Reading C2-style Applications Built in c2.fw

1
Reading C2-style Applications Built in c2.fw

• Eric M. Dashofy
• edashofy_at_ics.uci.edu
• For ICS 52
• October 20, 2004

2
Overview

• Software architectures
• The C2 architectural style
• With live example
• The Klax application

3
Software Architecture Basic Elements
Interfaces
Clock
Component
Connector
Bus1
Interfaces
4
Software Architecture Basic Elements (cont).
Clock
Configuration
Links
Bus1
LCD Driver
5
An Architectural Style

• One definition of an architectural style
• An architectural style is a named set of
  constraints (e.g., rules) you put on your
  development
• Constraints may be topological, behavioral,
  communication-oriented, you name it
• This can complicate development because these
  constraints may be inconvenient or unfamiliar
• BUT architectural styles elicit beneficial system
  properties that would be really hard to get
  otherwise

6
Examples from building architecture

1. Name some constraints in each style
2. Name some benefits (-ilities) elicited by each
   style.

7
The C2 Architectural Style

• Topological Constraints
• All components, connectors have two interfaces,
  top and bottom
• Components can be connected to 0-1 connector on
  each interface
• Connectors can be connected to 0 components or
  connectors on each interface

8
The C2 Architectural Style

• Communication Constraints
• Components connectors communicate using only
  independent events or messages
• Requests go up (requests rise)
• Notifications go down
• No passing pointers
• Components connectors communicate
  asynchronously
• Can send/receive events at any time
• No blocking!

9
The C2 Architectural Style

• Dependency Constraints
• Components may make assumptions about services
  provided above them
• But not who is providing them
• Components may NOT make assumptions about
  services provided below them
• Concurrency Constraints
• Each component connector assumes its running
  in its own thread of control

10
Live Example
Data Store
GUI Interpreter
Alarm
GUI
11
Live Example
Data Store
Stores data emits notifications whenever data
changes.
GUI Interpreter
Alarm
GUI
12
Live Example
Interprets basic GUI actions translates them
into data store operations
Data Store
GUI Interpreter
Alarm
GUI
13
Live Example
Data Store
Rings a bell whenever value of X changes
GUI Interpreter
Alarm
GUI
14
Live Example
Data Store
GUI Interpreter
Alarm
Accept process user actions
GUI
15
Live Example
Data Store
GUI Interpreter
Alarm
Bus connector routes messages
GUI
16
Live Example
Data Store
GUI Interpreter
Alarm
GUI
17
What ilities does C2 buy us?

• What do you think?

18
-ilities bought by C2

• Flexibility
• Loose coupling lets you swap out components,
  interpose components
• Flexible connectors allow run-time changes
• Distributability
• Since no assumption of shared address space,
  distributing an app across machines is easy
• Visibility
• Since all messages go through connectors, they
  are easy to catch and log
• Parallelizability
• One-thread-per-brick means multiprocessor
  machines are effectively utilized

19
Event-based vs. OO

• Event-based
• Communication by events
• Mostly asynchronous
• Requests emitted to unknown parties
• Responses and state changes go to many parties
• No shared pointers

• Object Oriented
• Communication by procedure calls
• Mostly synchronous
• Requests emitted to named party only
• Responses to caller only, state changes to many
• Lots of shared pointers

20
Implementing a C2 architecture
C2 architecture
Event-basedWorld
Implemented by
Application (implemented)
???
How do we bridge this gap?
Java/JVM
Object-orientedWorld
Uses services provided by
Native OS
21
Implementing a C2 architecture
C2 architecture
Event-basedWorld
Implemented by
Application (implemented)
Uses services provided by
Architecture Framework
Uses services provided by
Java/JVM
Object-orientedWorld
Uses services provided by
Native OS
22
Whats an architecture framework?

• An architecture framework is software that helps
  to bridge the gaps between an architectural style
  and a particular implementation platform.

23
Example

• C2 World
• Components
• Connectors
• Events
• Links
• Many threads
• Asynchronous communication

• Java World
• Objects
• Method calls
• Parameters
• References
• Few threads
• Synchronous communication

24
Enter c2.fw

• c2.fw is an architecture framework for the C2
  style built in Java, providing
• Abstract base classes for components, connectors
• Reusable connectors (local network)
• (Pluggable) topology management
• (Pluggable) message queuing policies
• (Pluggable) threading policies
• Essentially, c2.fw does the hard work, components
  and connectors simply implement behaviors.

