Title: OCEANIC PRECIPITATION VARIABILITY ASSOCIATED WITH THE NORTH ATLANTIC OSCILLATION


1
OCEANIC PRECIPITATION VARIABILITYASSOCIATED WITH
THE NORTH ATLANTIC OSCILLATION
  • Phillip A. Arkin, Heidi Cullen and Pingping
    XieUniversity of Maryland, ESSIC, NCAR/ESIG and
    Climate Prediction Center, NOAA

2
OUTLINE
  • Background and questions to be addressed
  • Data
  • Around the Atlantic
  • Boreal Winter
  • Boreal Summer
  • Elsewhere
  • Conclusions/Points for further study

3
The North Atlantic Oscillation (NAO)
  • Dominant mode of climate variability in the
    Atlantic in winter (van Loon Rogers, 1972)
  • Seesaw of atmospheric mass between subtropical
    high and subpolar low (Walker and Bliss, 1932)
  • Controls the path and intensity of storm track
    (Hurrell, 1995)
  • Spectral density of NAO weakly exists at 2-3
    years (QBO), 7-10 years, also an increasing trend
    (Hurrell and van Loon, 1997)
  • Significant impact on marine and terrestrial
    ecosystems

Images courtesy Martin Visbeck
4
Objectives/Questions
  • Describe oceanic precipitation anomalies
    associated with the NAO
  • What do they look like? In the Atlantic, tropical
    oceans?
  • What is the relationship to anomalies determined
    from gauge data?
  • Are they reasonable can CMAP et al. be used
    outside the tropics?
  • How do the observed anomalies relate to
    circulation and storm track anomalies?
  • Are the features we find sensitive to the dataset
    (CMAP all/observation only GPCP) used?
  • Are they sensitive to the time scale
    (monthly/pentad) examined?

5
Data Used
  • Indices from CPC web site
  • NAO (700 hpa Z), AO (1000 hpa Z)
  • Precipitation from CMAP
  • CMAP/O uses a combination of IR and microwave
    satellite estimates and gauge observations
  • CMAP/A uses reanalysis precipitation as well in
    regions without other data
  • Xie and Arkin (BAMS, 1997)
  • GPCP pentad
  • Same inputs as CMAP/O
  • Constrained to match GPCP monthly analysis
  • Xie et al. (J. Climate, accepted pending minor
    revisions)
  • Circulation from NCEP/NCAR Reanalysis
  • 1000 and 500hpa winds and geopotential heights
  • Kalnay et al. (BAMS, 1996)

6
Precipitation Climatology (CMAP)
DJFM
JJAS
7
Correlations with NAO Index (DJFM)
CMAP precipitation
REOF of 700mb Z
January
8
Correlations with NAO Index (DJFM)
1000 hpa height
500 hpa height
New CPC NAO index based on 500 hpa eof
9
DJFM Composites based on NAO Index (using monthly
anomalies)
CMAP precipitation High NAO quartile minus Low
NAO quartile
10
How much difference do using the reanalysis
precipitation make in these composites ?
CMAP/O
CMAP/A
Not much maybe provides a little continuity in
high latitudes
11
How robust are these results?
Low NAO
High NAO
Normalized CMAP composites
Each month normalized by standard deviation of
1000 composites based on random time series
12
Conclusions - DJFM
  • CMAP et al. appear to be usable in extratropics
  • Winter precipitation signal is consistent with
    earlier results
  • Positive NAO associated with wet conditions in
    North Atlantic/northern Europe
  • Negative NAO associated with wet conditions in
    Atlantic between 30-40N extending across the
    Mediterranean into the Middle East
  • Oceanic precipitation anomalies strongest near
    eastern end of the main storm track as much as
    50 of the mean
  • Signal appears to extend into the tropics

13
Correlations with NAO Index (JJAS)
CMAP precipitation
REOF of 700hpa Z
1000 hpa height
500 hpa height
14
JJAS Composites based on NAO Index (using monthly
anomalies)
15
How significant is the NAO signal in Boreal
summer?
High NAO
Low NAO
Normalized CMAP composites
16
Conclusions - JJAS
  • Positive/negative NAO associated with dry/wet
    conditions in northern Europe with opposite
    anomalies farther north
  • Oceanic anomalies less prominent than during DJFM
  • Positive NAO associated with positive rainfall
    anomalies in western Atlantic between 15-30N
    probably because of the positive SLP anomalies
    just to the north and their influence on tropical
    systems
  • Appears to be substantial dependence of the
    details of the results on the definition of the
    index

17
Does the NAO have manifestations outside the
North Atlantic Ocean?
  • Hoerling et al. (Science, 2001) found that
    increasing trend in tropical precipitation from
    1950-2000 was related to similar trend in NAO
  • Our record too short to compare directly, but
    maybe periods of high/low NAO index are
    characterized by coherent anomaly patterns away
    from the Atlantic Ocean

Implication high NAO index associated with
greater Indian/Pacific Ocean tropical
precipitation?
18
Composite DJFM Precipitation AnomaliesHigh NAO
Low NAO
CMAP/A
GPCP Pentad
19
CMAP normalized composite anomalies
Based on NAO index
DJFM
Based on Arctic Oscillation index
20
Conclusions
  • Merged precipitation datasets good enough for
    descriptive diagnostic studies
  • CMAP, GPCP pentad give similar results
  • High latitude results look pretty reasonable
  • The NAO has robust manifestations in Atlantic
    Ocean precipitation and circulation during Boreal
    winter
  • Boreal summer signal present, but weaker and
    displaced northward
  • Coherent precipitation/500hpa signal extends deep
    into tropics (maybe into SH for precip)
  • Some (equivocal) evidence of a tropical signal in
    Indian and Pacific Oceans
