NPACI All Hands Meeting 2002 User Feedback Session

1
NPACI All Hands Meeting 2002User Feedback Session

• Session Chair Dr. Jay Boisseau, TACC
• Speakers Dr. Kent Milfeld, TACC
• Dr. Bill Martin, U. Michigan
• Don Frederick, SDSC
• Friday, March 8, 2002

2
Organization of HPC Resourcesat TACCKent
Milfeldmilfeld_at_tacc.utexas.edu

• March 8, 2002

University of Texas at Austin
Texas Advanced Computing Center
3
TACC Resources
Allocatable Machines

• SV1, Vector Processing
• T3E, MPP (RISC) Processing
• April, Regatta (Power4)

Infrastructure

• Storage Archive (GigE machine room network)
• IA-32/64 Linux Cluster Computing (NPACI Rocks)
• Integrated Prog. Env. (modules, looks feels
  like NPACI machine)
• VISualization Facilities (world class)
• Mini TeraGrid (12-mile OC-48 Network experiment
  next month)
• Grid Team Development, Support and Portals
• NPACI/TACC Training Consulting

4
NPACI-TACC Resources

• SV1 16CPU 16 GB Memory (Vector)

• Memory Bandwidth
• Gather/Scatter
• 300MHz x 4 flop/CP 1200 MFLOPS
• -OpenMP, MPI

(RISC)

• T3E 272CPU 128MB/node

• RISC with streams
• Cache
• 300MHz x 2 flop/CP 600 MFLOPS
• High Speed Interconnect
• -MPI

5
TACC Regatta HPC longhorn.tacc.utexas.edu

• 64 IBM Power4 1.3 GHz Processors
• Arranged as 4 16-way SMP (now)
• 32 GB Memory/Node (128GB total)
• 1TB disk
• 1/3 TFLOPS (peak)
• Early Summer
• Interconnected by High Speed Switch
• (1-2 GB/sec. point to point, theoretical)

6
TACC Regatta HPC
7
Storage RobotPetabyte capacity
8
IBM p690 HPC Design Configuration
135 watts / die x 4 ?HOT!!!
9
TACC Visualization Lab

• SGI Onyx2
• 24 CPUs, 6 Infinite Reality 2 Graphics Pipelines
• 24 GB Memory, 1TB Disk
• Front and Rear Projection Systems
• 3x1 cylindrically-symmetric Power Wall
• 5x2 large-screen, 169 panel Power Wall

10
Power4
11
TACC IA-32 System 64 Compute Processors
32 compute nodes 2-way SMPs 1 GB mem./node 1
GHz Pentium III (IBM x330)
18 GB local disk per node
20 GB
/work
GigE 125MB/sec
Switch
32 lines
20 GB
x340
/home
100Base-T 12.5MB/sec
login node
32 lines
M3-SW16
x340
3/4 TB
/gpfs
x340
250MB/sec
Myrinet
2 GPFS nodes
12
TACC IA-64 System 40 Compute Processors
20 compute nodes 2-way SMPS Intel Itanium (IBM
x380) 2 GB mem./node
800 MHz
Switch
20 lines
125MB/sec
100Base-T
Fast Ethernet 12.5MB/sec
GigE
140GB
/work
x380
23GB
/home
login node
32 GB local disk per node
x340
TBD
/gpfs
x340
2 gpfs nodes
Myrinet 250MB/sec
M3-SW16
late spring, 02
20 lines
Myrinet
13
User Feedback SessionAHM2002

• Bill Martin
• Director, NPACI Midrange Site
• Director, Center for Advanced Computing
• University of Michigan
• March 8, 2002

14
Who we are .

• Tom Hacker head of Systems Support team
• Rod Mach
• Matt Britt
• Abhijit Bose head of User Support team
• Randy Crawford
• David Woodcock
• Contributing faculty
• Quentin Stout (EECS)
• John Volakis (EECS)
• Linda Abriola (Civil and Environmental
  Engineering)

15
The UM Mid-Range Site Operate and maintain HPC
equipment

• 112 cpu SP2 (160 MHZ) system including 64 cpu SP2
  from SDSC soon to be 176 nodes with the 64 cpu
  SP2 from SDSC (via Texas)
• 24 cpu (3 8-way nodes) Nighthawk (375 MHZ) system
  will add 4 interactive nodes soon
• Built and operated 100 cpu (soon to be 128 cpu)
  Intel cluster (Pentium III) during past year
• Operate mass store system (Timberwolf/Tivoli)

