An Investigation of the Therac-25 Accidents

1
An Investigation of the Therac-25 Accidents

• Nancy G. Leveson
• Clark S. Turner
• IEEE, 1993
• Presented by Jack Kustanowitz
• April 26, 2005
• University of Maryland

2
Overview

• What happened
• Accident history
• Development history
• Technical problems
• Company responses
• Lessons learned
• Ethical questions
• Resources

3
What Happened

• Between June 1985 and January 1987, 6 known
  accidents involving massive overdoses, causing
  death serious injury

4
Accident History

• June 3 1985 First overdose
• July-Dec 1985 Two more overdoses, patient sues
  AECL and hospital, two requests for modifications
• Jan-Feb 1986 Denial of possibility of overdose
• Mar-Apr 1986 Two more overdoses, software blamed
• May-Dec 1986 FDA declares Therac-25 defective,
  CAPs (Corrective Action Plans) sent back and
  forth between FDA and AECL. First Therac-25 user
  group meeting.
• Jan 1987 Sixth overdose
• Feb-July 1987 More CAPs back and forth until
  fifth revision of CAP sent to FDA
• Nov 1988 Final safety analysis report issued
• Grueling first-hand descriptions of what it felt
  like to get a massive radiation overddose

5
Development History

• Therac-6 6 MeV accelerator for x-rays
• Therac-20 20 MeV dual-mode (x-rays or electrons)
• Separate hardware interlocks
• Therac-25 25 MeV dual-mode
• All safeguards done in software
• Testing
• Unit and software testing was minimal, with
  most effort directed at the integrated system
  test
• Software written in assembly on a PDP-11

6
The Operator Interface
7
The Operator Interface

• At first, operator needed to enter information at
  the treatment table, and then re-enter at a
  console in the control room
• Operators complained safeguard was removed
• Error codes are reported on the screen with no
  English explanation
• Example (East Texas Cancer Center) Malfunction
  54 reported, caused by dose input 2. An AECL
  technician testified that does input 2 means
  the dose delivered was either too high or too low
  (!)
• Treatment Pause after non-critical error, which
  operator can ignore by pressing P
• Causes operators to become insensitive to errors

8
Example Bugs

• Data Entry Bug
• Setting the bending magnets takes 8 seconds
• Delay subroutine uses shared memory with the
  data entry subroutine
• So data changes within 8 seconds will be wiped
  out when Delay exits!
• Causes bugs that only show up with proficient
  users who do data entry in lt8 seconds
• Set-Up Test Bug
• On every 256th pass through Set-Up (one-byte
  counter), the upper collimator is not checked
• Problem if operator hits set exactly when
  counter rolls over to 0
• These kinds of bugs are notoriously difficult to
  track down

9
AECL Responses

• Denial
• We did not believe that there could have been
  any accelerator malfunction
• Incremental, local band-aid fixes
• Example P key removed to prevent operators
  from ignoring warnings
• Dragging feet, doing minimum of FDAs requests
• Perhaps justified? See ethics discussion
• Knee-jerk responses fix the bugs as they are
  reported
• Difficulty reproducing bugs (that only happened
  once in several hundred runs)

10
Lessons General

• Focusing on particular software bugs is not the
  way to make a safe system
• Assumption that fixing one error would prevent
  further accidents
• There is always another software bug
• It is a bad idea to remove independent hardware
  interlocks, and to believe too much in software
• Assume software will fail, and handle that
  properly, rather than trying to write perfect
  software
• Dont believe in numerical claims
• Risk assessment can be like the captured spy if
  you torture it long enough, it will tell you
  anything you want to know
• Record the reasons for design decisions (like
  duplicate data entry)
• Design for the worst case
• Dont enhance usability at the expense of safety
• Power of user groups to cause change when
  companies drag their feet

11
Lessons Software Engineering

• Documentation should not be an afterthought
• Establish QA practices standards
• Keep designs simple
• Design audit trails and logging from the
  beginning
• Perform extensive testing and formal analysis at
  the module and software level, rather than
  relying on system-level testing

Summary of this course!
12
Ethical Questions

• 500 patients treated in East Texas before first
  serious accident
• Too much government oversight slows progress
• If 1 person was getting hurt for every 1000
  helped, would you take the machine out of use?
  How about 1100? 110000? Wheres the line?

13
Resources

• http//www.technology.niagarac.on.ca/courses/ctec1
  435/notes/Therac-25/SouthPark/01.htm
