HIGH DIMENSION DYNAMIC CORRELATIONS

1
HIGH DIMENSION DYNAMIC CORRELATIONS

• By
• Robert Engle
• Stern School of Business

2
FINANCIAL FORECASTING

• Forecasting Risk
• In high dimension systems this means forecasting
  volatilities and correlations
• Predictive Failure?
• Black Swans?

3
WHY DO WE NEED CORRELATIONS?

• CALCULATE PORTFOLIO RISK
• FORM OPTIMAL PORTFOLIOS
• PRICE, HEDGE, AND TRADE DERIVATIVES

4
ARE CORRELATIONS TIME VARYING?

• Yes Correlations are time varying
• Derivative prices of correlation sensitive
  products imply changes.
• Derivatives on correlation now are traded.
• Time series estimates change. There are many
  varieties.

5
(No Transcript)
6
GENERAL ELECTRIC PROFITS
7
CHANGING EXTERNAL EVENTS

• CONSIDER BOEING AND GENERAL MOTORS
• CORRELATIONS MAY HAVE CHANGED BECAUSE OF CHANGING
  ENERGY PRICES. ENERGY PRICE VOLATILITY WILL MAKE
  THE RETURNS MORE CORRELATED.

8
(No Transcript)
9
Dynamic Conditional Correlation

• A simple approach to estimating and forecasting
  large covariance matrices
• Engle(2002), (200?)
• Based on standardized returns s

10
TWO SPECIFICATIONS

• Where in the integrated model
• And in the mean reverting model

11
CORRELATION TARGETING FOR THE INTERCEPT

12
ESTIMATION

• Two steps
• GARCH on returns
• MLE on standardized returns

13
OOps

• This is not a good solution for very large
  systems
• Inversion of R many many times is slow
• Downward bias in alpha for large systems- see
  Engle and Sheppard
• Possibly need more structure

14
THE MACGYVER METHOD
15
(No Transcript)
16
A SOLUTION

• Estimate all bivariate models. Each should be
  consistent for the same parameters.
• Combine these estimates
• Calculate all the correlations

17
MONTE CARLO

• Generate 1000 observations on n dimensional
  systems which are gaussian DCC with unit
  conditional variance.
• Construct with the following parameters
• N3,5,10,20,30,50

18
MLE ESTIMATION

• Bivariate Log likelihood function
• Although the parameters should be positive and
  sum to less than one, these restrictions are not
  imposed.

19
RESTRICTED MLE ESTIMATION

• Log likelihood function
• To constrain the sum of alpha and beta to be less
  than one a penalty is assigned whenever they
  exceed one.

20
ESTIMATORS

• Mean, Median and trimmed Mean where the 5
  largest and smallest values are deleted before
  taking the mean.
• When n3, median and trimmed mean are the same.
• The estimators are computed for both restricted
  and unconstrained Bivariate MLE.

21
EXPERIMENTS
22
RMS ERRORS ON BETA
23
RMS ERRORS ON ALPHA
24
BIAS ON BETA
25
BIAS ON ALPHA
26
BIAS OF MEDIAN ESTIMATOR
27
ADVANTAGES OF THIS APPROACH

• Requires only bivariate estimation
• Does not require the same number of observations
  on all assets
• Robust to occasional non-convergence and
  diverging estimates
• Potential to investigate validity of DCC
  assumptions relative to block DCC, GDCC
• Possible to estimate only a subset of pairs and
  apply parameters to all.

28
DYNAMIC EQUICORRELATION

• Robert Engle and Bryan Kelly

29
Dynamic EquiCOrrelation (DECO)

• Suppose all pairs of assets have the same
  correlation, but that this changes over time. It
  is like the average correlation.
• Can you estimate this directly?

30
PLAUSIBILITY?

• Elton and Gruber use this model for Asset
  Allocation. See their textbook.
• Derivatives are priced with a single average
  correlation
• Credit Risk often assumes homogeneity
• In many cases this can be interpreted as an
  average correlation
• A block equicorrelation model allows more
  flexibility.