16
Systems support local and distributed

• Three full time staff
• Operate and self-maintain all IBM equipment
• Developed joint job submission system with Texas
  with their SP2 for NPACI allocations
• Participate on development team for SRB (ported
  to Tivoli)
• Use SRB for Visible Human Project

17
User support and expert consultation

• Three full time user support staff (2 PhDs 1 MS)
• Assist in NPACI 800 hotline ( 260 Remedy
  tickets in 2001) for all NPACI platforms
  including data resources
• Work at algorithm and numerical methods level
• Monte Carlo photon cancer treatment therapy (Y.
  Dewarja)
• Gene sequence alignment and optimization (R.
  Goldstein)
• Environmental remediation simulator (MISER) for
  EPA
• More demand than capacity for user support
• Absolutely critical for effective utilization of
  parallel systems. Recall quote by Charlie Catlett
  yesterday
• User support, user support, user support

18
Workshops and Distance Training

• Developed several web-based modules for parallel
  computing
• Using the UM SP2 system
• Domain decomposition
• OpenMP
• Parallel Object-Oriented Programming
• Linux Clusters
• Parallel computing workshops (at Michigan)
• Fall NPACI Workshops (2x) 106 signed up 87
  attended
• Summer parallelization workshop 42 attendees

19
Michigan and Texas collaboration has yielded
improved user interface

• Co-scheduling SP2 systems ( one virtual SP2
  system) with single queue (Load Leveler), enables
  load balancing between sites
• Shared file space (single AFS cell)
• Data intensive computing infrastructure (SRB,
  AFS)
• Coordinated account management and accounting
  systems
• May be viewed as developing, testing, and
  deploying prototype Grid technologies in a
  production environment

20
New high end cluster at Michigan ..

• 256 node AMD cluster (Athlon 32 bit)
• 1.55 GHZ, 1 GB/cpu, Myrinet 2000
• Assembled by Atipa the first installment (100
  CPUs) is now operational
• Partnering with other UM research groups to
  increase size to gt 500 cpu
• Will exceed 2 teraflops peak
• Allocable NPACI resource 2/3 of system

21
(No Transcript)
22
AHM 02 - NPACI User Feedback Session
SDSC Current Future Resources Donald
Frederick, Scientific Computing
Department 858-534-5020, frederik_at_sdsc.edu
23
Current SDSC Resources - 2002
24
SDSC TeraGrid System Future Resource 2003
ANL 1 TF .25 TB Memory 25 TB disk
Caltech 0.5 TF .4 TB Memory 86 TB disk
Chicago LA DTF Core Switch/Routers Cisco 65xx
Catalyst Switch (256 Gb/s Crossbar)
NCSA 62 TF 4 TB Memory 240 TB disk
SDSC 4.1 TF 2 TB Memory 225 TB SAN
vBNS Abilene Calren ESnet
OC-12
OC-12
OC-12
OC-3
4
HPSS 300 TB
Myrinet
4
10
1176p IBM SP 1.7 TFLOPs Blue Horizon
Sun Server
4
16
2 x Sun E10K
25
All TeraGrid Sites Have Focal Points

• SDSC The TeraGrid Data Place
• Large-scale and high-performance data
  analysis/handling
• Every Cluster Node is Directly Attached to SAN

26
Basic Cluster Components

• Systems actual HW configuration not settled
• IA-64 McKinley-based IBM node candidate cpu
• 23 GB Memory/CPU
• Connectivity
• Gigabit Ethernet in every node (multiple?)
• Myrinet network in every node (multiple?)
• Storage
• Local Disk (gt 73GB)
• Access to large secondary, tertiary storage
• Primarily Open Source software stack
• Linux, cluster software, Grid software
• Proprietary where it makes sense (compilers,
  debugger, etc.)

27
TeraGrid Storage

• Storage in 4 flavors
• Local node, up to 91GB/node
• 2 SCSI drives/node
• Secondary storage on each site
• 0.6 PB across the sites
• Locally accessible at each site
• Secondary storage from remote sites
• Metadata management requires serious effort
• Data location and replication with SRB
• Unique SDSC configuration with dedicated Sun
  Starcat server
• Expected as major use of WAN
• Tertiary storage on each site
• Locally accessible, needs to be integrated with
  TeraGrid
