv.
Repairhepatocyte growth factorkeratocyte
growthfactor Nutrition therapyfatty acids,
anti-oxidants Gene-modulation
Sytemic Support Therapy Fluid Tx. and Cardiac
support Hypertonic solutionsInotropes, goal dir.
Tx. Source Control / Abx SIRS therapy Organ
support (MOF)
ARDS
Mechanical Lung Therapy Vent. Management Prone
position Tx. Recruitment maneuvers (partial)
liquid ventilation
3
ARDS Adjuvant Therapy
Mechanical Lung Therapy Prone position Tx.
Adjuvant Lung Therapy Inhaled NO Surfactant
Therapy Corticosteroids
4
Prone position Therapy

• ARDS an inhomogeneous disease process

5
Prone position Therapy

• Restructuring of VQ-zones ? posterior
  atelectasis precedes co-exists w. inflamm.
  process
• Pleural pressures much ? in de-pendent parts of
  lungchest-wall expansion (ventilation) mainly
  anterior
• In prone position pressures and ventilation
  distribution more uniform gt VQ-redistribution

6
Prone position Therapy

• Several studies since 1990s showed sign.
  improvement in
• Immediate and sustained oxygenation
• Resolution of posterior / dependent lung collapse
  and improvement of lung compliance
• Potential ALI-protective effect when instituted
  early(prevention of anterior alv. over-stretch
  and marginal zone open-close injury and
  posterior derecruitment)
• 65 - 75 of ARDS patients respond measurably
• CT suggested to identify patients w. predominant
  posterior disease
• Data on mortality equivocal

7
Prone position Therapy
Voggenreiter G, et al. Crit Care Med
199927(11)2375-2382
8
Prone position Therapy
Voggenreiter G, et al. Crit Care Med
199927(11)2375-2382
9
Prone position Therapy

• Currently no clear guides
• To predict who will benefit (most)
• When to start therapy general consensus to
  begin early
• Length of time per cycle / day to prone, for max.
  effect
• When to stop therapy until clear improvement of
  mechanics and
  oxygenation allow significant
  ventilator weaning
• Proning is not w.o. risk
• Access to ETT, lines,
• Pressure injury to face, brachial plexus

10
Prone position Therapy
11
Surfactant Composition Fct.

• Produced by type II alveolar cells
• 90 (complex) phospholipids, 10 surfactant
  specific (apo-)proteins
• Matures after secretion cycling through
  conversion of (apo-)proteins and alteration of
  PLs (enzymes, O2)
• Decreases surface tension in alv. and small
  airways, preventing (low pressure) collapse
• Important role in immune defense through specific
  and non-specific mechanisms (collectins,
  bacteriostasis)

12
Surfactant Changes in ARDS

• Decreased production / conversion of
  S(apo-)proteins
• Dilution / inactivation by plasma proteins and
  fluid (inflammatory leak CRP, Fibrinogen, )
  (117)
• Change of phospholipid composition ? function
  (i.e. neutrophil lipid peroxidation) (115, 118)

13
Surfactant Changes in ARDS

• Time dependent variable
• 30 gt70 reduction (severity, /- etiology)
• regional differences
• changes begin before clinical ARDS (at risk pt.
  ?!)
• may persist for weeks

14
Surfactant Changes in ARDS

• Result increased surface tension alveolar
  collapse decreased immune barrier /
  pro-inflammatory effect (filling of alveoli w.
  proteinaceous mat. migrated inflammatory cells)

15
Surfactant Tx Studies

• 1970s Recognition of function and composition,
  PL
• 1980s Early animal studies bovine/porcine,
  SP-A, B
• 1990s Early human studies Refined function
  and composition r-human products, r-SP-B, C, D
• 2000 Phase II/III human studies Combination
  therapy studies

16
Surfactant Tx Studies

• 1987 Lachmann (125) Delivery problems
• lt 30-50 of endotracheally admin.
  surfactantpresent in alveolus after 30 min.
• 1989 Chung (119) Component Problems
• Lipid moiety only modest surface activity at 37o
  w. CaCl repl. Soluble SP-A significantly
  contributes to function of surfactant preparation
• 1991 Robertson (112) Model Problems -gt Outcome
• SP-B restores nl. gas exchange in some animals w.
  severe parenchymal lesions effect of
  surfactant replacement depends on etiology of
  ARDS, animal model used and degree of lung injury

17
Surfactant Tx Studies

• 2002-4 Spragg r-SP-C Multi-center approach
• early treatment increases 28-day survival but not
  overall survival

18
Surfactant Tx Today

• Davidson et al. CC 2006 10(2)R41
  meta-analysis Adhhikari et al. Cochrane rev.
  2007, Ther.Resp.Med.
• 17 (20) adult human clinical trials 1996(0)-2006
  15(11) excl. all multi-center, 35-725 pts/trial
  total 1270 (1440) no SP, r-SP-C, bovine
  SP-B,C?PaO2FiO2 14 mmHg at 24 hours (0
  100)Increase in vent.-free days at 28 days (1-3,
  3 trials)no morality difference surfactant vs.
  control and between various preparations

