Title: Software Test Documentation IEEE Std 8291998


1
Software Test DocumentationIEEE Std 829-1998
  • H. David Le
  • EEL 6883
  • Software Engineer II
  • Feb 16 2004

2
1. Scope
  • Standard for basic documentation for dynamic
    aspect of software testing as prescribed by IEEE.
    It defines purpose, outline, and content for
    each basic documentation.

3
2. References and 3. Definitions
  • Can be found in Centralized IEEE Software
    Engineering Standards Glossary.

4
4. Test Plan
  • Should provide
  • Scope
  • Approach
  • Resources
  • Scheduling

5
4. Test Plan (cont.)
  • It should identify
  • Item being tested
  • Features being tested
  • Testing task to be performed
  • Personnel responsible for each task
  • Risk associated with the plan

6
4.2 Outline
  • Test plan identifier
  • Introduction
  • Test items
  • Features to be tested
  • Features not to be tested
  • Approach
  • Item pass/fail criteria
  • Suspension criteria and resumption requirements
  • Test Deliverables

7
4.2 Outline (Cont.)
  • Testing tasks
  • Environmental needs
  • Responsibilities
  • Staffing and training
  • Schedules
  • Risk and contingencies
  • Approvals

8
4.2.1 Test plan identifier
  • Specify the unique identifier assigned to the
    test plan

9
4.2.2 Introduction
  • Summarize the software items and features to be
    tested
  • Project authorization
  • Project plan
  • Quality assurance plan
  • Relevant policies
  • Relevant standards

10
4.2.3 Test items
  • Identify the test items including the
    version/revision level
  • Requirements specification
  • Design Specification
  • User guide
  • Operation guide
  • Installation guide

11
4.2.4 Features to be tested
  • Identify all software features, and combinations
    of software features to be tested.

12
4.2.5 Features not to be tested
  • Identify all software features, and combinations
    of software features not to be tested and the
    reason

13
4.2.6 Approach
  • Describe the overall approach to be tested
  • Groups of features or combination
  • Activities
  • Techniques
  • Tools

14
4.2.7 Item pass/fail criteria
  • Specify the criteria to be used to determine
    pass/fail testing

15
4.2.8 Suspension criteria and resumption
requirements
  • Specify the criteria used to suspend all or
    portion of the testing activities

16
4.2.9 Test Deliverables
  • Documentation
  • Test plan
  • Test design specification
  • Test case specification
  • Test procedure specification
  • Test item transmittal reports
  • Test logs
  • Test incident reports
  • Test summary reports

17
4.2.10 Testing tasks
  • Identify the set of tasks necessary to prepare
    for and performing testing.

18
4.2.11 Environmental needs
  • Specify the necessary and desired properties of
    the test environment.
  • Hardware
  • Communication and system software
  • Mode of usage (e.g. stand alone)
  • Other software or supplies need to perform
    testing
  • Level of security
  • Special tools needed

19
4.2.12 Responsibilities
  • Identify following groups responsible
  • Managing
  • Designing
  • Preparing
  • Executing
  • Witnessing
  • Checking
  • Resolving

20
4.2.13 Staffing and training
  • Specific testing stall and skill level needed.

21
4.2.14 Schedules
  • Milestone
  • Time for each task
  • Schedule for task and milestone
  • Each resource use specific period of time

22
4.2.15 Risk and contingencies
  • Identify the high risk assumption and
    contingency plan for each.

23
4.2.16 Approvals
  • Specific the name and titles foe all person who
    must approve the plan.

24
5. Test design specification
  • To specific the refinements of this approach and
    to ID the features to be tested by this design
    and its associated tests.

25
5.2 Outline
  • Test design specification identifier
  • Features to be tested
  • Approach refinements
  • Test identification
  • Feature pass/fail criteria

26
5.2.1 Test design specification identifier
  • Specify the unique identifier assigned to the
    test design specification.

27
5.2.2 Features to be tested
  • Identify all software features, and combinations
    of software features to be tested.

28
5.2.3 Approach refinements
  • Specify the refinements to the approach
    described in the test plan.
  • Test techniques
  • Analyzing test results
  • Common attributes for any test case

29
5.2.4 Test identification
  • List the identifier and a brief description
    associated with the design.

30
5.2.5 Feature pass/fail criteria
  • Specify the criteria to be used to determine
    pass/fail testing

31
6. Test case specification
  • Identify a test case identified by the test
    design specification.

