Robust Multi-modal Person Identification with Tolerance of Facial Expression

1
Robust Multi-modal Person Identification with
Tolerance of Facial Expression
Niall Fox Dr Richard Reilly
University College Dublin Ireland
2
Overview

• Motivation
• Analysis for Speech and Mouth Feature Experts
• Results for Individual 2 Experts
• Automatic Integration of Experts
• Results of Integration
• Conclusions

•

3
Motivation

• Human Communication is multimodal
• Benefits of using visual information
• - Unaffected by acoustic noise
• - Complementary to audio signal
• - Audio and visual noise is uncorellated
• - Increased robustness and accuracy

4
Audio-Visual Platform
Score
Modelling/
Integration
Scoring
5
Audio Expert

• 20 ms Hamming window, 10 ms overlap
• 16 static features
• 15 Mel Frequency Cepstrum Coefficients (MFCC)
• 1 Energy of each frame
• 16 delta features

6
Mouth Features Expert

• ROI Extraction
• Gray scale image is employed
• Pre-processing
• Histogram-equalisation,
• De-meaning
• DCT Transform applied to ROI (Top 14 features
  selected)

7
Database

• XM2VTS database
• 295 subjects
• 4 sessions (monthly spaced) of the sentence
• Joe took fathers green shoe bench out

8
Person Identification Tests

• Tested on 251 subjects from database of 295
• Train models on monthly sessions 1, 2 and 3,
  Test on session 4
• HMMs model audio and mouth features
• AWGN was added to the audio
• JPEG compression of video images

9
Audio Expert Scores

• 97 at 48 dB, 37 at 21dB

• Large roll off

10
Image Degradation Levels

• Image frames

• Mouth regions

• 10 levels of JPEG compression

11
Mouth Features Expert Scores

• 86 at GF 50, 48 at QF 2

12
Audio-Visual Platform
Score
Modelling/
Integration
Scoring
13
Expert Weightings

• Weighted Likelihood Summation

• Expert Reliability Measure

• Automatically Choose Weight

14
Expert Weightings

• Automatically choose weight

15
Fusion of Audio and Mouth Feature Experts

• A 37 at 21dB, V 48 at QF 2, AV 72 at
  (21db, QF2)

16
Conclusions

• AV system is robust to both audio and visual
  degradations
• High performance of mouth region (85)
• -Robust to facial expressions, occlusion.

Further work

• Test other types of audio and visual degradations
• XM2VTS DB High quality
• Record real world data in office type scenario

17
XM2VTS Database

• Controlled, uniform illumination
• Constant visual background
• Controlled acousitc background

18
UCD Recordings

• Non-controlled, non-uniform illumination
• Varying viusal background
• Noisy acousitc background

19
Niall Fox Email niall_at_ee.ucd.ie Web
http//ee.ucd.ie/niall/
Dr Richard Reilly (richard.reilly_at_ucd.ie) DSP
Group, UCD, Dublin, Ireland
This work is supported by Enterprise Ireland
under the Informatics Research Initiative