19
Adhikari, Cochrane review 2007
Davidson, Meta-analysis 2006
20
Various Animal Models vs. human trials
Direct vs. systemic etiology
Early vs. late(r) stage ALI / ARDS
Dosing regimen delivery system
Porcine vs. bovine vs. r-human
ARDS risk pt. vs. mild vs. severe ARDS
Supportive Tx. differences and progress
SP-A, vs. SP-B, C vs. mixed products
21
Surfactant Tx Future

• Identification of patient at risk / early ARDS -gt
  Therapy
• BAL, plasma SP levels, ARDS gene array
• may take advantage of anti-inflammatory/bactericid
  al properties of some surfactant preparations
  (3, 9, 19)
• ? Increased benefit in patients with direct lung
  injury (4)
• after cardiac surgery, lung transplant
• aspiration, pneumonia, radiation

22
Surfactant Tx Future

• ? Combination with other therapy
• Inhaled NO
• Aerosolized dextran, cyclooxygenase inhibition,
• Steroid therapy (combining anti-inflamm.
  properties)

23
Corticosteroids

• Inflammatory response in ALI/ARDS
• Early acute diffuse alveolar damage (DAD, ALI -gt
  ARDS, lt 7d)- capillary leak and vaso- stasis -
  leucocyte extravasation, acute phase cytokine
  release- activation of coagulation cascade,
  extravascular fibrin deposit- platelet
  activation, damage/dysfct. of Pneumocytes II
• Proliferation (ARDS, 7-28d)- further
  inflammatory cell recruitment, anti-body
  production, macrocytes fibroblast migration /
  proliferation, begin remodeling of
  extracellular matrix -gt partial repair vs.
  organization
• Late fibrosis (gt 28d)- fibroblast
  proliferation, epithelial growth, angiogenesis,
  collagen maturation- some patients have
  persistent marked inflammation in stage II, III

24
Corticosteroids

• Mechanism of action
• Cytoplasmic heat-shock protein-bound GC receptors
• Regulate transcriptional activity of responsive
  genes
• Cell / tissue specific nuclear co-regulators
  enhance or diminish effects -gt cell / tissue /
  context-specific action
• Priming of innate immune response, suppression of
  adaptive immune response (TH-1) and promoting
  TH-2 tolerance.
• Increase opportunistic infections at higher doses
  ? opposite effect at lower doses (m7)

25
Corticosteroids Studies

• 1984-87 Sprug, Bernhard, Weigeltearly high
  dose therapy not effective patients w.
  sepsis
• up to 30 mg/kg/day methylprednisolone
  varied duration

26
Corticosteroids Studies

• 1991-2007 Meduri Defining the topic (24 papers)
• 1991 late ARDS Tx. / the Meduri protocol
• 1997-01 gluco-corticoid therapy and infection -
  lower dose steroids may be beneficial for
  phagocytic bacterial killing and suppress IRS,
  while higher doses suppress both(m7) - low dose
  steroids may be beneficial in sepsis, overcomming
  NFk-B inactivation of GCRs
• 2002-04 steroid resistance / prolonged Tx in
  unresolving ARDS - failure of activated GCRs to
  down-regulate transcription of inflammatory
  cytokines despite elevated circulating cortisol
  potentially reversible with prolonged GC
  supplementation

27
Corticosteroids Studies

• 1991-2007 Meduri Defining the topic
• 2007 low dose early prolonged Tx. - 1mg/kg/d,
  up to gt 28 days reduction of ventilation, ICU
  stay and mortal (42 21) lower infection rate
• 2007 treatment of unresolving ARDS w.
  prolonged Tx - up to 3 mg/kg/d and gt30 days-
  gluco-corticoid inadequacy as one etiology for
  development of ARDS

28
Corticosteroids Studies

• 2005 Lee Organ specific disease - low dose Tx.
• reduction of mortalit gt20 in post-op thoracic
  pts.
• 2006 Annane Prophylactic low dose Tx.in septic
  shock
• 177 pts., 50 mg Hydrocortisone q6 hours?
  Reduction of mortality 75 gt 53 (short-term)
  inconclusive if preventive for ARDS development
• 2006 Koontz Rescue Tx. for late ARDS in Trauma
• Trauma pts., improved oxygenation, ? vent. free
  days survival to discharge 78 (10)

