1A real-time assessment of students mental models
of sound propagation
Dissertation Defense
Kansas State UniversityPhysics Education
Research Group
Supported by NSF ROLE Grant REC-0087788
2Outline
- Rationale Why use in-class, real-time
assessment? - Previous research
- Mental models of sound propagation.
- Hybrid mental models and their role.
- Test construction and validation
- Results
- Using the test
- Further study
3Real time, in class assessment
Uses some form of Class Response System
Enables quick collection and immediate analysis
of students responses in the classroom.
4Benefits of class assessment
- Engages students.
- Facilitates interactive learning and peer
instruction (especially in large enrolment
classes). - Gives immediate feedback to the teacher.
- Enables the teacher to adjust the teaching before
the exam rather than after it and according to
specific needs of his/her students. - Allows a post lecture detailed analysis.
5Goal of the study
- To create a multiple choice test
- that can elicit students mental models of sound
propagation - during the lecture
- using a class response system and appropriate
software.
6Mental model definition
- Mental model is
- an internal (mental) representation
- analogous to the physical world situations or
processes that it represents - and that serves to explain and predict the
physical world behavior (Greca Moreira, 2002) -
- Mental model has
- spatial configuration of identifiable kinds of
things - (a few) principles of how system works and
- (certain) predictive power (diSessa, 2002)
- Mental model state
- Is defined by students consistency (Pure Mixed)
7Research questions
- Main question
- What is the optimal multiple choice test that can
elicit students mental models of sound
propagation in a real time, during the
instruction? - (Some of) Sub questions
- Is model analysis the optimal analytical tool for
analysis of students responses in this test? - How do we represent data so the display provides
a variety of instruction guiding information? - How reliable is the test?
- How valid is the test?
8Starting point in test creationIdentifying
mental models of sound propagation
- Hrepic, Z., Zollman, D., Rebello, S. (2002).
Identifying students' models of sound
propagation. Paper presented at the 2002 Physics
Education Research Conference, Boise ID.
94 basic models - mechanisms of propagation
104 basic models - mechanisms of propagation
Wave ModelScientifically Accepted Model
() Ear Born Sound
Propagating Air
Hybrid Models
Dependent Entity
Independent Entity Dominant Alternative Model
11Implications of hybrid mental models
- Implications for analysis of our test
- Hybrid models cause overlaps in multiple choice
questionnaires more than one model corresponds
to the same choice (E.g.) - Model analysis requires one on one match of model
and answer choice - Implications for teaching
- A student can give a variety of correct answers
on standard questions using a hybrid (wrong)
model (E.g.)
12Constructing the test
- Four steps of test construction and validation
- Pilot testing
- Pre-survey testing
- Survey testing
- Post Survey testing
13Pilot testing
- Did we miss anything in terms of mental models?
- Open-ended questionnaire on a large sample
- Did we miss anything in terms of productive
questions to determine students mental models? - Battery of semi-structured conceptual questions
related to sound as a wave phenomena in variety
of situations
14Test Contexts1. Air
How does sound propagate in this situation?
15Test Contexts2. Wall
How does sound propagate in this situation?
16Test Contexts1a, 2a - Vacuum
What happens without the medium (air or wall)?
17Pre-survey testing
- 5 option multiple choice test needed
- Does our choice selection match students
needs? - Trial with
- None of the above
- More than one of the above
- Validation through expert reviews
- Probing and refining the test through students
interviews
18Survey testing
- Surveying - to determine
- Stability of results
- across different institutions at equivalent
educational levels - across different course levels at same
institutions - Instructional sensitivity of the test
- Correlations between response items
- Model distributions at different levels - for
future use - Interviewing to determine
- To validate new test version
- To inform and make sense of survey findings
19Test questions - paraphrased
- What is the mechanism of sound propagation in the
air/wall? - How do particles of the medium vibrate, if at
all, while the sound propagates? - How do particles of the medium travel, if at all,
while the sound propagates? - What does this motion have to do with sound
propagation cause and effect relationship? - What does this motion have to do with sound
propagation time relationship? - What happens with sound propagation in the vacuum?
20Displaying the test results
- Several representations of students state of
understanding - Available in real time and in post instruction
analysis - Consistency
- Consistent a student uses one model(Pure model
state) - Inconsistent a student uses more than one
model(Mixed model state)
21Using a particular model Pre Instruction
Calculus based University NY
Inconsistently
Consistently
N 100
22Using a particular model at least once Pre
Instruction Calculus based University NY
Inconsistently
Consistently
N 100
23Movements of particles of the medium Pre
Instruction Calculus based University NY
() Random Travel
() Travel Away From The source
Vibration on the Spot
N 100
24Model states Pre Instruction Calculus based
University NY
Mixed Any
Pure Other
Mixed Entity
Pure Wave
Mixed Ear-Wave
N 100
25Correctness Pre Instruction Calculus based
University NY
N 100
26Survey participants
27Survey Results
- Results stable? Differences meaningful?
- Comparing consistency and correctness
- Different levels Pre- and post-instruction
28Comparing correctness and consistencyDifferent
levels Pre- and post-instruction
29Comparing correctness and consistencyDifferent
levels Pre- and post-instruction
30Comparing model distributionDifferent
educational levels
31Comparing model distribution Grouped models
Different educational levels
32Comparing model distribution Grouped models
Different educational levels
33Comparing model distribution Grouped models
Different Educational Levels
34Comparing model distributionDifferent course
levels
35Comparing differences in model distributionVariab
ility within different educational levels
36Pre-Post instruction difference
Gain (G) (post-test) (pre-test) Normalized
gain (h) gain / (maximum possible gain) (Hake,
1997).
