Title: Insulin


1
Insulin
  • BIOL 4900
  • Peter Gadja Background
  • Danielle Hiers - Structure
  • Katie Peppers Homology/Phylogeny

2
BACKGROUND
  • Production
  • Produced in pancreas
  • Islets of Langerhans
  • Uses
  • Hormone that signals glucose metabolism
  • Uses feedback mechanism
  • Causes reduction in appetite
  • Organisms
  • Insulin is used by all vertebrates as a source of
    metabolic control
  • Organisms must have b-cells in pancreas in order
    to produce insulin

3
MECHANISM OF ACTION
  • Released when blood-glucose levels are high
  • Insulin binds to the cell membrane
  • Comprised of an a and b subunit
  • a-subunit is on the outside of the cell
  • b-subunit is on the inside of the cell
  • The b-subunit is a tyrosine kinase and when
    insulin binds it starts a phosphorylation cascade
  • GLUT 4 glucose transporters- become excited by
    this and move to bind to the plasma membrane
  • Glucose can now diffuse through the membrane

4
Reaction requires ATP
Insulin action2 http//www.elp.manchester.ac.uk/p
ub_projects/2000/mnby7lc2/insulin_action2.gif
Subunits held together by disulfide bridges
3) CH_12 insulin GT http//courses.cm.utexas.edu/
jrobertus/ch339k/overheads-2/ch12_insulin-gt.jpg
2) Insulin Binding site http//www.vivo.colostate
.edu/hbooks/pathphys/endocrine/pancreas/insulin_ph
ys.html
5
HOW INSULIN RELEASE WORKS IN THE CELL
http//www.apsu.edu/thompsonj/Anatomy2020Physio
logy/2010/201020Exam20Reviews/Exam20520Final2
0Review/insulin.Fig.25.18.jpg
6
DISEASES CAUSED BY INSULIN
  • Insulin does not cause a disease
  • Diseases arise due to lack of insulin
  • Resistance to insulin
  • Diabetes 1 and 2
  • Type 1
  • Total lack of production of insulin
  • Pancreas has been removed or b-cells damaged
  • Type 2
  • Resistance to insulin
  • Occurs in adults
  • Problems with receptor to signaling problems

7
CONTROLLING DIABETES
  • Type 1
  • Insulin replacement therapy
  • Synthetic insulin
  • Originally purified from pigs and cows
  • Produced in mass amounts through recombinant DNA
    techniques
  • Healthy diet
  • Type 2
  • Controlled by diet and monitored
  • Both increase your risk for heart disease,
    blindness, nerve damage, and kidney damage

8
SPECIAL APPLIACTIONS
  • Insulin coma therapy
  • 1930-1950s
  • Common psychiatric treatment of schizophrenia and
    depression
  • Discovered in Germany and immigrated to US before
    WWII
  • Insulin given to restrict glucose supply to brain
  • causing shock, coma, convulsions
  • Replaced by electroconvulsive therapy from
    1950-1980s

9
SPECIAL APPLICATIONS
  • Intravenous GIK solution
  • Decrease mortality rates caused by heart attack
    and postoperative cardiac failure
  • High dose used in heart surgery/transplantation
    to induce a heart attack
  • Infuse potassium in heart which impairs
    circulation
  • Body building
  • Most anabolic hormone
  • Enhance muscle growth rather than fat
  • If sufficient carbs are not consumed in time
    death occurs as a result

10
STRUCTURE FOR BOVINE-1APH
11
CHARACTERISTICS OF PROTEIN STRUCTURE
  • Two non-identical amino acid chains
  • Chain A 21 residues
  • Chain B 30 residues
  • One ligand - 1,2-dichloroethane
  • Three disulfide bridges
  • No active site present
  • Member of insulin-like family
  • Not transmembrane

12
LIGAND INTERACTIONS
  • C2H4Cl2
  • Total of 6 residues in Chain B interacting with
    this ligand
  • 3 Ser-9 residues
  • 1 Val -12 residue
  • 2 Glu-13 residues

13
STRUCTURAL MOTIFS
  • Chain A
  • 1 motif , residues 6-21
  • Insulin
  • Family of proteins that consists of an A and B
    chain linked by 2 disulfide bridges
  • Chain B
  • 1 motif, residues 27-30
  • pkc_phospho_site
  • Protein kinase C
  • Phosphorylation of serine or threonine residues
    close to the C-terminus

