Outline

• PRISM
• goals benefits
• FP5 project and the Support Initiative
• organisation
• the PRISM Areas of Expertise
• OASIS
• historical background
• the community today
• some key notes
• The OASIS4 coupler
• model adaptation
• component model description
• coupled model configuration
• communication
• regridding/transformations
• grids supported
• future developments and conclusions

3

• Increase what Earth system modellers have in
  common today (compilers, message passing
  libraries, algebra libraries, etc.)

• Share the development, maintenance and support of
  a wider set of Earth System Modelling software
  tools and standards.

4

• reduce the technical development efforts of each
  individual research team
• facilitate assembling, running, monitoring, and
  post-processing of ESMs based on state-of-the-art
  component models

Help climate modellers spend more time on science

• promote the key scientific diversity
• increase scientific collaboration
• stimulate computer manufacturer contribution
  (tool portability, optimization of next
  generation of platforms for ESM needs)

5

• 2001-2004 the PRISM EU project
• a European project funded for 4.8 M by the EC
• 22 partners
• 2005-2008 the PRISM Support Initiative
• 7 partners CERFACS, CGAM, CNRS, ECMWF, MPI-MD,
  UK MetOffice, NEC-CCRLE
• 9 associate partners CSC, CRAY, IPSL,
  Météo-France, MPI-M, NEC-HPCE, SGI, SMHI, SUN
• 8 py/y for 3 years

6
(No Transcript)
7

• PRISM is organised around 5 PRISM Areas of
  Expertise
• Promotion and, if needed, development of software
  tools for ESM
• Organisation of related network of experts
• Technology watch
• Promotion of community standards
• Coordination with other international efforts

8

• Leader S. Valcke (CERFACS)
• development and support of tools for coupling
  climate modelling component codes
• OASIS3 and OASIS4 couplers
• technology watch on coupling tools developed
  outside PRISM
• PALM coupler (CERFACS)
• Bespoke Framework Generator (U. of Manchester)
• CCSM (NCAR),
• relations with projects involving code coupling
• UK Met Office FLUME project
• US ESMF project, GENIE project
• ACCESS

9

• Leader M. Carter (UK MetOffice)
• source version control for software development
• code extraction and compilation
• job configuration running
• Subversion for source version control (PRISM SVN
  server in Hamburg)
• Standard Compiling and Running Environments
  (SCE/SRE, MPI-MD)
• integrated environment to compile and run
  different coupled models based on different
  component models (standard directory structure,
  coding rules)
• Flexible Configuration Management (FCM, UK Met
  Office)
• version control, compilation
• prepIFS (ECMWF)
• tailored graphical interface for model
  configuration (Web services tech.)
• prepOASIS4 GUI to configure a coupled model
  using OASIS4
• Supervisor Monitor Scheduler (SMS, ECMWF)
• management of networks of jobs across a number of
  platforms

10

• Leader M. Lautenschlager (MPI-MD)
• data processing, visualisation, archiving and
  exchange for Earth system research
• standards and infrastructure for networking
  between geographically distributed archives
• CDO (Climate data Operators form MPI-M)
• CDAT (Climate Data Analysis Tools, from PCMDI)
• CERA-2 data model (World Climate Data Centre)
• geo-referenced climate data detection, browse and
  use
• MARS (ECMWF)
• meteorological data access and manipulation (for
  major NWP sites)

11

• Leader L. Steenman-Clark (CGAM)
• Meta-data data about data, models, runs, ...
• a hot topic in the last few years
• exchange and use of data
• interchangeability of Earth system models or
  modelling components
• forum to discuss, develop, and coordinate
  metadata issues
• Numerical Model Metadata (U. of Reading)
  numerical code bases, simulations
• CURATOR project (USA) data, codes,
  simulations
• Numerical grid metadata (GFDL, USA) grid
• netCDF CF convention (PCMDI and BADC) climate
  and forecast data files
• OASIS4 metadata coupling and IO interface
• UK Met Office FLUME project management of
  model configuration

12

• Leader M.-A. Foujols (IPSL), R. Redler
  (NEC-CCRLE)
• Computing aspects are highly important for Earth
  system modelling
• Computer vendors have to be kept informed about
  requirements emerging from the climate modelling
  community
• Earth system modellers have to be informed about
  computing issues to preview difficulties and
  evolutions
• file IO and data storage
• algorithmic development
• portable software to fit the needs of parallel
  and vector systems
• sharing of experience (e.g. work on the Earth
  Simulator)
• establishment of links with computing projects
  (e.g. DEISA)
• information about important conferences and
  workshops.

13
OASIS developed since 1991 to couple existing
GCMs
1991
2001 --?
--- PRISM ? OASIS
1 ? OASIS 2 ? OASIS3?
? OASIS4 ?

• OASIS1, OASIS2, OASIS3
• low resolution, low number of 2D fields, low
  coupling frequency
• flexibility very important, efficiency not so
  much!

