INP 153: Designing for the User Experience I

1
INP 153 Designing for the User Experience I

• Lecture 11 Accessibility

2
Whats due?

• Last homework!
• Homework 5 Improving Navigation.
• Pick up your User Experience Deliverable 2 and
  any other papers you havent picked up yet.

3
Optional project

• The optional project is due in two weeks week
  13.
• Design a poster with a top ten theme!
• Read online description of assignment.

4
Class progress

• Good job with the submitted User Experience
  Deliverables 2.
• Reorganizations were professional
• Charts were clear
• Wireframes were well designed
• Demonstrated amazing progress

5
What is Accessibility

• Accessibility refers to barrier-free access to
  resources for all individuals, despite personal
  impairments and disabilities.
• Requires that you, the designer, and anyone else
  working directly with content understand the
  limitations of these disabilities.
• Furthermore, accessibility addresses issues such
  as the client technology used (e.g., browser,
  microbrowser, screen reader, etc.)

6
Your impact

• The man who involves himself and who realizes
  that he is not only the person he chooses to be,
  but is also a lawmaker choosing all mankind as
  well as himself, cannot help escape the feeling
  of his total and deep responsibility.
• Jean-Paul Sarte, Existentialism and Human Emotion
• What are some of our concerns ?

7
Sample concerns

• Visual deficiencies
• Motion blindness, achromatopsia (cortical color
  blindness), color blindness, agnosia, blindness
• Auditory deficiencies
• Deafness, tone deafness

8
More sample concerns

• Motor deficits
• Parkinsons, Huntingtons, paralysis
• Attentional disorders
• ADD, visual neglect (left neglect), etc.

9
And even more concerns

• Aging population
• Individuals with restricted access, such as with
  some wireless devices or text-only browsers
• Individuals with slow connection speeds

10
Good read!

• For a good book on clinical cases for lesser
  known (but socially important) diseases and
  disorders
• Oliver Sacks, The Man Who Mistook His Wife for a
  Hat
• However, you will not learn anything about
  accessibility from this book

11
Understanding the Digital Divide

• The Digital Divide involves limited access to
  networked electronic resources and software.
• Certain demographics (race, economic level, age,
  etc.) have been statistically linked to limited
  or no access to computers and the Internet.
• Not just whether or not someone has access, but
  the type of access.

12
Restricted access for certain groups

• Here are some examples of groups who have highly
  restricted access to information technology
• Rural America
• Impoverished neighborhoods
• Native American community
• Disabled community
• And more

13
and education suffers from restricted access

• K-12 classrooms often dont have proper access to
  information technology.
• Imagine your daily life without computers! How
  would you use the library? Communicate with
  friends/family? Shop? Share information publicly?
  Access class material?

14
Importance of accessible technology

• Hopefully, thinking about the digital divide
  places the importance of accessible technology in
  a context you can understand.
• After all, why should such a significant portion
  of the population be left behind or does a
  significant portion of the population have
  disabilities that restricts this access?

15
Disabilities very, very significant (very)

• In the US, the average life expectancy for a
  newborn is 75 years.
• The last 13 of those years will most likely
  involve some significant functional impairment
• In the US in 1984, over 37 million individuals
  had a disability.
• As of 1994, 15 of Americans had a significant
  disability!

16
Disabilities are becoming increasingly more
prominent

• Medical advances increasing life span
• Neonatal treatment sustain lives, but result in
  babies with increased occurrence of disability
• Drug abuse trends result in functional disability
• Life rescue technology is saving lives that,
  affected in trama, often result in impairments
• Maturation of baby boomers with greater life
  expectancies
• Urban violence

17
Historic barriers to accessibility legislation

• Misconception of cost/benefit of barrier-free
  environments
• High cost to public/businesses
• Small percentage of population (15!)

18
Cost of not providing equal access

• Cost of unemployment for increasing population
  with functional impairment
• Medical cost of injuries sustained in
  inappropriate, unsafe environments
• Cost of social services provided for individuals
  who could be integrate into accessible work
  environment
• Source Slavitt, Earl B. (2000). Accessibility
  Under the Americans with Disabilities Act and
  Other Laws A Guide to Enforcement and Compliance.