14
PREDICTIVE MODELING
  • All programs predicted the same number of amino
    acids in each chain

15
CHOFAS PREDICTED 2 STRUCTURE
CHAIN A
CHAIN B
16
PELE PREDICTED 2 STRUCTURE
CHAIN A
CHAIN B
Chain B there is a very small helix and a very
small b-sheet
17
PROTEIN EXPLORER- 2 STRUCTURE
Disulfide Bridges Bridge 1 intrachain bridge
within chain A CYS-6 and CYS-11 Bridge 2
interchain bridge CYS-7 between A and B Bridge 3
interchain bridge CYS-19 (B) and CYS-20 (A)
18
MUTATIONS IN THE PROTEIN
  • Several mutant sequences were found in ndjinn
  • Human growth factor mutant
  • Insulin mutant P28, D, chain B
  • Insulin human mutant with PHE-24, chain B,
    replaced by Serine
  • Many more
  • None significantly affected the function of
    insulin

19
HOMOLOGY/PHYLOGENY
  • Proinsulin precursor
  • Peptide links N-terminus of A chain w/ C-terminus
    of B chain
  • Synthesized by Rough Endoplasmic Reticulum
  • Enzymes outside Golgi convert proinsulin into
    insulin

http//ocw.tufts.edu/data/14/265878/278271_medium.
jpg
20
INSULIN IN BIOLOGY WORKBENCH
(Rneteria, Gandi, Vineusa, Helmerhorst,
Mancera, 2008)
21
HOMOLOGY/PHYLOGENY
  • Significant homologs to Bovine insulin
  • Amphioxus
  • Zebra fish
  • Frog
  • Chicken
  • Sheep
  • Wild Boar
  • Squirrel
  • Macaque
  • Human
  • All the above have lt1 E-value in BlastP

22
BOOTSTRAP VALUES
23
UNROOTED TREE
89.4
70.1
100
89.7
61.9
999.7
99.9
24
ROOTED TREE
25
CONSERVED REGIONS
26
BOXSHADE
KEY Completely Conserved Identical Similar
27
STRUCTURE ALIGNMENTS IN CN3D
VAST did not locate any related structure for
Chain A or B to align
28
WHAT DOES IT ALL MEAN?
  • Phylogeny begins with insulin producing b-cells
  • Amphioxus Protochordate
  • Cells confined to region of gut
  • Evolutionary accumulation of b-cells in this
    region
  • Primitive Vertebrates (Lamprey/Hagfish)
  • Collection of endocrine cells in duodenum
  • 99 b-cells
  • 1 somatic cells
  • b- cells are the pancreatic cells that produce
    insulin

29
WHAT DOES IT ALL MEAN?
  • Insulin has a significant role in the metabolism
    of vertebrates
  • Regulates metabolism
  • Any significant change in the sequence results in
    disease (diabetes)
  • Insulin should be well conserved in all
    vertebrates
  • Insulin is a homologous protein hormone

30
WORKS CITED FOR BACKGROUND
  • http//www.diabetes.org/home.jsp
  • http//www.fda.gov/Diabetes/insulin.html2
  • http//www.medbio.info/Horn/Time203-4/Insulin's2
    0Mechanism20of20Action.htm
  • http//www.endocrineweb.com/diabetes/2insulin.html
  • http//www.vivo.colostate.edu/hbooks/pathphys/endo
    crine/pancreas/insulin_phys.html
  • http//www.medbio.info/Horn/PDF20files/insulin's
    20mechanism20of20action20new20october202006.p
    df
  • http//www.abcam.com/index.html?pageconfigresourc
    erid10602pid7

31
WORKS CITED FOR PHYLOGENY
  • Madsen, O. D. (2007). Pancreas Phylogeny and
    Ontogeny in Relation to a "Pancreatic Stem Cell".
    Pubmed Central , 534-537.
  • Rneteria, M. E., Gandi, N. S., Vineusa, P.,
    Helmerhorst, E., Mancera, R. L. (2008). A
    Comparative Study of the Bioinformatics Analysis
    of the Insulin Receptor Family Ectodomain Based
    on Phylogentic Information. Plos One , 1-15.
  • Wilcox, G. (2005). A Review Article Insulin and
    Insulin Resistance. Clinical Biochemistry Review
    , 19-39.