• OASIS4
• higher resolution parallel models, massively
  parallel platforms, 3D fields
• need to optimise and parallelise the coupler

14

• CERFACS (France)
  ARPEGE3 - ORCA2-LIM ARPEGE4 -
  NEMO-LIM - TRIP
• METEO-FRANCE (France) ARPEGE4 - ORCA2
  ARPEGE medias - OPAmed ARPEGE3 -
  OPA8.1-GELATO
• IPSL- LODYC, LMD, LSCE (France)
  LMDz -
  ORCA2LIM LMDz - ORCA4
• MERCATOR (France) (for interpolation only)
• MPI - MD (Germany)
  ECHAM5 - MPI-OM ECHAM5 - C-HOPE
  PUMA - C-HOPE EMAD - E-HOPE
  ECHAM5 - E-HOPE ECHAM4 - E-HOPE
• ECMWF IFS - CTM IFS -
  ORCA2

15
(No Transcript)
16

• Developers CERFACS, NEC CCRLE, CNRS, SGI, (NEC
  HPCE)
• Public domain open source license (LGPL)
• Programming language Fortran 90 and C
• Public domain libraries vendor optimized
  versions may exist
• MPI1 and/or MPI2 NetCDF/parallel NetCDF libXML
• mpp_io SCRIP
• Static coupling

17
The OASIS3 coupler

• Coupler developed since more than 15 years in
  CERFACS
• Stable, well-debugged, but limited
• Last version oasis3_prism_2-5 delivered in
  September 2006
• User support provided but most development
  efforts go to OASIS4
• Mono-process coupler parallel coupling library
  (PSMILe)
• synchronisation of the component models
• coupling fields exchange
• I/O actions
• mono-process interpolation
• Platforms
• Fujitsu VPP5000, NEC SX5-6-8, Linux PC, IBM
  Power4, CRAY XD1, Compaq, SGI Origin, SGI O3400

18
OASIS3 model adaptation
PRISM System Model Interface Library (PSMILe) API

• Initialization
• Global grid definition (master process only)
• Local partition definition
• Coupling or I/O field declaration
• Coupling or I/O field sending and receiving
• in model time stepping loop
• depending on users specifications in namcouple
• users defined source or target (end-point
  communication)
• coupling or I/O sending or receiving at
  appropriate times
• automatic averaging/accumulation
• automatic writing of coupling restart file at end
  of run
• call prism_put (var_id, time, var_array, ierr)
• call prism_get (var_id, time, var_array, ierr)

19

• In text file namcouple, read by OASIS3 main
  process, and distributed to component model
  PSMILes at beginning of run
• total run time
• component models
• number of coupling fields
• for each coupling field
• source and target names (end-point communication)
  (var_name)
• grid acronym (grid_name)
• coupling and/or I/O status
• coupling or I/O period
• transformations/interpolations

20
PSMILe based on MPI1 or MPI2 message passing
21

• separate sequential process
• neighbourhood search
• weight calculation
• interpolation per se during the run

• on 2D scalar or vector fields
• Interfacing with RPN Fast Scalar INTerpolator
  package
• nearest-neighbour, bilinear, bicubic for regular
  Lat-Lon grids
• Interfacing with SCRIP1.4 library
• nearest-neighbour, 1st and 2nd order conservative
  remapping for all grids
• bilinear and bicubic interpolation for
  logically-rectangular grids
• Bilinear and bicubic interpolation for reduced
  atmospheric grids
• Other spatial transformations flux correction,
  merging, etc.
• General algebraic operations

22

• A parallel central Driver/Transformer
• launches models at the beginning of the run
  (MPI2)
• reads the user-defined configuration information
  and distributes it to the component PSMILes
• performs parallel transformations of the coupling
  fields during the run
• A parallel model interface library (PSMILe) that
  performs
• weight-and-address calculation for the coupling
  field interpolations
• MPI-based coupling exchanges between components
• component I/O (GFDL mpp_io library)

23

• Initialization
• call prism_init_comp (comp_id, comp_name, ierr)
• call prism_get_localcomm (comp_id, local_comm,
  ierr)
• Definition of grid (3D)
• call prism_def_grid (grd_id, grd_name, comp_id,
  grd_shape, type, ierr)
• call prism_set_corners(grd_id, nbr_crnr,
  crnr_shape, crnr_array, ierr)
• Placement of scalar points and mask on the grid
• call prism_set_points (pt_id, pt_name, grd_id,
  pt_shape, pt_lon, pt_lat, pt_vert
  ,ierr)
• call prism_set_mask (msk_id, grd_id, msk_shape,
  msk_array, ierr)
• Function overloading to keep the interface
  concise and flexible