25
What does a message look like?

• In c2.fw, a message can be any serializable (e.g.
  no pointers) object
• NamedPropertyMessages (or subclasses) are popular
  though
• Have a String name
• Plus a set of name-value pairs
• e.g. description, Rectangle 1
• e.g. width, 123
• e.g. color, java.awt.Color.BLACK

26
Reading a c2.fw application

• Basic format
• Lifecycle methods
• init(), begin(), end(), destroy()
• start(), stop(), suspend(), resume()
• Handling messages
• void handle(Message m)
• Sending messages
• sendToAll(Message m, Interface i)

27
Your basic c2.fw component
package edu.uci.ics.mypackageimport c2.fw.
//import c2.fw packageimport c2.legacy.
//import support for 2-interface
//C2 components
28
Your basic c2.fw component
package edu.uci.ics.mypackageimport c2.fw.
//import c2.fw packageimport c2.legacy.
//import support for 2-interface
//C2 componentspublic class MyC2Component
extends AbstractC2Brick
Implements lots of boilerplate functionality from
the base c2.fw.Brick interface declares a top
interface topIface and a bottom interface
bottomIface.
29
A boilerplate c2.fw component
package edu.uci.ics.mypackageimport c2.fw.
//import c2.fw packageimport c2.legacy.
//import support for 2-interface
//C2 componentspublic class MyC2Component
extends AbstractC2Brick public
MyC2Component(Identifier id) super(id)

Each component or connector has a unique
identifier.
30
A boilerplate c2.fw component
package edu.uci.ics.mypackageimport c2.fw.
//import c2.fw packageimport c2.legacy.
//import support for 2-interface
//C2 componentspublic class MyC2Component
extends AbstractC2Brick public
MyC2Component(Identifier id) super(id)
public void begin() //called automatically
by fw. //send out initial events
31
Lifecycle Methods
public void init() //called when
component/connector is created //but component
not guaranteed to be hooked up public void
begin() //called when component/connector is
hooked up //in the architecture, should send
initial messages public void end() //called
when component/connector is about to be
//unhooked, should send final messages public
void destroy() //called when
component/connector is about to be //destroyed
32
A boilerplate c2.fw component
package edu.uci.ics.mypackageimport c2.fw.
//import c2.fw packageimport c2.legacy.
//import support for 2-interface
//C2 componentspublic class MyC2Component
extends AbstractC2Brick public
MyC2Component(Identifier id) super(id)
public void begin() //called automatically
by fw. //send out initial events
public void handle(Message m) //handle
message
33
Implementing handle()
//handle() method for our hypothetical alarm
component //Called automatically when component
receives a message //Should ring bell whenever
value of X changes public void
handle(Message m) //handle message
34
Implementing handle()
//handle() method for our hypothetical alarm
component public void handle(Message m)
//handle message if(m instanceof
NamedPropertyMessage) NamedPropertyMessage
npm (NamedPropertyMessage)m
35
Implementing handle()
//handle() method for our hypothetical alarm
component public void handle(Message m)
//handle message if(m instanceof
NamedPropertyMessage) NamedPropertyMessage
npm (NamedPropertyMessage)m String name
npm.getName() if((name ! null)
(name.equals(valueChanged))
36
Implementing handle()
//handle() method for our hypothetical alarm
component public void handle(Message m)
//handle message if(m instanceof
NamedPropertyMessage) NamedPropertyMessage
npm (NamedPropertyMessage)m String name
npm.getName() if((name ! null)
(name.equals(valueChanged)) String
varName (String)npm.getParameter(varName)
if((varName ! null) (varName.equals(x))

37
Implementing handle()
//handle() method for our hypothetical alarm
component public void handle(Message m)
//handle message if(m instanceof
NamedPropertyMessage) NamedPropertyMessage
npm (NamedPropertyMessage)m String name
npm.getName() if((name ! null)
(name.equals(valueChanged)) String
varName (String)npm.getParameter(varName)
if((varName ! null) (varName.equals(x))
ringBell()
NamedPropertyMessage rnpm new
NamedPropertyMessage(AlarmFired)
rnpm.addProperty(time,
System.currentTimeMillis())
sendToAll(rnpm, bottomIface)

38
Implementing handle()
If we care, we could have checked what interface
that message came in on if(m.getDestination().g
etInterfaceIdentifier().equals(
AbstractC2Brick.TOP_INTERFACE_ID)) //its a
notification