32
6.2 Outline
  • Test case specification identifier
  • Test items
  • Input specifications
  • Input specifications
  • Environmental needs
  • Special procedural requirements
  • Intercase dependencies

33
6.2.1 Test case specification identifier
  • Specify the unique identifier assigned to the
    test case specification

34
6.2.2 Test items
  • Requirements specifications
  • Design specification
  • Users guide
  • Operations guide
  • Installation guide

35
6.2.3 Input specifications
  • Specify each input required to execute the test
    case.

36
6.2.4 Output specifications
  • Specify output and features required to test
    item.

37
6.2.5 Environmental needs
  • Hardware
  • Software
  • other

38
6.2.6 Special procedural requirements
  • Describe any special constraints on the test
    procedures that executes this test case.

39
6.2.7 Intercase dependencies
  • List test cases that must be executed prior ro
    this test case.

40
7. Test procedure specification
  • Specific the step for executing a set of test
    cases.

41
7.2 Outline
  • Test procedure specification identifier
  • Purpose
  • Special requirements
  • Procedure steps

42
7.2.1 Test procedure specification identifier
  • Specify the unique identifier assigned to the
    test procedure specification

43
7.2.2 Purpose
  • Specify the step for executing a set of test
    cases.

44
7.2.3 Special requirements
  • Identify any special requirements that are
    needed for the execution of the procedure.

45
7.2.4 Procedure steps
  • Log
  • Set up
  • Start
  • Proceed
  • Measure
  • Shut down
  • Restart
  • Stop
  • Wrap up
  • Contingencies

46
8. Test item transmittal report
  • Identify any test items being transmitted for
    testing.

47
8.2 Outline
  • Transmittal report identifier
  • Transmitted items
  • Location
  • Status
  • Approval

48
8.2.1 Transmittal report identifier
  • Specify the unique identifier assigned to the
    test item transmittal report.

49
8.2.2 Transmitted items
  • Identify the test item being transmitted.

50
8.2.3 Location
  • Identify the location of the transmitted item.

51
8.2.4 Status
  • Describe the status of the test item.

52
8.2.5 Approval
  • Specific the name and titles of all person who
    must approve this transmittal.

53
9. Test log
  • The purpose of the test log is to provide a
    chronological record of details about execution
    of test.

54
9.2 Outline
  • Test log identifier
  • Description
  • Activities and event entries

55
9.2.1 Test log identifier
  • Specify the unique identifier assigned to the
    test log.

56
9.2.2 Description
  • Identify the item being tested.
  • Identify the attributes of the enironments in
    which the test is conducted.

57
9.2.3 Activities and event entries
  • For each event, including the beginning and end
    of activities, record the occurrence date and
    time along with the ID of the author.
  • Execution description
  • Procedure results
  • Environmental information
  • Anomalous event
  • Incident report identifiers

58
10. Test incident report
  • To document any event that occurs during the
    testing process that requires investigation.

59
10.2 Outline
  • Test incident report identifier
  • Summary
  • Incident description
  • Impact

60
10.2.1 Test incident report identifier
  • Specify the unique identifier assigned to the
    test incident report.

61
10.2.2 Summary
  • Summarize the incident

62
10.2.3 Incident description
  • Inputs
  • Expected results
  • Actual result
  • Anomalies
  • Date and time
  • Procedure step
  • Environment
  • Attempts to repeat
  • Testers
  • Observers

63
10.2.4 Impact
  • Indicate what impact this incident will have on
    the test plans, test design specification, test
    procedure specification, or test case
    specification.

64
11. Test summary report
  • To summarize the results of the designated
    testing activities and to provide evaluation base
    on the results.

65
11.2 Outline
  • Test summary report identifier
  • Summary
  • Variances
  • Comprehensive assessment
  • Summary of results
  • Evaluation
  • Summary of activities
  • Approvals

66
11.2.1 Test summary report identifier
  • Specify the unique identifier assigned to the
    test summary report.

67
11.2.2 Summary
  • Summarize the evaluation of the test items.

68
11.2.3 Variances
  • Report and variances of the test items from
    their design specifications.

69
11.2.4 Comprehensive assessment
  • Evaluate the process vs. the criteria.

70
11.2.5 Summary of results
  • Summarize the results.

71
11.2.6 Evaluation
  • Provide the overall evaluation of each test item
    including the limitation.

72
11.2.7 Summary of activities
  • Summarize the major test and event activities.

73
11.2.8 Approvals
  • Specific the name and titles of all person who
    must approve this transmittal