24
(No Transcript)
25

• Coupling or I/O field declaration
• call prism_def_var
• (var_id, var_name, grd_id, pt_id, msk_id,
  var_nbrdims,
• var_shape, var_type, ierr)
• End of definition
• call prism_enddef (ierr)
• Coupling or I/O field sending and receiving
• in model time stepping loop
• depending on users specifications in SMIOC
• users defined source or target, component or
  file (end-point communication)
• coupling or I/O sending or receiving at
  appropriate times
• averaging/accumulation
• call prism_put (var_id, date, date_bounds,
  var_array, info, ierr)
• call prism_get (var_id, date, date_bounds,
  var_array, info, ierr)
• Termination
• call prism_terminate (ierr)

26

• Application and component description (XML
  files)
• For each application (code) one Application
  Description (AD)
• possible number of processes
• components included
• For each component in the application
• one Potential Model Input and Output Description
  (PMIOD)
• component general characteristics name,
  component simulated,
• grid information domain, resolution(s), grid
  type,
• potential I/O or coupling variables
• local name, standard name
• units, valid min and max
• numerical type
• associated grid and points
• intent input and/or output

27

• (Through a GUI), the user produces
• a Specific Coupling Configuration (SCC)
• experiment and run start date and end date
• applications, components for each application
• host(s), number of processes per host, ranks for
  each component
• For each component,
• a Specific Model Input and Output Configuration
  (SMIOC)
• grid information chosen resolution,
• I/O or coupling variables
• name, units, valid min max, numerical type, grid
• activated intent input and/or output
• source and/or target (component and/or file)
• coupling or I/O dates
• transformations/interpolations/combinations

28
(No Transcript)
29

• Model interface library PSMILe based on MPI1 or
  MPI2
• Parallel communication including repartitioning
• based on geographical description of the
  partitions
• parallel calculation of communication patterns in
  source PSMILe

30
OASIS4 communication (2/2)

• end-point communication (source doesnt know
  target and vice-versa)
• parallel 3D neighbourhood search, based on
  efficient multigrid algorithm, in each source
  process PSMILe
• extraction of useful part of source field only
• one-to-one, one-to-many

• parallel I/O (vector, bundles, vector bundles)
  GFDL mpp_io, parNetCDF

31

• source time transformations (prism_put)
• average, accumulation
• target time transformations (prism_get)
• time interpolation (for I/O only)
• statistics
• local transformations
• addition/multiplication by scalar
• interpolation/regridding (3D)
• nearest-neighbour 2D in the horizontal, none
  in the vertical
• nearest-neighbour 3D
• bilinear in the horizontal, none in the
  vertical
• bicubic (gradient, 16 nghbrs) in the horizontal,
  none in the vertical
• trilinear

32

• Regridding, repartitioning, I/O
• Regular in lon, lat, vert (Reglonlatvrt)
• lon(i), lat(j), height(k)
• Irregular in lon and lat, regular in the vert
  (irrlonlat_regvrt)
• lon(i,j), lat(i,j), height(k)
• Irregular in lon, lat, and vert (irrlonlatvrt)
  (not fully tested)
• lon(i,j,k), lat(i,j,k), height(i,j,k)
• Gaussian Reduced in lon and lat, regular in the
  vert (Gaussreduced_regvrt)
• lon(nbr_pt_hor), lat(nbr_pt_hor), height(k)
• Repartitioning and I/O only
• Non-geographical fields
• no geographical information attached
• local partitions described in the global index
  space (prism_def_partition)
• I/O only
• Unstructured grids (unstructlonlatvrt)
• lon(npt_tot), lat(npt_tot), height(npt_tot)

33

• OASIS4 tested and run with toy examples on
• NEC SX6 and SX8
• IBM Power4
• SGI O3000/2000
• SGI IA64 Linux server Altix 3000/4000
• Intel Xeon Infiniband and Myrinet Clusters
• Linux PC DELL
• OASIS4 now being used in a reduced number of real
  applications
• EU project GEMS atmospheric dynamic and
  chemistry coupling
• SMHI ocean-atmosphere regional coupling
• UK Met Office global ocean-atmosphere coupling
  (currently prototyping)
• IFM-GEOMAR (Kiel) in pseudo-models to interpolate
  high-resolution fields.
• Current developments
• 2D conservative remapping
• Parallel global search for the interpolation
• Transformer efficiency
• Full validation of current transformations
• Full public release planned beginning 2007.

34
Conclusions

• PRISM provides
• framework promoting common software tools for
  Earth system modelling
• some (more or less) standard tools (OASIS,
  source management, compiling, )
• network allowing ESM developers to share
  expertise and ideas
• visible entry point for international
  coordination
• metadata definition
• WCRP white paper with ESMF on Common Modeling
  Infrastructure for the International Community
• PRISM current decentralized organisation
  (bottom-up approach)
• allows best of breed tools to naturally emerge
• relies on the developments done in the different
  partner groups
• Additional funding needed
• more networking and coordination activities
• specific technical developments within the
  partner groups
• Additional contributors are most welcome to join
  !

35
The end
