GlobusWorld

1
GlobusWorld 4Globus Execution ServicesWhat's
New in 4.0 and 4.2 GRAM, What's Planned for the
FutureStuart Martin - UC/ANLVirtual Machine
Management ServicesKate Keahey -
UC/ANLExperiences with the use of GRAM in the
LEAD portalSuresh Marru - Indiana UniversityThe
GridWay MetaschedulerRubén S. Montero -
Universidad Complutense de MadridSwift and
FalkonIoan Raicu - UC
2
What's New in 4.0 and 4.2 GRAM, What's Planned
for the Future

• Stuart Martin
• Argonne National Lab

3
Session Overview

• Overview of GRAM
• High-level client examples
• Service Interface Details
• Goals for Service Quality
• Future Plans

4
What is GRAM?

• GRAM is a Globus Toolkit component
• For Grid job management
• GRAM is a unifying remote interface to Resource
  Managers
• Yet preserves local site security/control
• GRAM is for stateful job control
• Reliable create operation
• Asynchronous monitoring and control
• Remote credential management
• Remote file staging and file cleanup
• GRAM is middleware
• End Users Beware!!

5
Grid Job Management Goals

• Provide a service to securely
• Create an environment for a job
• Stage files to/from environment
• Cause execution of job process(es)
• Via various local resource managers
• Monitor execution
• Signal important state changes to client
• Enable client access to output files
• Streaming access during execution

6
Traditional Interaction

• Satisfies many users and use cases
• TACCs Ranger (62976 cores!) is the Costco of HTC
  -), one stop shopping, why do we need more?

Local Jobs
Scheduler (e.g., PBS)
Compute Nodes
Resource A
6
7
GRAM Benefit
remoteGRAM4Jobs

• Add remote execution capability
• Enable client/devices to manage jobs from off of
  the cluster (PDA)

gramJob API
Local Jobs
GRAM4 Service
Scheduler (e.g., PBS)
Compute Nodes
Resource A
7
8
GRAM Benefit

• Provides scheduler abstraction

GRAM4Jobs
gramJob API
Local Jobs
Local Jobs
GRAM4 Service
GRAM4 Service
Scheduler (e.g., PBS)
Scheduler (e.g., LSF)
Compute Nodes
Compute Nodes
Resource A
Resource B
8
9
GRAM Benefit

• Scalable job management
• Interoperablility

GRAM4 jobs
gramJob API
9
10
Users/Applications Job Brokers, Portals,
Command line tools, etc.
GRAM WSDLs Job Description Schema (executable,
args, env, )
WSRF standard interfaces for subscription,
notification, destruction, EPRs
GRAM4
Resource Managers PBS, Condor, LSF, SGE,
Loadleveler, Fork
11
GT4 and Web Services
Custom Web Services
Custom WSRF Services
GT4WSRF Web Services
Registry and Admin
GT4 Container(e.g., Apache Axis)
WS-A, WSRF, WS-Notification
WSDL, SOAP, WS-Security
12
Higher-level Clients and User Examples
13
caBIG and Globus

• caGrid is built on top of Globus 4 WSRF Java Core
  and Security

14
caBIG - TeraGridIntegration

• Leave caGrid service infrastructure as is with
  the exception of the analytical services.

globus
15
caBIG - TeraGrid Gateway
16
caBIG - TeraGrid Gateway
17
Hierarchical Clustering Results
18
Condor-G Architecture
Personal Condor
Remote Resource
19
GridWay Components
DRMAA library
CLI
Job Submission Job Monitoring Job Control Job
Migration
GridWay Core
Request Manager
Job Pool
Host Pool
Dispatch Manager
Scheduler
Execution Manager
Transfer Manager
Information Manager
Job Preparation Job Termination Job Migration
Resource Discovery Resource Monitoring
Information Services
File Transfer Services
Execution Services
20
GridWay / Condor-G Benefit

• Scalable job management
• Throttling
• Metascheduling

GridWay jobs
gramJob API
20
21
Falkon Overview

• Falkons goal enable the rapid and efficient
  execution of many independent jobs on large
  compute clusters combines streamlined task
  dispatching, resource provisioning, and data
  diffusion

• Dynamic Resource Provisioning ? uses GRAM4 to
  provision resources on-demand based on load (i.e.
  wait queue length)

22
AstroGrid-D

• GEO600
• eScience group at Albert Einstein Institute
• part of LIGO, running the same Einstein _at_ home
  app, but on grid resources (not user desktops)
• Currently using D-Grid and OSG resources
• In production since Oct 07
• All jobs submitted using WS-GRAM (globusrun-ws)
• Averaging 4000 jobs per day

23
AstroGrid-D Performance

• 1 as reported on Einstein_at_home top users
• http//einstein.phys.uwm.edu/top_users.php

24
AstroGrid-D

• Scalable job management
• Throttling
• (Metascheduling)

GEO600 jobs
GEO600
globusrun-ws

• Uses Cron
• Save state (EPRs) onthe file system

24
25
Nektar-G2 Large Scale Flow
Simulationson TeraGrid

• The new version of Nektar-G2 features direct
  coupling between 3D domains.
• Increased volume of data transfer between 3D
  blocks requires high level of parallelism.
• MPIg is used for intra-site and inter-site
  communications on TeraGrid.

