The Dynamic Earth

1
The Dynamic Earth
2
Banda Aceh Shore (Before Tsunami)
3
Banda Aceh Shore
4
Banda Aceh Northern Shore (Before Tsunami)
5
Banda Aceh Northern Shore
6
Banda Aceh Before Flooding
7
Banda Aceh Flooding
8
Banda Aceh City Overview (Before Tsunami)
9
Banda Aceh City Overview
10
(No Transcript)
11
BBC Tsunami Tsunami pdf
12
Earths Internal Zones

• CORE
• 1/2 radius
• 2 parts
• 16 volume, but 31 of mass
• inner core - solid, mostly iron, 3400C
  3,000,000Gs gravity
• outer core - liquid, 3700-4300C

13
Earths Internal Zones

• MANTLE
• solid
• 10-2900km from surface
• 82 of volume, but 68 of mass
• iron, plus O, Si, Mg
• low velocity zone
• upper part of mantle
• semi-liquid (1-10)
• seismic waves slow down
• asthenosphere

14
Earths Internal Zones

• CRUST
• thinnest section
• 2 volume, 1 mass
• 10-65 thick
• earthquakes are generated
• plate movement
• lithosphere

15
determining the earths interior

• seismic wave A wave that travels outward from the
  site of an earthquake through the Earth.
• First to arrive at a monitoring site after a
  distant earthquake are the primary waves, or
  P-waves. These are pressure waves, a little like
  ordinary sound waves in air

16
(No Transcript)
17

• Seismic P-waves usually travel at speeds ranging
  from 5 to 6 km/s and can travel through both
  liquids and solids.
• Some time later (the actual delay depends on the
  distance from the earthquake site), secondary
  waves, or S-waves, arrive. These are shear waves.

• S-waves cause side-to-side motion, more like
  waves in a guitar string.
• S-waves normally travel through Earth's interior
  at 3 to 4 km/s they cannot travel through
  liquid, which absorbs them.

18
(No Transcript)
19
Seismic Waves
20
(No Transcript)
21
Composition of Earths Crust
22
Types of Crust Oceanic

• 71 of surface, dense, 10km thick
• oceanic ridge system
• 80,000 km long
• 1500-2500km wide
• 2-3km wide
• Abyssal Floor
• deep ocean basins, 5km below sea level
• trenches
• 8 km below sea level

23
Abyssal Sea Floor and Trenches
24
Continental Crust
Oceanic Ridge System and Continental Shelf

• Higher and thicker than oceanic crust
• averages 35km thick
• lower density--gt floats
• continental shelf- underwater portion of the
  continental crust

25
Crust Plates

• 100km thick (crust and mantle) - lithosphere
• move over the semi-liquid asthenosphere
• move at the same rate as finger nails grow (1
  inch/year)

26
Plate Tectonics

• Theory that explains the apparent movement of
  Earths plates and the geological process that
  occur at the boundaries
• The movement of the plates
• is an explain the biogeography of organisms
• is responsible for the earth surface features
• concentration of minerals

27
Plate Tectonics

• Evidence
• polar wander curves
• distribution of organisms
• distribution of ice
• shape of continents
• continued activity at boundaries

28
(No Transcript)
29
Plate Boundaries
30
PAST CONTINENTAL DRIFT
31
Divergent Boundaries

• Plates move in opposite directions
• ocean spreading
• creates ridge
• youngest area of ocean
• earthquakes and volcanoes

32
Convergent Boundaries

• Plates move toward each other
• often oceanic plate is subducted under
  continental plate
• subduction zone makes a trench
• earthquakes and volcanoes
• oldest part of ocean

33
Transform Fault

• Plates move in opposite, parallel directions
• San Andreas
• only earthquakes

34
External Processes Break Down Earths Surface

• Erosion
• material is broken down, worn away, and moved
• streams are primary source
• also wind and gravity

35
External Processes Break Down Earths Surface

• Weathering
• mechanical - a large rock is broken down into
  smaller rocks (frost wedging)
• chemical - a rock is decomposed by chemical
  reactions (oxidation, acid rain, hydration)

36
External Processes Break Down Earths Surface

• Mass wasting
• large amounts of material are carried downhill by
  gravity
• rock slides

37
External Processes Break Down Earths Surface

• Glaciers
• solid, dense ice
• moves downhill, carving as it goes
• carries material (leaves moraines)

38
External Processes Break Down Earths Surface

• Human Activities
• clearing land and vegetation
• over grazing
• mining
• off-road vehicles

39
Rock Types Igneous

• Rocks formed by molten rock (magma)
• made at plate boundaries
• below surface - intrusive
• Large crystals
• e.g.. granite
• above ground - extrusive
• lava, no crystals
• e.g.. obsidian, pumice
• Porphyritic both in. and ex.

