Title: Open Ocean Communities, Part 2


1
Open Ocean Communities,Part 2
  • Lecture 5
  • Marine Biology

2
Schedule for Today
  • Non-binding Practice Quiz - next week
  • Readings for next week - on the website
  • (http//www.bchs.uh.edu/coralreef)
  • The Great Climate Flip-flop
  • Greening the Ocean
  • Dis-crediting Ocean Fertilization
  • Review and finish Open Ocean Communities

3
Review of Last Lecture
4
Food Chain
5
Trophic Pyramids
  • Highest levels of productivity are upwelling
    regions in the temperate zone at near-shore sites

6

Biological aspects in the marine environments
that are in contrast to terrestrial systems
  • External fertilization.
  • Environment dominated by single-celled organisms
  • Longevity patterns opposite
  • - animals long-lived, plants shorter-lived.
  • Longer food chains, more complicated, higher
    efficiency
  • Neritic waters vs. Oceanic waters
  • - neritic extends to continental shelf
  • -influenced by coastal processes.

7
Life in the Plankton
  • Adaptation to planktonic life
  • Transparency
  • - high water content, no complex sensory organs
  • - feeding, respiration and swimming all
    simultaneous
  • 2. Life history adapted for high reproductive
    output in response
  • to patchy and unpredictable food supply
  • - high growth rates - 10 of body length per
    hour and
  • exponential through life
  • - short generation times
  • 3. High fecundity sexual and asexual reproduction

8
Life in the Plankton, cont.
4. Direct development (with exception of tadpole
stages in a few) 5. Viviparity and maternal
nutrition - live bearers 6. Large size - avoid
predation - colonial lifestyles 7. Generalist
feeding - takes advantage of all available
foods 8. High filtering efficiency - exploits
patchy planktonic lifestyle
9
Copepod Development
10
Plankton Size Classes
11
Planktonic Biomassby Season and Location
12
Larval Settlement
  • Various factors of the environment to which
    larvae respond in selecting a suitable site for
    settling.

13
Grazing on Phytoplankton
14
Primary Productivity (PP)
  Definition the rate of formation of organic
compounds from inorganic materials   - It is
approximately equal to photosynthesis   Gross PP
total carbon fixed Net PP Production -
Respiration   - Currency gC/m2/yr, integrated
over all depths
15
Primary Productivity, cont.
Important terms compensation depth - point
where photosynthesis respiration compensation
intensity - light level at the compensation depth
D, usually approximately equal to 1 surface
irradiance
16
Measurements of Productivity
How can productivity be measured? 1) Light-dark
bottle technique   light bottle photosynthesis
respiration dark bottle respiration
only   currency O2 level   difference between
the two equals photosynthesis, - this value
minus original level of O2 equals net
production or new production
17
Measurements of Productivity, cont.
2) C14 labeling method H14C03 (labeled
bicarbonate)   Carbon uptake during
photosynthesis 14C particles on filter x the
available inorganic carbon x 1.05 (factor to
account for differential uptake of
12C   problem tends to underestimate
productivity
18
Measurements of Productivity, cont.
3) direct measurement using satellite
imaging   measures intensity of reflected light
wavelengths emitted at 630 and 663 nm
(chlorophyll a and c)
19
Factors Affecting Primary Productivity
  1) Light - major factor 2) Nutrients and
trace elements - 2nd major factor 3)
Hydrography
20
Nutrients and Productivity
-important for formation of proteins for
biochemical pathways to function   Nitrate
NO3- Nitrite NO2- Ammonium PO4 Phosphate
PO4--   Minerals Si to form SiO2 (test in
diatoms and silicaflagellates)
Fe and other trace minerals
21
Light and Productivity
  • Light for production is measured in PAR
    (photosynthetically active
  • radiation) from 400-700nm wavelength
  • Most important for photosynthesis 630 and
    663nm, corresponding
  • to peaks in chla and chlc
  • - Red end of spectrum differentially absorbed
  • UV end is scattered
  • Extent of absorption can be measured as
    downwelling
  • (or extinction) coefficient

22
Irradiance and Productivity, cont.
Defined as Iz Ioe -kz(exponent)
kextinction coefficient, pure water k0.035
(PAR wavelengths averaged) the smaller number,
the clearer the water   z
depth , I intensity of light
(watts/m2) Io intensity of light
just below surface Iz intensity
of light at depth z
23
Compensation Depth
  • Compensation depth as a function of increasing
    number of phytoplankton
  • ranging from no plants to large number of
    plants.

24
Phytoplankton Irradiance Curves
25
Phytoplankton Photodynamics
  • - Algae are adapted to lower light levels
    relative to surface
  •
  • reasons - mixing
  • - avoidance of UV (migrate to depth less than
    surface)
  • - photo-inhibition at highest light levels
  • - Algal chlorophyll levels adapted to optimum
    light levels.
  • - Highest production usually at 33 surface
    values
  • As plankton multiply, light levels will decrease
  • compensation depth will become shallower through
    time during the development of an
    algal bloom

26
Mixing of Plankton
Turbulence - mixing driven by surface
winds   Critical depth (respirationphotosynthesis
) is deeper than compensation depth -
Circulation needed deliver nutrients, but also
moves passive algal cells into zones of low
light. Production can be shut down if there is
deep circulation.
27
Vertical Mixing of Plankton
28
Vertical Movement of Plankton
29
Production versus Depth and Irradiance
30
Euphotic Zone Variation
31
Global Net Primary Production
32
Primary Production in the Biosphere
33
Variations in Oceanic Primary Productivity
Geographic variation in productivity tropic lt
temperate ltpolar less seasonal to strongly
seasonal   Tropics less seasonal,
dependent on delivery of nutrients
more than light levels - thermal
stratification outside areas of upwelling
- very low production
34
Photosynthesis and Chla biomass in different
oceans
35
Seasonal Phytoplankton Succession
36
Next Week
Ocean Nekton
