The Pivot: Static Analysis of C Applications

1
The PivotStatic Analysis of C Applications

• Bjarne Stroustrup
• Texas AM University
• http//www.research.att.com/bs

2
Overview

• Static analysis of C
• What would be useful
• Why it is hard
• C0x
• The Pivot
• Context
• Aims
• Organization
• Basic representations
• High-level program representation for HPC
• Concept-based checking and transformation

3
What would be useful?

• Direct representation of high-level ideas in code
• E.g. no sideeffects, idempotent operation, always
  gives the same answer for the same element, no
  security violation, no memory leak, no race
  condition, no deadlock, being sorted, being
  band-diagonal, parallel application
• Use of such direct representation
• For providing guarantees
• For information
• For optimization
• For program transformation

4
Its hard

• C is
• Large
• Extremely flexible and general
• Quite irregular
• Has its type-unsafe C subset
• High-level ideas tend to be represented as
  templated classes and functions
• Generic programming, Template meta-programming,
  generative programming
• We have little experience with tools representing
  and manipulating templates
• Such templates tend to be provided as part of
  domain specific libraries

5
Bell Labs proverbs

• Library design is language design
• Language design is library design
• But the devil is in the details

6
C0x

• 1998 ISO C standard
• 2009 (estimated) ISO C standard
• Better libraries and better support for library
  building
• Hash maps, regular expressions, file system,
• Threads and memory model
• Concepts
• A type system for types, integers, and operations
• Auto, template aliases, general, initializer
  lists,

7
Concept trivial example

• // Caveat likely C0x
• templateltForwardIterator Iter, ValueType Valgt
• where AssignableltItervalue_type,Valgt
• Iter find(Iter first, Iter last, Val v)
• templateltContainer Cont, ValueType Valgt
• where AssignableltContvalue_type,Valgt
• Iter find(Iter first, Iter last, Val v)
• vectorltintgt v 2, 3, 5, 8, 13, 21, 34
• auto p1 find(v.begin(), v.end(), 42)
• auto p2 find(v,42.3)
• auto p3 find(7,42) // error 7 is not a
  Container

8
Concepts

• Can express many high-level abstractions
• A type system for sets of types, integers, and
  operations
• We have experimental implementations of concepts
• A concept is a handle to which we can attach
• some standard semantics within the language
• essentially arbitrary semantics outside the
  language using tools
• Until we get concepts, we can fake them with
  static analysts and transformation tools

9
Context for the Pivot

• Semantically Enhanced Library (Language)
• Enhanced notation through libraries
• Restrict semantics through tools
• And take advantage of that semantics

Domain Specific Library
C
Semantic Restrictions
10
Context for the Pivot
Domain Specific Library
C
Semantic Restrictions

• Provide the advantages of specialized languages
• Without introducing new special purpose
  languages
• Without supporting special-purpose language tool
  chains
• Avoiding the 99.? language death rate
• Provide general support for the SELL idea
• Not just a specialized tool per
  application/library
• The Pivot fits here

11
Example SELL Safe C

• Add
• Range-checked stdvector
• iterators
• Resource handles
• Any (if needed) (a typesafe union type)
• Subtract
• Arrays
• Pointers
• New/delete
• Unions
• Excessively complex/obscure code
• Uses of undefined construct not caught by
  compilers (e.g. ai i)
• Transforms
• Pointers into iterators and resource handles (if
  porting)
• New/delete into resource handle uses

12
Example SELL STAPL

• Wait for Lawrences talk

13
Aims

• To allow fully general analysis of C source
  code
• What a human can do
• Foci
• Templates (e.g. specialization)
• C0x features (e.g. concepts, generalized
  initializers)
• Distributed programming
• Embedded systems
• Limitation we work after macro expansion
• To allow transformation of C code
• i.e. production of new code from old source
• Non-aim handling other languages
• e.g. Fortran, Java
• but C and C dialects are relatively easy

14
Related work

• Lots
• 20 tools for analyzing C
• But
• Most are specialized
• E.g. alias analysis, flow analysis, numeric
  optimizations
• Most are attached to a single compiler/parser
• None handles all of C
• E.g. C classes, C but not standard libraries
• (that requires full handling of templates)
• Hardly two tools handle the same subset
• None handles the key C0x features (e.g.
  concepts)
• Some are proprietary
• No serious interoperability

15
The Pivot
16
The Pivot
C source
Object code
Tool 1
Compiler
Compiler
Compiler
IDL
Tool 2
IPR
C source
Tool 3
Tool 4
Specialized representation (e.g. flow graph)
XPR
information
17
Why? The Original Project

• Communication with remote mobile device
• Calling interface
• CORBA, DCOM, Java RMI, , homebrew interface
• Transport
• TCP/IP, XML, , homebrew protocol
• Big, Ugly, Slow, Proprietary,
• Why cant I just write ISO Standard C?