40

• TYPES OF MAGMA
• FELSIC - LIGHT IN COLOR, MAINLY MADE OF FELDSPAR
  AND SILCA SiO2 , FLOW IS SLOW AND THICK,
• EX GRANITE,
• MAFIC - DARK IN COLOR, HIGHER OF IRON,
  MAGNESIUM AND CALCIUM, FERROMAGNESIAM, LOWER IN
  SILCA, FLOW IS FASTER AND THINNER
• EX BASALT
• IGNEOUS ROCKS ARE CLASSIFIED BY
• 1. TEXTURE - SIZE OF THE CRYSTALS
• COARSE-GRAINED, FINE-GRAINED, GLASSY
• 2. TYPE OF MAGMA - FELSIC OR MAFIC

41
Types of Igneous rocks FELSIC GRANITE, OBSIDIAN
- ( dark but still felsic ) PUMICE-(floats)
RYOLITE MAFIC GABRO, BASALT, SOCRIA( DOES NOT
FLOAT BECAUSE IT IS DENSER THAN PUMICE)
42
Rock Types Sedimentary

• Rocks formed from sediments, other rocks
• A. small rocks carried by water
• sandstone/shale
• B. compaction of dead animals
• limestone
• C. decomposition of plants
• coal
• 3/4 of Earths surface

43

• KINDS OF SEDIMENTARY ROCKS
• CLASTIC - FORMED FROM FRAGMENTS OF ROCKS THAT
  ARE CEMENTED TOGETHER - sandstone, shale,
  conglomerate
• DEPOSITION OF SEDIMENTS PLAYS A MAJOR ROLE IN THE
  TYPE OF CLASTIC ROCKS
• CHEMICAL OR PRECIPITATE - fallen out of a
  solution - rock salt, some limestone, gypsum
• ORGANIC - forms from the remains of plants and
  animals - coal or shell limestone
• Stratification

44
Rock Types Metamorphic

• Rock formed when a pre-existing rock is subjected
  to extreme heat, chemicals and/or pressure
• e.g.. marble, talc, graphite, slate, gneiss,
  schist
• Foliation layers or nonfoliated

45
The Rock Cycle
46
Mineral Resources

• Minerals naturally occurring materials in or on
  the crust that can be extracted and converted
  into useful materials
• within the scale of human activities they are
  nonrenewable because of the slowness of the rock
  cycle
• energy resources coal, oil, uranium
• metallic resources iron, copper
• nonmetallic salt, clay, water, sand

47
Categories of Mineral Resources

• Identified
• known location and quantity

48
Categories of Mineral Resources

• Undiscovered
• believed to exist, but location unknown

49
Categories of Mineral Resources

• Reserves
• identified resources that can be extracted
  economically

50
Categories of Mineral Resources

• Other Resources
• identified, but not economical, and undiscovered
• may become reserves

51
SOIL
The nation that destroys its soil destroys
itself - F.D.R.
52
Renewable or nonrenewable?

• Soil is created at a rate of 10 tons per hectare
  (2.5 acres) per year under the best conditions
• Under poor conditions, it can take thousands of
  years to form that much soil
• Soil is created by natural processes, but we are
  depleting it at a faster rate than it can be
  created

53
Formation of soils

• Soils are formed from weathering biological
  (plants and fungi), chemical (oxidation), and
  physical (wind, water)
• They are enriched by organic material from plants
  and animals
• The rate at which soil is made is determined by
  the temperature, the amount of soil organisms and
  biotic community

54
Major Characteristics of Soil

• Soil Composition
• Particle Size
• Soil Texture
• Organisms
• Soil Horizons

55
Soil Composition

• Soils are made of
• particles
• gravel (2-64mm) sand (.05-2mm) silt (.002-.05mm)
  and clay (less than .002mm)
• minerals
• organic material - humus (sticky brown residue
  from partially decomposed plants and animals)
• humus creates structure -how particles cling
  together
• humus holds minerals in soil

56
Particle Size

• Particle size determines the amount of air and
  water that is contained in a soil

57
Soil Texture
58
Properties of Soil Types
59
Soil Organisms

• The soil organisms are responsible for breaking
  down the organic material
• Algae live on the surface
• Fungi and bacteria are in the top few cms.
• One half teaspoon can contain hundreds of
  millions of cells
• bacteria fix nitrogen in the soil
• worms and insects add and cycle nutrients in the
  soil

60
Soil Horizons
61
(No Transcript)
62
Types of Soils Desert
63
Types of Soils grassland
64
Types of Soils tropical rain forest
65
Types of Soils deciduous forest
66
Types of Soils coniferous forest
67
Soil Erosion

• Soil erosion the movement of topsoil and leaf
  litter from one place to another
• Caused by wind and air
• Although erosion is normal, plants normally
  anchor topsoil
• logging, farming, grazing, burning an off-road
  vehicles are causing rapid erosion

68
Types of Erosion

• Sheet erosion
• surface water moves down a slope thin uniform
  sheets of soil are removed
• Rill erosion
• little rivulets gather to cut small channels
• Gully erosion
• water forms channels and ravines
• Streambank erosion
• washing away of soil from the banks of a river
• results from tree removal and cattle damage

69
Rill and Sheet Erosion
70
Gully Erosion
71
Global soil erosion
72
Desertification

• Denuding and degrading land inducing a
  desert-producing cycle
• productive potential of arid or semiarid land
  falls by 10 or more (more than 50)
• Things leading to desertification
• overgrazing of rangelands
• deforestation
• surface mining
• soil compaction
• salt buildup and waterlogging

73
Desertification
74
Salinization and Waterlogging

• Water contains dissolved salts
• When water evaporates, the salts are left behind
• Soil salt levels increase
• Farmers apply large amounts of water in order to
  leach salts deeper into the soil
• Roots are saturated with water, killing plants

75
Soil Conservation

• Contour plowing
• plowing across the field instead of up and down
• Strip farming
• planting different types of crops in rows (only
  one is harvested and other maintains soil
• Terracing
• shaping land to make flat shelves to hold water
• Alley cropping
• a form of intercropping where trees that can
  provide shade and nutrients for crops

76
Contour planting and strip cropping
77
Terracing