29
Corticosteroids Therapy
ALI / ARDS
At risk patient- Sepsis- Thor. surgery- Trauma
lt7 d
7-28 d
gt28 d
Ultra-low-dose 50-100 mgHydrocortisoneevery 6
hours? Duration (5-12-28d)
Low-dose1mg/kg/dayMethylpred.?duration
Meduri ProtocolLoad 2mg/kg 2mg/kg/d 1 to
14 1mg/kg/d 15 to 21.50mg/kg/d 22 to
28.25mg/kg/d 29 to 32pot. crossover d 7-10
Meduri Protocol vs. higher dose more prolonged
salvage therapyup to 3 mg/kg/d gt30 days
? Combination therapies
Absence of contraindications (Infection, HIV,
PUD, WD)Confirmed Diagnosis, XR/CT,
PaO2FiO2lt200, FiO2gt50,
? Use of which clinical lung function markers
? Use of BAL / systemic inflammatory markers /
NF-kB expression /
30
Corticosteroids Studies

• 2006 Steinberg (NEJM) NHLBI multi-center trial
• 180 ARDS pts Meduri-protocol
• improved oxygenation and pulm. compliance ?
  ventilator free and shock free days, first 28
  days
• no significant ? in 60 / 180 day overall
  mortality
• Significant ? 60 180 day mortality in pts.
  enrolled gt 14 days no ? in infectious disease,
  but increased incidence of neuromuscular disease
• No support for the routine use of GCs in ARDS

31
Corticosteroids Future

• The topic continues to evolve
• 2007 Hudson, Da, Combination therapy
• Inhaled NO Animal studies up-regulates
  gluco-corticoid receptors, blunts inflammation
  and may make steroids more effective (lung
  selective Tx?)
• a-Prot CARDS from sepsis highest mortality
  a-Prot C has been shown to reduce mortality ?
  combination w. steroids

32
Inhaled Nitric Oxide

• Rel. new, 1980s endothelium-derived relaxing
  factor
• ARDS aveolar Hypoxia -gt local vasoconstriction
  -gt pulmonary Hypertension (children severe
  ARDS)
• I-NO is an ultra-short acting vasodilator
• Will affect mostly (marginally) ventilated areas
  -gt improve VQ mismatch
• Overall decrease of pulmonary resistance will
  improve cardiac function and DO2

33
Inhaled Nitric Oxide

• I-NO has anti-inflammatory properties
• Will reduce local inflammatory response in the
  lung
• Most initial clinical trials premature neonates
  / meconium aspiration ARDS -gt favorable outcomes
• Since 1990s Adult clinical trials fail to
  demonstrate desired results

34
Inhaled Nitric Oxide

• To date gt 200 trials in adults
• 2007, two Meta-analyses
• Sokol, Cochrane review 20 yrs, included 5 major
  studies and 535 patients Oxygen index, P/F
  ratio, vent.-free days, ILOS, HLOS, mortality
• Akhiklari, BMJ, included 12 trials and 1237
  patients mortality, duration of ventilation,
  pulm. arterial pressures, adverse events

35
Inhaled NO Oxygenation

• At 12 - 24 hours !

36
Inhaled NO Oxygenation

• ? No or Negative effect at 48 96 hours
• No difference in vent. free time (d 30-60-90),
  ILOS / HLOS

37
Inhaled Nitric Oxide

• No difference
• Oxygen index (MAwP x FiO2 x100)/PaO2 after 48
  hours
• Vent. free time at 30 or 60 or 90 days
• ICU-LOS or HLOS

38
Inhaled NO Mortality
39
Inhaled NO Mortality

• No difference low vs. high dose I-NO
• No difference in mortality at 30 or 90 days
• No difference if cross-over allowed for
  non-responders
• Mortal. Variability 29-60

40
Inhaled NO Side effects

• NO2 formation
• NO2, peroxynitrite and other NO metabolites may
  act synergistically w. other free radicals and
  cause further lung injury
• not clin. detected until very high doses of I-NO
  (gt80 ppm)lt 1-3 ppm
• Met-Hb formation
• not clin. detected (gt5) until high doses (gt 40
  ppm)
• Platelet dysfunction and bleeding
• NO blocks ADP and collagen induced adhesion/
  aggregation
• Rare effect

41
Inhaled NO Side effects

• Kidney dysfunction
• Nearly ¾ of patients showed increased renal
  dysfct. (post hoc analysis)

42
Inhaled NO Why, When, Future

• I-NO may yield improved results in some patients
• Premature Neonates / children (sev. Pulm HTN)
• ? Adults with severe pulm. HTN (CO improvement)
• ? Patients with initial OI gt 25 and
  immunosuppressed patients had increased /
  prolonged response to I-NO
• Combination therapy
• Cluco-corticoids in early ALI (inflammatory
  phase) and corticoid resistant patients
• Almitrine selective pulm. Vasoconstrictor
  (Gallart, 1998, 48 pts, low dose NO substantial
  immediate increase in PaO2 w.o increase in
  pulm. art. pressures.

43
ARDS Summary of Adjuvant Tx.
Integrated Systematic Organ Specific
Treatment Approach
44
(No Transcript)
45
ARDS Summary of Adjuvant Tx.

• Browner et al., Treatment of ARDS, Chest
  20011201347-67
• Adhikari et al., Pharm Treatment for Adults w.
  Acute Lung Injury and ARDS, http.thecochranelibrar
  y.com