18
The original Project Distributed programs in ISO
C
// use local object X x // remote at my
host A a stdstring s("abc") // x.f(a, s)
// a function call
// use remote object proxyltXgt
x x.connect("my_host") A a stdstring
s("abc") // x.f(a, s) // a message send

• as similar as possible to non-distributed
  programming, but no more similar

19
IPR high-level principles

• Complete Direct representation of C
• Built-in types, classes, templates, expressions,
  statements, translation units
• Can represent erroneous and incomplete C
  programs
• Regular
• The structure contains all of C but doesnt
  mimic irregularities
• Programming effort proportional to complexity of
  task
• IPR is not just a data structure
• Extensible
• Node types
• Information associated with a node
• Operations
• No integration with compilers

20
IPR design choices

• Type safe
• IPR (not its users) handles memory management
• Minimal (run-time and space)
• Minimal number of nodes (unification)
• Minimal number of checked indirections (usually,
  virtual function calls)
• Expression-based regular superset of C
• E.g. statements, declarations are expressions too
• C0x features (most important concepts types
  have types)
• Interfaces
• Purely functional, abstract classes, for most
  users
• No mutation operation on abstract classes
• Users don't get pointers directly
• Mutating (operates on concrete classes)
• Users get to use pointers for in-place
  transformation
• Traversals (and queries)
• Several, most not in the Pivot core

21
IPR is minimal

• Necessary for dealing with real-world code
• Multi-million line programs are not uncommon
• Given the constraint of completeness
• C is complex
• especially when we use the advanced template
  features essential for high-performance work
• Unified representation
• E.g., there is only one int and only one 1
• Type comparison becomes pointer comparison
• Indirections are minimized
• An indirection (only) when there is a choice of
  different types of information

22
Original idea (XTI)

• Too large, too slow

23
Current hierarchy (IPR)

• Compact
• minimal call overhead

24
IPR Example 1
void foo(float b 2.4)
25
IPR Example 2
26
XPR (eXternal Program Representation)

• Can be thought of as a specialized portable
  object database
• Easy/fast to parse
• Easy/fast to write
• Compact
• About as compact as C source code
• Robust
• Read/write without using a symbol table
• LR(1), strictly prefix declaration syntax
• Human readable
• Human writeable
• Can represent almost all of C directly
• No preprocessor directives
• No multiple declarators in a declaration
• No lt, gt, gtgt, or ltlt in template arguments, except
  in parentheses

27
XPR

• i int // int i
• C class // class C
• m const int // const int m
• mm const int // const int mm
• f (int,char) double // double f(int,char)
• f (zcomplex) C // C f(complex z)
• //
• vector ltTgt class // templateltclass Tgt class
  vector
• p T // T p
• sz int // int sz
• //

28
Extremely simple SELL example

• template ltParallelizable Tgt
• void f(const T v)
• double d v2 // OK
• double d v2 // not OK

29
Current and future work

• Complete infrastructure
• Complete EDG and GCC interfaces
• Represent headers (modularity) directly
• Complete type representation in XPR
• Initial applications
• Style analysis
• including type safety and security
• Analysis and transformation of STAPL programs
• Build alliances

30
References

• GJS06 Gregor, Douglas Järvi, Jaako Siek,
  Jeremy Lumsdaine, Andrew Dos Reis, Gabriel
  Stroustrup, Bjarne Concepts Linguistic Support
  for Generic Programming in C. to appear
  OOPSLA'06.
• DRS05 Stroustrup, Bjarne Dos Reis, Gabriel A
  concept design. C Committee, paper N1782. April
  2005.
• SDR05 Stroustrup, Bjarne Dos Reis, Gabriel
  Supporting SELL for High Performance Computing.
  LCPC '05.
• Str05 Stroustrup, Bjarne A rational for
  semantically enhanced libraries. LCSD '05.