UC/ANL
NCSA
IU
RENO
SDSC
26
MPIg

• Grid-enabled MPI
• Co-scheduling
• GUR GARS
• Rendezvous

mpirun
GUR
globusrun-ws
GRAM4
multi
GRAM4
GARS
R
R
R
Scheduler
Scheduler
Compute Nodes
Compute Nodes
P
P
P
P
P
P
P
P
Resource A
Resource B
26
27
GRAM4Usage Statistics

• Averaging 692K per month in 2008
• 40 unique domains reported jobs in March 08
• e.g. .edu, .net, .gov, .org, .de, .es, .uk, .jp,

• Additional Details - http//www-unix.mcs.anl.gov/
  liming/stats/

28
Service Interface Details
29
Job Submission Options

• Optional file staging
• Transfer files in before job execution
• Transfer files out after job execution
• Optional file streaming
• Monitor files during job execution
• Optional credential delegation
• Create, refresh, and terminate delegations
• For use by job process
• For use by GRAM to do optional file staging

30
Job Submission Monitoring

• Monitor job lifecycle
• GRAM and scheduler states for job
• StageIn, Pending, Active, Suspended, StageOut,
  Cleanup, Done, Failed
• Job execution status
• Return codes
• Multiple monitoring methods
• Simple query for current state
• Asynchronous notifications to client

31
Secure Submission Model

• Secure submit protocol
• PKI authentication
• Authorization and mapping
• Based on Grid ID
• Further authorization by scheduler
• Based on local user ID
• Secure control/cancel
• Also PKI authenticated
• Owner has rights to his jobs and not others

32
Secure Execution Model

• After authorization
• Execute job securely
• User account sandboxing of processes
• Initialization of sandbox credentials
• Client-delegated credentials
• Multiple levels of audit possible
• Container
• GRAM Service Auditing
• Sudo
• Local resource manager

33
Secure Staging Model

• Before and after sandboxed execution
• Perform secure file transfers
• Create RFT request
• To local or remote RFT service
• PKI authentication and delegation
• In turn, RFT controls GridFTP
• Using delegated client credentials
• GridFTP
• PKI authentication
• Authorization and mapping by local policy files
• further authorization by FTP/unix perms

34
GRAM4 Architecture
Service host(s) and compute element(s)
SEG
Job events
GT4 Java Container
Compute element
GRAM services
Local job control
GRAM services
Local scheduler
Job functions
sudo
GRAM adapter
Delegate
Transfer request
Client
Delegation
Delegate
GridFTP
User job
RFT File Transfer
FTP control
FTP data
Remote storage element(s)
GridFTP
35
GRAM4 Architecture
Service host(s) and compute element(s)
SEG
Job events
GT4 Java Container
Compute element
GRAM services
Local job control
GRAM services
Local scheduler
Job functions
sudo
GRAM adapter
Delegate
Transfer request
Client
Delegation
Delegate
GridFTP
User job
RFT File Transfer
FTP control
FTP data
Remote storage element(s)
Same delegated credential can be Made available
to the user application
GridFTP
36
GRAM4 Architecture
Service host(s) and compute element(s)
SEG
Job events
GT4 Java Container
Compute element
GRAM services
Local job control
GRAM services
Local scheduler
Job functions
sudo
GRAM adapter
Delegate
Transfer request
Client
Delegation
Delegate
GridFTP
User job
RFT File Transfer
FTP control
FTP data
Remote storage element(s)
Same delegated credential can be used to
authenticate with RFT
GridFTP
37
GRAM4 Architecture
Service host(s) and compute element(s)
SEG
Job events
GT4 Java Container
Compute element
GRAM services
Local job control
GRAM services
Local scheduler
Job functions
sudo
GRAM adapter
Delegate
Transfer request
Client
Delegation
Delegate
GridFTP
User job
RFT File Transfer
FTP control
FTP data
Remote storage element(s)
Same delegated credential can be used to
authenticate with GridFTP
GridFTP
38
GRAM Service Auditing