31
ADVANTAGES

• The likelihood is very simple
• It can be estimated about as fast as GARCH no
  matter how many assets there are.
• It is easy to interpret and analyze.

32
Estimation

• Matrix Results

33
Estimation

• Assuming Normality and examining the second step
  as in DCC

34
UPDATING

• Each period, new information becomes available on
  the equicorrelation. We specify this in several
  ways.
• Where U can be various measures. i.e.

35
FACTOR DCC

• And its special cases
• FACTOR ARCH
• FACTOR DOUBLE ARCH

36
FACTOR ARCH

• Introduced by Engle Ng and Rothschild(1990)(1992)
• Or, assuming normality

37
ESTIMATION OF FACTOR ARCH

• MLE is estimation by OLS to get the betas
• GARCH estimation of the factor
• Correlations are calculated from

38
FACTOR DOUBLE ARCH

• Idiosyncrasies are also GARCH models
• or

39
ESTIMATION OF FACTOR DOUBLE ARCH

• Regress returns on the factor assuming the errors
  are GARCH. This is MLE by weak exogeneity
  argument.
• Model the factor volatility with GARCH
• Calculate correlations

40
FACTOR DCC

• Model the residuals of the FACTOR DOUBLE ARCH and
  the residuals of the factor with DCC
• Two step method is not MLE
• If residual correlations are all zero then there
  is no change from FACTOR DOUBLE ARCH

41
COVARIANCE MATRIX

• Now four terms in covariance matrix
• and correlations are given by

42
FEATURES

• This model has time varying correlations between
  the idiosyncrasies.
• This is what would be observed if there are
  multiple factors with time varying volatilities
• This model has time varying covariances with the
  factor that is time varying betas.

43
PERFORMANCE
44
DATA

• 18 LARGE CAP STOCKS AND SP500
• aa, axp, ba, cat, dd, dis, ge, gm, ibm, ip, jnj,
  jpm, ko, mcd, mmm, mo, mrk, msft
• 1994-2004 DAILY FOR 2771 Obs

45
MacGyver

• Use TARCH or GJR-GARCH for all 18
• Estimate 153 bivariate models without
  restrictions
• Median alpha0.0157
• Median beta. 9755

46
Bivariate Alphas
47
Bivariate Betas
48
RESULTS

• 153 TIME SERIES
• LOOK AT AVERAGE CORRELATION BY DCC AND BY 100 DAY
  HISTORICAL OR MOVING AVERAGE

49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
(No Transcript)
53
(No Transcript)
54
FACTOR DCC

• Estimate DCC on residuals from FACTOR DOUBLE ARCH
• Use MacGyver method again
• Median alpha.009
• Median beta .925
• Less persistent and less responsive to shocks
  than for DCC.

55
(No Transcript)
56
(No Transcript)
57
(No Transcript)
58
(No Transcript)
59
(No Transcript)
60
UPDATING

• USING PARAMETER VALUES ESTIMATED FROM 1994-2004,
  CALCULATE CORRELATIONS THROUGH SEPTEMBER 14,2007
• WHAT DO THE CORRELATIONS SHOW THROUGH THE SUMMER
  OF 2007 WITH THE MARKET TURBULENCE?

61
(No Transcript)
62
(No Transcript)
63
WHICH CORRELATION ESTIMATE IS MOST ACCURATE?

• CONSIDER AN ASSET ALLOCATION SOLUTION.
• FOR EACH PAIR OF STOCKS FORM THE MINIMUM VARIANCE
  PORTFOLIO AND SEE WHICH COVARIANCE ESTIMATOR
  ACHIEVES THE SMALLEST VARIANCE.

64
WHICH HEDGE GIVES THE BEST LONG - SHORT PORTFOLIO?

• For each pair of assets hold one long and take a
  short position in the other to minimize variance.

65
Average standard deviation of the minimum
variance portfolio of all pairs of stocks
66
Average standard deviation of the minimum
variance long - short portfolio of all pairs of
stocks
67
WINNING FRACTIONS MV
68
WINNING FRACTIONS HEDGE
69
(No Transcript)