19
Who else benefits from accessible environments

• Barrier-free environments have unexpectedly
  addressed multiple needs
• Sidewalk ramps not only address needs of
  individuals in wheelchairs, but also mothers with
  strollers and individuals pushing shopping carts
• Web sites that are accessible are not only usable
  for blind individuals with screen readers, but
  also individuals with text-only browsers or
  limited browsing capabilities (e.g., wireless
  devices).

20
Early example of accessibility

• A handful of universities were the first
  institutions to offer equal access to facilities
• Plywood ramps on sidewalks and buildings
• Support programs for handicapped pursuing a
  higher education

21
ANSI

• American National Standards Institute
• In 1958, ANSI declared the need to develop
  standards for accessible facilities
• In 1961, ANSI published A117.1, Making Buildings
  Accessible to and Usable by the Physically
  Handicapped.

22
A117.1

• A117.1
• offered technical specifications for parking
  spaces, ramps, doorways, elevators, and toilet
  stalls
• Didnt accommodate individuals with sensory
  disabilities
• Voluntary standard, though adopted by a handful
  of states

23
A117.1 Cont

• Revised in 1980, 1986, 1992, and 1998
• The 1980 revision addressed sensory impairments,
  including visual fire alarms, auditory cues in
  elevators, Braille signs, and the elimination of
  dangerous protruding objects.

24
ABA First federal accessibility standard

• Architectural Barriers Act (ABA)
• Enacted by congress in 1968
• Required accessibility for facilities funded with
  federal funds
• Not retroactive only when facilities were
  altered or constructed!

25
Rehabilitation Act of 1973

• Title V of the Rehabilitation Act of 1973
• Includes Section 504, which prohibits
  discrimination of qualified individuals based on
  disabilities for recipients of federal funding
• Accommodations must be made for the handicapped
• Section 508, an amendment to this Act, requires
  information technology be accessible

26
Setback in the 1980s Perceived Costs

• In 1983 a little Braille terminal came out You
  could hook it to a printer and do very
  rudimentary word processing. It had a Braille
  display and cost 7000.
• GCN.com, Barrett illuminates 508 Gains

27
Setback in the 1980s Public concerns over cost

• There was a lot of concern in the 1980s that
  section 508 compliance would cost society too
  much.
• The Reagan administration, due to popular
  pressure (including many derisive newspaper
  editorials) narrowed the application of Section
  508.
• Administration also restricted access to Social
  Security funds for the disabled.

28
Politics behind the Rehabilitation Act

• In 1979, the Supreme Court required that minimal
  reasonable accommodations be made for Section V
  of the Rehabilitation Act.
• Reagan suggested withholding action based on the
  Rehabilitation Act unless the potential benefits
  to society for the regulation outweigh the
  potential cost to society.
• Every administration since has utilized a similar
  heuristic for evaluating the costs/benefits of
  accessibility.

29
The reversal of the deregulation

• During the next presidential campaign, concerns
  about accessibility reached the population. The
  disabled community worked hard to barter for fair
  rights they likened their cause to the Civil
  Rights Movement.
• Groups like the Red Cross and the Salvation Army
  were influential in the adoption of disability
  legislation.
• As popular opinion shifted, the Reagan
  administration reversed their early decisions.

30
Section 508

• Section 508 is an amendment to the Rehabilitation
  Act of 1973
• Signed in 1998
• Information technology purchased by the
  government must be accessible to individuals with
  disabilities
• Provided the accessibility is not an undue burden
  on the agency
• Specific standards for software and hardware,
  telecommunications equipment, and the web.

31
Section 508 and the Web

• 16 specific items for web accessibility
• All .gov websites must follow the 16 guidelines!

32
WAI

• W3C (World Wide Web Consortium, an independent
  council for important web issues at MIT)
  spearheaded the Web Accessibility Initiative
  (WAI), which also provides guidelines for
  accessible web sites.