• As of 4.0.5, GRAM generates a DB record per job
• Submitters DN, mapped user id, grid job id,
  local job id, stageIn job id,
• Part of TeraGrids solution to support community
  credential access from gateways
• Provides the capability for a TG grid user to get
  TG usage info using a grid job id (generated from
  GRAM EPR)
• Audit DB records provide join between grid job id
  and local TG accounting DB (job records)

39
TG Gateway Job Accounting
TeraGrid Resource Provider (RP)
-No Changes required to AMIE-DAI provides
virtualization for audit and accounting DBs
GT4 Java Container
Core Audit Table
Core
Deleg Audit Table
Delegation
RFT Audit Table
RFT
Client / Gateway
sudo
RM adapter
Create Job Get EPR
Control Jobwith EPR
MJFS
Resource Manager
RM log
- Query Using Grid JID
SEG
MEJS
GRAM Audit Table
RM Accounting
- Reply with Accounting record
User Job(s)
OGSA DAI
Local AMIE Accounting
Locally convert EPR to Grid JID
AMIE upload
Central TG Accounting DB
40
Goals for Service Quality
41
GRAM should

• add little to no overhead over to the underlying
  batch system
• Load cpu, memory, disk
• be able to manage as many jobs as the underlying
  batch system
• Max concurrency
• be able to keep a large cluster filled with jobs
• Throughput
• be reliable
• Not fall over / crash
• Service initiated recovery

42
Effect on Load

• UCSD testing results, Jan 08, Terrence Martin
• Version GRAM4 in GT 4.0.5
• Scenario Condor-G submitting 1000 jobs to the
  same GRAM4 service
• Service load was comparable to GRAM2
• Client memory was significantly higher than GRAM2
• This was improved in 4.0.7, saving cloned EPRs
  reduced memory significantly
• Client load was higher than GRAM2
• Probably mostly due to the inefficient use of
  memory
• Retesting with 4.0.7 is coming

43
Max Concurrency

• Total jobs a GRAM4 service can manage at one time
  without failure
• Early 4.0 testing achieved 32,000
• Has not been an issue

44
Throughput

• Number of jobs GRAM4 can process per second
• We are improving and formalizing our throughput
  testing
• 1000 Condor-G jobs with
• file staging, unique job dir and file cleanup to
  Condor as the LRM
• Achieved processing 1 job every 2 seconds
• file staging, unique job dir and file cleanup to
  Fork as the LRM
• Achieved processing 1 job every 1 second
• No staging, no delegation to Fork as the LRM
• Achieved processing 2 jobs every 1 second

45
Throughput Results

• Average seconds (3 runs) fork 1000 jobs
• Condor-g to GRAM to Condor LRM

46
Job Bursts

• Many simultaneous job submissions
• Recent TeraGrid testing showed limit around 200
  simultaneous jobs (upcoming TG08 paper)
• Most basic job was tested
• no staging, no delegation jobs
• Are the error conditions acceptable?
• Job should be rejected or timeout before
  overloading the service container or service host
• For tests gt 200, many client-side timeouts, which
  is ok
• but also other service/container issues that
  need further investigation

47
Reliability

• Service/Container should not fall over / crash
• Recent TeraGrid testing also showed a limit at
  10,000 jobs
• Repeated 200 simultaneous job submission tests,
  until 10,000 jobs in total, results in container
  requiring to be restarted - needs investigation
• OSG/CMS/ATLAS Goal
• handle 10k jobs from 2-3 users from 2-3 Condor-G
  instances - reliably
• Basic service recovery tests are successful, more
  sophisticated tests need to be written

48
GRAM4 Improvements in 4.2 Series

• Job termination interface
• Asynchronous model replaces blocking destroy
  operation
• Prevents a core thread being consumed per destroy
• New final job states
• userCancelDone, userCancelFailed
• Better Job lifetime controls for users and admins
• maxJobLifetime, jobTTLAfterProcessing
• Notification interface for GramJob API
• Now supports a single client notification
  consumer for many job submissions

49
GRAM4 Improvements in 4.2 Series

• Improved documentation
• Multi-threaded client example
• Using the GRAM4 throughput-tester program
• Useful for higher-level clients as optimized code
  examples
• GridWay, Condor-G, Science Gateways, Portals
• CEDPS logging
• Service logging formatted to be parsable /
  scriptable
• Related service events are linked with IDs
• Core session ID ltgt security authorization ltgt job
  submission
• Migration guides
• GRAM2 to 4
• GRAM4 from 4.0 to 4.2