37Using a particular model Pre Instruction
Calculus based University NY
Inconsistently
Consistently
N 100
38Using a particular model Post Instruction
Calculus based University NY
Inconsistently
Consistently
N 95
39Movements of particles of the medium Pre
Instruction Calculus based University NY
() Random Travel
() Travel Away From The source
Vibration on the Spot
N 100
40Movements of particles of the medium Post
Instruction Calculus based University NY
() Random Travel
() Travel Away From The source
Vibration on the Spot
N 95
41Correctness Pre Instruction Calculus based
University NY
N 100
42Correctness Post Instruction Calculus based
University NY
N 95
43Correlation analysis of answer choices
44Validity interviews
- 17 x 4 probes in the interviewed sample.
- The invalid display of a model would have
occurred in 6 instances - 8.8 of the probes
- 3 instances because of 5a
- ( another 3 that did not cause invalid probe)
45Post-Survey Testing
- Expert review
- To validate post survey version
- Few minor items improved
- Surveying
- To determine correlations between response items
and see if changes made the desired effect. - Problems fixed
- Role playing validation
- To validate new test version in an additional way
- Perfect score
46Test Reliability
- Reliability pertains to the degree to which a
test consistently measures what it is supposed to
measure. (Oosterhof, 2001) - Content sampling error
- Occasion sampling error
- Examiner Error
- Scorer Error
47Reliability addressedContent sampling error
- Occurs because students may be more or less lucky
with how test items correspond to things they
know. - To reduce Test more content
- To measure Need parallel form
- Issues No parallel form, Context dependence
- Reduced by probing a single model multiple times
- Addressed by showing meaningful correlations
between the answer choices - Not neg. if related to same model (pos. and
frequently sig.) - Not sig. pos. if related to different models
(Except Dependent/Independent entity models -
continuum) - Pertain only to secondary and tertiary levels
but not to primary
48Occasion sampling error
- Occurs because students can be more or less lucky
with respect to time when the test was
administered. - To reduce Test more often
- To measure Need multiple administrations of the
same test - Issues Problematic for instructors and students,
Economy - Did not probe time stability
- Addressed by showing
- Stable results across institutions at the same
level - Meaningful differences between educational levels
- Meaningful differences between course levels
- Meaningful differences between pre- and
post-instruction
49Examiner error Scorer error
- Examiner error occurs because of the differences
in examiners. - Not measurable
- Was reduced through the standard introduction to
the test (verbal and written) - Scorer error occurs if students scores depend on
who happened to mark their work. - Not an issue - computerized analysis of results.
- All four of the treats to the reliability well
addressed - Gives a ground for the statement that the test is
a reliable instrument.
50Validity addressed
- Test Validity
- The extent to which a test measures what it is
supposed to measure and nothing else. (Oosterhof,
2001) - Validity concerns the appropriateness of
inferences and actions that are based on a tests
scores. (Hanna, 1993, p. 8) - Validity is not an attribute of the test, but of
the interaction of a test with a situation in
which the test is used to make decisions.
(Hanna, 1993 p. 382) - Content-related evidence of validity
- Criterion-related evidence of validity
- Construct-related evidence of validity
51Content-related evidence of validity
- Indicates how well the content of a test
corresponds to the student performance that we
want to observe. (Oosterhof, 2001) - Addressed by
- Experts review of the content and correctness of
the answer choices - Demonstrated instructional sensitivity
- Table of (content) specifications
52Criterion-related evidence of validity
- Indicates how well performance on a test
correlates with performance on relevant criterion
measures external to the test (Oosterhof, 2001,
p.55) - concurrent validation (compares the test results
a parallel, substitute measure). - predictive validation (compares the test results
with follow up testing) - Addressed by
- Validation through the interviews
- Think aloud interview protocols
- Comparisons of students free answers in interview
setting with their results on the test - Role playing validation
- Correlation analysis of answer choices
53Construct-related evidence of validity
- Establishes a link between the underlying
psychological construct we wish to measure and
the visible performance we choose to observe.
(Oosterhof, 2001, p.46) - Addressed by
- Building the case on previous research
- Table of (construct) specifications
54Prospective uses of test, test questions
- Formative assessment combined with any
instructional method/approach - traditional
- progressive
- misconception oriented
- Model cause
- Misconception symptom
- As peer instruction questions (not model
defining) - Not recommended as a summative assessment
- Online package related to test and analysis of
data available at http//web.phys.ksu.edu/role/so
und/
55Limitations
- Common to multiple choice tests
- Answer options do affect students understanding /
models - Test taking strategies may obscure results
- Test projects no model state as mixed model state
and possibly pure model state.
56Future researchUnique approach - Wide themes
opened
- Applicability of the approach in other domains of
physics - Is the approach hybrid model-(in)dependent?
- Applicability in domains of other natural
sciences? - How effectively teachers can implement the
real-time aspects of this testing approach? - Instructional utility of this type of testing
Will addressing of the underlying models in real
time help students learn? - Possibility of individualized addressing of
students models in real time? - Applicability of the testing approach in
eliciting non-cognitive psychological constructs - Personality tests Would it provide information
that current tests in that field do not? - Reduction of items when compared to Likert scale
57Future researchSpecific issues opened
- Optimal using of the test in combination with
online homework - Saving of time
- Any classroom benefit counterbalance?
- How applicable is this test at the middle school
level? - How would a branched version of the test look,
and would it have any advantages with respect to
this one? - Improved simplicity and validity of the test
58More Information / Feedback
zhrepic_at_phys.ksu.edu http//www.phys.ksu.edu/zhre
pic/
Thank You!