33
Checking web sites for accessibility

• Probably the most popular tool for checking
  accessibility of web pages/sites is Bobby
• http//cast.org/bobby/

34
Accessibility Heuristics1 of 17

• Here are 16 accessibility heuristics that will
  satisfy section 508 and make a web site more
  accessible to individuals using assistive
  technology

35
Accessibility Heuristics2 of 17

• Create alternative content for graphics, such as
  alternative text
• Alternative text (alt tags) should be brief and
  convey meaningful messages
• Use long descriptions (longdesc tags) for
  graphs and images using data

36
Accessibility Heuristics3 of 17

• Page should display legibly when graphics are
  disabled, such as with some wireless technology,
  screen readers, or Lynx a text-based web
  navigator.

37
Accessibility Heuristics4 of 17

• Web pages should be keyboard enabled. Some
  individuals with fine motor disabilities cannot
  use a mouse!

38
Accessibility Heuristics5 of 17

• The use of color should not restrict access to
  individuals with color deficiencies, color
  blindness, or who are using browsers that disable
  the designers color scheme.

39
Accessibility Heuristics6 of 17

• Provide a way for users utilizing screen readers
  to skip repetitive navigation links and get to
  the main content of a page
• Users with vision can easily scan a page, but
  users with screen readers must listen to
  everything!
• Use 1x1 pixel transparent graphic to link to main
  content
• Text-only version?

40
Accessibility Heuristics7 of 17

• If using frames, use labels for each frame that
  aid individuals with screen readers, such as
  navigation bar, main content, etc.
• You can use the lttitlegt to do this!

41
Accessibility Heuristics8 of 17

• Links should state where they lead, and not rely
  on context.
• Some screen readers/assistive technology scan
  pages for links.
• Links like click here do not offer clues
• What about URLs as links?

42
Accessibility Heuristics9 of 17

• Offer alternatives for media/multimedia
• Textual transcripts for audio
• Synchronous captioning for audio in video

43
Accessibility Heuristics10 of 17

• Do not depend on color to convey important
  information.
• Dont say find the red or click on the green

44
Accessibility Heuristics11 of 17

• Flickering animations at 4 to 55 flickers per
  second can trigger seizures, and should be
  avoided!

45
Accessibility Heuristics12 of 17

• Text-only pages must be updated as often as the
  web site is updated.
• Well marked-up code will avoid the need for
  text-only pages

46
Accessibility Heuristics13 of 17

• Forms should be accessible to individuals using
  assistive technology.

47
Accessibility Heuristics14 of 17

• If using tables for layout, make sure they make
  sense when linearly read out.

48
Accessibility Heuristics15 of 17

• For complex tables, use summary elements to
  explain content.

49
Accessibility Heuristics16 of 17

• 15. Make sure web pages work when scripts and
  applets are disabled or not supported, or provide
  equivalent information on alternative pages.

50
Accessibility Heuristics17 of 17

• Documents should be readable without a style
  sheet.
• Gracefully degrade

51
WebAIM Section 508 ChecklistWhen a web page
fails 1 of 4

• Non-text elements have no alternative
  descriptions
• Multimedia files dont provide synchronized
  captions
• Use of color monitor is required
• Contrast is poor

52
WebAIM Section 508 ChecklistWhen a web page
fails 2 of 4

• Document is confusing when the style sheet is
  turned off.
• Data tables do not have header rows/columns
• Layout tables do have header rows/columns

53
WebAIM Section 508 ChecklistWhen a web page
fails 3 of 4

• Frames do not have descriptive titles.
• Animations flicker between 2 and 55 Hz.
• Text-only version is not concurrent with main
  version.
• Scripts work only with mouse.
• Page doesnt provide link to downloadable
  plugin.

54
WebAIM Section 508 ChecklistWhen a web page
fails 4 of 4

• Forms dont have labels adjacent to controls.
• Pages dont offer links past redundent
  navigational links.
• Unnecessary time restraints require fast
  actions. E.g., while filling out a form.

55
Class exercise creating an inaccessible website

• We want to create a pet store that is intended
  to throw off screen readers and other assistive
  technology

56
For next class

• No homework due!
• Have a great week!