50
GRAM4 DependenciesImprovements in 4.2 Series

• Java WS Core
• Upgrade to final WSRF specifications
• Makes 4.0 and 4.2 series wire incompatible
• Multiple service deployments during transition
• Notification performance Improvements
• Also in 4.0 series since 4.0.6
• http connection caching
• Maybe only useful for submission and
  notifications
• Must reuse client stub to benefit

51
GRAM4 DependenciesImprovements in 4.2 Series

• Java Authorization Framework
• Pluggable PIPs, PDPs and combining algorithm
• More sophisticated authorization capabilities for
  GRAM4
• GridShib

52
GRAM4 DependenciesImprovements in 4.2 Series

• RFT
• GridFTP connection caching
• manage a cache of GridFTP server connections
  amongst all RFT requests
• improve performance and reliability for GRAM4
  file staging jobs, 30 in some tests
• Also in 4.0 series since 4.0.6
• Exponential backoff and retry improvements

53
Dev.Globus - Open Development

• Globus governance model based on Apache
• Developers (committers) control direction of
  software components (projects)
• dev.globus.org
• GRAM project
• dev.globus.org/wiki/GRAM
• Email lists
• gram-user, -dev, -announce, -commit
• GT project email lists
• gt-user, gt-dev

54
Documentation

• 4.0.x GRAM documentation
• Guides admin, user, developer, overview, public
  interface
• www.globus.org/toolkit/docs/4.0/execution/wsgram/
• 4.2.x GRAM documentation (coming end May 08)
• www.globus.org/toolkit/docs/4.2/execution/wsgram/
• Main 4.0.x documentation
• www.globus.org/toolkit/docs/4.0/
• Download, release notes, links to all GT
  projects/ components

55
Future Plans
56
GRAM Auditing v2

• Strong community feedback
• Feature requests from OSG, SURA, D-Grid, APAC
• Getting development contribution from Shawn McKee
  (University of Michigan)
• Adding actions and timestamps needed for a
  complete view of service interactions
• Improve security
• Remove need for update privs to DB, inserts only
• Desire for integration with LRM accounting
• GRAM Fork accounting wanted
• Design complete system, but leave accounting
  integration to others
• Targeting 4.2 Q408

57
v2 Auditing tables
GT4 Java Container
Core Audit Table

• After request is received
• Include client hostname/IP address

Core
Deleg Audit Table
Delegation
RFT Audit Table
RFT
Sec Audit Table
Security

• After request is authorized
• Include credential attributes

MJFS
GRAM Audit Table(s)

• After job is received
• After job is submitted
• After job is done
• After job termination started
• Client initiated
• Lifetime expired
• Service processing failed

MEJS
58
Improve Reliability

• Improve tests to simulate user scenarios
• Work with TG and OSG users on the current issues
  and limitations
• Make improvements where necessary
• GRAM4, RFT, Java WS Core, higher-level clients

59
Prologue / Epilogue?

• A recent request for the ability to have GRAM4
  define and run a prologue and epilogue
• Maps to the LRM capability for this same
  functionality.
• Along with the LRM job submission include
• Prologue
• A program run before the main application
  execution
• Epilogue
• A program run after the main application
  execution
• Seems like valuable functionality, needs
  investigation for use with various LRMs
• http//bugzilla.globus.org/bugzilla/show_bug.cgi?i
  d5698

60
Standards Compliance

• JSDL
• Hopefully can resume JSDL work in 2008
• OGSA-BES
• No specific plans yet for support

61
Globus Advance Reservation Service (GARS)
62
Globus Advance Reservation Service (GARS)

• Globus incubator project
• Enable GT4 users to create and manage advance
  reservations of compute nodes.
• Leverage advance reservation support provided by
  LRMs via adapter interface (ala GRAM)
• MOAB, Catalina, MAUI
• Leverage GT4 Authn and Authz security model /
  callouts
• Service middleware for co-schedulers
• Complementary with execution services like GRAM
• SC07 demod alpha version of GARS
• GUR co-scheduled 2 GARS running on TeraGrid RPs
• Testbed running on TeraGrid
• UC/ANL, SDSC, NCSA

63
GARS Approach
ARFS
LRM Adapter
LRM
create reservations
ARS
manage
Client
J1
J1
J3
J3
create jobs
J1
J1
J3
MJFS
J2
J2
manage
MJS
Compute Cluster

• Client creates
• a reservation for 4 nodes
• a 1st job (J1) with 4 processes
• a 2nd job (J2) with 2 processes
• a 3rd job (J3) with 3 processes

GT WSRF Container
64
Thanks to the GRAM developers!

• Martin Feller - UC
• Joe Bester - ANL
• John Bresnahan - ANL
• Ravi Madduri - ANL
• Dina Sulakhe - UC
• Plus the entire GT dev team
