How safe are you when using your computer

1
A Guide for Pupils and Students

• How safe are you when using your computer?

2
Is your computer out to harm you?

• No! is the simple answer
• however, you can harm yourself from careless use
  of computers

3
Computers can cause injury and harm health if
your

• posture is bad and
• you work without a break and
• you use them too much.

4
It is the mixture of hazards

• bad posture, and
• long sessions, and
• too much use

that can lead to harm.
5
Getting the right posture Step 1 Adjusting the
chair height

• Elbow level with top of keyboard

• Upper arm vertical or forward by 5?

• Fingertips just above the home row of the keyboard

• Forearms and hands horizontal

• Elbows with right-angle bends

• Elbows tucked in at the side

• Adjust your seat height to allow all of the above

Dos and Donts
6
Getting the right postureStep 2 Adjusting the
backrest

• Sit back in the chair

• The spine should be curved in at the back

• Adjust the backrest height to support the small
  of the back

• Sit erect, or lean slightly back by about 5?
  letting the backrest support some of your weight

Dos and Donts
7
Getting the right postureStep 3 Legs and feet

• Sit with thighs horizontal, not letting them
  support the weight of the body

• The lower legs should be vertical

• The knee joint should have a right-angle bend

• Feet should be flat on the floor, or resting on
  a footrest

Dos and Donts
8
Getting the right postureStep 4 Head and
shoulders

• The shoulders should be relaxed

• Slouching should be avoided

• The head should be kept up, but the screen must
  not be above eye level

Dos and Donts
9
Getting the right postureStep 5 Position of
keyboard screen

• Both the keyboard and screen should be directly
  in front of you not to one side

• You should not have to twist either your body or
  neck to use the keyboard or to look at the screen

Dos and Donts
10
Getting the right postureStep 6 Setting the
screen height

• Ideally the top of the screen should be just
  below eye level (but it must not be above eye
  level)
• The normal height of a laptop screen is also
  satisfactory

Dos and Donts
11
Getting the right postureStep 7 Setting the
screen distance

• The viewing distance should lie between 0.45 and
  0.75 metres
• The display screen should be moved back or
  forward to give comfortable viewing
• A viewing distance of 0.6 metres is about right
  for most

12
Getting the right postureStep 8 Setting the
keyboard position

• The keyboard should be about 10 cm back from the
  front edge of the desk giving your hands space to
  rest
• The keyboard should be parallel to the edge of
  the desk
• The letters H and K in the home row should be in
  front of you and in the centre
• The use of a palm-rest between the edge of the
  desk and front of the keyboard is recommended

Dos and Donts
Workstations with 2 users
13
Getting the right postureStep 9 Setting the
screen angle

• Screen glare should be avoided because it can
  cause you to
• twist your head and body, or
• crane your neck forward, or
• get into other bad posture positions in order to
  read the screen.
• If there is glare,
• swivel or tilt the screen to remove the unwanted
  reflection, or
• close the blinds

Dos and Donts
14
Getting the right postureStep 10 Using a mouse

• Position the mouse very close to the edge of the
  keyboard and about 10 cm from the front edge of
  the desk (a mini-keyboard brings the arm closer
  to a neutral posture, so reducing the tension on
  your arm and shoulder)

Mini-keyboard

• You should not have to stretch to reach the mouse
  and your arm and wrist should not be bent
  outwards away from the keyboard

• If lots of mousing is necessary, the keyboard
  should be shifted aside and the mouse placed
  directly in front of you

Dos and Donts
15
Getting the right postureStep 11 Stop using the
mouse

• Try not to use the mouse too much
• Use keyboard commands in place of drop-down menu
  instructions e.g.
• Ctrl B for Bold Text
• Ctrl I for Italic Text
• Ctrl C For Copy then Ctrl V to Paste
• CtrlFunction Key(3) for ALTERING CASE
• Ctrl S Save the current file

16
Getting the right postureStep 12 Document
holder

• Paperwork should be placed in a document holder
  so that it is below or alongside the screen
• You should not have to continually twist the back
  or neck to read documents

17
Getting the right postureStep 13 Neutral posture

• You should try to keep the body relaxed in a
  neutral posture with very little strain on any
  muscles
• Too much stretching, twisting or bending can harm
  you, especially if repeated day after day

18
Taking breaks

• You should be take a break of at least 10 minutes
  every hour
• Take suitable physical exercise during breaks
• Every so often, you should gaze outdoors,
  focusing on something distant (this allows the
  eyes to relax)

Dos and Donts
19
Over-use

• If you use a computer a lot, then you must
• take hourly breaks, and
• sit with correct posture.

