Eye Movements

1
Eye Movements

• Donna L. Hill, MD
• Neuro-ophthalmology
• Departments of Neurology and Ophthalmology
• UFShands Jacksonville

2
Normal Eye Movements

• Objective Foveation
• Extraocular muscles
• Muscle innervation CNs III, IV, and VI
• Cranial nerve nuclei
• Three primary types of movements
• Pathologic eye movements

3
Objective foveation

• fovea most sensitive portion of retina
• we need to orient, either voluntarily or
  reflexively, to important stimuli
• accomplished by directing our eyes to a target so
  that it is projected onto the fovea
• to maintain foveation, we depend on visual
  feedback as the primary source of information on
  eye movement accuracy

4
Extraocular muscles

• Superior rectus moves eye up
• Inferior rectus moves eye down
• Medial rectus moves eye in (a-d-duction)
• Lateral rectus moves eye out (a-b-duction)
• Inferior oblique moves eye up when it is in an
  adducted position also extorts the eye.
• Superior oblique moves eye down when it is
  adducted also intorts the eye.

left
5
Isolating Extraocular Muscles
6
CN III
7
CN III

• Superior division
• - Superior rectus muscle
• - Levator palpebrae superioris muscle
• Inferior division
• - Medial rectus muscle
• - Inferior rectus muscle
• - Inferior oblique muscle
• - Parasympathetic innervation to pupil

8
CN IV CN VI
9
CN VI
10
Coordination of Eye Movements

• Separate systems exist to control each different
  subtype of eye movement saccades, smooth
  pursuit, and vergence
• May be nuclear or supranuclear control
• May be reflexive or voluntary
• Separate systems exist to govern vertical and
  horizontal eye movements

11
Targeting Eye Movements

• Saccades Quick, darting conjugate movements
  which direct the eyes to a new target.
• Smooth pursuit A slower conjugate movement
  which allows for tracking of a moving object, or
  of a stationary object while we are moving.
• Convergence A dysconjugate movement of both
  eyes toward the midline to allow for focusing on
  a near object by adjusting the angle between the
  eyes.

12
Variety of pathways contribute to saccadic
control and smooth pursuit
13
Saccades

• Under the control of three different areas in the
  brain
• voluntary saccades - frontal eye fields
  (Brodmanns area 8)
• reflexive saccades to complex stimuli - parietal
  lobes (Brodmanns area 7)
• reflexive saccades to elementary stimuli -
  superior colliculi

14
Voluntary Saccades (horizontal)
results in saccade to contralateral space
15
Voluntary Horizontal Saccades
FEF
FEF
CEREBRAL HEMISPHERE
III
MIDBRAIN
III
PONS
VI
VI
PPRF
PPRF
16
Yoking Mechanism
17
Reflexive Saccades
- to complex stimuli originates in area 7 of the
parietal lobe - to elementary stimuli originates
in superior colliculi dorsolateral prefrontal
cortex involved in planning of eye mvts
18
Smooth Pursuit

• Two types
• Voluntary (actually termed smooth pursuit)
  movements - originate in the temporo-parietal
  lobe
• Reflexive - which are under vestibular nuclear
  control alone and constitute what is called the
  vestibulo-ocular reflex (VOR).

19
Voluntary Smooth Pursuit

• originates near the angular gyrus - Area 39 at
  the temporal parietal occipital junction
• cells in this region are able to compute the
  speed and direction of a moving object
• results in ipsilateral smooth pursuit

IPSI
20
Optokinetic Reflex

• Combination of saccades and smooth pursuit that
  allow tracking of targets in turn (e.g. counting
  sheep as they jump over a fence).
• smoothly pursue one target, then saccade in the
  opposite direction to pick up the next target
• parieto-temporal junction (smooth pursuit area)
  projects down to ipsilateral vestibular nucleus,
  inhibits it allowing ipsilateral smooth pursuit
• then, the FEF of the same hemisphere generates a
  saccade back (contralateral) to the next target

21
Reflexive Smooth Pursuit - VOR

• maintains gaze on a target despite head movement
• reflex arc semicircular canal opposite the
  head turn detects motion and activates the ipsi
  vestibular n. which deactivates its inhibitory
  input on the ipsilateral VI
• results in eyes turning opposite to the head turn

p339 Medical Neuroscience, Nadeau et al
22
Convergence

• When areas of the occipital cortex detect a
  discrepancy in the retinal projection from each
  eye and amount of blur, a signal is sent to
  initiate convergence.
• To bring a near object into focus actually
  involves convergence, accomodation (lens
  curvature increases) and pupillary constriction.
  Together, these 3 movements are called the near
  triad.

23
Pathologic eye movements

• Muscle
• Trauma, entrapment, inflammation, infiltrating
  diseases
• Neuromuscular Junction
• myasthenia gravis, botulism, organophosphate
  poisoning
• Cranial nuclei or nerve
• Brainstem stroke, hemorrhage, multiple
  sclerosis, tumor, trauma
• Subarachnoid space Increased intracranial
  pressure, aneurysm, meningitis, sarcoidosis,
  autoimmune
• Cavernous sinus Tumor, sinus thrombosis,
  pituitary apoplexy, sphenoid sinusitis,
  carotid-cavernous fistula, Tolosa-Hunt syndrome
• Orbit Trauma, tumor, infection

24
right cranial nerve III palsy
25
right cranial nerve VI palsy
26
(No Transcript)
27
Gaze Palsy

• inability to look in a particular direction (ie.
  neither eye can look right)
• lesion in the FEF, the PPRF, or the CN VI nucleus

• Lesion in the FEF unable to look
  contralaterally, eyes deviate toward the lesion,
  can be overcome with VOR
• Lesion in PPRF or CN VI nucleus inability to
  look ipsilaterally with either eye

28
Voluntary Horizontal Saccades
FEF
FEF
CEREBRAL HEMISPHERE
III
MIDBRAIN
III
PONS
VI
VI
PPRF
PPRF
29
Left MLF lesion intranuclear ophthalmoplegia
30
Yoking Mechanism
31
Acknowlegdements

• Dr. Tariq Bhatti and his patients for clinical
  images
• Dr. Angela McSwain, Dr. Nadeaus text, Peter Duus
  ( Topical Diagnosis in Neurology), and Frank H.
  Netter (Ciba Collection of Medical Illustrations,
  Vol 1)
• Dr. Nancy Newman and Dr. Valerie Biousse,
  Neuro-ophthalmology Emory University