20
Workstations with two users

• Minimum
• recommended
• table dimensions
• 1.5-1.8 metres wide
• by 0.750 metres deep
• You should sit directly in front of the keyboard
  and mouse (Step 8). The second person sits to one
  side.
• Tilt the screen so that you can both see it.
• Back to Step 8 Setting the keyboard position

21
Laptops

• Set up a laptop on a table or desk as specified
  for a desktop computer
• Adjust your chair for good posture

Dos and Donts
22
Dos and Donts

• Dont sit with your elbows far from your sides
• Dont extend the upper arm
• Dont flex your wrists by more than 15?
• Do keep your forearms horizontal
• Back to Step 1 Adjusting the chair height

23
Dos and Donts

• Dont slouch forward
• Dont lean back
• Do sit up straight
• Do let the backrest support some of your weight
• Back to Step 2 Adjusting the backrest
• Back to Step 4 Head and shoulders

24
Dos and Donts

• Dont sit on the edge of your seat
• Dont let your thighs support your weight
• Do sit back in your seat
• Do place your feet on the floor, or on a footrest

• Back to Step 3 Legs and Feet

25
Dos and Donts

• Dont place the keyboard at an angle to the desk
• Dont sit to one side of the keyboard
• Dont sit to one side of the screen
• Do sit directly on front of the keyboard and
  screen
• Back to Step 5 Position of keyboard screen
• Workstation with two users

26
Dos and Donts

• Dont place the mouse far back from the front
  edge of the desk stretching causes unnecessary
  tension in the muscles of the shoulder and upper
  arm
• Dont place the mouse far out to one side
  rotating the arm causes unnecessary tension in
  the muscles of the shoulder and upper arm
• Do place the mouse next to the side of the
  keyboard about 10 cm from the front edge of the
  desk
• Back to Step 10 Using a mouse

27
Dos and Donts

• Dont place the top of the screen above eye level
• Do sit with the top of the screen at eye level
• Or do sit with it 50 mm below eye level
• Or do sit with the centre of the screen at 35?
  below eye level
• Back to Step 6 Setting the screen height

28
Dos and Donts

• Dont sit with a laptop on your lap
• Dont use a laptop on the floor
• Dont use a laptop on a low table
• Do set up your laptop as you should a desktop
• Back to Laptops

29
Dos and Donts

• Dont peer at the screen if the image is hard to
  see
• Do swivel or tilt the screen to remove glare
• Do close a blind to block out the sun or sky
• Do clean the screen if dusty or smudged
• Do magnify the image or increase the font size
• Do adjust the screen brightness or contrast
• Back to Step 9 Setting the screen angle

30
Dos and Donts

• Dont work without a break
• Do take a break of at least 10 minutes every hour
• Do take some exercise
• Do look away from the screen from time to time,
  letting your eyes focus on something distant
• Back to Taking breaks

31
Summary

• Set up your workstation using all the rules on
  good posture
• Do take regular breaks, especially with exercise
• Dont use computers for extended periods.

32
It is the mixture of hazards

• bad posture, and
• long sessions, and
• too much use

that can lead to harm.
33
Index of pages on this Powerpoint
How safe are you when using your computer? A
Safety Guide for Pupils and Students

• Intro - how safe are you when using your
  computer?
• Is your computer out to harm you?
• Computers can cause injury and harm health if
  your
• Steps to getting the right posture -
• 1 Adjusting the chair height
• 2 Adjusting the backrest
• 3 Legs and feet
• 4 Head and shoulders
• 5 Position of keyboard screen
• 6 Setting the screen height
• 7 Setting the screen distance
• 8 Setting the keyboard position
• 9 Setting the screen angle
• 10 Using a mouse
• 11 Stop using the mouse
• 12 Document holder
• 13 Neutral posture

Taking breaks Over-use Workstations with two
users Laptops Dos and Donts related to steps
in getting the right posture etc. - Step 1
Adjusting the chair height Step 2 Adjusting the
backrest Step 4 Head and shoulders Step 3 Legs
and Feet Step 5 Position of keyboard
screen Step 10 Using a mouse Step 6 Setting the
screen height Laptops Step 9 Setting the screen
angle Taking breaks Summary
